24-INCH BUILT-IN

DISHWASHER

Model No.

GLD2440RE

Publication No: 5995439642 GLD2440RE

06/05 2

CONTROL PANEL

P30C0143

GLD2440RE Publication No: 5995439642

# Functional Parts 3 06/05

* Non-Illustrated Parts

CONTROL PANEL

Model Index: AGLD2440RE (GLD2440REB0)

BGLD2440RE (GLD2440REC0)

CGLD2440RE (GLD2440REQ0)

DGLD2440RE (GLD2440RES0)

POS. NO PART NO. DESCRIPTION

1 154486003 A B - - Panel, control, black

1 154486004 - - C - Panel, control, bisque

1 154486001 - - - D Panel, control, white

2 154483803 A B - - Insert, control panel, black, 10 pad

2 154483804 - - C - Insert, control panel, bisque, 10 pad

2 154483801 - - - D Insert, control panel, white, 10 pad

3 154555004 A B C D Board, control

3* 154200401 A B C D Screw, 6-10 x 3/8, pan plask

4 154554601 A B C D Cover, control

4* 154478901 A B C D Gasket, cover

8 # 154474601 A B C D Switch, selector, 10 pad

8A 154486201 A B C D Shield, tactile switch

20 154423601 A B C D Vent assy, active dry, w/actuator

20* 154436201 A B C D Screw, dry duct, (3)

27 154433501 A B C D Actuator, active dry vent

28 154474401 A B C D Adapter, vent

* # 154468901 A B C D Harness, wiring

* 154540024 A B C D Energy guide label

Publication No: 5995439642 GLD2440RE

06/05 4

DOOR

GLD2440RE Publication No: 5995439642

# Functional Parts 5 06/05

* Non-Illustrated Parts

DOOR

Model Index: AGLD2440RE (GLD2440REB0)

BGLD2440RE (GLD2440REC0)

CGLD2440RE (GLD2440REQ0)

DGLD2440RE (GLD2440RES0)

POS. NO PART NO. DESCRIPTION

1 154430501 A B C D Spring, door, (2)

1A 154325201 A B C D Linkage, door spring, (2)

2 154093301 A B C D Screw, arm assy, (4)

3 154558102 A B C D Arm Assy, LH

3A 154558502 A B C D Arm Assy, RH

* 154529101 A B C D Pin, arm assy

5 154079601 A B C D Nut, arm assy, and handle mtg.

7 154494601 A B C D Liner, door assy.

9 154452704 A B C D Dispenser, det/rinse aid, w/reed

9* 154294701 A B C D Screw, #7 plas .375, (6), disp. assy.

10 154103702 A B C D Screw, latch mtg, (2)

12 # 154529403 A B - - Latchassy, black

12 # 154529404 - - C - Latch assy, bisque

12 # 154529401 - - - D Latch assy, white

20 154436803 A - - - Door Assy, black, outer

20 154533401 - B - - Door, stainless

20 154436804 - - C - Door Assy, bisque, outer

20 154436801 - - - D Door Assy, white, outer

20* 154253201 A B C D Insulation, door

20* 5304428306 A B C D Screw, door mtg., (2)

49 154297603 A B C D Gasket, door, bottom

50 154211401 A B C D Support, door hinge

51 154320301 A B C D Clamp, drip loop, wire

Publication No: 5995439642 GLD2440RE

06/05 6

TUB

GLD2440RE Publication No: 5995439642

# Functional Parts 7 06/05

* Non-Illustrated Parts

TUB

Model Index: AGLD2440RE (GLD2440REB0)

BGLD2440RE (GLD2440REC0)

CGLD2440RE (GLD2440REQ0)

DGLD2440RE (GLD2440RES0)

POS. NO PART NO. DESCRIPTION

1 # 154534701 A B C D Tub assy, w/frame parts

2 154429101 A B C D Strike, door

3 # 154211801 A B C D Gasket, tub

4 154200602 A B C D Screw, 10-16 x 3/8, hex

5 154333902 A B C D Roller, tub

6 5303943103 A B C D Screw, w/washer, (8)

22 154446002 A B C D Tubing, water inlet

23 5303318539 A B C D Clamp, tubing, (2)

24 # 154525301 A B C D Hose, drain

25 # 154209701 A B C D Float

28 154408701 A B C D Switch Assy, float

29 # 154290204 A B C D Thermostat, re-settable

30 154241101 A B C D Retainer, thermostat

30* 154297701 A B C D Screw, retainer-thermo

* 154447102 A B C D Insulation,blanket

* 154447301 A B C D Insulation, tub back

* 154041001 A B C D Screw, plask #1, 10-10 x 9/16

* 5300807270 A B C D Screw, (2), countertop mtg.

Publication No: 5995439642 GLD2440RE

06/05 8

MOTOR & PUMP

GLD2440RE Publication No: 5995439642

# Functional Parts 9 06/05

* Non-Illustrated Parts

MOTOR & PUMP

Model Index: AGLD2440RE (GLD2440REB0)

BGLD2440RE (GLD2440REC0)

CGLD2440RE (GLD2440REQ0)

DGLD2440RE (GLD2440RES0)

POS. NO PART NO. DESCRIPTION

1 # 154482901 A B C D Heater, round

1* 154106201 A B C D Nut, heater, (2)

1* 154289801 A B C D Shield, heater terminal

2 154465101 A B C D Bracket, heater, (2)

10 154245501 A B C D Cover, volute

13 154246801 A B C D Gasket, sump

14 154461902 A B C D Housing, sump

16 154246502 A B C D Retainer, sump

24 154467702 A B C D Spray arm, grey, lower

24A 154468502 A B C D Spray arm, grey, center

24B 154478201 A B C D Spray arm, 3rd level

32 154464101 A B C D Tube, delivery

32* 154491101 A B C D Screw, delivery tube

32A 154406401 A B C D Gasket, delivery tube

40 154348401 A B C D Clamp, red, pump

40 154348502 A B C D Clamp, red, pump

40* 154106801 A B C D Clamp, hose, (2)

40* 154380601 A B C D Clamp, hose, (1)

54 154234401 A B C D Hose, connector

55 154362301 A B C D Bracket, motor, askoll

55* 5303316032 A B C D Screw, truss ss, 8 .625

58 154246402 A B C D Check ball

59 154246901 A B C D O-ring, rear

59A 154247001 A B C D O-ring, front

60 154491301 A B C D Pump, drain

60* 5303318719 A B C D Screw, mtg.

61 154463402 A B C D Grommet, delivery tube

62 154294102 A B C D Support, spray arm, grey, lower

63 154252201 A B C D Base, soil director

64 154252302 A B C D Filter, soil director, grey

65 154283005 A B C D Filter Assy, grey

66 154252702 A B C D Trap, glass, grey

70 # 154536101 A B C D Motor assembly, circulation, w/o o'rings

71 # 154473901 A B C D Sensor, turbidity

71* 154376001 A B C D O-ring, turbidity

* 154200601 A B C D Screw, #10-16 x 3/8

Publication No: 5995439642 GLD2440RE

06/05 10

FRAME
