Germozap ICAS Manual
INSTRUCTION GUIDE
Large Room UVC Air Sanitizer
Sanitize the Air You Breathe!
99.9% disinfection rate
confirmed by accredited lab
Tested on:
Escherich coli 8099
To view or download reports go to www.germozap.com
Please read all warnings and instructions before using
this device. Save these instructions.
This product is intended for household use only.
Reset
Timer
Sleep
Speed Auto
Auto
On/Off
Sterilize Anion
Fan Speed Mode Timer On/Off
AQI Good
Purify
Timer
Speed
Sleep
AUTO
Anion
UV
PM2.5
TEMPERATURE
AQI Poor
AQI Medium
F
H
Staphylococcus aureus ATCC 6538
6 Filtration Processes
IONIZER HEALTH WARNING
4 Filters in 1
4 UVC Bulbs
Pre-Filter Active
Carbon Filter
Hepa Filter Cold Catalyst
Filter
UVC Light Negative Ion
1 2 3 4 5 6
√Pre-Filter: Cleans the air of hair, dust and mites so the UVC light is not blocked by particles
√ Ionic Air Filtration: Eliminates ultra-fine particles down to 0.1 microns in size by causing them to stick to the negatively
charged ions on a charged collector plate
√ Active Carbon Filter: Removes odors, mold and smoke to make rooms smell fresh
√ HEPA Filter (H11*):
• Removes pollen, dust, smoke, pet dander, mold spores, PM2.5, & allergens
• Cleans the air of smaller particles so the UVC light is not blocked
• Captures particles as small as 10nm. SARS-Co-V-2 is 12.5 times larger at 125nm and can be captured by this filter
*The sweet spot in the tradeoff between air flow and particle capture. If the HEPA filter is too thin, particles get through. If
it is too thick, air flow is hindered, and the number of times air can flow through in an hour is less. Our HEPA 11 filter
captures 95% of air pollution on first pass, but it cycles the air more quickly than heavier filters. Once the air passes back
through the filter a second time, it captures another 95% of remaining particles. In just 2 passes, it captures 99.25%.
√ Cold Catalyst Filter: Absorbs dangerous formaldehyde and other harmful gases emitted by paint, carpet, and flooring
materials
√ UVC Light - Zaps up to 99.99% of bacteria & viruses from the air
To change the filter, simply remove the front cover and remove the filter.
Bulb life: Approximately 6,000 hours.
The ionizer collection plate is located inside the electronics behind the touch screen display. This does not require
maintenance or cleaning.
Negative ions exist in nature. They are found in ultraviolet (UV) rays, after a thunderclap or lightning strike and wherever water
collides like the shower, a waterfall or from ocean waves. It is also produced as part of the normal growth process for many
plants.
Negative ions purify the air by magnetically attracting to pollutants until these newly-formed larger particles become too heavy
to remain in the air you breathe. Negative ions produced by the ionizer function in this sanitizer are believed to produce
biochemical reactions that increase levels of the mood and chemical serotonin, helping to alleviate depression, relieve stress,
increase concentration and boost energy. For these reasons, we have included this ionizer function in our UVC Air Sanitizer.
However, for some individuals, negative ions may cause adverse reactions and should not be used. Symptoms may
include throat irritation, coughing, chest pain and shortness of breath, as well as an increased risk of respiratory
infection.
Do not use the ionizer function if you have asthma, bronchitis, COPD or other breathing problems or respiratory
disorders. You can DISABLE THE IONIZER FEATURE BY PRESSING THE ANION BUTTON ON THE REMOTE CONTROL
AND CHECKING THE DISPLAY PANEL TO BE SURE IT HAS BEEN DEACTIVATED.
The 4 UVC bulbs are located behind the filters.
Cycles air 5 times per hour
Rooms up to 645sf
FanSpeed Mode Timer On/Off
AQIGood
Purify
Timer
Speed
Sleep
AUTO
Anion
UV
PM2.5
TEMPERATURE
AQIPoor
AQIMedium
F
H
To see how to easily and safely change the UVC bulbs, go to www.germozap.com/change-uv-air-purifier-bulbs
Your sanitizer is only as powerful and effective as the filter and bulbs you put inside, and our genuine Germozap replacement
parts are essential for maintaining product performance. Each filter or bulb is designed specifically for this particular machine.
Not only will genuine replacement parts fit like a glove, but they also have the combination technology to match so that you
can get the most out of your air sanitizer. You can buy replacement filters and bulbs at www.germozap.com.
Read all of these instructions before plugging in or turning on the UVC Air Sanitizer1.
2. Remove the front cover from the machine by pulling the bottom part of the front panel toward you.
3. Remove the air filters. Behind the filters you will find 4 UVC bulbs. Check to make sure they are not broken and have not
become disconnected during shipping. Replace filters and make sure they fit snugly. Replace front cover.
FAN SPEEDS: You can manually adjust the 3 fan speeds by pressing the Fan Speed button until you obtain the desired fan
speed. Or set the sanitizer to auto and it will automatically adjust the fan speed as necessary when dirtier air is sensed.
The lowest setting can be used as gentle white noise at night for a quiet, restful sleep.
7.
