SAFETY INFORMATION

READ AND SAVE THESE INSTRUCTIONS

Please read and understand this entire manual before attempting to assemble, install or operate the

product.

• Do not discard fan carton or foam inserts. Should this fan need to be returned to the factory for

repairs, it must be shipped in its original packaging to ensure proper protection against damage

that might exceed the initial cause for return.

• Make sure that all electrical connections comply with local codes, ordinances, the National

Electrical Code and ANSI/NFPA 70-1999. Hire a qualified electrician or consult a do-it-yourself

wiring handbook (available at Lowe's) if you are unfamiliar with installing electrical wiring.

• Make sure the installation site you choose allows a minimum clearance of 7 ft. from the blades to

the floor and at least 30 in. from the end of the blades to any obstruction.

• After you install the fan, make sure that all connections are secure to prevent the fan from falling.

• The net weight of this fan including the light kit is: 12.72 lbs. (5.77 kg).

SAFETY INFORMATION

To reduce the risk of fire, electrical shock, or personal injury, mount fan to outlet box

marked "ACCEPTABLE FOR FAN SUPPORT OF 35 LBS. (15.9 KG) OR LESS" and use

mounting screws provided with the outlet box. Most outlet boxes commonly used for the

support of lighting fixtures are not acceptable for fan support and may need to be replaced.

Consult a qualified electrician if in doubt.

When mounting fan to a ceiling outlet box, use a METAL octagonal outlet box. Secure the outlet

box directly to the building structure. The outlet box and its support must be able to support the

moving weight of the fan (at least 35 lbs.). Do NOT use a plastic outlet box.

To avoid personal injury, the use of gloves may be necessary while handling fan parts with

sharp edges.

To reduce the risk of fire, electrical shock, or personal injury, wire connectors provided with this

fan are designed to accept only one 12-gauge house wire and two lead wires from the fan. If your

house wire is larger than 12-gauge or there is more than one house wire to connect to the

corresponding fan lead wires, consult an electrician for the proper size wire connectors to use.

To reduce the risk of fire or electrical shock, do not use the fan with any solid state speed

control device or control fan speed with a full range dimmer switch.

To reduce the risk of fire, electrical shock, or personal injury, do not bend the blade arms when

installing them, balancing the blades, or cleaning the fan. Do not insert objects between the

rotating fan blades.

To reduce the risk of personal injury, use only parts provided with this fan. The use of parts

OTHER than those provided with this fan will void the warranty.

WARNINGS

CAUTIONS

Before proceeding, be sure to shut off electricity at main switch or circuit breaker in order to avoid

electrical shock.

Read all instructions and safety information before installing your new fan. Review the

accompanying assembly diagrams.

3Lowes.com/harborbreeze

PACKAGE CONTENTS

Lowes.com/harborbreeze

Mounting Bracket 1

Motor Housing

Motor Assembly

Light Kit Fitter

Glass Shade

Pull Chain Extension

Blade

H Finial Plate

(preassembled)

I Finial (preassembled)

Blade Arm

Cap

L Plastic Lock Tab

M Bulb

DESCRIPTIONPART QUANTITY

Motor Screw

(preassembled)

+ 1 extra

O 5.4 mm Lock Washer 10

(preassembled)

+ 1 extra

P Hex Nut (preassembled)

Q Lock Washer

(preassembled)

Mounting Bracket Screw

(preassembled)

Star Washer

(preassembled)

T Rubber Washer

(preassembled)

Switch Housing Cap

Screw (preassembled)

DESCRIPTIONPART QUANTITY

IMPORTANT REMINDER: You must use the

parts provided with this fan for proper installation

and safety.

Before beginning assembly of product, make sure all parts are present. Compare parts with package

contents list and hardware contents list. If any part is missing or damaged, do not attempt to

assemble the product.

Estimated Assembly Time: 120 minutes

Tools Required for Assembly (not included): Electrical Tape, Phillips Screwdriver, Pliers, Safety

Glasses, Stepladder and Wire Strippers

Helpful Tools (not included): AC Tester Light, Tape Measure, Do-It-Yourself Wiring Handbook and

Wire Cutters

Bulbs Required (included): 3 candelabra-base 40-watt max. bulbs

DANGER: When using an existing outlet box, make sure the outlet box is securely attached to

the building structure and can support the full weight of the fan. Failure to do this can result in serious

injury or death. The stability of the outlet box is essential in minimizing wobble and noise in the fan

after installation is complete.

CAUTION: Be sure outlet box is properly grounded and that a ground wire (green or bare) is

present.

After opening top of carton, remove mounting hardware package from foam inserts. Remove motor

from packing and place on carpet or on foam to avoid damage to ﬁnish.

CAUTION: Carefully check all screws, bolts and nuts on fan motor assembly to ensure that they

are secured.

HARDWARE CONTENTS (shown actual size)

PREPARATION

Lowes.com/harborbreeze

Blade

Screw

Qty. 15

+ 1 extra

E3 Wire

Connector

Qty. 4

Fiber

Blade

Washer

Qty. 15

+ 1 extra

Turn off circuit breakers and wall switch to the fan

supply line leads.

