Haier HWM110-401S User manual

Names of the parts

Meaning and description of the symbols

Warning sign

Forbidding sign

Contents marked with that symbol are related to the safety of the product and

the personal safety of the users. Please operate in strict conformity to the

contents, otherwise it may cause damage of the machine or injure the personal

safety of the user.

Contents marked with that symbol are actions forbidden to perform. Performing

of those actions may result in damage of the machine or injure the personal

safety of the user.

Please understand theshapes of thewashing machine andaccessories may bedifferent

from the sketchfigures in thismanual due toproduct improvement.

1

Out tub cover

ÄÚ²¿¹¹ÔìºÍ²¿¼þÃû³Æ

Detergent box

Handle

Top lid component

Filter frame

Lint filter

Inner tub

Pulsater

Cabinet

Adjustable leg

Adjustable leg film

Base frame

Power cord

Drain hose

Back cover

Water inlet valve

Water absorption

(3 pieces)

Fixed leg

Control pannel

Liquid detergent inlet

Panel

Hook

Screw cover
