User Manual

Washing Machine

Cotton Daily Wash

Ultra White

Express 15'

Baby Care

Delicate

Hand Wash

Spin/Drain

Self Clean

Synthetic

Mix

Wool

Under-

wear

Sport

Jeans

Hygienic

°C

Yes

General information and tips

Warning! Important safety information!

Environmental information

The presence of this symbol on the product,

accessories or materials that goes with this in-

formation indicates that at the end of its useful

life the product or its electronic accessories

(e.g. cable, Aqua Stop hose) should not be dis-

posed with other household waste. To prevent

possible damage to the environment or human

health from uncontrolled waste disposal, please

separate these items from other types of was-

te and recycle them.This will promote the sus-

tainable reuse of material resources. Household

users should contact either the retailer where

they purchased the product or relevant local

authorities to ﬁnd out how they can take this

item for environmentally safe recycling and safety.

Business users should contact their supplier and

check the conditions of the purchase. This pro-

duct and its electronic accessories should not

be mixed with other commercial waste.

Disposal

Legend

Thank you for purchasing a Haier product

Please read these instructions carefully before using this appliance. It contains impor-

tant information which will help you get the best out of your appliance and ensure safe

and proper installation, use, care and cleaning.

Keep this manual in a convenient place so you can always refer to it for safe and

proper use.

If you sell the appliance, give it away, or leave it behind when you move, make sure you

also pass on this manual so that the new owner can become familiar with all features

and safety warnings.

3Index

Safety........................................................................................... 4-5

Product description....................................................................... 6

Control panel.............................................................................. 7-9

Programmes................................................................................. 10

Consumption................................................................................ 11

Daily use...................................................................................12-15

Care and cleaning.................................................................. 16-18

Troubleshooting...................................................................... 19-21

Installation............................................................................... 22-24

Technical data ............................................................................. 25

After sales service....................................................................... 26

Safety

Before switching on the appliance for

the ﬁrst time...

...make sure all transport bolts are removed.

...make sure the power cord is not caught under or in

the appliance and there is no damage or risk for damaging.

...make sure the power circuit fuse is rated for15A.

...use a separate earthed socket for the power supply.

...make sure the plug is always accessible.

...hold the plug and not the electric cable when unplugging

the power supply.

...check that hose joints and connections are ﬁrm and

by opening tap check for any waterleakage.

...do not switch on the appliance until everything is properly

installed!

Do not …

...allow children or inﬁrm persons to play with the appliance

or packing materials.

...install the appliance outdoors in a damp place, or in an

area which may be prone to water leaks such as under

or near a sink unit. In the event of a water leak cut power

supply and allow the machine to dry naturally.

...expose machine to any frost, heat or direct sunlight.

...touch or use the appliance when barefoot or with wet or

damp hands or feet.

...use ﬂammable detergent or dry cleaning agent.

...use any ﬂammable sprays in close vicinity to the appliance.

...remove or insert the plug in presence of ﬂammable gas.

...place the appliance directly on a carpet, or close to

a wall or furniture.

5Safety

During daily use of the appliance...

...supervise children.

Ensure that they don’t play with the appliance and its packaging.

...ensure that appliance is not used by people with

reduced physical, sensory or mental capabilities, lack of

experience and knowledge.

...pull up zips, ﬁx loose threads and take care for small items

to prevent laundry from being entangled. If necessary, use

an appropriate bag or net.

...switch off at the wall socket after each wash programme

to save electricity and for safety.

...keep the lower part of the porthole clean and open door

and detergent drawer if appliance is not in use to prevent

odours.

...a damaged power cord is only to be replaced by the

manufacturer, his service agent or other speciﬁcally

qualiﬁed people.

Do not ...

...touch the door during the washing process, it gets hot.

...place heavy objects or sources of heat or damp on top of

the appliance.

...hot wash from rubber or sponge-like materials.

...open detergent drawer during any wash cycle.

...force the door to open, it is ﬁtted with a self-lock

device and will open shortly after wash cycle end.

...open the door if the water level is visibly over the

porthole.

...cover or encase the appliance during operation or after

wards to allow any moisture or dampness to evaporate.

