Hotpoint Ariston Hotpoint User manual

English,1

Contents

Installation, 2-3

Unpacking and levelling

Connecting the electricity and water supplies

The first wash cycle

Technical data

Description of the washer-dryer and

starting a wash cycle, 4-5

Control panel

Indicator lights

Starting a wash cycle

ash cycles, 6

Table of wash cycles

Personalisation, 7

Setting the temperature

Setting the drying cycle

Functions

Detergents and laundry, 8

Detergent dispenser drawer

Bleach cycle

reparing the laundry

Garments requiring special care

Load balancing system

Precautions and tips, 9

General safety

Disposal

Opening the porthole door manually

Care and maintenance, 10

Cutting off the water or electricity supply

Cleaning the washer-dryer

Cleaning the detergent dispenser drawer

Caring for the door and drum of your appliance

Cleaning the pump

Checking the water inlet hose

Troubleshooting, 11

Service, 12

ARMXXF 149

Instructions for use

ASHER-DRYER

Polski,37

Nederlands,25

Français,13

Installation

 This instruction manual should be kept in a safe

place for future reference. If the washer-dryer is sold,

transferred or moved, make sure that the instruction

manual remains with the machine so that the new

owner is able to familiarise himself/herself with its

operation and features.

 Read these instructions carefully: they contain vital

information relating to the safe installation and

operation of the appliance.

Unpacking and levelling

Unpacking

1. Remove the washer-dryer from its packaging.

2. Make sure that the washer-dryer has not been

damaged during the transportation process. If it has

been damaged, contact the retailer and do not

proceed any further with the installation process.

3. Remove the 4

protective screws (used

during transportation) and

the rubber washer with

the corresponding

spacer, located on the

rear part of the appliance

(see figure).

4. Close off the holes using the plastic plugs provided.

5. Keep all the parts in a safe place: you will need

them again if the washer-dryer needs to be moved to

another location.

 ackaging materials should not be used as toys for

children.

Levelling

1. Install the washer-dryer on a flat sturdy floor,

without resting it up against walls, furniture cabinets

or anything else.

2. If the floor is not

perfectly level, compen-

sate for any unevenness

by tightening or loosening

the adjustable front feet

(see figure); the angle of

inclination, measured in

relation to the worktop,

must not exceed 2°.

Levelling the machine correctly will provide it with

stability, help to avoid vibrations and excessive noise

and prevent it from shifting while it is operating. If it is

placed on carpet or a rug, adjust the feet in such a

way as to allow a sufficient ventilation space

underneath the washer-dryer.

Connecting the electricity and water

supplies

Connecting the water inlet hose

1. Insert seal A into the

end of the inlet hose and

screw the latter onto a

cold water tap with a 3/4

gas threaded opening

(see figure).

Before performing the

connection, allow the

water to run freely until it

is perfectly clear.

2. Connect the inlet hose

to the washer-dryer by

screwing it onto the

corresponding water inlet

of the appliance, which is

situated on the top right-

hand side of the rear part

of the appliance (see

figure).

3. Make sure that the hose is not folded over or bent.

 The water pressure at the tap must fall within the

values indicated in the Technical details table (see

next page).

 If the inlet hose is not long enough, contact a

specialised shop or an authorised technician.

 Never use second-hand hoses.

 Use the ones supplied with the machine.

Technical data

Model ARMXXF 149

Dimensions

width 59,5 cm

height 85 cm

depth 53,5 cm

Capacity

from 1 to 7 kg for the wash

programme;

from 1 to 5 kg for the drying

programme

Electrical

connections

please refer to the technical data plate

fixed to the machine

ater

connections

maximum pressure 1 M a (10 bar)

minimum pressure 0.05 M a (0.5 bar)

drum capacity 52 litres

Spin speed up to 1400 rotations per minute

Energy rated

programmes

according to

regulation

EN 50229

Wash: programme 6; temperature

60°C; using a load of 7 kg.

Drying: first drying cycle performed

with a 2 kg load, by selecting the

dryness level ;

the second drying cycle is performed

with a 5 kg load, by selecting the

dryness level .

