FujiFilm X-A7 Owner's manual

New Features Guide

Version 1.30

Features added or changed as a result of rmware updates may no

longer match the descriptions in the documentation supplied with

this product. Visit our website for information on the updates avail-

able for dierent products:

https://fujifilm-x.com/support/download/firmware/

BL00005107-200 EN

Contents

X-A7 rmware version 1.30 adds or updates the features

listed below. For information on earlier versions, visit the

following website.

http://fujifilm-dsc.com/en/manual/

No. Description X-A7

See

PVer.

1The “BATTERY LEVEL” item in the standard indicator dis-

play now defaults to R(on). 12, 161 1 1.02

The D CONNECTION SETTING> USB IMAGE

TRANSFER SETTING item in the setup menu

has been renamed USB MODE and now contains

an option that lets the camera serve as a webcam.

171 2 1.30

3A MY MENU SETTING option has been added to

DUSER SETTING in the setup menu.

154, 174,

175

1.10

The camera now supports instax mini Link smart-

phone printers, resulting in changes to the instax

PRINTER PRINT item in the playback menu

and the DCONNECTION SETTING > instax

PRINTER CONNECTION SETTING item in the

setup menu.

149, 171,

197, 198,

201

1.20

Changes and Additions

Changes and additions are as follows.

X-A7 Owner’s Manual: P12, 161 Ver. 1.02

Customizing the Standard Display

DISP. CUSTOM SETTING

Choose the items shown in the standard indicator display.

1 In shooting mode, use the DISP/BACK button to display stan-

dard indicators.

2 Press MENU/OK and select DSCREEN SET-UP> DISP. CUSTOM

SETTING in the D(SET UP) tab.

3 Highlight items and press MENU/OK to select or deselect.

Item

Default

FRAMING GUIDELINE R

ELECTRONIC LEVEL R

FOCUS FRAME R

AF DISTANCE INDICATOR R

MF DISTANCE INDICATOR R

HISTOGRAM R

SHOOTING MODE R

APERTURE/S-SPEED/ISO R

INFORMATION BACKGROUND R

Expo. Comp. (Digit) R

Expo. Comp. (Scale) R

FOCUS MODE R

PHOTOMETRY R

Item

Default

SHUTTER TYPE R

FLASH R

CONTINUOUS MODE R

DUAL IS MODE R

WHITE BALANCE R

FILM SIMULATION R

DYNAMIC RANGE R

FRAMES REMAINING R

IMAGE SIZE/QUALITY R

MOVIE MODE & REC.TIME R

IMAGETRANSFER ORDER R

BATTERY LEVEL R

4 Press DISP/BACK to save changes.

5 Press DISP/BACK as needed to exit the menus and return to the

shooting display.

X-A7 Owner’s Manual: P171 Ver. 1.30

USB MODE

Choose a mode for USB connections to computers, smartphones,

and tablets.

Option

Description

USB CARD READER

USB CARD READER Pictures can be transferred when the camera is connected

to a computer, smartphone, or tablet via USB.

USB WEBCAM

USB WEBCAM When connected to a computer via USB, the camera func-

tions as a webcam.

OFF

OFF Data transfer is disabled when the camera is connected to a

computer, smartphone, or tablet via USB.

• Select USB CARD READER for USB MODE before connecting the

USB cable to transfer pictures to a computer, smartphone, or tablet

(X-A7 Owner’s Manual, P195).

• Select USB WEBCAM for USB MODE before connecting the cam-

era for use as a webcam. “FUJIFILM X-A7”will be displayed when the

computer detects the camera.

• The webcam feature is supported under Windows 10 (x64), macOS

10.14 (Mojave), and macOS 10.15 (Catalina).

• When USB WEBCAM is selected:

⁃ HIMAGE QUALITY SETTING and ASHOOTING SETTING cannot

be adjusted,

⁃ apart from the ON/OFF button and rear command dial (which can be

used only for exposure compensation), camera controls cannot be used,

⁃ GAF/MF SETTING> PRE-AF is xed at ON and the camera focus-

es only on the subject in the center focus area,

⁃ GAF/MF SETTING> FACE/EYE DETECTION SETTING is set to

FACE DETECTION ON,

⁃ HDMI output is not available,

⁃ audio from built-in and external microphones is not output to the

connected device,

⁃ images are not displayed in the LCD monitor, and

⁃ the AF lamp will light if the battery is low; insert a spare battery if

available.

• For more information on web conferencing, see the documentation

for the web conference application.

X-A7 Owner’s Manual: P154 Ver. 1.10

MY MENU SETTING

Edit the items listed in the E(MY MENU) tab, a personalized cus-

tom menu of frequently-used options (P4).

X-A7 Owner’s Manual: P174 Ver. 1.10

Shortcut Options

Frequently-used options can be added to “my menu” or the Q

menu or assigned to the function button (Fn1) or touch function

buttons (T.B.Fn1/T.B.Fn2) for direct access:

• My menu (P4): Add frequently-used options to this custom

menu, which can be viewed by pressing MENU/OK and selecting

the E(“MY MENU”) tab.

