Heidolph MR Hei-Standard Quick guide

M1M3_108

Safe Heating and Mixing

Translation of the original operating instructions

Operating instructions must be read before initial start-up.

Please follow the safety instructions provided.

Please keep for future reference.

Magnetic stirrer

MR Hei-Standard, MR Hei-Tec

Overview

MR Hei-Standard

Contents

Overview .................................................................................................. B

Scope of supply MR Hei-Standard ......................................................................................................................... D

Scope of supply MR Hei-Tec .....................................................................................................................................E

Key to illustrations ....................................................................................F

Applied standards and guidelines ............................................................. 1

Safety instructions.................................................................................... 1

Device description .................................................................................... 7

Storage & transport .................................................................................. 7

Unpacking the device................................................................................ 7

Installation ............................................................................................... 7

Start-up .................................................................................................... 9

Operation................................................................................................ 11

Stirring............................................................................................................................................................................11

Heating ...........................................................................................................................................................................13

Error codes ............................................................................................. 23

Maintenance ........................................................................................... 25

Cleaning.................................................................................................. 25

Disassembly ........................................................................................... 25

Disposal.................................................................................................. 25

Accessories............................................................................................. 26

Technical data ........................................................................................ 26

Warranty bond........................................................................................ 28

Contact/Technical Service ...................................................................... 28

Confirmation of condition of unit ............................................................ 29

MR Hei-Standard

Scope of supply MR Hei-Standard

Accessories (optional)

Scope of supply

MR Hei-Standard

As standard (EU): 505-20000-00 (230 V, 50/60 Hz)

For US: 505-20000-01 (115 V, 50/60 Hz)

For UK: 505-20000-02 (230 V, 50/60 Hz)

For IN: 505-20000-18 (230 V, 50/60 Hz)

Power cord

As standard (EU): 14-007-003-81 (230 V, 50/60 Hz)

For US: 14-007-045-10 (115 V, 50/60 Hz)

For UK: 14-007-005-45 (230 V, 50/60 Hz)

For IN: 14-300-009-36 (230 V, 50/60 Hz)

Operating instructions

01-005-005-39

MR Hei-Tec

Scope of s upply M R He i-Te c

Accessories (optional)

Scope of supply

MR Hei-Tec

As standard (EU): 505-30000-00 (230 V, 50/60 Hz)

For US: 505-30000-01 (115 V, 50/60 Hz)

For UK: 505-30000-02 (230 V, 50/60 Hz)

For IN: 505-30000-06 (230 V, 50/60 Hz)

Power cord

As standard (EU): 14-007-003-81 (230 V, 50/60 Hz)

For US: 14-007-045-10 (115 V, 50/60 Hz)

For UK: 14-007-005-45 (230 V, 50/60 Hz)

For IN: 14-300-009-36 (230 V, 50/60 Hz)

Operating instructions

01-005-005-39

MR Hei-Tec

Key to illustrations

MR Hei-Standard (page A, C)

1Hotplate

2Mains switch: Switch device on/off

3Speed control knob: Set set speed

4LED I/O: Device on/off

5Heating button: Switch heating function on/off

6LED light for heating function: Device heats up/does not heat up

7Temperature control knob: Set set temperature

8Drill hole for support rod with protective cap

9Temperature sensor socket

10 Power plug

11 Support rod

12 Temperature sensor Pt 1000

13 Attachment with cable inlet

MR Hei-Tec (page D, E)

1Hotplate

2Mains switch: Switch device on/off

3Control panel

4Rotary-push button Hei-GUIDE: Set and determine the set speed/set temperature

5Heating button: Switch heating function on/off and switch between Fast-/Precise-Mode

6Stirring button: Switch stirring function on/off

7Display

8set rotation: Indicates the set speed

9Stirring symbol: The device is stirring

10 Rotation speed and mode: Displays actual speed/set speed and Fast-/Precise-Mode

11 set temp: Indicates the set temperature

12 set temp ext: Indicates the set temperature and temperature control using the temperature sensor

13 ext: Indicates the temperature control using the temperature sensor

14 Heating symbol [flashing]: Is shown when heat energy is supplied

15 Temperature: Displays actual temperature/set temperature and Fast-/Precise-Mode

16 Selection frame: Highlights the pre-selected value

17 Drill hole for support rod with protective cap

18 Temperature sensor socket

19 Power plug

20 Support rod

21 Temperature sensor Pt 1000

22 Attachment with cable inlet

Applied standards and guidelines

NOTICE

EC declaration of conformity

See the "EC declaration of conformity" enclosed.