This appliance conforms to the

following EC Directives:

- 89/336/EEC dated 03/05/89

(Electromagnetic Compatibility) and

subsequent modifications

- 2002/96/EC

- 2006/95/EC (Low Voltage)

65 - 100 cm

Connecting the drain hose

Connect the drain hose,

without bending it, to a

drainage duct or a wall

drain located at a height

between 65 and 100 cm

from the floor;

alternatively, rest it on

the side of a washbasin

or bathtub, fastening the

duct supplied to the tap

(see figure). The free end

of the hose should not

be underwater.

 We advise against the use of hose extensions; if it is

absolutely necessary, the extension must have the

same diameter as the original hose and must not

exceed 150 cm in length.

Electrical connections

Before plugging the appliance into the electricity

socket, make sure that:

 the socket is earthed and complies with all

applicable laws;

 the socket is able to withstand the maximum power

load of the appliance as indicated in the Technical

data table (see opposite);

 the power supply voltage falls within the values

indicated in the Technical data table (see opposite);

 the socket is compatible with the plug of the

washer-dryer. If this is not the case, replace the

socket or the plug.

 The washer-dryer must not be installed outdoors,

even in covered areas. It is extremely dangerous to

leave the appliance exposed to rain, storms and other

weather conditions.

 When the washer-dryer has been installed, the

electricity socket must be within easy reach.

 Do not use extension cords or multiple sockets.

 The cable should not be bent or compressed.

 The power supply cable must only be replaced by

authorised technicians.

Warning! The company shall not be held responsible

in the event that these regulations are not respected.

The first wash cycle

Once the appliance has been installed, and before

you use it for the first time, run a wash cycle with

detergent and no laundry, using the wash cycle 1.

Detergent dispenser drawer: used to dispense

detergents and washing additives (see Detergents

and laundry).

There is a key which provides a summary of the

available wash cycles inside the detergent dispenser

drawer; this may be consulted at any time.

ON/OFF button with indicator light: switches the

machine on and off.

If the indicator light is illuminated, this indicates that

the machine is switched on.

ASH CYCLE knob: programmes the wash cycles.

During the wash cycle, the knob does not move.

DRYING button: used to set the desired drying

programme (see Personalisation).

TEMPERATURE button: sets the temperature or the

cold wash cycle (see Personalisation).

DISPLAY: indicates the time remaining for the

selected wash cycle and, if a delayed start has been

programmed, the time remaining until the start of the

wash cycle.

CHILD LOCK button with indicator light: activates or

deactivates the control panel lock.

FUNCTION buttons with indicator light: used to

select the available functions. The indicator light

corresponding to the selected function will remain lit.

ASH CYCLE PROGRESS

indicator light

s: used to

monitor the progress of the wash cycle.

The illuminated indicator light shows which phase is in

progress.

DOOR LOCKED indicator light: indicates whether

the door may be opened or not (see next page).

START/PAUSE button with indicator light: starts or

temporarily interrupts the wash cycles.

N.B. To pause the wash cycle in progress, press this

button; the corresponding indicator light will flash

orange, while the indicator light for the current wash

cycle phase will remain lit in a fixed manner. If the

DOOR LOCKED indicator light is switched off, the

door may be opened.

To start the wash cycle from the point at which it was

interrupted, press this button again.

Description of the washer-dryer and

starting a wash cycle

DOOR

LOCKED

indicator light

START/PAUSE

button with indicator

light

Control panel

ASH CYCLE PROGRESS

indicator lights

FUNCTION

buttons with

indicator lights

Detergent dispenser drawer

ASH CYCLE

knob

DISPLAY

ON/OFF

button with indicator

light

TEMPERATURE

button

DRYING

button

CHILD LOCK

button with indicator light

Indicator lights

The indicator lights provide important information.

This is what they can tell you:

ash cycle phase indicator lights

As the WASH CYCLE knob is rotated, the indicator

lights illuminate, indicating the stages which will be

performed by the machine in accordance with the

selected wash cycle.