8. TIMER: Press the button once to set the timer to turn off the machine in 1 hour. Press twice for 2 hours, 3 times for 3
hours, etc. Settings: 1-8 hours.
10. To manually turn on/off the UVC and ionizer functions individually, use the remote control (included)
9. AUTO: Press the button once and the fan speed will authomatically adjust for dirtier air
11. Always unplug the sanitizer from the outlet before removing cover
Be sure the sides, top and bottom of the UVC Air Sanitizer are not blocked or covered so that air can circulate in and out of
the machine.
*You can read more about PM2.5 and what constitutes good, moderate, and poor air quality readings at
once to shut off auto modea.
b. twice to set the machine to sleep mode
c. third time to reset to auto mode with UVC and ionizer functions off
4. Plug the UVC Air Sanitizer into an electrical outlet.
5. ON/OFF: Turn on UVC Air Sanitizer using the touch screen display button or the remote control.
6. MODE: Press the button:
a. When the machine first comes on, it will automatically be in Auto mode with UVC light and ionizer functions on.
No timers are set so the machine will run continuously until you turn it off manually or set a timer function.
b. Upon start up, the air quality sensor will alternate between poor, fair and good until it filters enough air through
the machine to obtain a PM2.5 reading. Initially, the PM2.5 reading will register as 4 flat lines (----) until the
sanitizer obtains a PM2.5 reading.
Instructions for Use
Display Functions/Buttons
Decibel Levels
On/Off – Turn sanitizer on/off
Timer – Sets time to shut off sanitizer (1-8 hours)
Mode – Controls auto, settings
Fan Speed - Adjust the 3 fan speeds
Remote Control Functions (see above for explanations)
On/Off – Turn sanitizer on/off
Reset – Remove all user settings and reset to default settings
Timer – Sets time to shut off sanitizer (1-8 hours)
Speed – Adjust the 3 fan speeds
Auto – Turn on/off automatic setting
Sleep – Turns on sleep mode (display off, quiet)
UVC – Turn on/off UVC bulbs
Anion – Turn on/off ionizer
3 Fan
Speeds
Air Quality
Display
PM2.5
Particulate
Monitor
Auto Shut-off
1,2,8 + 12
Hour Settings
Touch Screen
Controls
Sleep Mode
< 25 Decibles
Temperature
Display
Automatically
Adjusts for
Dirtier Air
Ionic Air
Filtration
UVC Light
Disinfection
Fan Speed Mode Timer On/Off
AQI Good Purify
Timer
Speed Sleep AUTO
Anion UV
PM2.5
TEMPERATURE
AQI Poor
AQI Medium
F
H
UV
Fan Speeds: Low
21db
Medium
28db 35db
High
Sanitize Rooms up to 645 square feet
EPA Co. No. 97721
Reset
Timer
Sleep
Speed Auto
Auto
On/Off
Sterilize Anion
Never look at the UVC light or shine on skin. Direct, prolonged exposure of eyes or skin to the UVC bulb can cause
serious skin burns and eye inflammation.
The UVC bulb in this device contains trace amount of mercury, a chemical known to the state of California to cause
birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov
• Never shine the light in eyes or on skin of animals or people
• To avoid shock hazard, do not remove front cover unless the air
sanitizer is unplugged
• Do not handle this device with wet hands
• Do not use outdoors
• Do not place device on wet surfaces
• Do not get device wet or submerge in water
• It is a violation of federal law to use this device in a manner inconsistent
with its labeling or instructions
• If this device is no longer working properly, has been dropped or
damaged in any way, or left outdoors, do not use
• Do not directly expose this device to an open flame or other heat source
• Handle device with care to prevent breakage
• This device is for use to sanitize air only. It is not meant to be used to
disinfect surfaces or objects
• Store in a cool, dry place
• THIS DEVICE IS NOT A TOY. KEEP OUT OF THE REACH OF CHILDREN
This Large Room UVC Air Sanitizer is not a medical device. It is
for sanitizing only. This device cannot keep users from getting
sick and cannot be used to treat any illness
Warnings
CAUTION
WARNING
WARNING
The ionization feature in this machine emits ozone. Ozone is a gas known to cause irritation to the lungs
and airways. You can disable the ionization feature by pressing the anion button on the remote control
What’s Included
Instructions
(1)
UVC Bulb Disposal
The sealed bulb in this device
contains mercury. Do not dispose
of used bulb in the trash. Dispose
of properly. For recycling and
proper disposal protocols consult
your local waste authority or visit
www.epa.gov/cfl
Specifications
UVC Bulb:
UVC Strength:
Wavelength:
Size:
Weight:
Model:
Power: 120v
16w
254nm NO OZONE UVC
2350 uW/cm2
16”W x 10”D x 27”H
10lbs
ASLG16254
© 2020 Germozap LLC
Seal Beach CA
All Rights Reserved
Made in China
EPA Co No. 97721
Distributed by
4-in-1Filter
(1)
UVC Air Sanitizer
(1)
Remote Control
(1)
Reset
Timer
Sleep
Speed Auto
Auto
On/Off
Sterilize Anion
Fan Speed Mode Time On/Off
AQIGood
Purif
Time
Speed
Sleep
AUTO
Anio
UV
PM2.
TEMPERATURE
AQI Medium
F
H
