Global Sat TR-600 User manual

AVL Tracking System

TR-600

V 1.2

Globalsat Technology Corporation

16F., No. 186, Jian-Yi Road, Chung-Ho City, Taipei Hsien 235, Taiwan

Tel: 886.2.8226.3799/ Fax: 886.2.8226.3899

[email protected]

www.globalsat.com.tw

USGlobalSat Incorporated

14740 Yorba Court , Chino, CA 91710

Tel: 888.323.8720 /Fax: 909.597.8532

[email protected]

www.usglobalsat.com

CONTENT

1. Introduction .......................................................................................................................................3

1.1 Introduction.............................................................................................................................3

1.2 Features ....................................................................................................................................3

1.3 Hardware Architecture ........................................................................................................4

1.4 Hardware specification ........................................................................................................5

1.5 Appearance..............................................................................................................................6

1.6 LED indicator...........................................................................................................................7

1.7 able description ...................................................................................................................8

1.8 Accessories ............................................................................................................................10

2 Operation............................................................................................................................................11

2.1 Install the SIM card............................................................................................................11

2.2 Install the GPS and GSM antenna ................................................................................12

2.3 Installing the Emergency button...................................................................................13

1. Introduction

1.1 Introduction

The TR-600 is a multi-functional and economically feasible communication platform for mobile

positioning applications. It integrates highly sensitive GPS module and quad-band GSM

communication module with a powerful microcontroller that fits into a compact enclosure. The

TR-600 has a solid and rigid housing, for simple installation. It provides real-time GPS positions

anytime and anywhere with an open view to the sky, and offers precise positioning, and reports

vehicle status to the server with necessary information shown on the map. Benefits such as

enhanced fleet management, improved vehicle safety, emergency response, are all

accomplished through the implementation of the TR-600 system.

1.2 Features

Build in Quad-band 850/900/1800/1900 MHz GSM system

Build in high sensitivity GPS system

SupportsAT command via SMS/ TCP/UDP

Remote control via SMS/GPRS command

Real-time GPS position feedback and vehicle status monitoring

Built-in in digital outputs (3), digital inputs (3), an ACC input, 1 analog input, and 1 serial

port

Power supply for Li-ion battery and lead-acid battery

Supports multi geo-fence function

OTA (Over the air) firmware updates

Data logger for 50,000 points

Ignition/ Power Low/ Power Lost / Speed Limit detection alarm

3 LED indicators for GSM, GPS, power status

External panic button for emergency SOS (Optional)

1.3 Hardware Architecture

GPS antenna GSM antenna

Speaker

Microphone

CPU

GPS

GSM

MODEM

Analog

Input

Digital

output

Digital

input

Li backup

Battery

USART/

RS-232

Motion

Sensor

SOS

1.4 Hardware specification

Item Description

Dimension 98 mm X 65 mm X 22 mm

CPU High performance line ARM-base 32-bit MCU

GPS receiver SiRF Star III high performance GPS chipset

Temperature Operation -30℃ ~ + 80℃

Storage -40℃ ~ + 85℃

GPS Antenna SMA Type connector

Active antenna ( 3.3~3.8V)

GSM Antenna SMA Type connector

Communication Telit (GE865) Quad-band GSM 850/900/1800/1900 MHz

Protocol Voice/SMS/GPRS (TCP/UDP)

Built-in Memory 32 Mb

GPS logging capacity 50,000 points

Emergency Input Negative trigger 1

Ignition (ACC) Input Positive trigger 1

Digital Input Port Negative trigger 2

Positive trigger 1

Digital Output Port Negative trigger 3 (300 mA)

Analog Input Port Analog Input 1( 0~28V)

Serial Port 115200 bps

Backup battery (Option)

Internal 800 mAh Lion battery

Support external Lead-acid battery (12V/24V)

Hands-free Kit (Option) Support external speaker and microphone

Sensor Motion sensor

1.5 Appearance

1 Peripheral interface port

2 I/O port

3 Power Status LED

4 GPS LED

5 GSM LED

6 For fixing device with screws

7 GSM antenna connector

8 For fixing device with belt

9 GPS antenna connector

10 SIM card holder

1 2

6 6

1.6 LED indicator

Power Status LED (Red)

LED Permanently On

State Main power on, device on

GPS LED (Yellow)

LED Permanently off Fast blinking (Once

every 1 second) Slow blinking (Once

every 3 seconds)

State GPS off GPS not fix GPS fix

GSM LED (Green)

LED Permanently off Fast blinking (Once

every 1 second) Slow blinking (Once

every 3 seconds)

State GSM off 1. TR-600 is

searching GSM

network

2. SIM card is

registering to GSM

network

TR-600 is registered

full service

1.7 Cable description

14 Pin I/O Cable

Wire Color Description

Green/ White Analog Input_1

White Digital Output 3 (Negative Trigger)

Gray Digital Output 1 (Negative Trigger)

Purple Digital Input 3 (Positive Trigger)

Blue Digital Input 1 (Negative Trigger)

Black Ground

Red Main Power

Green Digital Output 2 (Negative Trigger)

Yellow ACC (Positive Trigger)

Orange Digital Input 2 (Negative Trigger)

Brown SOS (Negative Trigger)

Pink 12V/24V Backup Battery

Black Ground

8 Pin Cable

Wire Color Description

Pink Audio_5V

Blue Speaker 1(Positive)

Red Serial-1_5V

White Receiver 1

White Microphone 1 P

Black (3 Pieces) Ground

Orange Speaker 1(Negative)

Green Transmission 1

1.8 Accessories

Main Unit

GPS Antenna

GSM Antenna

14 Pin I/O Cable

8 Pin Cable

RS-232 Cable (Option)