Once the desired wash cycle has been selected and

has begun, the indicator lights switch on one by one

to indicate which phase of the cycle is currently in

progress.

Note:

during the "Drain" phase, the indicator light

corresponding to the "Spin" cycle phase will illuminate.

Function buttons and corresponding indicator lights

When a function is selected, the corresponding

indicator light will illuminate.

If the selected function is not compatible with the

programmed wash cycle, the corresponding indicator

light will flash, a sound signal will be emitted and the

function will not be activated.

If a function which is incompatible with another

function selected previously, only the most recent

selection will remain active.

Temperature indicator light

When a temperature value is selected, the

corresponding indicator light will illuminate.

Drying indicator light

When a drying value is selected, the corresponding

indicator light will illuminate.

Child lock indicator light

To activate the control panel lock, press and hold the

button for approximately 2 seconds. When the

indicator light is illuminated, the control panel is

locked. This means it is possible to prevent wash

cycles from being modified accidentally, especially

where there are children in the home.

To deactivate the control panel lock, press and hold

the button for approximately 2 seconds.

Door locked indicator light

If this indicator light is on, the appliance door is locked

to prevent it from being opened accidentally; to avoid

any damage, wait for the indicator light to switch off

before you open the appliance door.

N.B. If the DELAY TIMER function is activated, the door

cannot be opened; pause the machine by pressing the

START/ AUSE button if you wish to open it.

 If the START/ AUSE indicator light (orange) flashes

rapidly at the same time as the function indicator

light, this indicates a problem has occurred (see

Troubleshooting).

Starting a wash cycle

1. Switch the washer-dryer on by pressing the ON/OFF button. All indicator lights will switch on for a few

seconds, then they will switch off and the START/ AUSE indicator light will pulse.

2. Load the laundry and close the door.

3. Set the WASH CYCLE knob to the desired programme.

4. Set the washing temperature (see Personalisation).

5. Set the drying cycle if necessary (see Personalisation).

6. Measure out the detergent and washing additives (see Detergents and laundry).

7. Select the desired functions.

8. Start the wash cycle by pressing the START/ AUSE button and the corresponding indicator light will remain lit

in a fixed manner, in green.

To cancel the set wash cycle, pause the machine by pressing the START/ AUSE button and select a new cycle.

9. At the end of the wash cycle the indicator light will switch on. The DOOR LOCKED indicator light will switch

off, indicating that the door may be opened. Take out your laundry and leave the appliance door ajar to make

sure the drum dries completely. Switch the washer-dryer off by pressing the ON/OFF button.

Wash

Rinse

Spin

Dry

End of wash cycle

Note: As soon as a drying

level or time period has

been set, this indicator light

illuminates to indicate that

the selected wash cycle

will be followed by a drying

phase.

Special wash cycles

Sanitizing cycle (wash cycle 6). A high-temperature hygienic wash cycle (over 60°C) which requires the use of

bleach. our the bleach, the detergent and the additives into the relevant compartments (see paragraph entitled

Detergent dispenser drawer).

Goodnigt cycle (wash cycle 7). This is a silent cycle which can be run at night, when the electricity prices are

lower. The wash cycle is designed for cottons and synthetics. At the end of the cycle the machine stops while

there is still water in the drum; to spin and drain the laundry press the START/ AUSE button; alternatively the

machine will perform the spin cycle and drain the water automatically after 8 hours.

Baby cycle (wash cycle 8). This wash cycle can be used to remove the soiling typically caused by babies, while

ensuring that all detergent is removed from nappies in order to prevent the delicate skin of babies from suffering

allergies. The cycle has been designed to reduce the amount of bacteria by using a greater quantity of water and

optimising the effect of special disinfecting additives added to the detergent.

At the end of the wash cycle, the machine will slowly rotate the drum to prevent the formation of creases; to end

the cycle press the START/ AUSE button.

Mix 30 wash cycle 4) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 30

minutes and therefore saves both energy and time. By selecting this wash cycle (4 at 30°C), it is possible to wash

different fabrics together (except for wool and silk items), with a maximum load of 3 kg.