DANGER: Failure to disconnect power supply

prior to installation may result in serious injury or

death.

Secure mounting bracket (A) to outlet box using

screws, spring washers, and flat washers provided

with the outlet box. Pull wires from outlet box

through center hole in mounting bracket (A).

*NOTE: It is very important that you use the proper

hardware when installing the mounting bracket (A)

as this will support the fan.

Check to make sure blades (G) are at least 30 in.

from any obstruction and at least 7 ft. above the

floor.

INITIAL INSTALLATION

OFF

Lowes.com/harborbreeze

7 ft.

min.

30 in.

min.

Remove motor screws (N) and 5.4 mm lock

washers (O) from underside of motor and save for

blade arm (J) attachment later on. [If there are

plastic motor blocks installed with the motor

screws (N) and 5.4 mm lock washers (O), discard

the plastic motor blocks.]

To ensure the safety of the installation and to

prevent the motor assembly (C) from becoming or

coming loose, use the plastic lock tab (L). Slide

plastic lock tab (L) under bracket tabs so that it

will snap into place.

IMPORTANT: Keep in mind that it will require

some force to fully insert the plastic lock tab

(L) so that it does not move or come out once

in the correct position.

INITIAL INSTALLATION

Lowes.com/harborbreeze

Motor

Install ball end of motor assembly (C) into

mounting bracket (A) opening. Align slot in ball

with tab in mounting bracket (A).

DANGER: Failure to align slot in ball with tab

in mounting bracket (A) may result in serious

injury or death. Tab

Bracket

Tab

Ball

Slot

WIRING

8Lowes.com/harborbreeze

WARNING: To reduce the risk of fire, electrical

shock, or personal injury, wire connectors provided

with this fan are designed to accept only one

12-gauge house wire and two lead wires from the

fan. If your house wire is larger than 12-gauge or

there is more than one house wire to connect to the

corresponding fan lead wires, consult an electrician

for the proper size wire connectors to use.

CAUTION: Be sure outlet box is properly

grounded and that a ground (green or bare) wire is

present.

WARNING: If house wires are different colors

than referred to in the following steps, stop

immediately. A professional electrician is

recommended to determine wiring.

Choose wiring diagram (Fig. 1A, Fig. 1B or Fig. 1C)

that fits your situation and make appropriate wiring

connections as follows: [NOTE: For each wire

connection below, use one of the wire connectors

(CC) provided, making sure to screw wire connector

(CC) on in a clockwise direction.]

1A. FAN AND LIGHT CONTROLLED BY PULL

CHAINS: Connect BLACK and BLUE wire from

fan to BLACK wire from ceiling. Connect WHITE

wire from fan to WHITE wire from ceiling. Connect

all GROUND (GREEN) wires together from fan

(on motor assembly (C) and mounting bracket (A))

to BARE/GREEN wire from ceiling. (Fig. 1A)

1B. FAN CONTROLLED BY PULL CHAIN,

LIGHT BY WALL SWITCH: If you intend to

control the fan light with a separate wall switch,

connect BLACK wire from fan to BLACK wire

from ceiling. Connect BLUE wire from fan to the

BLACK wire from the independent wall switch for

the light. Connect WHITE wire from fan to WHITE

wire from ceiling. Connect all GROUND (GREEN)

wires together from fan (on motor assembly (C)

and mounting bracket (A)) to BARE/GREEN wire

from ceiling. (Fig. 1B)

FAN AND LIGHT CONTROLLED BY PULL CHAINS

BLACK

WHITE

GROUND/GREEN (BARE)

WHITE

BLUE

WHITE

FROM FAN

120 V Power

FROM

CEILING

GREEN

BLACK

GREEN

FAN

FAN CONTROLLED BY PULL CHAIN, LIGHT BY WALL SWITCH

WHITE

BLACK

BLACK (WALL SWITCH)

GROUND/GREEN (BARE)

BLACK BLUE

WHITE

FROM FAN

120 V Power

FROM

CEILING

GREEN

WHITE

GREEN

FAN

9Lowes.com/harborbreeze

NOTE: Black wire is hot power for fan. Blue wire is

hot power for light kit. White wire is common for fan

and light kit. Green or bare wire is ground.

WIRING

1C. FAN AND LIGHT CONTROLLED BY TWO

WALL SWITCHES: If you intend to control the fan

and light with separate wall switches, connect

BLACK wire from fan to BLACK wire from the

independent wall switch for the fan. Connect

BLUE wire from fan to the BLACK wire from the

other independent wall switch for the light.

Connect WHITE wire from fan to WHITE wire

from ceiling. Connect all GROUND (GREEN)

wires together from fan (on motor assembly (C)

and mounting bracket (A)) to BARE/GREEN wire

from ceiling. (Fig. 1C)

Wrap electrical tape (not included) around each

individual wire connector (CC) down to the wire.

WARNING: Make sure no bare wire or wire

strands are visible after making connections. Place

green and white connections on opposite side of

box from the black and blue (if applicable)

connections.

Turn spliced/taped wires upward and gently push

wires and wire connectors (CC) into outlet box.

FAN AND LIGHT CONTROLLED BY TWO WALL SWITCHES

WHITE

BLACK (WALL SWITCH)

(WALL SWITCH FOR LIGHT)

GROUND/GREEN (BARE)

BLACK BLUE

WHITE

FROM FAN

120 V Power

FROM

CEILING

GREEN

WHITE

GREEN

FAN

BLACK

Hardware Used

E3 Wire Connector x 4

WIRING

10 Lowes.com/harborbreeze

IMPORTANT: Using a full range dimmer

switch (not included) to control fan speed will

cause a loud humming noise from fan. To

reduce the risk of fire or electrical shock, do

NOT use a full range dimmer switch to control

fan speed.

3. 3

Dimmer

Switch Speed

Switch

For illustrative purposes only--not

intended to cover all types of controls

FINAL INSTALLATION

1. Temporarily raise motor housing (B) to

mounting bracket (A) to determine which two

mounting bracket screws (R) align with slotted

holes in motor housing (B) and partially loosen

these two mounting bracket screws (R).

Remove the other two mounting bracket screws

(R) and star washers (S). Now, lift motor

housing (B) to mounting bracket (A) again,

aligning slotted holes in motor housing (B) with

loosened mounting bracket screws (R) in

mounting bracket (A). Twist motor housing (B)

to lock. Re-insert mounting bracket screws (R),

along with star washers (S), that were

previously removed. Tighten all four mounting

bracket screws (R) securely.

2. Partially insert three blade screws (AA), along

with three fiber blade washers (BB), into holes

in blade (G) to attach blade arm (J) to blade

(G). Then, tighten each blade screw (AA)

starting with the one in the middle.

Repeat Step 2 with remaining blades (G).

Hardware Used

Blade Screw x 15

Fiber Blade Washer x 15

Other manuals for BTH44ABZC5C

This manual suits for next models

Table of contents

Other Harbor Breeze Fan manuals

Harbor Breeze

Harbor Breeze PRESTWICK 42868 User manual

Harbor Breeze

Harbor Breeze TIEMPO E-TM52BNK5CS User manual

Harbor Breeze

Harbor Breeze 00887 User manual

Harbor Breeze

Harbor Breeze MZ44WW3LR User manual

Harbor Breeze

Harbor Breeze 41161 User manual

Harbor Breeze

Harbor Breeze Teolo User manual

Harbor Breeze

Harbor Breeze CENTREVILLE 40117 User manual

Harbor Breeze

Harbor Breeze 40837 User manual

Harbor Breeze

Harbor Breeze E-TM52BNK5LED User manual

Harbor Breeze

Harbor Breeze OCEANSIDE User manual

Harbor Breeze

Harbor Breeze LANDON LAN52SS5L User manual

Harbor Breeze

Harbor Breeze NAVIN 41555 User manual

Harbor Breeze

Harbor Breeze JP18EB3 User manual

Harbor Breeze

Harbor Breeze RLG52NWZ5L User manual

Harbor Breeze

Harbor Breeze LP8210LAZ User manual

Harbor Breeze

Harbor Breeze BTH44ABZC5C User manual

Harbor Breeze

Harbor Breeze TALAMORE TAL60MBK8LR User manual

Harbor Breeze

Harbor Breeze BRADBURY BRD48BNK6LR User manual

Harbor Breeze

Harbor Breeze MARINA COVE II User manual

Harbor Breeze

Harbor Breeze ECHOLAKE 00876 User manual

Harbor Breeze

Harbor Breeze LANSING 40198 User manual

Harbor Breeze

Harbor Breeze 40945 User manual

Harbor Breeze

Harbor Breeze WCK52NWZ5D User manual

Harbor Breeze

Harbor Breeze E-BDB52ABZC5BC4N User manual

Popular Fan manuals by other brands

ELTA FANS

ELTA FANS H03VV-F installation guide

Hunter

Hunter 20714 Owner's guide and installation manual

Emerson

Emerson CARRERA VERANDA CF542ORB00 owner's manual

Hunter

Hunter Caraway Owner's guide and installation manual

Panasonic

Panasonic FV-15NLFS1 Service manual

Kompernass

Kompernass KH 1150 operating instructions

VES

VES FALA100/12V/TR Original instructions

Vertiv

Vertiv Liebert DCD user manual

Westinghouse

Westinghouse GFP Series owner's manual

Venmar

Venmar KUBIX HRV PLUS Series user guide

Maico

Maico ECR 31 installation instructions

Sonnenkonig

Sonnenkonig Dinky instruction manual

S&P

S&P ECOWATT HXBR manual

Wider

Wider IMP03369BH instruction manual

Panasonic

Panasonic F-60DHN Operating and installation instructions

Hinkley

Hinkley HIGHLAND instruction manual

Broan

Broan 766BN installation guide

Premium

Premium PFS16022 Use manual
