Matters Needing Attention
Safety
1. A separate earthed socket is required for the
power supply. The socket should be reachable
by the power cable of the machine.
2. Hold the plug and not the electric cable
when unplugging the washing machine.
3. Fuses in the power circuit should be rated for
15A. Refer to a washing machine technician or a
Haier designated service point for power cable
replacement.
4. Do not touch or use the washing machine
bare-footed or when the hands or feet are wet.
5. Do not use flammable detergent or dry cleaning
agent; do not use flammable spray in close vicinity
to the washing machine; do not remove or insert
the plug in the presence of flammable gas.
6. The door of the washing machine will become
hot during the heating process. Avoid contact with
the door during the heating process. For safety,
keep children away from the washing machine.
7. The machine is not intended for use by young children or infirm persons without supervised.
Keep children away from the packing materials after unpacked.Young children should be
supervised to ensure that they do not play with the appliance.
ʎ
Matters Needing Attention
8. The washing machine should not be installed
outdoors or in a damp place. In the event of
water leakage or splashes allow the machine to
dry naturally.
9. Do not place the washing machine directly
on a carpet, or close to a wall or furniture.
10. Keep away from heat sources and direct
sunlight to prevent plastic and rubber components
from aging.Use the new hose and the old hose
should not be reused.
11. During installation, ensure that the electric
cable is not trapped by the washing machine and
avoid damage to the electric cable. For built-in
appliance, the socket should be kept far away
from the solenoid valve.
During Use
1. Before use, check the joints of the filling hose,
the tap and the drainage hose for possible
problems from water pressure fluctuations. If
joints are loose or there is leakage, turn off the
tap and repair. Do not use the washing machine
until the hoses are properly fixed.
2. To select a washing program, turn the knob
clockwise after the power is switched off.
When you close the door, please hold the
handle and lightly push the porthole shut.
Never force to close the door.
If the appliance is supplied from a cord
extension set or electrical portable
outlet device the cord extension
set or electrical portable outlet
device should be positioned to
splashing or ingress of moisture.
Matters Needing Attention
3. Do not place heavy, heating source or wet
articles on the top of the washing machine.
4. Do not hot wash foam rubber or sponge-like
materials.
5. Before washing, do up zippers, buttons and
clothes straps and put small articles, such as
socks, laces or bras, into a washing bag or a
pillow.
Steel wires in bras will
pop out during washing;
never wash bras
containing steel wires.
6. Do not open the detergent distribution drawer
during a wash program.
7. The door is fitted with a self-lock device and
will not open until 2~3 minutes after the washing
machine stops. Do not force the door open. Do
not open the door if water level can reach the
porthole.
8. After each wash program, turn off the tap to
prevent leakage; and unplug the washing machine
and wipe clean the lower part of the porthole. Ensure
carpet does not obstruct the opening in the bases.
9. Do not cover the washing machine with a plastic cover when it is not in use so that the inside
dampness will not be kept in.
HG1600TXVEME
HG1400TXVEME
4
HG1600TXVE
HG1400TXVE
4
four
1.
2. turn the packaging bolts clockwise or counter-
clockwise 90 degree, and then take it out.
The installation of the built-in appliance
There must be enough space around the washing machine for us to install, and the
dimension may be no less than those as shown in figure 4.
10cm 10cm
5cm
Fig.4
5
from
Such information as remaining time during a wash cycle or a delay wash program, speed and temperature
setting and error message will be shown(refer to Page 14).
Work light
program is running , the light is on.