Product description

1 Detergent / Softener drawer

2 Door

3 Worktop

4 Door handle

5 Control panel

6 On/Off

7 Service ﬂap

1 Transportation bolts (T1-T4)

2 Back cover

3 Back cover screws (S1-S4)

4 Power cord

5 Water inlet valve

6 Drain hose

Accessories

1x Inlet hose

assembly 4x Blanking

plugs 1x Drain hose

bracket 1x User manual

This drawing may be slightly different from the layout of the washing machine you have just purchased.

Check the accessories and literature in accordance with this list.

7Control panel

1Detergent / Softener drawer

2Display

3Programme selector

4“Start/Pause“ button

5“On/Off“ button

6Function button (a-f)

a Function

b Selection

c.Temperature

d. Spin Speed (rpm)

e. Memo

f. Delay (Start time)

Detergent drawer

Open the drawer, three compartments can be seen:

Compartment 1: Water inlet only, no detergent

Compartment 2: Detergent for program

Compartment 3: Softener, Conditioning agent etc.

Display

If the appliance is on display will light up the actual status on six different sections (see

next pages). During operation display will be deactivated after a while (Energy saving

mode) until programme selector is turned at random.

Programme selector

By turning the knob one of 16 programmes can be selected, related LED will light up

its default settings will be displayed.

“Start/Pause” button

Press this button gently to start or interrupt the currently displayed programme. During

operation its symbol is shining, or if interrupted blinking.

“On/Off” button

Touch this button gently to switch on, the display is shining.Touch it again for about

2 seconds to switch off. If no panel element or programme is activated after a while

machine will shut down automatically.

િૺ

כ࡮

அ䥉䂫ࡥ

1400

Љ䟝ٴ

400

600

800

1000

1200

ٯ࢓

70 ௄঳ޞ୿Ӿѿޞ୿

Ԇବ࡮

૝Ӕ࡮

Ԇ䈒࡮

௤ࡊѹ

123

Rinse

Anti crease

Speed up

Intense

Soak

Temp.

M emo

Function Selection Spin Delay

a-f

12 3 4 5

T1 T2

S2 S4

િૺ

כ࡮

அ䥉䂫ࡥ

1400

Љ䟝ٴ

400

600

800

1000

1200

ٯ࢓

70 ௄঳ޞ୿Ӿѿޞ୿

Ԇବ࡮

૝Ӕ࡮

Ԇ䈒࡮

௤ࡊѹ

123

Rinse

Anticrease

Speedup

Intense

Soak

Temp.

Memo

Function Selection Spin Delay

156

2 3 4

The recommendation on the type of detergents is suitable for the various washing temperatu-

res, please refer to the manual of detergent.

°C

Cotton DailyWash

UltraWhite

Express15'

BabyCare

Delicate

HandWash

Spin/Drain

SelfClean

Synthetic

Mix

Wool

Under-

wear

Sport

Jeans

Hygienic

Cotton Daily Wash

Ultra White

Express 15'

Baby Care

Delicate

Hand Wash

Spin/Drain

Self Clean

Synthetic

Mix

Wool

Under-

wear

Sport

Jeans

Hygienic

°C



Control panel - function buttons

“Selection“ (button b)

 

 

!"!# 

$%



“Child lock“ - control panel lock function

(button a + b)

""#

"&'

(!")*"



“Temperature“ (button c)

" *!"



“Spin Speed” (button d)

""

"+!" 



,"-

""

#$"%

.function buttons - Control panel

“Memo” (button e)

/"

!

0"*

#

“Delay“ – Start time delay (button f)

"" 1

1234

!"5"  !

-"!

"4!

 5 4! )"

 $"%   

   

 6" 4 )"

  



 )!"" 4" 7

  



 5" " 5

  $%

 

  4"$%



  4$%

Rinse

Anti crease

Speed up

Intense

Soak

TempFunction Selection

Temp.

M em

election

Spin Speed

M emo

pin Speed

Delay

Display symbols

Basic status indication Programme cycle Programme settings

indication

General information and tips:

To cancel any actual setting change programme or press

”On/Off” about 3 seconds.To cancel a running program-

me touch “Start/Pause“ and then ”On/Off” for about 3

seconds.

“Function“(button a)

Touch it to select sequentially required functions and set-

tings.The related function name and setting will shine.

- “Speed up“:Saves time and energy.Preferable if laundry

is slightly soiled.

- “Intense“:Intensiﬁes cleaning results.Preferable if laundry

is heavily soiled.

- “Soak“:Laundry will remain in last rinse cycle water.

