Grandstream Networks GXP2130v2 User manual
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Grandstream Networks, Inc.
GXP2130v2/GXP2140/GXP2160/GXP2135/GXP2170
Bluetooth User Guide
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 1 of 13
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Table of Content
OVERVIEW..................................................................................................4
BASIC FUNCTIONS....................................................................................5
TURN BLUETOOTH ON OR OFF.........................................................................................................6
CHANGE GXP2130v2/2140/2160/2135/2170 BLUETOOTH NAME....................................................6
PAIRING TO A BLUETOOTH DEVICE..................................................................................................6
CONNECTING TO A BLUETOOTH DEVICE.................................................................................7
UNPAIRING AND DISCONNECTING A BLUETOOTH DEVICE ...................................................8
USE BLUETOOTH HEADSET ....................................................................8
BT ON AND BT OFF..............................................................................................................................8
HANDSFREE MODE.................................................................................10
TURN ON/OFF HANDS FREE MODE................................................................................................10
CONNECT TO HANDS FREE DEVICE............................................................................................... 11
USE BLUETOOTH PHONEBOOK ......................................................................................................12
INITIATE A CALL WITH HANDS FREE MODE...................................................................................13
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 2 of 13
Table of Tables
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Table 1: Bluetooth Configuration...................................................................................................................5
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 3 of 13
Table of Figures
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Figure 1: Bluetooth Configuration.................................................................................................................5
Figure 2: Scan Bluetooth Device ..................................................................................................................7
Figure 3: Pairing to Bluetooth Device ...........................................................................................................7
Figure 4: Bluetooth Device Connected.........................................................................................................8
Figure 5: Disconnect Bluetooth Device.........................................................................................................8
Figure 6: BT is OFF.......................................................................................................................................9
Figure 7: BT is ON ........................................................................................................................................9
Figure 8: Turn On Hands Free Mode..........................................................................................................10
Figure 9: Hand Free Enabled...................................................................................................................... 11
Figure 10: Hands FreeAccount Connected................................................................................................11
Figure 11: Bluetooth Phonebook.................................................................................................................12
Figure 12: Search under Bluetooth Phonebook..........................................................................................12
Figure 13: Hands Free Call Screen ............................................................................................................13
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 4 of 13
OVERVIEW
Bluetooth is a proprietary, open wireless technology standard for exchanging data over short distances
from fixed and mobile devices, creating personal area networks with high levels of security.
GXP2130v2/2140/2160/2135/2170 supports Bluetooth Class 2 of version 2.1. On GXP color phones,
users could connect to mobile phones (which support Bluetooth function) via hands free mode, or use
Bluetooth headset to answer calls.
This document serves as an end user guide on how to use Bluetooth headset and hands free mode on
GXP2130v2/2140/2160/2135/2170.
Please ensure your GXP2130v2/2140/2160/2135/2170 is on the latest firmware release:
http://www.grandstream.com/support/firmware
Software release reference:
The original GA 1.0.1.6 build only supports connecting to Bluetooth Headsets.
The current Beta 1.0.5.29 supports both connecting to Bluetooth Headsets and Bluetooth Phones
(one at a time).
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 5 of 13
BASIC FUNCTIONS
Bluetooth related settings are under GXP2130v2/2140/2160/2135/2170's LCD
Menu->System->Bluetooth. To connect to a Bluetooth device, turn on
GXP2130v2/2140/2160/2135/2170’s Bluetooth power first. The first time when using a new Bluetooth
device with GXP2130v2/2140/2160/2135/2170, "pair" the device with the phone so that both devices know
how to connect securely to each other. After that, users could simply connect to a paired device. Turn off
Bluetooth if it is not used.
Figure 1: Bluetooth Configuration
Table 1: Bluetooth Configuration
System -> Bluetooth
Bluetooth Status
Displays the status of Bluetooth. When Bluetooth power is on, the status is
“Discoverable”; when Bluetooth power is off, the status is “Off”.
Bluetooth MAC
Displays the GXP phone’s MAC address
Power
Turns on/off Bluetooth.
Handsfree Mode
Enables/Disables Handsfree mode
Bluetooth Name
Defines the GXP2130v2/2140/2160/2135/2170 Bluetooth name.
