Grandstream Networks GXV3240 User manual

GXV3240 XML Based Downloadable Phonebook Guide

Grandstream Networks, Inc.

GXV3240 IP Multimedia Phone for AndroidTM

XML Based Downloadable Phonebook Guide

GXV3240 XML Based Downloadable Phonebook Guide

Page 1 of 21

GXV3240 XML Based Downloadable Phone Book Guide

Index

INTRODUCTION ........................................................................................3

WHAT IS XML........................................................................................................................................3

WHY XML ..............................................................................................................................................3

XMLAPI ARCHITECTURE....................................................................................................................3

XML PHONEBOOK CONFIGURATION.....................................................6

FIRMWARE............................................................................................................................................6

LCD CONFIGURATION.........................................................................................................................6

PROVISIONING.....................................................................................................................................9

IMPORT/EXPORT PHONEBOOK.........................................................................................................9

XML PHONEBOOK SYNTAX...................................................................14

HEADER..............................................................................................................................................14

PHONEBOOK XML STRUCTURE......................................................................................................14

PHONEBOOK XML ELEMENT ...........................................................................................................15

ROOT ELEMENT <AddressBook>...............................................................................................16

<pbgroup> ELEMENT ..................................................................................................................16

<Contact> ELEMENT...................................................................................................................17

<Phone> ELEMENT.....................................................................................................................18

XML PHONEBOOK EXAMPLE................................................................19

GXV3240 XML Based Downloadable Phonebook Guide

Page 2 of 21

Table of Figures

GXV3240 XML Based Downloadable Phone Book Guide

Figure 1: GXV3240 XMLAPI via HTTP ........................................................................................................4

Figure 2: GXV3240 XMLAPI Structure 1......................................................................................................4

Figure 3: GXV3240 XMLAPI Structure 2......................................................................................................5

Figure 4: Contacts->Menu.............................................................................................................................6

Figure 5: XML Phone Book Download..........................................................................................................7

Figure 6: Import and Export Phone Book XML File ....................................................................................10

Figure 7: Import Phone Book XML File: Settings........................................................................................10

Figure 8: Import Phone Book XML File: Choose File..................................................................................11

Figure 9: Import Phone Book XML File: Import...........................................................................................11

Figure 10: Export Phone Book XML File: Settings......................................................................................12

Figure 11: Export Phone Book XML File: Choose Directory.......................................................................12

Figure 12: Export Phone Book XML File: Export ........................................................................................13

Table of Tables

GXV3240 XML Based Downloadable Phone Book Guide

Table 1: <AddressBook> Element...............................................................................................................16

Table 2: <pbgroup> Element.......................................................................................................................16

Table 3: <Contact> Element........................................................................................................................17

Table 4: <Phone> Element..........................................................................................................................18

GXV3240 XML Based Downloadable Phonebook Guide

Page 3 of 21

INTRODUCTION

The Grandstream GXV3240 supports XML based downloadable phone book for users to share and

maintain a phone book remotely with ease. Besides directly importing vcard/csv format contacts, loading

contacts from synced-up accounts and manually editing from LCD, the GXV3240 offers this XML API as a

user-friendly downloading method via the phone's LCD and web UI.

For the ease of efficient deployment and management, the XML phone book file could be stored on a web

server for the phones to download. There are also applications that require a centralized directory server

and have all phones synchronized with the server periodically.

This document specifies the Grandstream XML based downloadable phone book configuration that will be

applied to GXV3240 firmware version 1.0.1.20 or newer. An example XML phone book file is provided at

the end of this guide. Users could start a phone book by adding contacts to the example file or exporting

the existed phone book file from phone's LCD.

WHAT IS XML

XML (eXtensible Markup Language) is a markup language* for documents and applications containing

structured information. This information contains both content (text, pictures, input box and etc.) and an

indication of what role that content plays (e.g. contents in a section header is different from contents in a

footnote). Almost all documents are structured.

*A markup language is a mechanism to identify structures in a document. The XML specification defines a

standard way to add markup to documents.

WHY XML

What benefits does XML provide to SIP endpoints? XML enables our SIP phones to serve as output

devices and allows the phones to interact with external applications in a flexible and programmable

manner.

XML API ARCHITECTURE

The XML based phone book downloading for the GXV3240 could use HTTP or TFTP as the transport

protocol. The following figure shows how it works via HTTP as an example. First, the GXV3240 initiates the

HTTP GET Request to the HTTP server and waits for the response. Once the phone receives the

GXV3240 XML Based Downloadable Phonebook Guide

Page 4 of 21

response with XML content in BODY, it displays the information.

Figure 1: GXV3240 XML API via HTTP

Two types of XMLAPI architecture are introduced below, depending on whether the transaction is via LAN

or Internet.

1. A transaction in the LAN may exchange information in the following manner. The GXV3240 sends a

request to the web server via HTTP/TFTP and waits for a response with the XML contents. The web

server will handle the request and communicate with the application server to get the information for

the XML phone book content display. The following figure shows downloading XML phone book file via

HTTP within a LAN.

Figure 2: GXV3240 XML API Structure 1

2. If the above Web Server accesses Internet, it could interact with outside web server and respond with

real-time content to the GXV3240.