- “Signal“:Activates the signal tone mode.

- “Rinse+“:Adds 1-3 rinse cycles.Preferable to better ﬂush

out possible residues

Note: Display of “ “ stands for “no operational heating“.

Note: Display of “ “ stands for “no operational spinning“.

1110 ConsumptionProgrammes

1 Cotton 0-90°C 40°C Cotton /Synth 1200 rpm

2 Synthetic 0-60°C 30°C Chemical 1000 rpm

ﬁbre fabrics

3 Mix 0-60°C 40°C Cotton /Synth.1000 rpm

4 Wool 0-40°C --- Woolen 600 rpm

fabrics

5 Underwear 0-60°C 40°C Underwear 1000 rpm

6 Sport 0-40°C 30°C Sports Wear 1000 rpm

7 Jeans 0-60°C 40°C Jeans 1000 rpm

8 Hygienic 0-90°C 90°C Cotton /Synth.1000 rpm

9 Daily Wash 0-40°C 40°C Cotton fabrics 1000 rpm

10 Ultra White 0-60°C 40°C Cotton /Synth 1000 rpm

11 Express 15 0-30°C 20°C Cotton /Synth 1000 rpm

12 Baby Care 0-90°C 90°C Cotton /Synth 1000 rpm

13 Delicate 0-40°C 30°C Silk or wool 600 rpm

14 Hand Wash 0-40°C 30°C Cotton fabrics 800 rpm

15 Spin/Drain --- --- --- 1200 rpm

16 Self Clean 90°C 90°C --- 1000 rpm

Programme Temp.Preset Fibre Type Preset

Max.Spin Speed

Programme table

OptionalYes No

*General information and tips:

Standard programme for the Energy Labelling according to

2010/30EU:

Cotton 60°C/40°C with max.spin speed setting and activated

intensive function

The standard 60°C and 40°C cotton programmes are suitable to clean

normally soiled cotton laundry.They are the most efﬁcient programmes in

terms of combined energy and water consumption for cotton laundry.Used

water temperature may differ from declared cycle temperature.

140

CDEFG

kWh/annum

9240

HW70-B14266

7,0

2010/1061

A+++

A++

+++

ENERG

ENER · N P EIA

ENERGIJA·ENERGY·ENERGIE

ENERGI

L/annum

1 Water inlet only, no detergent

2 Detergent compartment

3 Softener compartment

Programme Energy Water Washing

time Spin drying

performance

Temp.

Max.load

kg kWh L°C h:min%

Hygenic 2 2,00 36,0 90 2:03 ---

Jeans 4 0,56 40,0 40 1:27 ---

Sport 2 0,26 35,0 30 0:47 ---

Underwear 4 0,50 40,0 40 1:01 ---

Wool 1 0,10 50,0 --- 0:37 ---

Mix 4 0,56 34,0 40 Auto ---

Synthetic 4 0,25 46,0 30 Auto ---

Cotton 40* 3,5 0,48 30,0 40 Auto <53

Cotton 60* 3,5 0,66 31,0 60 Auto <53

Cotton 60* 7 0,65 39,0 60 Auto <53

Daily Wash 4 0,58 46,0 40 1:20 ---

Ultra White 2 0,60 45,0 40 1:25 ---

Express 15’ 1 0,20 20,0 20 0:15 ---

Baby Care 4 2,00 67,5 90 2:03 ---

Delicate 1 0,25 50,0 30 0:46 ---

Hand Wash 2 0,25 36,0 30 0:48 ---

Spin/Drain 7 0,10 --- --- 0:10 ---

Self Clean --- 1,80 15,0 90 1:20 ---

The indicated consumption values may differ in addiction of local conditions.

2 3 1

1312 Daily useDaily use

Power supply

Connect the washing machine to the power supply (220V to

240V~/50Hz).

Water connection

Turn on the tap.The water must be clean and clear.

Warning!

Before use, turn tap on and check for any leackage.

Preparing laundry

Sort out clothes according to fabric (cotton, synthetics, wool

or silk) and to how dirty they are.

Separate white clothes from coloured ones.Wash coloured

textiles ﬁrst by hand to check if they fade or run.

Garments without hems, delicates and ﬁnely woven textile

such as ﬁne curtains are to be put into a wash bag to care

this delicate laundry (hand or dry cleaning would be better).