Mix 15 (wash cycle 5) this wash cycle was designed to wash lightly soiled garments quickly: it lasts just 15

minutes and therefore saves both energy and time. By selecting this wash cycle (5 at 30°C), it is possible to wash

different fabrics together (except for wool and silk items), with a maximum load of 1.5 kg.

ash cycles

The information contained in the table is intended as a guide only.

For a Test Institutes:

1) Test wash cyc e in comp iance with regu ation EN 50229: set wash cyc e 6 with a temperature of 60°C.

2) Long wash cyc e for cottons: set wash cyc e 1 with a temperature of 40°C.

3) Short wash cyc e for cottons: set wash cyc e 2 with a temperature of 40°C.

Wash cyc es

Table of wash cycles

Description of the wash cyc e

Max.

temp.

(°C)

Max.

speed

(rpm)

Drying

Detergents Max.

oad

(kg)

Cyc e

duration

B each Wash Fabric

softener

Special cycles

6Sanitizing cyc e: Extremely soiled whites. 90° 1400 lll l 7

6Sanitizing cyc e (1): Heavily soiled whites and resistant colours. 60° 1400 l-ll7

7Goodnigt cyc e: Lightly soiled delicate colours. 40° 800 - - ll4

8Baby cyc e: Heavily soiled delicate colours. 40° 800 l-ll2

9Si k/Curtains: For garments in silk and viscose, lingerie. 30° 0 - - ll1

10 Woo : For wool, cashmere, etc. 40° 800 l-ll

1,5

Everyday wash cycles (Daily)

1Cotton: Heavily soiled whites and resistant colours. 60° 1400 lll l 7

1Cotton (2): Heavily soiled whites and delicate colours. 40° 1400 lll l 7

2Co oured Cottons (3): Lightly soiled whites and delicate colours. 40° 1400 lll l 7

3Synthetics resistents: Heavily soiled resistant colours. 60° 800 l-ll3

4Mix 30': To refresh lightly soiled garments quickly (not suitable for

wool, silk and clothes which require washing by hand). 30° 800 l-ll3

5Mix 15': To refresh lightly soiled garments quickly (not suitable for

wool, silk and clothes which require washing by hand). 30° 800 l-ll

1,5

Partials wash cycles

ARinse -1400 l- - l7

BSpin -1400 l- - - 7

CDrain no spin -0- - - - 7

Drying cycles

11 Cotton drying cycle - - l- - - 5

12 Synthetics drying cycle - - l- - - 3

13 Wool drying cycle - - l- - - 1,5

The duration of the wash cycles can be checked on the display.

Setting the temperature

By pressing the TEM ERATURE button to set the wash temperature (see Table of wash cycles).

The temperature may be lowered, or even set to a cold wash ( ).

The washer-dryer will automatically prevent you from selecting a temperature which is higher than the maximum

value set for each wash cycle.

Setting the drying cycle

The desired drying cycle type may be set by pressing the

DRYING button once or several times. Two options are

available:

A - Based on time: from 40 to 180 minutes.

B - Based on the how damp the clothes are once they have

been dried:

ron dry : slightly damp clothes, easy to iron.

Cupboard dry : very dry clothes, recommended for towelling

and bathrobes.

If your laundry load to be washed and dried is much greater than the maximum stated load (see adjacent table),

perform the wash cycle, and when the cycle is complete, divide the garments into groups and put some of them

back in the drum. At this point, follow the instructions provided for a "Drying on y" cycle. Repeat this procedure

for the remainder of the load.

N.B.: when the drying is complete there is a cooling period, even though the DRYING button is in the 0 position.

Drying on y

Turn the WASH CYCLE knob to one of the drying settings (11-12-13) according to the type of fabric, then select

the desired drying duration using the DRYING button.

Functions

The various wash functions available with this washer-dryer will help to achieve the desired results, every time.

To activate the functions:

1. ress the button corresponding to the desired function;

2. the function is enabled when the corresponding indicator light is illuminated.

Note: If the indicator light flashes rapidly, this signals that this particular function may not be selected in

conjunction with the selected wash cycle.

