USER MANUAL

使用說明書

HITACHI FULLY AUTOMATIC WASHING MACHINE

日立全自動洗衣機

Model NW-80AS

Thank you for your purchase of HITACHI Fully Automatic

Washing Machine.

• Please read this manual carefully for proper operation.

• Please keep this manual for future reference.

承蒙您選購日立的全自動洗衣機，謹此致衷心謝意。

• 請細閱本說明書，以便正確使用本洗衣機。

• 閱讀完畢，請妥善保存本說明書，以備將來查閱。

CONTENTS

Key Features 前言................................................................................................................... 3

Safety Precautions 安全方面的注意事項 ................................................................................ 4

Installation Guide 安裝指南..................................................................................................... 7

Installation 安裝 .................................................................................................................... 13

Safety Check 安全檢查 ......................................................................................................... 14

Washing Machine Repair 洗衣機修理事宜............................................................................ 14

Technical Description 各部件名稱......................................................................................... 15

Control Panel 控制面板......................................................................................................... 16

Before Using Your Machine 開始洗衣前................................................................................ 19

Checking Amount of Laundry and Detergent (Approximate Amount)

檢測洗衣量和洗衣粉量（大致用量） .................................................................................... 20

How to Use Liquid Detergent, Bleach and Fabric Softener

洗衣粉、漂白劑、柔軟劑的使用方法 .................................................................................... 21

Amount of Laundry and Detergent 洗衣量和洗衣粉量.......................................................... 23

Selection of Laundry Program 洗衣程序的選擇方法............................................................. 24

Content of Laundry Program 洗衣程序的內容 ...................................................................... 26

Program Description 各程序的說明 ...................................................................................... 27

Wool Program 毛絨程序........................................................................................................ 29

Using the Timer for Washing 預校時間洗衣 .......................................................................... 33

Using the Detergent Again 再次使用洗衣液 ......................................................................... 35

Using the Washing Cap 使用洗衣蓋 ..................................................................................... 36

Air-Jet Program 風乾程序 ..................................................................................................... 38

Washing in Your Favorite Way 按照您喜歡的方式進行洗衣................................................... 42

Use Guidelines 使用中的注意事項........................................................................................ 44

Tub Clean Program 筒清洗程序 ............................................................................................ 45

Tub Dry Program 筒風乾程序................................................................................................ 46

Maintenance and Repair 維護保養方法 ................................................................................ 47

When Failure Happens 有故障發生時................................................................................... 50

Optional Parts 另售部件........................................................................................................ 56

Product Speciﬁcations 產品規格........................................................................................... 56

Key Features

前言

Inﬁltration washing 滲透清洗

Laundry rearrangement and spinning 理衣脫水

The number after this symbol is the page number for detailed description.

後面的數字表示具體說明的頁數。

※Please use concentrated powder detergent to wash.

請使用濃縮合成粉末洗衣粉進行洗衣。

The inﬁltration washing cannot be performed for the programs of "Wool", "Blanket", "Speedy" and "Tub Clean". (Because of no

detergent dissolution course in these programs)

「毛絨」、「被毯」、「快速」、「筒清洗」程序不能進行滲透清洗。（因為沒有溶解洗衣劑的過程）

Inﬁltrate the detergent inside the cloth to detach the dirt off the ﬁber.

使洗衣粉滲入到衣料內部，使污垢從布料纖維上脫落。

The detergent dissolves sufﬁciently to become the highly concentrated detergent that washes the laundry in inﬁltration

mode for easier detachment of dirt off the cloth ﬁber.

洗衣粉充分溶解，形成高濃度洗衣液，對衣物進行滲透清洗，使污垢更易從布料纖維上分離。

Put detergent in, adding some water

加入洗衣粉，供給少量水

The detergent put in at the injection

opening will fall below the pulsator.

從注入口加入的洗衣粉將落在攪拌翼

下方，並注入少量水。

1Make the detergent

dissolves fast by

rotating the spinning

basket.

通過脫水桶旋轉加速

洗滌劑溶解。

The detergent dissolves inside

the cloth

溶解洗衣粉使其滲入衣物

The concentrated detergent dis-

solves with the agitating power of

pulsator, and inﬁltrates sufﬁciently

inside the cloth.

濃縮洗衣粉在攪拌翼強力攪拌下溶

解，充分滲透到衣物內部。

THREE-STEP washing

三步洗衣

Inject a little water, and the dirt will

detach with the highly concentrated

detergent; inject more water to the

normal water level for washing.

加入少量水，污垢在高濃度洗衣液下脫

落，再加水到通常水位處進行洗衣。

※Some washing capacity may not be done.

有的洗衣量有可能無法進行理衣工序。

※The laundry rearrangement does not perform in the case of manual setup of "Rinse", "Spin" or "Spin Only".

手動設定“沖洗”、“脫水”或“只脫水”等時，不進行理衣程序。

Loosen the post-spinning laundry for easy taking out. 疏鬆脫水後的衣物，使之易於取出。

Detergent injection

opening

洗衣粉注入口

Outer basket

外槽 Pulsator

攪拌翼

Stainless-steel basket

不銹鋼槽

Nanometer titanium deodorization filter net ₗ›⹃ぜ⎌ᛍջℐ

Nanometer titanium can absorb and remove the peculiar smell, while the artificial oxygen

generation function can capture and remove substances which cause hyper sensitivity like pollen.

ₗ›⹃רؚᄇʏ׏ぜᯌػŊːడӼᖒԼ⋱רྐྵྯʏ׏ぜ␕⁆ᾀ⳧ᄖ᧎⫨ȯ

Inhaling hole

ؚᖎם

Air will blow out from here.

ഺᔍ⚠Ⲷㆺ

Be sure to open it when TUB is drying.

ᾉㆺʯᆹ⦼Ֆൕ༌⿭ȯ

Nanometer titanium

deodorization filter net

ₗ›⹃ぜ⎌ᛍջℐ

Safety Precautions

安全方面的注意事項

Please read this part of substance carefully for proper operation before using your machine.

使用之前，請仔細閱讀這部分的內容，以便正確使用。

★The precautions stated here are classiﬁed as "Warning" and "Attention" according to the damage and the emergency caused by

misoperation, and are described respectively in line with the marks below

這裡所說的注意事項根據誤操作而引起的傷害大小以及緊迫程度，分為“警告”和“注意”兩種，並且按照以下標識進行區分說明

With no respect to this mark, the misoperation may cause body harm or object damage.

表示如果無視此標記，誤操作後，可能引起人身傷害或物體損壞事故。

⨸ب

Graphic mark

圖形例子 This mark indicates the content of warning or attention.

表示敦促警告及需要注意的內容。

This mark indicates the prohibited action.

表示禁止行為。

This mark indicates the compulsory action to be carried out.

表示必須執行的強制行為。

⨸ب

Warning

警告

Attention

注意

⨸ب

Warning 警告

With no respect to this mark, the misoperation may cause death or GBH.

表示如果無視此標記，誤操作後，可能引起死亡或重傷事故。

Dismantle, repair or alterations should

only carried out by professional techni-

cians.

除指定的專業維修人員外，應絕對禁止他人

拆卸、修理或改裝洗衣機。

• Avoid electric shock, ﬁre, and body injury due to improper activ-

ity.

避免因不恰當行為而導致觸電、火災及人身傷害。

Dismantling

Prohibited

禁止拆卸

220V~

10A!

Please use the single socket with

220V~,10A speciﬁcation.

請單獨使用額定值為交流220V~、10A以上

容量的電源插座。

• The share of the same socket with

other electric appliances may cause

ﬁre due to excessive heat.

若與其它電器設備共用同一插座，可能

因異常發熱而導致火災事故。

Power

電源

Washing machine should not be

installed in humid place or in places

exposed to wind and rain.

