FujiFilm X-T30 Owner's manual

New Features Guide

Version 1.20

Features added or changed as a result of rmware updates may no

longer match the descriptions in the documentation supplied with

this product. Visit our website for information on the updates avail-

able for dierent products:

https://fujifilm-x.com/support/download/firmware/

BL00005083-200 EN

Contents

X-T30 rmware version 1.20 adds or updates the features

listed below. For information on earlier versions, visit the

following website.

http://fujifilm-dsc.com/en/manual/

No. Description X-T30

See

PVer.

1The Q(quick menu) button can now be used as an

Fn (function) button.

204, 225,

228, 230 1, 2, 4 1.10

Movie recording can now be controlled from external

devices, and the DCONNECTION SETTING> PC

CONNECTION MODE item in the setup menu has

consequently been renamed CONNECTION MODE.

218 5 1.20

Changes and Additions

Changes and additions are as follows.

X-T30 Owner’s Manual: P225 Ver. 1.10

The Q (Quick Menu) Button

Press Qfor quick access to selected options.

• Use DBUTTON/DIAL SETTING > FUNCTION (Fn) SETTING to

choose the function performed by the Q(quick menu) button or as-

sign its default function to other controls.

• To disable the Q(quick menu) button, select NONE for DBUTTON/

DIAL SETTING > FUNCTION (Fn) SETTING > Q BUTTON SETTING.

The Quick Menu Display

At default settings, the quick menu contains the following items:

BASE

400

SELECT CUSTOM SETTING

ENDSET

SELECT CUSTOM SETTING

ISO

DYNAMIC RANGE

WHITE BALANCE

NOISE REDUCTION

IMAGE SIZE

IMAGE QUALITY

FILM SIMULATION

HIGHLIGHT TONE

SHADOW TONE

COLOR

SHARPNESS

SELF-TIMER

AF MODE

FLASH FUNCTION SETTING

EVF/LCD BRIGHTNESS

X-T30 Owner’s Manual: P228 Ver. 1.10

The Fn (Function) Buttons

Assign a role to the function buttons for quick access to the

selected feature.

• The functions assigned to T-Fn1 through T-Fn4 can be accessed by

icking the monitor.

• Touch-function gestures are disabled by default. To enable

touch-function gestures, select ON for DBUTTON/DIAL SETTING>

TOUCH SCREEN SETTING> cTOUCH FUNCTION.

The default assignments are:

Fn1 button

Performance

AE-L button

AE lock only

Q button

Quick menu

AF-L button

AF lock only

T-Fn1 (ick up)

Drive setting

T-Fn2 (ick left)

Film simulation

T-Fn3 (ick right)

White balance

T-Fn4 (ick down)

AF mode

Center of rear command dial

Focus check

X-T30 Owner’s Manual: P204, 230 Ver. 1.10

FUNCTION (Fn) SETTING

Assigning Roles to the Function Buttons

3 Highlight the desired role and press MENU/OK to assign it to

the selected control. Choose from:

• IMAGE SIZE

• IMAGE QUALITY

• RAW

• FILM SIMULATION

• GRAIN EFFECT

• COLOR CHROME EFFECT

• DYNAMIC RANGE

• D RANGE PRIORITY

• WHITE BALANCE

• SELECT CUSTOM SETTING

• FOCUS AREA

• FOCUS CHECK

• AF MODE

• AF-C CUSTOM SETTINGS

• nFACE SELECT op

• FACE DETECTION ON/OFF

• DRIVE SETTING

• SPORTS FINDER MODE

• PRE-SHOT sJ

• SELF-TIMER

• PHOTOMETRY

• SHUTTER TYPE

• FLICKER REDUCTION

• ISO

• IS MODE

• WIRELESS COMMUNICATION

• FLASH FUNCTION SETTING

• TTL-LOCK

• MODELING FLASH

• FULL HD HIGH SPEED REC

• ZEBRA SETTING

• INTERNAL/EXTERNAL MIC LEVEL

ADJUSTMENT

• MOVIE SILENT CONTROL

• PREVIEW DEPTH OF FIELD

• PREVIEW EXP./WB IN MANUAL MODE

• NATURAL LIVE VIEW

• HISTOGRAM

• ELECTRONIC LEVEL

• LARGE INDICATORS MODE

• AE LOCK ONLY

• AF LOCK ONLY

• AE/AF LOCK

• AF-ON

• AWB LOCK ONLY

• APERTURE SETTING

• PERFORMANCE

• AUTO IMAGE TRANSFER

• SELECT PAIRING DESTINATION

• Bluetooth ON/OFF

• PLAYBACK

• QUICK MENU

• NONE (control disabled)

X-T30 Owner’s Manual: P218 Ver. 1.20

CONNECTION MODE

Adjust settings for connection to external devices.

Option

Description

USB CARD READER

Connecting the camera to a computer via USB automatical-

ly enables data transfer mode, allowing data to be copied

to the computer. The camera functions normally when not

connected.

USB MOVIE

SHOOTING AUTO *

The camera’s movie-recording features can be controlled

from gimbals, drones, or other devices connected via USB.

The camera automatically enters“tethered shooting” (i.e., re-

mote-control) mode when the external device is turned on

and returns to normal operation when the external device

turned oﬀ or disconnected. The features available vary with

the type of device connected.

USB MOVIE

SHOOTING FIXED *

As for USB MOVIE SHOOTING AUTO, except that the

camera remains in “tethered shooting” (remote-control)

mode when the external device is oﬀ or not connected, al-

lowing the device to resume control when the connection

is re-established after an accidental disconnection or other

disruption.

USB RAW CONV./

BACKUP RESTORE

Connecting the camera to a computer via USB automatical-

ly enables USB RAW conversion/backup restore mode. The

camera functions normally when not connected.

• USB RAW CONV. (requires FUJIFILM X RAW STUDIO): Use the

camera’s image processing engine to rapidly convert RAW

ﬁles to high-quality JPEG images.

• BACKUP RESTORE (requires FUJIFILM X Acquire): Save and load

camera settings. Reconﬁgure the camera in an instant or

share settings with other cameras of the same type.

* Rotate the drive dial to F(movie).

DPOWER MANAGEMENT> AUTO POWER OFF settings also apply

when the camera is connected to an external device. To prevent the

camera turning o automatically, select OFF for AUTO POWER OFF.

7-3, AKASAKA 9-CHOME, MINATO-KU, TOKYO 107-0052, JAPAN

https://fujifilm-x.com