Delay timer

To set a delayed start for the selected wash cycle, press the button repeatedly until the desired delay time is

displayed (this may be between 1 hour and 24 hours).

To disable the function press the button until the text is displayed.

N.B. Once you have pressed the START/ AUSE button, the delay time may only be decreased if you wish to modify it.

This option is enabled with all programmes.

Super ash

Because a greater quantity of water is used in the initial phase of the cycle, and because of the increased cycle

duration, this function offers a high-performance wash.

 This function may not be used in conjunction with wash cycles 4, 5, 6, 9, 10, 11, 12, 13, A, B, C.

Extra rinse

By selecting this function, the efficiency of the rinse is increased and optimal detergent removal is guaranteed. It is

particularly useful for sensitive skin.

 This function may not be used in conjunction with wash cycles 4, 5, 11, 12, 13, B, C.

1400-600

By selecting this function, reduces the spin speed.

 This function may not be used in conjunction with wash cycles 9, C, 11, 12, 13.

Personalisation

Fabric

type

Load type Max.

oad

(kg)

Cupboard

dry

Iron

dry

Cotton Clothing of different

sizes, Terry towels 5180160

Synthetics Sheets, Shirts, yjamas,

socks, etc. 3180160

Wool Knitwear, ullovers, etc. 1,5 150 130

Table of Drying times (guideline values)

Detergents and laundry

Detergent dispenser drawer

Good washing results also depend on the correct

dose of detergent: adding too much detergent will not

necessarily result in a more efficient wash, and may in

fact cause build up on the inside of your appliance

and contribute to environmental pollution.

 Do not use hand washing detergents because these

create too much foam.

Open the detergent

dispenser drawer and

pour in the detergent or

washing additive, as

follows.

compartment 1: Detergent for the wash cycle

(powder or liquid)

Liquid detergent should only be poured in immediately

prior to the start of the wash cycle.

compartment 2: Additives (fabric softeners, etc.)

The fabric softener should not overflow the grid.

extra compartment 3: Bleach

Bleach cycle

Bleaching may only be performed in conjunction with

wash cycles 1, 2, 6.

our the bleach into extra compartment 3; pour the

detergent and softener into the corresponding

compartments, then select one of the

abovementioned wash cycles.

This option is recommended only for very soiled

cotton garments.

Preparing the laundry

 Divide the laundry according to:

- the type of fabric/the symbol on the label.

- the colours: separate coloured garments from

whites

 Empty all garment pockets and check the buttons.

 Do not exceed the listed values, which refer to the

weight of the laundry when dry:

Durable fabrics: max. 7 kg

Synthetic fabrics: max. 3 kg

Delicate fabrics: max. 2 kg

Wool: max. 1,5 kg

MAX

How much does your laundry weigh?

1 sheet 400-500 g

1 pillow case 150-200 g

1 tablecloth 400-500 g

1 bathrobe 900-1200 g

1 towel 150-250 g

Garments requiring special care

Silk: use special wash cycle 9 to wash all silk

garments. We recommend the use of special

detergent which has been designed to wash delicate

clothes.

Curtains: fold curtains and place them in a pillow

case or mesh bag. Use wash cycle 9.

ool: Hotpoint/Ariston is the only washer-dryer

manufacturer to have been awarded the prestigious

Woolmark latinum Care endorsement (M.0508) by

the Woolmark Company, which means that all

woollen garments may be washed in the washer-

dryer, even those which state hand wash only

on the label. Wash cycle 10 therefore offers complete

peace of mind when washing woollen garments in the

washer-dryer (max. load 1,5 kg) and guarantees

optimal performance.

Load balancing system

Before every spin cycle, to avoid excessive vibrations

and to distribute the load in a uniform manner, the

drum rotates continuously at a speed which is slightly

greater than the washing rotation speed. If, after

several attempts, the load is not balanced correctly,

the machine spins at a reduced spin speed. If the

load is excessively unbalanced, the washer-dryer

performs the distribution process instead of spinning.

To encourage improved load distribution and balance,

we recommend small and large garments are mixed

in the load.

