Hoover VHC180-80 User manual

31100236 VHC180-80

Service Manual

31100236 VHC180-80 0730 (27/07/2007)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

14a Drying knob 40004892

19a Button on/off 40004882

19h Door opening button 40004885

31 Control panel 40005099

48 R/H side frame 41019260

48a L/H side frame 41019261

49 Top rear frame 40004597

51 Work top 40004601

60 Hinge 40001064

76 Cabinet-assy 40004167 0730 (27/07/2007)

76 Cabinet-assy 40004998 0730 (27/07/2007)

77 Rear panel 40004062

79 Foot 40002885

82 Door panel 40001285

88 Front panel 40004620

131 Hose clip 92470020

133 Hose clip 92470012 0730 (27/07/2007)

135 Water valve 03860531 0730 (27/07/2007)

135 Water valve 40004935 0730 (27/07/2007)

135a Valve body 03860530 0730 (27/07/2007)

135b Foam ring 03620295 0730 (27/07/2007)

135b Foam ring 09182833

136 Water container valve 03860523 0730 (27/07/2007)

136 Water container valve 40004933 0730 (27/07/2007)

136a OR (O-Ring) 25156026 0730 (27/07/2007)

136b O-Ring small 25156027 0730 (27/07/2007)

136c O-Ring large 25156025 0730 (27/07/2007)

153 Pressure switch 28375043 0730 (27/07/2007)

155 Indicator liht 91209510

157 Harness 40004703 0730 (27/07/2007)

157 Harness 40004999 0730 (27/07/2007)

162 Microswitch 28353502 0730 (27/07/2007)

163 Microswitch holder 03870737 0730 (27/07/2007)

31100236 VHC180-80 0730 (27/07/2007)

Ref. Descrizione - Description - Beschreibung - Descripcion

Fine

Ending

Fin

End

Fin

Inizio

Beginning

Debut

Begin

Inicio

Ricambio

Part No.

Piece

E-Teil

Pieza

164 Anti jamming filter radio 91200489

171 Main motor 40002179 0730 (27/07/2007)

171 Main motor 40005004 0730 (27/07/2007)

202 Drum 40002637

205 Drum shaft assy 40003979

218 Bearing 03210179

219 Bolt 21446068

229 Circlip 97911424

230 Bearing clamp 40004306

265 Relay 91201247

271 Door gasket 40001055

292 Drive belt 40001012

420 Time lag device 97923304 0730 (27/07/2007)

420 Time lag device 40005008 0730 (27/07/2007)

442 Fan 03870702 0730 (27/07/2007)

442 Fan 40004669 0730 (27/07/2007)

442a Rear fan 40001069

443 Thermostat 40001954

448 Heather 40004315 0730 (27/07/2007)

448 Heather 40004314 0730 (27/07/2007)

491 Main cable 91201807

494 Red window 40004889

520 Door coupler 40004092

618 Unipolar NC switch 41006060

619 Bipolar switch NA 41012643

631 Stopper 03730696

647 Water condenser 04350220 0730 (27/07/2007)

647 Water condenser 40004812 0730 (27/07/2007)

671 Washer 03610428

690 Rear sealing felt 40003167

690a Rear cover seal 40004577

696 Heater support 40003227

697 Heater support disk 40003226
