FujiFilm FinePix Z3 User manual
BL00547-200(1) E
Camera Controls
FPT/Y-608104-PY
Picture Taking
Refer to Owner’s Manual for more detailed instructions
OPEN
A. Loading the Battery
Make sure that the indicators are aligned. Push the battery release
catch down while loading the battery.
Check that the battery is firmly held in place.
C. Setting up the Camera
B. Charging the Battery
Set the camera in the cradle.
Plug the connecting
cable into the power
outlet.
When connecting is completed, battery charging begins. Charging
ends when the indicator lamp turns off (about 2 hours).
Open the lens cover completely to turn
the camera on.
1.
screen appears on the LCD
monitor.
2.
SET NO
START MENU
/ LANG.
Press n, o, p, or q to select the
language.
3.
D. Taking Pictures
Still images that can be viewed on FinePix Z3
You can use this camera to view still images recorded on FinePix Z3 or still
images (excluding some uncompressed images) recorded on a FUJIFILM
digital camera that supports xD-Picture Card.
Press the shutter button down halfway to
adjust the focus.
Press the shutter button down fully to
take a picture. The camera makes a
“Click” sound and takes the picture.
FinePix Z3 has internal memory that can store images without
xD-Picture Card. Use an xD-Picture Card (sold separately) when
recording a large number of images.
Press p or q to select Year, Month,
Day, Hour, or Minute. Press n or o to
correct the setting.
✽ Refer to the Owner’s Manual for
“Turning On and Off”.
2.
3.
Halfway pressed
You can select your preferred date
format.
5.
SET NO
DATE / TIME NOT SET
YY.MM.DD 1. 1 12:00
AM
E. Viewing the Images
Press w.
Press p or q to move through your
images.
2.
1.
Double
beep
Click
6.
Set the Mode switch to q.
1.
4.
Plug the connecting
cable into the AC
power adapter.
1.
3.
5.
Flash
Microphone
Lens
Speaker
Mode switch
Shutter button
Self-timer lamp
POWER switch/
Lens cover
DISP/BACK
W
T
MENU
/OK
W (Wide zoom)
button
T (Tele zoom)
button
Photo mode
(p) button
Strap mount
MENU/OK button
Picture stabilization
button
DISP (Display)/
BACK button
Indicator lamp
w (Playback) button
LCD monitor
4-direction nopq button
Battery cover
Cradle connection socket
xD-Picture Card slot
Battery release catch
Battery compartment
Battery release catch
Indicators
Plug the AC power
adapter connector into
the DC IN 5V socket
on the cradle.
2.
Fully pressed
Press MENU/OK to confirm the setting.
4.
Viewing Images on your PC
For more information
Refer to “How to use FinePixViewer” in the HELP menu, or “Software
Installation” in the Owner’s Manual, or visit Fujifilm “Q&A Search” in the
following website.
( http://home.fujifilm.com/products/digital/ )
For Macintosh users, refer to “Software Installation” in the Owner’s
Manual.
A. Installing Software
Do not connect the camera to your PC until the software
installation is completed.
1. Turn on your PC and start up Windows.
●
!
Users of Windows 2000 Professional or Windows XP
should log in by using a system administrator account (e.g.
“Administrator”).
2. Quit all other active applications until no applications are
shown in the taskbar.
3. Load the enclosed CD-ROM into
the CD-ROM drive. The installer
starts up automatically.
4. The Setup screen appears.
Click the [Installing
FinePixViewer] button.
5. After installation completed, press [Close] button.
B. Connecting the Camera to your PC
1. Insert the xD-Picture Card with images into the camera.
2. Connect the camera to your PC using the USB cable (mini-B).
C. Saving the Images
1. The Save Image Wizard starts up. Click the [Start] button.
2. Check that the files are downloaded from the camera to your
PC and that a folder with the date is created.
Ex. \My Documents \ My Pictures \ 2006_0624
2.
Select “Preview” in the View menu to display an enlarged image.
D. Viewing the Images
1. Click the [Show List of Images] button.
Windows XP
The “Found New Hardware” help message appears in the
bottom-right corner of your screen. This message will close
when the settings are completed. No action is required.
FinePixViewer starts up automatically.
A.Installing Software
A.Installing Software
B.Connecting the Camera to your PC
B.Connecting the Camera to your PC
C.Saving the Images
C.Saving the Images
3. Press POWER on the cradle to turn the camera on in
Playback mode.
4.
Windows 98/98 SE/Me/2000 Professional
FinePixViewer starts up automatically.
AC-5VC
USB cable (mini-B)