Anti-crease

This function interrupts the wash programme, and the

washing is left to soak in water before the appliance

is drained.

It can only be used with programme 9 (Silk/Curtains)

and helps to prevent the formation of creases.

To complete the cycle press the START/ AUSE

button.

Precautions and tips

 This washer-dryer was designed and constructed in

accordance with international safety regulations. The

following information is provided for safety reasons

and must therefore be read carefully.

General safety

 This appliance was designed for domestic use only.

 The washer-dryer must only be used by adults, in

accordance with the instructions provided in this manual.

 Do not touch the machine when barefoot or with

wet or damp hands or feet.

 Do not pull on the power supply cable when

unplugging the appliance from the electricity

socket. Hold the plug and pull.

 Do not open the detergent dispenser drawer while

the machine is in operation.

 Do not touch the drained water as it may reach

extremely high temperatures.

 Never force the porthole door. This could damage

the safety lock mechanism designed to prevent

accidental opening.

 If the appliance breaks down, do not under any

circumstances access the internal mechanisms in

an attempt to repair it yourself.

 Always keep children well away from the appliance

while it is operating.

 The door can become quite hot during the wash cycle.

 If the appliance has to be moved, work in a group

of two or three people and handle it with the utmost

care. Never try to do this alone, because the

appliance is very heavy.

 Before loading laundry into the washer-dryer, make

sure the drum is empty.

 During the drying phase, the door tends to get

quite hot.

 Do not use the appliance to dry clothes that have

been washed with flammable solvents (e.g.

trichlorethylene).

 Do not use the appliance to dry foam rubber or

similar elastomers.

 Make sure that the water tap is turned on during

the drying cycles.

Disposal

 Disposing of the packaging materials: observe local

regulations so that the packaging may be re-used.

 The European Directive 2002/96/EC on Waste

Electrical and Electronic Equipment, requires that

old household electrical appliances must not be

disposed of in the normal unsorted municipal waste

stream. Old appliances must be collected

separately in order to optimise the recovery and

recycling of the materials they contain and reduce

the impact on human health and the environment.

Opening the porthole door manually

In the event that it is not possible to open the

porthole door due to a powercut, and if you wish to

remove the laundry, proceed as follows:

1. remove the plug from

the electrical socket.

2. make sure the water

level inside the machine is

lower than the door

opening; if it is not, remove

excess water using the

drain hose, collecting it in a

bucket as indicated in the

figure.

3. using a screwdriver,

remove the cover panel on

the lower front part of the

washer-dryer (see figure).

4. pull outwards using the tab as indicated in the

figure, until the plastic tie-rod is freed from its stop

position; pull downwards and open the door at the

same time.

5. reposition the panel, making sure the hooks are

securely in place before you push it onto the

appliance.

The crossed out "wheeled bin" symbol on the

product reminds you of your obligation, that when

you dispose of the appliance it must be separately

collected.

Consumers should contact their local authority or

retailer for information concerning the correct

disposal of their old appliance.

Care and maintenance

Cutting off the water and electricity

supplies

 Turn off the water tap after every wash cycle. This

will limit wear on the hydraulic system inside the

washer-dryer and help to prevent leaks.

 Unplug the washer-dryer when cleaning it and

during all maintenance work.

Cleaning the washer-dryer

The outer parts and rubber components of the

appliance can be cleaned using a soft cloth soaked

in lukewarm soapy water. Do not use solvents or

abrasives.

Cleaning the detergent dispenser

drawer

Remove the dispenser

by raising it and pulling it

out (see figure).

Wash it under running

water; this operation

should be repeated

frequently.

Caring for the door and drum of your

appliance

 Always leave the porthole door ajar in order to

prevent unpleasant odours from forming.

Cleaning the pump

The washer-dryer is fitted with a self-cleaning pump

which does not require any maintenance. Sometimes,

small items (such as coins or buttons) may fall into the

pre-chamber which protects the pump, situated in its

bottom part.

 Make sure the wash cycle has finished and unplug

the appliance.

