GoWISE USA GW22612 User manual

ELECTRIC AIRWISE FRYER

GW22611/GW22612

WWW.GOWISEPRODUCTS.COM

Instruction Manual

Product Introduction

Important Safeguards

Electromagnetic Fields

Product Structure & Features

Before First Use

How to use your Air Fryer

Cooking Guide

Cleaning your Air Fryer

Troubleshooting

Warranty

Table of Contents

Product Introduction

GoWISE USA would like to introduce the GW22611(black) and

GW22612(white). A new model of Air Fryers. The air fryers use Rapid Air

Technology to prepare food that usually needs to be dunked in oil and fried.

Rapid Air Technology works by quickly circulating hot air around a grill top.

The best part about the air fryer is that it heats food in all directions and

most dishes require no oil at all. It is a 3.7 Quart Air Fryer with 8 built-in

smart programs, such as Warm-up; Chips; Chicken; Steak; Shrimp; Meat;

Cake; Fish. It also has a wide temperature range from 176°F - 392°F and a

timer for up to 30 minutes. This Air Fryer is an easy and healthy way to

prepare your favorite fried foods.

Important Safeguards

(continued on next page)

1. READ THE MANUAL.

2. Keep the box and packing material for storage.

3. Do not immerse the cord, plug, or any part of the appliance in water or

any other liquids to avoid electric shock.

4. Keep all the ingredients in the basket to prevent any contact from

heating elements.

5. Do not cover the air inlet and air outlet when the appliance is on.

6. Do not fill the pan with oil. Filling the pan with oil may cause a fire

hazard.

7. Do not touch the inside of the appliance while it is operating.

8. Do not use the appliance if there is any damage to the plug, main cord,

or other parts.

9. Do not go to any unauthorized person to replace or fix the appliance.

10. keep the main cord away from hot surface.

11. Do not plug in the appliance or use the appliance with wet hands.

12. Make sure that the appliance is plugged into the wall socket properly.

13. Make sure that the appliance is out of reach of children, especially when

the fryer is operating.

14. Do not connect the appliance to an external timer switch.

15. Do not place the appliance on or near combustible materials, such as a

tablecloth or curtain.

16. Do not place the appliance against a wall or any other appliances. Leave

at least 5 inches of free space on the back, sides, and above the

appliance.

17. Do not place anything on top of the appliance.

18. Do not use the appliance for any other purposes other than described

in this manual.

19. Do not leave the appliance unattended while it is operating.

20. During hot air frying, hot steam is released through the air outlet

openings. Keep your hands and face at a safe distance from the steam

and from the air outlet opening. Be careful of hot steam and air when

you remove the pan from the appliance. Any accessible surface may

become hot during use.

Important Safeguards(continued)

21. Immediately unplug the appliance if you see dark smoke coming out

of the appliance. Wait for the smoke emission to stop before you

remove the pan from the appliance.

22. Ensure that the appliance is placed on a horizontal, even, and stable

surface.

23. This appliance is designed for household use only. It is not safe to use

in environments, such as staff kitchens, farms, motels, and other

non-residential environments.

24. The warranty is void if the appliance is used for professional or semi-

professional purposes, or it is not used according to instructions.

25. Always wait 30 minutes for the appliance to cool down before handling

or cleaning it.

Electromagnetic Fields(EMF)

This GoWISE USA air fryer complies with all standards regarding

Electro-magnetic fields(EMF). Under proper handling, there is no harm done

to the human body based on available scientific evidence.

If you have any questions regarding your Air Fryer, please contact Customer

Service at 1-855-233-9199.

Product Structure & Features

UNIT

STRUCTURE

CONTROL

BOARD

FRYER

BASKET

PAN/POT

(continued on next page)

Before First Use

1. Remove all packaging materials, stickers, and labels.

2. Clean the basket and pan with hot water, soap, and a non-abrasive

sponge.

3. Wipe the inside and outside of the appliance with a clean cloth

NOTE: There is no need to fill pan with oil and frying fat because the

appliance works with hot air.

Product Structure & Features(continued)

8 COOKING

PRESETS

THIS ICON

WILL BLINK TO SHOW

AIR FRYER IS HEATING UP

COOKING

TIME

COOKING

TEMPERATURE

DISPLAYS COOK

PRESET SELECTED

ADJUST COOK

TEMPERATURE

STOP COOKING/

CANCEL SETTINGS

THIS ICON WILL LIGHT UP

AND BLINK WHEN THE

FAN IS BLOWING

START/PAUSE

COOKING

ADJUST

COOK TIME

(CONTROL BOARD)

How to use your Air Fryer

1. Place the air fryer on a flat and even surface. DO NOT PLACE THE

FRYER ON A SURFACE THAT IS NOT HEAT RESISTANT.

2. Put the basket in the pan. DO NOT FILL THE PAN WITH OIL OR ANY

OTHER LIQUID.

3. Place the ingredients in the basket and then put the basket and pan

back into the appliance.

4. Set your cooking time and temperature by either choosing one of the

8 presets or manually setting it with the “+” or “-” icons.

5. Once you have set your cooking time and temperature, press the START

button.

6. The heat up and blower icon will blink to show that the fryer is heating

up and circulating hot air.

7. There are some ingredients that you may need to shake midway through

the cooking cycle. To do this, pull the pan out of the air fryer by the

handle(the air fryer will automatically shut down), then carefully shake

the ingredients. When done, slide the pan and basket back into the

air fryer.

8. After sliding pan back into the air fryer, it will automatically go back to

frying, however, the timer will be reset to the original cook time. Please

keep this in mind when sliding back into fryer after shaking.

CAUTION: DO NOT PRESS THE BUTTON ON THE HANDLE DURING SHAKING,

THIS WILL DETACH THE BASKET FROM THE PAN. If shaking the ingredients

in the pan is difficult. You can place pan on pot holder, then release the

basket, and shake the basket.

9. When the cooking time has been reached, the timer will beep five times.

After the timer beeps, the air blower will stop shortly after(approx. 20

seconds)

10. Pull the pan out of the fryer and place it on a pot holder. NOTE: Oil

from the ingredients will gather in the bottom of the pan, be careful

when sliding pan out of fryer.

(continued on next page)

How to use your Air Fryer(continued)

11. To remove the ingredients, press the fryer basket release button on the

handle to free the basket from the pan. Carefully pour ingredients out

of basket onto plate.

To order replacement parts please

contact GoWise USA® customer

service at 1-855-233-9199.

*TheGoWise USA® Air Fryer complies with

Fields (EMF). Under properhandling, there is

no harm caused to the human bodybased on

1. Press fryer basket release

to free the basket from the pot

CAUTION: AFTER COOKING,

NEVER PRESS THE RELEASE BUTTON

DURING SHAKING; THIS WILL DE-

TACH THE BASKET FROM THE PAN.

down
