Heinner HSWM-65S User manual

www.heinner.com

SEMI-AUTOMATIC WASHING

MACHINE

Model: HSWM-65S

Model: HG-150SS

www.heinner.ro

Semi-automatic washing machine

Capacity: 6.5 kg

www.heinner.com

Thank you for purchasing this product!

I. INTRODUCTION

Before using the appliance, please read carefully this instruction manual and keep it for future reference.

This instruction manual is designed to provide you with all required instructions related to the installation,

use and maintenance of the appliance.

In order to operate the unit correctly and safety, please read this instruction manual carefully before

installation and usage.

II. CONTENT OF YOUR PACKAGE

III.

Washing machine

User manual

Warranty card

www.heinner.com

III. SAFETY MEASURES

Be sure to comply with the following to prevent damage to body and property of you and

others:

The sign stands for “pay attention”, and the picture of specific items needs

attention shows in .

The sign stands for “forbid”, and the picture of specific items forbidden shows in

The sign stands for “must do”, and the picture of specific items must be done shows in

This appliance is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision or

instruction concerning u se of the appliance by a person responsible for their safety.

This appliance is for indoor use only.

Children should be supervised to ensure that they do not play with the appliance.

When choosing the water inflowing to wash tub or spin tub, please do not move the water inlet valve

during the process of water inflowing.

The new hose-sets supplied with the appliance are to be used and that old hose-sets should not be

reused.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

The openings must not be obstructed by a carpet.

If strong vibration occurs in time of spinning, open the spin cover immediately. Make sure that the

washing machine is placed on a flat and stable floor, and then adjust washing materials, distribute them

evenly.

To do spinning and draining together, please spin for 1 minute before draining.

Do not wash or spin waterproof clothes or clothes that float easily to avoid abnormal vibration or damage

to the clothes.

www.heinner.com

WARNING

1. Do not dismantle the machine by yourself.

2. Do not install the machine in damp or rainy environment to avoid electric shock, fire, machine

failure,or deformation.

3. Do not place inflammable materials like burning candle, mosquito incense, cigaret etc. or heating

source like electric stove, calorifier etc. on the machine.

4. Do not spray water directly to the machine.

5. Do not let baby sit on it or place heavy things on it.

www.heinner.com

6. Do not wash clothes that are stained with kerosene, petrol, alcohol, and other flammable substance.

7. Make sure that the water inlet hose is connected and the tapis opened before washing.

8. Do not exceed the max. water level to avoid water overflowing and machine failure.

9. To avoid electric shock resulting from electric leakage, please connect grounding wire of the plug

properly.

10. Do not let baby climb to the machine or play near running tub to avoid accident.

11. If use warm water, the water temperature should not exceed 50℃.

www.heinner.com

12. Do not wash down-filled coat, raincoat or similar clothes.

13. Wipe off dirty and dust on the plug of ten to prevent poor contact with power supply.

14. Do not put hands into the tub before it stopping running.

15. Do not replace power cord by yourself.

16. Do not damage the power cord and plug to avoid electric shock, short circuit or fire.

17. Insert the plug tightly when use.

www.heinner.com

18. Do not pull the cord when unplug the plug.

19. Do not insert or unplug the plug with wet hands to avoid electric shock.

20. Unplug the plug from socket after use.

ATTENTION TO INSTALLATION

Lay upper drain hose

●Needs a drain hose with minimum diameter of 3 cm, and minimum carry away capacity of 40 liters

per minute.

●For upper drain system, the drain hose must be placed at least 86 cm(30 inches) from thebottom of

washer, but not higher than 100 cm.

FOR UPPER DRAIN SYSTEM ONLY

Change the position of the drain hose

The ex-factory installation position of the drain hose is located at the spin side. According to the

installation site, the drain hose can also be installed at the wash side of the machine. The method is as

follows:

Unplug the power cord and empty water in the drain hose completely.

www.heinner.com

Spread a piece of soft cloth on the floor (e.g. a blanket) and place the washing machine on it

gently.

Take the drain hose out from the buckle at the spin side, and put it into the buckle at the wash

side.

Hang up the drain hose kit.

FOR LOWER DRAIN SYSTEM ONLY

Installation site

In order to avoid electrical failure, discoloration and deformation, do not install the machine in the

following places:

●Locations exposed to direct sunlight

●Locations exposed to rain or snow

●Locations with uneven or unstable ground

www.heinner.com

ACCESORIES

CONTROL PANEL

THE DRAWING ABOVE IS FOR REFERENCE ONLY, SPECIFIC DRAWING IS SUBJECT TO ACTUAL MODELS.

- Water inlet: be used to inject water.

- Wash timer: be used to select required washing time.

- Spin timer: be used to select required spinning time.

- Wash-Drain selector: For washing or rinsing, select “ Normal”or“ Heavy”. For Draining ,select “Drain”.

IV. PRODUCT DESCRIPTION

www.heinner.com

V. USING INSTRUCTIONS

PREPARATION INSTRUCTIONS

1. Plug in power and connect the water inlet hose.

2. Lay down the lower drain hose and connect it to the sewer , or lay the upper drain hose to places as

indicated in page 3.

3. Check that there are no objects such as coins, hairpins, mud or sand in the pocket.

4. Strings should be knotted in advance to prevent entanglement.

5. Clothes can be classified for washing according to the texture, dirty degree and color.

6. For small pieces (e.g.,stockings) or fluffy clothes, put them into a nylon net for washing.

Attachment: Reference of laundry quantity corresponding to different capacities

CAPACITY

SHIRT about 500g

UNIFORM about 650g

JEANS about 900g

JACKET about 1600g

6,5 kg

About 12 pcs

About 9 pcs

About 6pcs

About 3pcs

NOTE: The TABLE above is for reference only, specific weights are subject to actual clothes.

Attachment : Laundry volume and detergent dosage reference

FABRIC TYPE

Laundry

capacity(kg)

Water level

Water flow

Wash time

(minutes)

Detergent

amount( g)

Synthetics,

silk,Delicate

fabrics

0 –3,0

Low

Normal

About 39

3,0 –5,0

Mid

3-5

About 51

Cotton or

linen

0 –5,0

Mid

Normal

About 51

5,0 –6,5

High

7-10

About 59

Heavy soils

0 –5,0

Mid

Heavy

About 51

5,0 -6,5

High

10-35

About 59

NOTE: The dosage of washing detergent varies according to dirty degree and texture of laundries.