Start Scan
Starts to scan other Bluetooth devices in range. If new device is found, user
could press “Pair”soft key, and enter Pin code to pair to other Bluetooth
devices.
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 6 of 13
TURN BLUETOOTH ON OR OFF
1. Go to GXP2130v2/2140/2160/2135/2170's LCD MENU->System->Bluetooth
2. Highlight Power option by pressing Up/Down arrow key
3. When the Power option is highlighted, pressing LEFT/RIGHT arrow key to turn on/off Bluetooth.
Note: While Bluetooth is turned on, GXP2130v2/2140/2160/2135/2170 is discoverable by other Bluetooth
devices. To make the phone undiscoverable, user needs to turn off Bluetooth.
CHANGE GXP2130v2/2140/2160/2135/2170 BLUETOOTH NAME
Under Bluetooth Name option user can change the Bluetooth name of GXP2130v2/2140/2160/2135/2170.
When discovered by other Bluetooth devices, GXP2130v2/2140/2160/2135/2170 will show the name
configured in this option.
1. Go to GXP2130v2/2140/2160/2135/2170's LCD MENU->System->Bluetooth
2. Highlight Bluetooth Name option by pressing Up/Down arrow key
3. Enter the desired Bluetooth name from keypad.
PAIRING TO A BLUETOOTH DEVICE
Before connecting GXP2130v2/2140/2160/2135/2170 with other Bluetooth device, users must pair them
first. Both devices will stay paired afterwards unless they are unpaired.
1. Go to GXP2130v2/2140/2160/2135/2170's LCD MENU->System->Bluetooth
2. Enter Start Scan option
3. GXP2130v2/2140/2160/2135/2170 scans and displays the Names of all available Bluetooth devices in
range. See Figure 2 Scan Bluetooth Device.
If the device you would like to pair with does not show up in the list, ensure that the device is turned on
and set to be discoverable. If need, user could press “Clear” and “Rescan”soft keys to restart the
scanning;
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 7 of 13
Figure 2: Scan Bluetooth Device
4. The discovered devices will show in the scan result list with device name. If it is not paired, it will show
"Unpaired" behind the device name. Select the device name, and press “Pair”soft key to pair it. Then
a window will prompt up. See Figure 3 Pairing to Bluetooth Device. User may input the Pin code in the
window, and press “OK”soft key to start pairing.
Note: Usually, the default Bluetooth headset Pin code is 0000.
Figure 3: Pairing to Bluetooth Device
CONNECTING TO A BLUETOOTH DEVICE
After successfully paired, the GXP2130v2/2140/2160/2135/2170 will show "Paired" behind the Bluetooth
device name in the scan list. Highlight the device name and press “Connect”soft key to connect.
Once connected, GXP2130v2/2140/2160/2135/2170 will show “Connected”behind the Bluetooth device
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 8 of 13
name in the scan list.
Figure 4: Bluetooth Device Connected
UNPAIRING AND DISCONNECTING A BLUETOOTH DEVICE
In the Bluetooth settings, highlight the Bluetooth device name and press “Disconnect”/”Unpair”soft key to
disconnect/unpair the Bluetooth device.
Figure 5: Disconnect Bluetooth Device
USE BLUETOOTH HEADSET
On GXP2130v2/2140/2160/2135/2170, user can answer/terminate incoming call from Bluetooth headset.
BT ON AND BT OFF
After Bluetooth headset is successfully connected, GXP2130v2/2140/2160/2135/2170 will show “BT On”
GXP2130v2/2140/2160/2135/2170 Bluetooth User Guide
Page 9 of 13
soft key on call screen. User may press it to active Bluetooth headset. See Figure 6 BT is OFF.
Figure 6: BT is OFF
When “BT Off”soft key shows up in call screen and the Bluetooth icon on status bar changes to be solid, it
means the Bluetooth headset is ready to use. See Figure 7 BT is ON.
Figure 7: BT is ON
When BT is on, both Bluetooth headset and GXP2130v2/2140/2160/2135/2170 will alert for incoming calls.
User may press the answer button on Bluetooth headset to answer the incoming call.
During an active call, user may switch the audio channel between Bluetooth headset and phone handset
by pressing “BT Off”/”BT On”soft key.