• The Q menu: The Qmenu is displayed by pressing the Qbutton.

Use the Qmenu to view or change the options selected for fre-

quently-used menu items.

• The function button: Use the function (Fn1) button for direct access

to selected features.

• Touch function buttons: Use the touch function buttons (T.B. Fn1/

T.B.Fn2) in the touch menu for direct access to selected features.

X-A7 Owner’s Manual: P175 Ver. 1.10

MY MENU

Access a personalized menu of frequently-used options.

To display “my menu”, press MENU/OK in the

shooting display and select the

(MY

MENU) tab.

EXIT

SELF-TIMER

INTERVAL TIMER SHOOTING

FILM SIMULATION

PORTRAIT ENHANCER LVW

SHUTTER TYPE

IS MODE

WIRELESS COMMUNICATION

MY MENU

FACE/EYE DETECTION SETTING

The Etab is only available if options have been assigned to

MY MENU.

MY MENU SETTING

To choose the items listed in the E(MY MENU) tab:

1 Highlight DUSER SETTING> MY

MENU SETTING in the D(SET UP)

tab and press MENU/OK.

ADD ITEMS

RANK ITEMS

REMOVE ITEMS

MY MENU SETTING

To reorder items, select RANK ITEMS. To delete items, select

REMOVE ITEMS.

2 Press the focus stick (focus lever) up

or down to highlight ADD ITEMS and

press MENU/OK. Options that can be

added to “my menu” are highlighted

in blue.

FILM SIMULATION

IMAGE SIZE

IMAGE QUALITY

PORTRAIT ENHANCER LV

HIGHLIGHT TONE

DYNAMIC RANGE

WHITE BALANCE

BRIGHT MODE

MY MENU SETTING

SELECT CANCEL

Items currently in “my menu”are indicated by check marks.

3 Choose a position for the item and

press MENU/OK. The item will be added

to “my menu”.

IMAGE SIZE

IMAGE QUALITY

SELECT ITEM LOCATION

MOVE SAVE

4 Press MENU/OK to return to the edit display.

5 Repeat Steps 3 and 4 until all the desired items have been

added.

“My menu”can contain up to 16 items.

X-A7 Owner’s Manual: P149, 198 Ver. 1.20

instax PRINTER PRINT

Printing Pictures

Pictures can be printed using optional instax SHARE and instax

mini Link printers. The printer must rst paired with the camera

using DCONNECTION SETTING > instax PRINTER CONNECTION

SETTING.

instax SHARE Printers

1 Turn the printer on.

2 Select instax PRINTER PRINT in

the playback menu, then highlight

instax Wi-Fi CONNECTION and press

MENU/OK.

PRINTER PRINT

Wi-Fi CONNECTION

EXIT

Bluetooth CONNECTION

3 The camera will connect to the printer.

FUJIFILM-CAMERA-1234

PRINTER PRINT

CONNECTING

CANCEL

instax-12345678

4 Use the focus stick (focus lever) to

display the picture you want to print,

then press MENU/OK.

100-0020

instax-12345678

PRINTER PRINT

SET CANCEL

• Pictures taken with other cameras cannot be printed.

• Pictures are cropped and printed at a size selected automatically

by the printer, and consequently not all the picture appears in

the printed copy.

•

The displays may vary depending on the printer connected.

5 The picture will be sent to the printer and printing will start.

instax mini Link Printers

1 Turn the printer on.

2 Select instax PRINTER PRINT in

the playback menu, then highlight

instax Bluetooth CONNECTION and

press MENU/OK.

Wi-Fi CONNECTION

PRINTER PRINT

Bluetooth CONNECTION

EXIT

3 The camera will connect to the printer.

FUJIFILM-CAMERA-1234

PRINTER PRINT

CONNECTING

CANCEL

instax-12345678

4 Use the focus stick (focus lever) to

display the picture you want to print,

then press MENU/OK.

100-0020

instax-12345678

PRINTER PRINT

SET CANCEL

• Pictures taken with other cameras cannot be printed.

•

Pictures are cropped and printed at a size selected automatical-

ly by the printer, and consequently not all the picture appears

in the printed copy.

•

The displays may vary depending on the printer connected.

5 The picture will be sent to the printer and printing will start.

The camera cannot connect to a smartphone while connected to an

instax mini Link printer.

X-A7 Owner’s Manual: P171, 197 Ver. 1.20

instax PRINTER CONNECTION SETTING

Establishing a Connection

Adjust settings for connection to an optional instax SHARE or

instax mini Link printer.

instax SHARE Printers

Select DCONNECTION SETTING > instax

PRINTER CONNECTION SETTING, then

highlight instax Wi-Fi CONNECTION,

press MENU/OK, and enter the instax SHARE

printer SSID and password.

PRINTER CONNECTION SETTING

Wi-Fi CONNECTION

EXIT

Bluetooth CONNECTION

The Printer Name (SSID) and Password

The printer name (SSID) can be found on the

bottom of the printer; the default password is

“1111”. If you have already chosen a dierent

password to print from a smartphone, enter

that password instead.