Close zippers and hooks, make sure the buttons are sewn

on tightly and place small items such as socks, belts, bras, etc.

in a wash bag.

Unfold large pieces of fabric such as bed sheets, bedspreads

etc.Turn clothes inside out. Empty pockets (keys, coins, etc.)

and remove harder decorative objects (e.g. brooches).

Warning!

Non-textile, as well as small, loose or sharp-edged items may cause

malfunctions and damage of clothes and appliance.

This appliance is only for domestic use inside the house. If it is used for commercial,

industrial or not intended purposes any Haier guarantee will not be valid anymore.

Consider anytime instructions of each garment label and wash only machine-washable

laundry.

Loading the appliance

Open the door and put in the laundry piece by piece.

Close the door carefully. Don‘t overload. Check if you can

put a hand upright on top of load.

General information and tips:

After each installation or longer down time run at ﬁrst

programme “Self Clean“with no load and added deter-

gent in washing agent compartment (2) to remove possib-

ly corruptive residues.

Selecting detergent

Washing efﬁciency and performance is determined by

used detergent quality. Use only machine wash approved

detergent and if needed speciﬁc detergents, e.g. for synthe-

tic and woolen fabric. Mind always detergent manufacturer

recommendations.

General information and tips:

Remove detergent residues before next wash cycle.

Please follow given detergent dosage recommendation

from detergent package. Using “Prewash“add half of the

nominal dosage.

Adding detergent

Slide out the detergent drawer and put the required che-

micals into corresponding compartments. Push back the

drawer gently.

િૺ

כ࡮

அ䥉䂫ࡥ

1400

Љ䟝ٴ

400

600

800

1000

1200

ٯ࢓

70 ௄঳ޞ୿Ӿѿޞ୿

Ԇବ࡮

૝Ӕ࡮

Ԇ䈒࡮

௤ࡊѹ

123

Rinse

Anticrease

Speedup

Intense

Soak

Temp.

Memo

FunctionSelection Spin Delay

Express15'

BabyCare

Mix

Sport

Jeans

SelfClean

Spin/Drain

HandWash

DelicateUnderwear

UltraWhite

Wool

DailyWash

Hygienic

Synthetic

CottonM

Please note instructions

on the drawer!

1514 Daily useDaily use

Select a programme

To get the best washing results, select a programme which

ﬁts the degree of soiling and sort of laundry type. Please

turn the programme knob to select the right programme.

Select options

Select required options (refer to “Control Panel“).

Start wash programme

Touch “Start/Pause“ button to start.Appliance operates

according to present settings. Changes are only possible by

cancelling wash programme. At programme cycle end “End“

is displayed, afterwards machine will shut off automatically.

Interrupt - cancel wash programme

To interrupt a running programme press gently “Start/Pause“

button. Press it again to resume operation.

To cancel a running programme and all its individual set-

tings activate “Start/Pause“ and then “On/Off“ for about 3

seconds.

General information and tips:

Choose programme settings carefully refering to icons on

each laundry label and “Care chart“.

Removing laundry promptly at cycle end will be gently and

minimize wrinkling.

After washing

Turn off the water supply and unplug the power cord.

Open the door to prevent formation of moisture and

odours. Let it open while not used.

Care chart

Maximum washing Maximum washing Maximum washing

temperature 90°C - temperature 60°C - temperature 60°C

normal process normal process mild process

Maximum washing Maximum washing Maximum washing

temperature 40°C - temperature 40°C - temperature 40°C -

normal process mild process very mild process

Maximum washing Maximum washing Maximum washing

temperature 30°C - temperature 30°C - temperature 30°C -

normal process mild process very mild process

Wash by hand Do not wash

max. temp. 40° C

Any bleaching agent Only oxygen / Do not bleach

allowed non-chlorine

bleach allowed

Tumble drying possible Tumble drying possible Do not tumble dry

normal temperature lower temperature

Line drying Flat drying

Iron at a maximum Iron at a maximum Iron at a maximum

sole-plate temperature sole-plate temperature sole-plate temperature

of 200°C of 150°C of 110°C

without steam

Do not iron (steam ironing may cause

irreversible damage)

Professional dry cleaning Professional dry cleaning Do not dry clean

in tetrachloroethene in hydrocarbons

Professional Do not professional

wet clean wet clean

Washing Process

Bleaching Process

Tumble Drying Process

Ironing Process

Professional Textile Care Process

Rinse

Anti crease

Speed up

Intense

Soak

Temp.