請勿將洗衣機安裝在潮濕或容易受到風吹

雨淋的地方。

• Otherwise, electricity leak causing electric shock or ﬁre may

occur.

避免觸電或因漏電而引發火災事故。

Humid places

prohibited

禁止潮濕的地方

Electricity supply must be unplugged /

plugged with dry hands.

嚴禁使用濕手插拔電源插頭。

• Otherwise, this may cause electric shock.

否則可能導致觸電事故。

Wet hands

Prohibited

禁止濕手觸摸

Do not put water in direct contact with

the unit during maintenance and repair.

進行保養時，請勿直接

將水淋灑在洗衣機的各個部位。

• This may cause short circuit or electric shock.

否則可能造成短路而導致觸電事故。

Prohibited

禁止

This washing machine is equipped with

the electricity wire with bi- electrode

grounding plug, please use the bi-elec-

trode grounding socket.

The creepage protector shall be used

if possible.

本品採用二極接地插頭電源線，請使用二極

接地電源插座。可能的話，最好使用漏電保

護器。

• To prevent electricity leak which may cause injuries.

避免因漏電故障引起傷害。

Grounding

接地連接

⨸ب

Warning 警告

Do not damage or alter the wire forc-

ibly bend, pull, twist or handle the

wire. Besides that, please do not put

heavy object on or trap the wire.

請勿隨意進行改裝、強行彎曲、拉

伸、扭曲及捆紮電源線。此外，亦請

勿將重物壓在其上或夾於其中。

Do not damage wire.

嚴禁損壞電源線。

• Damage of wire may cause electric shock or ﬁre.

若電源線遭受損傷，可能導致觸電或火災。

• To prevent ﬁre or explosion

which may cause injuries.

否則可能引發爆炸或火災事故。

Do not put gasoline, benzine, alcohol,

thinner of fabrics with these stains

into or near to the washing machine.

請勿將汽油、香蕉水、酒精、燒鹼或沾有

上述液體的衣物放入槽內或靠近洗衣機。

This washing machine is strictly pro-

hibited from being placed close to the

locations with candle, mosquito- repel-

lent incense, dog-end or other kinds of

open ﬂame.

本洗衣機嚴禁靠近蠟燭、

蚊香或煙頭等有明火的場所。

• To avoid injuries caused by the lock installation

damage.

避免因裝置損壞而招致意想不到的傷害。

Do not put your hand into the basket

until it has stopped completely.

在脫水槽完全停止轉動前，

嚴禁將手伸進槽內拿取衣物。

• Even when the spinning of the basket is

slow, there is still a danger of being caught

in the motion, resulting injuries. Particular

attention should be paid when children are

around.

即使旋轉緩慢，手部仍有被衣物纏繞的危

險。兒童尤需注意。

Prohibited

禁止

Do not put your hands into the wash-

ing • spinning basket during the wash-

ing and rinsing processes.

洗衣和沖洗過程中，嚴禁將手伸入洗衣 •

脫水槽內。

• Even when the spinning is slow, hands may be trapped by

clothes. If necessarily, please press pause button, and put

your hands into the basket after it has stopped completely.

即使旋轉緩慢，手部仍有被衣物纏繞的危險。（若必須將手伸

入槽內時，請按下暫停按鈕，待洗衣‧脫水槽完全停止旋轉後

再伸入槽內）。

Prohibited

禁止

Prohibited

禁止

Prohibited

禁止

No smoke or ﬁre

禁止煙火

• Otherwise electric shock, short circuit or ﬁre may take place.

否則可能導致觸電、短路或起火。

Damaged or loosen wire or plug should

not be used.

嚴禁使用已損壞的電源線、插頭或鬆動的

插座。

Prohibited

禁止

Keep child away from the washing •

spinning basket and do not place box

or shelves next to the washing machine.

嚴禁讓兒童探看洗衣 • 脫水槽。也請勿在洗

衣機旁放置台架等物品。

• Children may fall into the bas-

ket resulting in injuries.

兒童可能因掉入洗衣 • 脫水槽

中造成人身傷害。

Prohibited

禁止

Thoroughly wipe the power plug when

dirt is adhering the prong or around the

base of the prong.

電源插頭的插片以及插片的夾緊面上，

若有塵垢附著時，請擦拭乾淨後再使用。

• Failure to do so may cause a ﬁre.

可能會引起火災。

Clear

清掃

•

• Children should be supervised to ensure

that they do not play with the appliance.

請督導兒童，確保其不玩耍機器。

⨸ب

Warning 警告

⨸ب

Attention 注意

Safety Precautions (continued)

安全方面的注意事項（續）

Do not open the lid in locked status by

force.

嚴禁強行打開處於鎖定狀態的機蓋。

Do not insert a screwdriver into the Lid

Lock hole.

嚴禁用螺絲刀插入洗衣機機蓋緊鎖裝置部

位的孔內。

• To avoid injuries caused by the lock damage.

避免因裝置損壞而招致意想不到的傷害。

Do not connect to the hot water supply.And, water

of above 50

C should not be used for washing.

請勿連接至熱水管，並且用溫水進行洗滌

時，水溫嚴禁超過50 ˚C。

• Electric shock or leakage may occur

due to deformation of plastic parts

of the unit.

可能因塑膠部件的變形受損而導致觸

電或漏電事故。

Water supply hose should be tightly

screwed to the unit.

供水管連接機體的螺母必須擰緊。

• Failure to do so may result in

water leakage.

可能導致漏水。

• After being used for a long period of

time, the unit may result in water leakage caused by loosen

union nut. So please check it in time and screw tightly again.

長期使用後，可能會因連接螺母鬆動造成漏水而遭受不必要

的損失。因而請務必定期檢查並重新擰緊已鬆動的螺母。

Please unplug the unit when not using

the unit for a long period of time.

不使用洗衣機時，必須將電源插頭拔出。

•

Electric shock or leakage due to aging of insulator may cause ﬁre.

可能因絕緣老化而引發觸電、漏電或火災事故。

Electricity supply must be unplugged with

dry hands during maintenance and repair.

維修保養時，請務必將電源插頭從插座拔

出。

• Otherwise, electric leakage may occur

causing injuries.

避免因漏電而招致傷害。

Prohibited

禁止

Prohibited

禁止

Do not stand on or put heavy object

on the top of the unit.

請勿站立在洗衣機上，

或者在其上放置重物。

• Otherwise, deformation or damage

may result causing injuries.

可能因變形或損壞造成人身傷害。

Prohibited

禁止

Prohibited

禁止

Union nut

連接螺母

Do not pull the wire from the socket

when unplugging the unit.

拔掉電源插頭時，切勿拉扯電源線，必

須拿住插頭本體向外拉。

• To avoid electric shock or ﬁre cause by short

ciruit may result.

避免觸電或因短路導致火災事故。

Prohibited

禁止

water leakage

漏水

•

To prevent damages caused by possible water leakage due to loosen screw.

如果螺釘松脫，會因漏水而招致不必要的損失。

Check water supply hose connection by

turning on the water tap before washing.

開始洗衣前，請先打開水龍頭，檢查供水

管的連接狀況。

water leakage

漏水

When installing the washing machine,

be sure to draw out the water drainage

hose until the (left) and

(right) mark is seen.

安裝洗衣機時，請務必將排水管拉出至刻印文

字（左）或（右）標記處。

• Failure to do so may cause damage to the drainage hose and

water leakage.

如果排水管沒有完全拉出，會與其它部件觸碰而導致破損，引發漏水等意想不到的損失。

water leakage

漏水

Keep hands and feet away from the

bottom of the washing machine when it

is in motion.

運轉過程中，請勿將手或腳伸至

洗衣機的下部。

• Ports in motion beneath the unit may

cause injuries.

旋轉部件可能會引起人身傷害。

Prohibited

禁止

• Otherwise, the lid or locking

device may be damaged, result-

ing in unstoppable spinning of

washing • spinning basket and

thus causing injuries.

否則將會損壞機蓋或鎖緊裝置，導

致洗衣 • 脫水槽無法停止旋轉，造成人身傷害。

Do not wash, rinse and spin the water-

proof fabric or cloth.

請勿洗滌防水性的苫布或衣物。

⨸ب

Attention 注意

Please turn off the water tap when not

using the unit.

不使用洗衣機時，必須關閉水龍頭。

sleeping bag, raincoat, cover of skiing

utilities, bicycles, cars and motors

睡袋、雨衣、滑雪用具以及自行車、轎車、

摩托車的車罩等。

Safety Precautions (continued)

安全方面的注意事項（續）

• To prevent damages caused by

water leakage.

以防產生漏水。

•

Otherwise may lead to injury by abnormal vibration during spinning

or damage the washing machine, wall, ﬂoor and clothes.

可能在脫水時產生異常振動而引起人身傷害，或者導致洗衣機、牆

壁、地板以及衣物的損壞。

Installation of Washing Machine 洗衣機的安裝

Please install on a solid horizontal

surface.

請安放在堅硬、平坦的地面上。

• Installation on a slippy or irregular surface may

result in noise and shaking.

安放在易於滑動、柔軟的地面上，會容易產生

振動和噪音。

The unit should be installed on a ﬂat horizontal surface.

請水準安裝洗衣機。

Otherwise sudden stop or abnormal sound may occur during the spinning cycle.

若安裝得不水準，會導致脫水時停機或產生異常聲音。

Where to install 安裝地方

Avoid installing the unit too close to the

wall.

請勿靠近牆壁安放。

• This is to prevent abnormal vibration and noise.

以防止異常振動和噪音。

Solid, horizontal surface

堅硬、平坦的地面

Weak surface

柔軟的地面

Irregular surface

凹凸的地面

At least 1.5cm

1.5cm˫ʀ

At least 1.5cm

1.5cm˫ʀ

At least 9cm(Water drainage hose onside)

9cm

˫ʀ(࿢ᖛᾷɺϳ)

Installation Guide

安裝指南

How to install 安裝方法

Do not slant the washing cap. Do not use the washing cap except Blanket, Wool program.

嚴禁傾斜安裝洗衣蓋，並絕對禁止在「被毯」、「毛絨」程序以外使用洗衣蓋。

• Splash of water may occur or washing cap may be swung out of the basket.

可能會因水滴飛濺或洗衣蓋彈飛出造成洗衣機受損或人身傷害事故。

Prohibited

禁止

Prohibited

禁止

water leakage

漏水

Installation of Washing Machine 洗衣機的安裝

1Adjust the washing machine with adjust-

able leg.

用可調機腳來調整洗衣機的不平穩。 2Please make sure the horizontality of the

washing machine.

請確認機體的水平度。

• As shown in the ﬁgure, the horizontality can be easily

observed by a string hanging an object.

如圖所示，用懸掛重物的細繩來觀察，即可輕易確認其

水平度。

Fixed leg

固定腳 Adjustable leg

可調機腳

It is level if

the clearance

between A and

machine body is

the same with that

between a and the

machine body.

A和A兩點與機體

之間的間隙相同，

即表示水準。

string

細繩

object

重物

(front or

proﬁle)

（正面或

側面）

Put some water into the washing tub and reconﬁrm its horizon-

tality.

在洗衣槽內放些水，請再一次確認其水平度。

• The ground is level if all front, rear, left and right height difference between

the spinning hole and water surface are less than 3mm.

脫水孔相對於水面的高度差（B與C的差），如果前後左右均在3mm以內，

就表示地面是水準的。

Inspection of trial run 試運轉的檢查

Installation Guide (continued)

安裝指南（續）

Spinning hole

脫水孔

How to Use the Adjustable Leg 可調機腳的使用

1Loosen the lock nut by unscrewing in arrow

direction 1before using the adjustable leg

to stabilize the unit.

