Global Sat BT-338 User manual

UserManual

Bluetooth GPS Receiver

BT-338

ver 1.08

1 BT-338 at a glance

1.1 Appearance and Function

1.2 How to change battery

Figure 1 Open the cover of battery

Figure 2 Take out the battery with pull tag

Figure 3 Put new battery into BT-338

Figure 4 Fit battery into BT-338

Figure 5 Slide the cover of battery to close

Figure 6 Slide the cover of battery to close

1.3 Accessories

2. Introduction

The BT-338 is a GPS receiver with Bluetooth interface and built-in active antenna for

high sensitivity to tracking signal. Based on the SiRF star III Low power chip set and

supports all functions (Single Sat updates in reduced visibility, Superior urban canyon

performance, FoliageLock for weak signal tracking, etc.). The BT-338 is well suited to

system integrations including PDA, Smart phone, Tablet PC and Notebook PC with

Bluetooth devices. It satisfies a wide variety of applications that are purposes in automotive,

and outdoor recreation navigation systems.

2.1 Package

Before you start up, make sure that your package includes following items. If any item

is missing or damaged, please contact your dealer immediately.

 Bluetooth GPS Receiver

 A CD with the User Manual and the Testing Program.

 AC Power Charger

 DC Car Power Charger

2.2 Power Switch

Power on:

Press the power button 1 second until the GPS status LED is on.

Power off:

Press the power button 1 second until the GPS status LED is off.

2.3 Power Jack

The power jack lets you to connect either a DC car power charger (included) or AC

power charger (included) to recharge the internal battery. Please note that the adapter

rating 5V, 1.2 A, positive pole center.

2.4 LED Function

Bluetooth Status LED (Blue):

Blinking (Slowly) ---- Not connected to any Bluetooth device.

Blinking (Quickly) ---- Connected to other Bluetooth device.

GPS Status LED (Green):

Blinking ---- GPS position is fixed

Steady light ---- GPS position is not fixed

Battery Status LED (Red/Yellow):

Red ---- Battery power is critically low. Charge immediately.

Yellow ---- Battery is charging now.

LED off ---- Battery is partially full or fully charged.

2.5 Power-saving Function

When you start the power of the Bluetooth GPS Receiver BT-338, if the Bluetooth is not

connected to any devices within 10 minutes, BT-338 will turn off the power automatically,

and all the LED will go off simultaneously.

3. Specification

3.1 System Specification

Electrical Characteristics (Receiver)

Frequency L1, 1575.42 MHz

C/A Code 1.023 MHz chip rate

Channels 20 all-in-view tracking

Tracking Sensitivity -159 dBm

Accuracy

Position Horizontal 10m 2D RMS (SAoff)

WAAS enabled 5m 2D RMS (SAoff)

Time 1 micro-second synchronized to GPS time

Velocity 0.1m/sec 95% (SA off)

Datum

Datum WGS-84

Acquisition Rate

Hot start 1 sec., average (with ephemeris and almanac valid)

Warm start 38 sec., average (with almanac but not ephemeris)

Cold start 42 sec., average (neither almanac nor ephemeris)

Reacquisition 0.1 sec. average (interruption recovery time)

Protocol

GPS Output Data NMEA 0183 protocol, and supports command:

GGA(1sec), GSA(1 sec), GSV(5 sec), RMC(1sec)

( VTG and GLL are optional)

GPS transfer rate 38400,N,8,1

Dynamic Condition

Acceleration Limit Less than 4g

Altitude Limit 18,000 meters (60,000 feet) max.

Velocity Limit 515 meters/sec. (1,000 knots) max.

Jerk Limit 20 m/sec**3

Power

Voltage Built-in rechargeable battery(1650 mAh) and 5V DC

input charging circuit

Operation Time 15 hr. After fully recharged, in continuous mode

>20 hr in trickle power mode

Physical Characteristics

Dimension 72.5mm x 40.4mm x 26mm

Weight 75g

Temperature

Operating -20°~ 60°C

Storage -30°~ 80°C

Humidity Up to 95% non-condensing

3.2 Bluetooth Specification

●Bluetooth V1.2 Compliant

●Supply Voltage : 2.8V ~ 3.3V

●Frequency Range : 2.402 ~ 2.480 GHz

●Receiver Sensitivity : -80 dBm

●Transmit Power : Class 2

●Transmitting Range : 10 m (Depends on environment)

●Power Consumption : 45 mA (Typical)

4. Usage

4.1. For PDAwith built-in Bluetooth

1. Turn on the power switch in BT-338

2. Please refer to the user manual of PDA to enable the Bluetooth of PDA

connecting to the BT-338. Some PDAs may need the Bluetooth passkey, the

passkey is “0000”.

3. Check the number of COM port used by Bluetooth.

4. Run the suitable mapping/navigation software and select the correct COM port

& baud rate : 38400

4.2. For PDAwith Bluetooth Compact Flash card

1. Turn on the power switch in BT-338

2. Please refer to the user manual of Bluetooth Compact Flash card to enable it

connects to the BT-338. Some Bluetooth devices may need the Bluetooth

passkey, the passkey is “0000”.

3. Check the number of COM port used by Bluetooth.(Example COM 6).

4. Running the suitable mapping/navigation software and select the correct COM

port & baud rate : 38400.

4.3. For Notebook with Bluetooth device

1. Turn on the power switch in BT-338

2. Please refer to the user manual of Bluetooth device to enable it connects to the

BT-338. Some Bluetooth devices may need the Bluetooth passkey, the passkey is

“0000”.

3. Check the number of COM port used by Bluetooth.(Example COM 6).

4. Running the suitable mapping/navigation software and select the correct COM

port & baud rate : 38400.

Note: The Bluetooth device in most of the applications have an “auto-detect”

feature that you do not need to select the Baud Rate.
