Haier HG1000TXVE User manual

HG1200TXVEME/HG1200TXVE

HG1000TXVEME/HG1000TXVE

HG800TXVEME/HG800TXVE/WD800TXVE

Automatic Drum Washing Maching

I1-Start/Pause

I2-Anti-crease soaking button

I3-Delay wash button

I1-Start/Pause

I2-Anti-crease soaking button

I3-Delay wash button

HG800TXVE/ME





HG1000TXVE/ME HG1200TXVE/ME





Technical Specifications

MODEL HG1200TXVEME HG1000TXVEME HG800TXVEME

Power supply

Maxi u working current(A) 10 10 10

ater pressure (MPa) 0.05 < P < 1 0.05 < P < 1 0.05 < P < 1

ashing power( ) 300 250 250

Spinning power( ) 700 530 500

Max. wash load (kg) 5 5 5

Spinning speed (MAX) (r/ in) 1200 1000 800

ash progra 15 15 15

Heating power ( ) 1700 1700 1700

eight (kg) 86 86 86

HG1200TXVEME

HG1200TXVE

HG1000TXVEME

HG1000TXVE

HG800TXVEME

HG800TXVE

1800 1800 1800

NAME

220V~230V/(50Hz) 220V~230V/(50Hz)

220V~230V/(50Hz)

HG1200TXVEME/HG1200TXVE

HG1000TXVEME/HG1000TXVE

HG800TXVEME/HG800TXVE

413

A Wash program knob

By turning this knob, the required program can be selected.

(Refer to the Guide to Operational Program Selection).

Caution: The program knob is at the same time a power

button. When the knob is set to Stop , the power is turned off;

when the knob is set to other positions, the power is turned on.

B Wash temperature knob

By turning this knob, the required temperature can be selected

(temperatures between 30 -90 can be selected). Refer to

the Guide to Operational Program Selection.

C Speed knob

By turning this knob, the required spinning speed can be

selected. The maximum speed will vary when a different

program is selected.

Control pannel

611

ing

D Detergent distribution drawer

Instructions are printed on the handle of the drawer. Open the

drawer, three compartments can be seen:

Compartment 1: Pre-wash detergent

Compartment 2: Normal wash Super quick wash detergent

Compartment 3: Softener, conditioning agent, perfume, etc.

Fig. A

E Door lock indicator

When the light is on, the door is locked.

F Soaking indicator

When this light is on, the washer is in a soaking cycle. If the anti-crease button is

pressed and a soaking cycle is started, this light will blink and the time reading on

the screen will stop changing.

G Start / Pause button

When the washing machine is connected to the power, and a

program is selected, the time reading on the display will stop

blinking. Touch this button lightly, the washing machine will start

operation automatically; touch it again during operation, operation

will pause and the time reading on the display will blink. Press it

again to resume operation.

H Anti-crease soaking button

Press this button, the washing machine will start a soaking cycle

when the preset softening program is due during any of the

synthetic, wool, cashmere and silk wash cycles. Now the washing

machine will not drain but start a soaking cycle. And the soaking

indicator will blink. If you want to spin the laundry, press this button

again, operation will resume.

Control pannel

I Delay wash button

Press this button,the washing machine will start to adjust delay time.Each press

of the button,the delay will increase 30 minutes.Keep pressing the button and

the delay time will keep increasing.The range is 0-24 hours.For example,adjust it to

10 hours,press the "start" button and the washing machine will end 10 hours

later.The delay time should be longer than the washing time.Don’t press this

button,if the delay time isn’t needed.

Preparation

1. Power supply

Plug in the power supply

220-230V~/50Hz.

Detergent selection

Turn on the tap ensure that the water is clear.

Caution: Before staring the washing machine turn on

the water faucrt to ensure that the water faucet and the

water inlet hose are connected correctly and do not leak.

2. Water supply

Only special Iow foam detergent

should be used in automatic

drum washing machine, form

blended or wool fabrics special

detergent should be used. dry

cleaning solvent should not be

used such as trichhloroethylene

or alike (caution :load the re-

quired amount of detergent

only).

3. Laundry treament

sort out clothes according to type and extent of dirt.

There are three types of clothes: cotton, synthetical

and woolen (silk) fabrics.

separate white clothes from colored. If whites and

coloreds are combined for one load, make sure the

coloreds are colorfast.

-Remove all objects from pockets that may cause dam-

age to the machine, such as keys and coins.

-Clothing with frayed edges or yarns should be put in

a wash bag or special bag before washing.

-Repaire damaged clothing,lose buttons or damaged

zips and hooks before washing.

-Bed sheets and table ware should be loosely loaded

and not folded.

This washing machine is for household use and de-

signed for mechanically washable clothes. When wash-

ing, separate unwashable clothes with reference to

clothes labels.

Type non-fade cottons Delicat fabrics Woolen fabrics Blending fabrics

Max load 5 kg 2 kg 1 kg 2.5 kg

5.Wash Load

Normal

Delicate

Intensive

Normal

Soak

Note: indicates that softener or bleacher can be added if needed; indicates

that detergent must be added; X indicates that detergent must not be added.

The wash temperature indicates the maximum temperature. Different laundry requires

different wash temperatures, functions and time. The above wash cycle times are

intended as a guide only and will be subject to local conditions.

Soak wash program,suitable for needing disinfecting clean clothes,can't join detergent,if temperature

is 60-90 degrees Centigrade of ranges,The program heats to 90 degrees Centigrade,the the temperature

is suitble for sterilization of fabric of flax wash;if temperature is 0-60 degrees Centigrade of ranges,it

will heat to 60 degrees Centigrade ,this temperature is suitable for the sterilization of the chemical fibre

manufactured goods

Program description table

Intensive

PROGRAMME OPTIONS