將鎖緊螺母沿箭頭方向1旋松，再旋轉可調機

腳調整機身的平穩。

2After adjusting of the unit, tighten the lock

nut by screwing it in arrow direction 2.

調整完畢後，將鎖緊螺母沿箭頭方向2旋緊。

Loosening

ᅩኇ

Lock nut

⽁ℤ➦ᕒ

Adjustable leg

ר⦲ᑨ⌳

Lowering

⦲ᆹ

Elevating

⦲㋧ᆹ

Maximum adjust able range is 40mm.

⦲ῃ῅ߣ߱40mm˫ҙȯ

Tightening

ᅩℤ

Lock nut

⽁ℤ➦ᕒ

Plastic base

࢞⍑ಎᲷ Tighten the lock nut until it reaches the plastic base.

⽁ℤ➦ᕒະე⎏࢞⍑ಎᲷᣅᔋȯ

At most 40mm

40mm˫ʁ

Water drainage hose

࿢ᖛᾷ

ater drainage outlet

࿢ᖛם

■When ﬁtting the water drainage hose to the

water drainage outlet

排水管插入排水口時

If the water drainage outlet is too shal-

low or the end of the water drainage hose

touches the grounds, cut the end of the

water drainage hose in an oblique angle.

排水口較淺或排水管前端與地面碰觸時，可將

排水管的前端沿斜向切除一部分。

• Failure to do so may cause insufﬁcient rinsing or unit mal-

function due to poor drain-

age or too much bubbles

during rinsing and spinning.

若不切除，在沖洗及脫水

時，由於排水狀況的不良，

將會引起沖洗不充分或因肥

皂沫而影響電機運轉。

How to Install the Water Drainage Hose 排水管的安裝

1Lay the unit down slowly.

請將機體輕輕地放倒。

• Lay the unit down on some corrugate paper to pre-

vent damage.

放倒機體時，請在地面上放置一些瓦楞紙類的襯墊，

以免損傷機身。

2Pull out the water drainage hose from the

left side of the unit.

排水管從左面引出。

1Remove the left water drainage hose cover.

將機體左面的排水管蓋拆下。

2Insert in the scoop channel with a minus screwdriver,

loosens the hose clamp.

用一字螺絲刀插入凹槽內，鬆開軟管固定夾。

※Attention: For the screwdriver please do not bump into the hose.

注意：螺絲刀請勿碰到軟管。

3After pulling out the end with marking“”(right) of

the water drainage hose from the right groove of the unit,

the end with marking“”(left) of the water drain-

age should be inserted into the corresponding groove of

the left unit.

把排水管刻印文字“ ”(右)標記部從機體右側的凹槽

內引出，刻印文字“ ”（左）標記部應嵌入機體左

側對應的凹槽內。

The water drainage hose should be pulled out through the

proper hose clamps when the hose is pulled out on the left.

排水管從左面引出時，排水管應通過相應的軟管固定夾後

再引出。

■The water drainage hose is installed at the factory on the right side. It can be moved to the left

side if necessary.

產品出廠時，排水管安裝在機身右側，請視排水位置的具體情況將其換至左側。

Water drainage hose is pulled

out on the right

ߗહ߱࿢ᖛᾷ೧ӛםņ׬Ň⚠ᆹ

Ԁ֬ᄽ઎

Letter

ing (right)

Corr

ugate paper

Water drainage

hose cover

࿢ᖛᾷ╾

᭺Ꮌ₣

Front

Ԋϳ

Water drainage hose outlet

࿢ᖛᾷ೧ӛם

Water drainage hose cover

࿢ᖛᾷ╾

Water drainage hose is pulled

out on the left

ߗહ߱࿢ᖛᾷ೧ӛםņఢŇ⚠ᆹ

Ԁ֬ᄽ઎

Hose clamps

Ⱆᾷߗહ

ater drainage

hose outlet

࿢ᖛᾷ೧ӛם

End with making "Left"

Attention 注意

The (left) or (right) mark of

the water drainage hose should be inserted

into the corresponding groove of the unit.