Safety instructions

WARNING

Risk of injury due to failure to observe safety signs and safety in-

structions!

Dangers emerge when safety signs, located on the device, are not ob-

served or when safety instructions detailed in the operating instructions

are not followed.

Please note the safety signs.

Please carefully read and observe the safety instructions provided.

Warning notices

The design of warning notices is based on a combination of signal words and continuous text.

In this way, the signal word indicates the level of risk. The following table explains the significance of each of

the signal words.

Signal word

Meaning

DANGER

DANGER indicates a hazardous situation which, if not avoided, will result in death or seri-

ous injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, could result in death or

serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, may result in minor or

moderate injury.

NOTICE

NOTICE indicates a property damage message

The warning notice also provides information on the type and source of the danger, the possible consequences

of the danger and measures to prevent any danger arising. The following example warning notice indicates

the design of a warning notice.

DANGER

The type and source of the danger are displayed here!

Here, the possible consequences are described when no measures are taken to prevent

dangers occurring.

Here, the measure for risk prevention is specified.

Other symbols used in these operating instructions provide information on the handling instructions. The fol-

lowing table explains the use of each symbol.

Symbol

Use

Explanation



Handling instructions

Here, you are required to take action.

Handling instructions, multi-step

The handling instructions must be carried out in the

sequence specified. Deviations from this sequence

may lead to damage to the device or accidents.

General safety instructions

The device has been constructed according to state-of-the-art technology and recognized safety regulations.

However, risks may still arise during installation, operation and maintenance.

Please observe the safety instructions and warning notices.

The safety instructions provided in this chapter are supplemented by specific warning notices in the following

chapters. This warning notice explains exactly how you must behave in order to protect yourself, others and

objects from damage.

These operating instructions are a component of the device described here.

Please ensure the operating instructions are available at all times.

Please pass on the operating instructions to the subsequent owner.

The device may only be used under the following circumstances:

The device is in full working order.

The device is used according to its intended purpose.

All operators of the device possess the necessary safety and risk awareness.

The instructions stipulated in this instruction manual are followed.

Errors must be eradicated immediately; especially those which jeopardize safety.

Intended use

The device is a magnetic stirrer with a heating function, suitable for continuous operation. The device stirs

and/or heats substances in a container. A magnetic stir bar, which is guided by a magnet, moves to adminis-

ter stirring.

A suitable operating location for the device is one of the following areas:

Chemical and biological laboratories in industry and universities

In order to use the device according to its intended use, please also observe these operating instructions, the

safety instructions and the instructions provided for cleaning (see chapter "Cleaning").

Uses not permitted

Any use which deviates from the device's intended use is considered to be improper. The manufacturer does

not accept liability for any damages resulting from non-permitted uses. The risk is carried by the operator

alone.

Do not use the device in potentially explosive areas. The device is not protected against explosion.

Do not insert any objects into the area between the hotplate, the cover plate and the base of the device.

Do not cover the ventilation slots.

Use in potentially explosive areas

Do not use the device in potentially explosive areas. The device is not protected against explosion. There

is no explosion or ATEX protection available.

Operating company’s obligations

Only operate the device in full and proper working order.

Ensure that only qualified personnel operate the device.

Ensure that the personnel has received safety instructions in order to guarantee responsible and safe work

procedures in the laboratory.

Ensure that the device is positioned in a suitable location.

Ensure that the device is sufficiently stable.

Ensure that installation and operation of the device is only carried out in facilities which are fitted with the

appropriate laboratory equipment (e.g. with air extraction units).
