Hayward XE Series User manual

XE Pump Series

SIMPLE BUTTON PROGRAMMING

SOLID LED

Daily Schedule Only

SLOW FLASHING

Override Mode Only

QUICK FLASHING

Program Mode Only

# blink indicates intervals

4 second hold

This illustration is showing TriStar®XE.

TriStar®XE | MaxFlo®XE | Super Pump®XE

QUICK START GUIDE

Button & LED location

OVERRIDE MODE

Energy Efficient Programmable

Variable Pump Speed

PRESS & HOLD

Program mode /

Save & continue

SHORT PRESS

Override mode /

Choose pump speed

STATUS LIGHT

PUSH BUTTON

3 RAPID FLASHES

Confirms press and hold

successful

To ENTER

Press once

To EXIT

Press & Hold

HIGH

3 hours

MEDIUM

3 hours

LOW

3 hours

STOP

No time limit

Press for next speed Light flashes slowly in

OVERRIDE MODE

4 second hold

230 VAC

(Default)

Ground

Jumper in

230V position

115 VAC

Ground

Jumper in

115V position

START

Hazardous Voltage: Always turn off power at the circuit breaker before wiring. The pump can be wired to

230 VAC (factory default) or 115 VAC supply. Move the jumper to the corresponding input voltage as shown.

WIRING INSTRUCTIONS

Back to Daily Schedule

Solid

For detailed information

about XE Series Pumps,

scan this QR code

QRG3200VSMD

Press & Hold Press & Hold Press & Hold Press & HoldPress one time

DEFAULT DAILY SCHEDULE

PROGRAMMING EXAMPLES

100% 80%

24 hour

1 2 3 4

4 second hold 4 second hold

100% for 24 hours

1 2 3 5

4 second hold 4 second hold

4 6

4 second hold

80% for 4 hours / 40% for 8 hours / 0% for 12 hours

HOW TO PROGRAM THE DAILY SCHEDULE

Press & Hold

until the light

blinks

Choose

pump speed

INTERVAL 2 INTERVAL 3

8 hours 12 hours

To ENTER

PROGRAM MODE

Choose

pump speed

Back to

Daily

Schedule

INTERVAL 1

4 hours

Solid

70% 50% 45% 40% 0%

4 hours 8 hours 12 hours

INTERVAL 1 INTERVAL 2 INTERVAL 3

50% Pump speed

START: POWER ON

START

50% Pump speed 50% Pump speed

50 50

CHOOSE PUMP SPEED

DAILY SCHEDULE

4 hours

8 hours

12 hours

INTERVAL 1

INTERVAL 2

INTERVAL 3

100

4 hours

8 hours

12 hours

INTERVAL 1

INTERVAL 2

INTERVAL 3

PRESS FOR NEXT SPEED

123

Save &

Continue

4 second hold

Save &

Continue

4 second hold

Choose

pump speed

Save &

Continue

4 second hold

Press

two times

Press

six times

Press

seven times

Press &

Hold

Press &

Hold

Press &

Hold

Press &

Hold

The pump will start at 100% speed for 8 minutes to prime

3x 3x 3x 3x