To access the pre-chamber:

1. using a screwdriver,

remove the cover panel

on the lower front part of

the washer-dryer (see

figure);

2. unscrew the lid by

rotating it anti-clockwise

(see figure): a little water

may trickle out. This is

perfectly normal;

3. clean the inside thoroughly;

4. screw the lid back on;

5. reposition the panel, making sure the hooks are

securely in place before you push it onto the

appliance.

Checking the water inlet hose

Check the inlet hose at least once a year. If there are

any cracks, it should be replaced immediately: during

the wash cycles, water pressure is very strong and a

cracked hose could easily split open.

 Never use second-hand hoses.

Other manuals for Hotpoint

This manual suits for next models

Table of contents

Languages:

Other Hotpoint Ariston Washer Dryer manuals

Hotpoint Ariston

Hotpoint Ariston AQUALTIS AQM8D 69 U User manual

Hotpoint Ariston

Hotpoint Ariston Hotpoint ARMXXD 129 User manual

Hotpoint Ariston

Hotpoint Ariston ARMXXD 1290 User manual

Hotpoint Ariston

Hotpoint Ariston AQUALTIS AQM9D 29 U User manual

Hotpoint Ariston

Hotpoint Ariston RDSG 86207 User manual

Hotpoint Ariston

Hotpoint Ariston AQUALTIS AQD970F 69 User manual

Hotpoint Ariston

Hotpoint Ariston Aqualtis AQD1171D 69ID User manual

Hotpoint Ariston

Hotpoint Ariston RDPG 96607 J User manual

Hotpoint Ariston

Hotpoint Ariston ARMXXF 149 User manual

Hotpoint Ariston

Hotpoint Ariston WDD 9640 User manual

Hotpoint Ariston

Hotpoint Ariston WDG 8640 User manual

Hotpoint Ariston

Hotpoint Ariston Aqualtis AQM8D 49 U User manual

Hotpoint Ariston

Hotpoint Ariston CAWD 129 User manual

Hotpoint Ariston

Hotpoint Ariston ARMXXL 125 User manual

Hotpoint Ariston

Hotpoint Ariston FDD 10761 User manual

Hotpoint Ariston

Hotpoint Ariston RDPD 96407 J User manual

Hotpoint Ariston

Hotpoint Ariston WDD 9640 User manual

Hotpoint Ariston

Hotpoint Ariston WDD 9640 User manual

Hotpoint Ariston

Hotpoint Ariston AQM9D 49 U H User manual

Hotpoint Ariston

Hotpoint Ariston FDG 8640 User manual

Hotpoint Ariston

Hotpoint Ariston ARMXXD 109 User manual

Hotpoint Ariston

Hotpoint Ariston RDSG 86207 User manual

Hotpoint Ariston

Hotpoint Ariston WDG 8640 User manual

Hotpoint Ariston

Hotpoint Ariston Aqualtis AQD1171D 69ID User manual

Popular Washer Dryer manuals by other brands

Whirlpool

Whirlpool WFC8090GX Use and care guide and installation instructions

Whirlpool

Whirlpool LTE5243DQ6 User instructions

Bosch

Bosch XQG100-WDU285H00W User manual and installation instructions

montpellier

montpellier MWD7512S Installation and operating instructions

LG FHD0905 T Series owner's manual

Midea

Midea MF200D85B owner's manual

Maytag

Maytag MGT3800XW installation instructions

Siemens

Siemens WD15G440TR Instruction manual and installation instructions

Equator

Equator Clothes Processor EZ1500 owner's manual

Splendide

Splendide WDC7100XCP Specifications

John Lewis

John Lewis JLWD 1408 instruction manual

Ariston

Ariston A1200WD Instruction booklet

Whirlpool

Whirlpool YLTE5243DQ5 installation instructions

Whirlpool

Whirlpool WFCR 75230 Health & safety, use & care and installation guide

ATT

ATT Hammer Jet v1 operating manual

AEG

AEG LAVAMAT 63742 VI Instruction booklet

Electrolux

Electrolux EWW8024P5WB user manual

GE GTD42EASJWH owner's manual