GXV3240 XML Based Downloadable Phonebook Guide

Page 5 of 21

Figure 3: GXV3240 XML API Structure 2

As illustrated above, all the logic lies within the server side of the architecture. The GXV3240 phone just

receives the XML documents and displays it accordingly.

GXV3240 XML Based Downloadable Phonebook Guide

Page 6 of 21

XML PHONEBOOK CONFIGURATION

FIRMWARE

Before the XML phone book is used on GXV3240, please make sure the firmware on the phone is

upgraded to the latest version. Please refer to the following link for firmware upgrading information:

http://www.grandstream.com/support/firmware

LCD CONFIGURATION

To download the XML phone book file to GXV3240, go to LCD Menu->Contacts and tap on

Menu->Download to open the XML Phone Book download interface.

Figure 4: Contacts->Menu

GXV3240 XML Based Downloadable Phonebook Guide

Page 7 of 21

Figure 5: XML Phone Book Download

Download Mode

The phone book XML file could be downloaded via HTTP or TFTP. Users could also set it to "OFF" to

disable phone book download.

Delete the History

If this option is set to "ON", all the existed entries in the GXV3240 Contacts will be automatically

removed when the XML phone book is downloaded to the phone. The default value is "OFF".

Replace duplicate entries

If this option is set to "ON", the duplicate entries in the Contacts will be automatically replaced with the

ones in the downloaded XML phone book. The default value is "OFF".

Slide

Down

GXV3240 XML Based Downloadable Phonebook Guide

Page 8 of 21

File encoding

The encoding format for the XML phone book file. Users could select "UTF-8", "GBK" (for Chinese

characters), "UTF-16", "UTF-32", "Big5", "Big5-HKSCS", "SHIFT-JIS", "ISO8859-1", "ISO8859-15",

"Windows-1251" and "EUC-KR". The default value is "UTF-8".

Download Server

This specifies the path where the phone is going to download the XML phone book file. Since

download method is already specified in the previous selection, users do not have to provide this

information in the server path. The accepted format are as follows:

IP_address[:port]/dir

Hostname[:port]/dir

Examples:

192.168.40.10/XMLphonebookdir

192.168.40.10:443/XMLphonebookdir

service.mycompany.com/XML/phonebook

mycompany.com:8080/phonebook

Note:

1. If "[:port]" is not specified, port 80 will be used as default for HTTP and Port 69 will be used as

default for TFTP;

2. The GXV3240 will always look for the phone book file phonebook.xml for downloading if no file

name is specified in the server path. Users could also change the phone book name if desired. In

this case, the phone book file name needs to be specified in the server path. For example, if the

phone book file name is GXV3240contacts.xml and the server directory is 192.168.40.10/XML, the

download server path should be 192.168.40.10/XML/GXV3240contacts.xml.

Time Interval

This allows users to select the phone book automatic download time interval. The available intervals

are 2 hour, 4 hour, 6 hour, 8 hour and 12 hour. If it's set to None, automatic download will be disabled.

After the above configuration, tap on "Save" to save the change. Users could also always tap on

"Download Now" to start the downloading process.

GXV3240 XML Based Downloadable Phonebook Guide

Page 9 of 21

PROVISIONING

Users may also use the config file to provision the phone with the above XML phone book downloading

options. In this case, the GXV3240 needs to be rebooted and provisioned. The corresponding P values are

as shown below.

P330: Download Mode. Possible values: 1 (HTTP) / 2 (TFTP); other values are ignored. The default

value is 0.

P1435: Delete the History. Possible values: 0 (No) / 1 (Yes); other values are ignored. The default

value is 0.

P1436: Replace duplicate entries. Possible values: 0 (No) / 1 (Yes); other values are ignored. The

default value is 0.

P1681: File encoding. Possible values: UTF-8, GBK, UTF-16, UTF-32, Big5, Big5-HKSCS, SHIFT-JIS,

ISO8859-1, ISO8859-15, Windows-1251, EUC-KR. The default value is UTF-8.

P331: Download Server. This is a string for the path to download the phonebook.xml file. It MUST be

in the host/path format.

P332: Time Interval (in minutes). Possible values: 0 - "None", 120 - "2 hour", 240 - "4 hour", 360 - "6

hour", 480 - "8 hour", and 720 - "12 hour"; other values are ignored. The default value is 0 (automatic

download disabled).

The phone will be set up with the P values when the provisioning routine is completed. It will attempt to

download the phone book XML file specified in "Download Server" with configured interval and process it.

If the "Time Interval" is set to a non-zero value, a recurring timer will be activated periodically to check the

phone book file in the server and the phone will repeat this process automatically.

Note:

1. As you may know, it is also possible to enter the XML phone book file server path into a web

browser. In this way you’ll be able to see the exact XML document on your PC that your phone will

be receiving.

2. The downloaded XML phone book file can be displayed but it won't be saved internally on the

phone. It is recommended to save the XML phone book file externally on your PC or server for

your reference and future use.

IMPORT/EXPORT PHONEBOOK

Besides downloading phone book file from remote server, users could also directly import phonebook.xml

to the GXV3240 in the LCD from local storage/USB storage/SD card. If there is an existing phone book in