安裝洗衣機時，請務必將排水管的刻

印文字標記部嵌

入機體相對應的凹槽內。

• Water drainage hose which inserts into the unit,

cannot touch other parts, to prevent the damage

caused by water leakage.

排水管在機體內的部分，不應與其它部件碰觸，以

免因破損產生漏水而導致不必要的損失。

• Water drainage hose clamp must be tightened.

排水管固定夾必須夾緊。

• The inner section of the water drainage hose must be

secured by the clamp before being fetched out.

排水管機內部分必須經固定夾固定後再引出。

⨸ب

Installation Guide (continued)

安裝指南（續）

Ensure that the water drainage hose will not separate from its outlet even if there is vibration or

the outlet is too big or too shallow.

當排水管因排水而引起振動，或排水口較大或排水口較淺時，應確保排水管不得脫出排水口。

■Extended hose

排水管的延長

Please use optional extension drainage tube to extend the length of the water drain-

age hose.

請使用另售的延長軟管。

• Follow the instructions below to improve drainage efﬁciency.

為了有效地排水，請遵照下列的指示。

• Please avoid pulling out the water drainage hose as shown below. Otherwise, water leakage or abnormal sound may occur.

下圖所示的排水管取出方式應絕對禁止。否則會造成漏水或產生異響。

• When purchasing extension hose, make sure that the inner diameter of the hose is big enough, otherwise, poor drainage

may be caused and result in the malfunction of the unit.

如果使用市售的其他延長管，那麼您選擇的軟管內徑不應太小。否則將會降低排水性能，導致洗衣機不能正常運轉。

࿢ᖛᾷʃവഺҙⵒ᳅࿲တҘ࿢ᖛםȯ

Water Drainage Hose Related Parts 排水管的相關部件

Attention 注意

Length of water drainage hose

should not exceed 5m.

Extension drainage hose

Height of water drainage hose should

not exceed 15cm and length should

not exceed 2m.

15cm

Less than 5m

Less than 2m

Less than 15cm

15cm

࿢ᖛᾷҚ⿢ʃ⬢⳧

ೖ⿢Ⱆᾷ

˫ʁ

࿢ᖛᾷ⬢⬤㋧ಙ߱ ˫ҙŊʈҚ⿢

˫ҙȯ

Table of contents

Other Hitachi Washer manuals

Hitachi

Hitachi BD-70CVE User manual

Hitachi

Hitachi BD-W90AV Product guide

Hitachi

Hitachi AJ-S70WXP User manual

Hitachi

Hitachi BD-90YFVEM User manual

Hitachi

Hitachi SF-120MV User manual

Hitachi

Hitachi PS-100LJ TH User manual

Hitachi

Hitachi HWF-800X Specification sheet

Hitachi

Hitachi BD-W80MV Product guide

Hitachi

Hitachi BD-W85TV Product guide

Hitachi

Hitachi BD-W75TSP Product guide

Hitachi

Hitachi SF-140TE User manual

Hitachi

Hitachi SF-240XWV Product guide

Hitachi

Hitachi BD-W75TV Product guide

Hitachi

Hitachi PS-T700BJ User manual

Hitachi

Hitachi SF-95XA Product guide

Hitachi

Hitachi PS-115LSJ TH User manual

Hitachi

Hitachi BD-W80PAE Product guide

Hitachi

Hitachi SF-P90DJ User manual

Hitachi

Hitachi Twin-tub PS-99BSP User manual

Hitachi

Hitachi SF-P80CJ User manual

Hitachi

Hitachi BD-100XFVEADM User manual

Hitachi

Hitachi BD-W70MAE Product guide

Hitachi

Hitachi AJ-S55PXP User manual

Hitachi

Hitachi SF-125XE Product guide

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