M emo

Function Selection

Spin Speed

Delay

Cotton Daily Wash

Ultra White

Express 15'

Baby Care

Delicate

Hand Wash

Spin/Drain

Self Clean

Synthetic

Mix

Wool

Under-

wear

Sport

Jeans

Hygienic

Cotton Daily Wash

Ultra White

Express 15'

Baby Care

Delicate

Hand Wash

Spin/Drain

Self Clean

Synthetic

Mix

Wool

Under-

wear

Sport

Jeans

Hygienic

Cotton Daily Wash

Ultra White

Express 15'

Baby Care

Delicate

Hand Wash

Spin/Drain

Self Clean

Synthetic

Mix

Wool

Under-

wear

Sport

Jeans

Hygienic

°C

1716 Care and cleaningCare and cleaning

Cleaning the detergent drawer

Clean the drawer from detergent residues regularly Pull out

the drawer until it stops (1) and press the release button (2)

to remove the drawer.Then ﬂush the drawer with water

until it is clean and insert the drawer back in the appliance.

Cleaning the machine

Unplug the machine during cleaning and maintenace. Use a

soft cloth with soap liquid to clean the machine case and

rubber components. Do not use organic chemicals or corro-

sive solvents.

General information and tips:

After each installation or longer downtime run at ﬁrst pro-

gramme “Self Clean“with no load and added detergent

in washing agent compartment (2) to remove possibly

corruptive residues.

Environmental information

To achieve best use of energy, water, detergent and time

you should use the recommended maximum load size.

Do not exceed indicated chemical dosages.

Choose always lowest washing temperature.

Modern detergents are cleaning efﬁciently below 60°C.

Only due to heavy soil raise accordingly default settings.

Using afterwards a domestic dryer max. spinning speed is

recommended.

Pump ﬁlter

Please check the pump ﬁlter for instance if the appliance

- doesn´t drain the water,

- doesn´t spin,

- cause unusual noise while running.

Warning!

Scalding Risk! Water in the pump ﬁlter can be very hot! Before any

action please ensure water has cooled down.

1. Turn off and unplug the machine.

2. Open service ﬂap.You can either use a coin or a

screwdriver.

3. Provide a ﬂat container to catch leach water.

There could be bigger amounts!

4. Pull the drainhose out and hold its end above the

container.

5. Take the sealing plug out of the drainhose.

6. After complete drainage, unscrew and remove counter

clockwise the pump ﬁlter.

7. Remove contaminants and dirt.

8. Clean carefully pump ﬁ lter, e.g. using running water.

9. Reﬁx it thoroughly.

10. Close drainhose and push it back into the machine.

11. Close service ﬂap

Warning!

Pump ﬁlter sealing has to be clean and unhurt.

If the lid is not full tightened, water can escape.

િૺ

כ࡮

அ䥉䂫ࡥ

1400

Љ䟝ٴ

400

600

800

1000

1200

ٯ࢓

70 ௄঳ޞ୿Ӿѿޞ୿

Ԇବ࡮

૝Ӕ࡮

Ԇ䈒࡮

௤ࡊѹ

123

Rinse

Anticrease

Speedup

Intense

Soak

Temp.

Memo

FunctionSelection Spin Delay

Express15'

BabyCare

Mix

Sport

Jeans

SelfClean

Spin/Drain

HandWash

DelicateUnderwear

UltraWhite

Wool

DailyWash

Hygienic

Synthetic

CottonM

. TroubleshootingCare and cleaning

Water inlet valve and inlet valve filter

"#!""

## 

Period of disuse

,""""

"$%!""$%

8""#

9"!



:*"!!

7#""

!

Display code

  0"

      "

;2 4!   4

.; 1 4!   <

9 5    0"

< <!

< 5!  6"" 

 !=  6

      ""

< 9    '""

  "  6#

<3 0# 7""

 5"  !"

      6

3 +$""% 6#

> 7    6#

< 0"##   !

#

 0#!    6"

      6#

 0#   6#

6 <   6#

? ?  6"!""6



      ""

Warning!

   





Code Cause Solution

+

%

Other manuals for HW70-B14266

Table of contents

Languages:

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Electrolux

Electrolux EWF1284EDW Service manual

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide
