Four-Faith F1003 User manual

F1X03 Series

User Manual

Documentation No.

Product Version

Page

Product Name：

Total:

F1X03 Series User Manual

The user manual is suitable for the following model:

Model

Product Type

F1003

GSM MODEM

F1103

GPRS MODEM

F1203

CDMA MODEM

F1303

EDGE MODEM

F1403

WCDMA MODEM

F1503

TD-SCDMA MODEM

F1603

EVDO MODEM

Xiamen Four-Faith Communication Technology Co., Ltd.

Add：J1-J3,3rd Floor,No.44,GuanRi Road,SoftWare

Park,XiaMen,China Zip Code:361008

Tel：+86 592-6300326 ，6300325，6300324

Fax:+86 592-5912735

http://www.fourfaith.com

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 2 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

Files Revised Record

Date

Version

Remark

Author

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 3 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

All contents in the files are protected by copyright law, and all copyrights are reserved by Xiamen

Four-Faith Communication Technology Co., Ltd. Without written permission, all commercial

use of the files from Four-Faith are forbidden, such as copy, distribute, reproduce the files, etc.,

but non-commercial purpose, downloaded or printed by individual (all files shall be not revised,

and the copyright and other proprietorship notice shall be reserved) are welcome.

Trademark Notice

Four-Faith、四信、、、 are all registered trademarks of Xiamen

Four-Faith Communication Technology Co., Ltd., illegal use of the name of Four-Faith,

trademarks and other marks of Four-Faith is forbidden, unless written permission is authorized in

advance.

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 4 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 5 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

Chapter 1 Brief Introduction of Product...........................................................................................6

1.1 General................................................................................................................................6

1.2 Features and Benefits..........................................................................................................6

1.3 Working Principle ...............................................................................................................7

1.4 Specifications......................................................................................................................7

Chapter 2 Installation Introduction.................................................................................................10

2.1 General..............................................................................................................................10

2.2 Encasement List................................................................................................................10

2.3 Installation and Cable Connection....................................................................................10

2.4 Power ................................................................................................................................11

2.5 Indicator Lights Introduction ............................................................................................11

Chapter 3 Dial-Up Settings.............................................................................................................13

3.1 MODEM Connection........................................................................................................13

3.2 Dial-Up Settings................................................................................................................13

Chapter 4 SMS Test ........................................................................................................................29

Chapter 5Appendix ........................................................................................................................32

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 6 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

Chapter 1 Brief Introduction of Product

1.1 General

F1X03 series MODEM is a kind of cellular terminal device that provides SMS, dial-up and

CSD function by public cellular network.

It adopts high-powered industrial cellular module and supports RS232 port that can

conveniently connect one device to a cellular network, allowing you to connect to your existing

serial device.

It has been widely used on M2M fields, such as intelligent transportation, smart grid,

industrial automation, telemetry, finance, POS, water supply, environment protection, post,

weather, and so on.

1.2 Features and Benefits

Design for IndustrialApplication

High-powered industrial cellular module

Housing: iron, providing IP30 protection

Power range: DC 5~35V

Stability and Reliability

RS232 port: 15KV ESD protection

SIM/UIM port: 15KV ESD protection

Power port: reverse-voltage and overvoltage protection

Antenna port: lightning protection(optional)

Standard and Convenience

Support standard RS232 port that can connect to a serial device directly

Provide dial-up software that can make it always online

Provide SMS tool software

Support standard AT command

High-performance

Support SMS

Support dial-up（Except F1003）

CSD function(F1003/F1103)

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 7 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

SupportAPN/VPDN（Except F1003）

1.3 Working Principle

The principle chart of the MODEM is as following:

1.4 Specifications

Cellular Specification

Standard and Band

Bandwidth

TX power

sensitivity

F1003 GSM MODEM

EGSM900/GSM1800MHz,

GSM850/900/1800/1900MHz(optional)

Compliant to GSM phase 2/2+

14.4Kbps CSD

GSM850/900：

<33dBm

GSM1800/1900 ：

<30dBm

<-107dBm

F1103 GPRS MODEM

EGSM900/GSM1800MHz,

GSM850/900/1800/1900MHz(optional)

Compliant to GSM phase 2/2+

GPRS class 10, class 12(optional)

85.6Kbps

GSM850/900：

<33dBm

GSM1800/1900 ：

<30dBm

<-107dBm

F1203 CDMA MODEM

CDMA2000 1xRTT 800MHz,

800/1900MHz(optional),450MHz(optional)

153.6Kbps

<30dBm

<-104dBm

F1303 EDGE MODEM

GSM850/900/1800/1900MHz

GPRS/EDGE Class 12

236.8Kbps

GSM850/900：

<33dBm

<-106dBm

Cellualr Module

Power

RS232 serial

Interface

Indicator lights

User interface

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 8 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

GSM1800/1900 ：

<30dBm

F1403 WCDMA MODEM

UMTS/WCDMA/HSDPA/HSUPA

850/1900/2100MHz,

850/900/1900/2100MHz(optional)

GSM850/900/1800/1900MHz

GPRS/EDGE CLASS 12

HSUPA:5.76Mbps(Upl

oad speed)/

HSDPA:7.2Mbps(Down

load speed)

UMTS:384Kbps

(DL/UL)

<24dBm

<-109dBm

F1503 TD-SCDMA MODEM

TD-SCDMA/HSDPA/HSUPA

1880-1920/2010-2025MHz

GSM850/900/1800/1900MHz

GPRS/EDGE CLASS 12

Download

speed:2.8Mbps, upload

speed:2.2Mbps

<24dBm

<-108dBm

F1603 EVDO MODEM

CDMA2000 1X EVDO Rev A

800MHz,800/1900MHz(optional),

450MHz (optional)

CDMA2000 1X RTT, IS-95 A/B

Download

speed:3.1Mbps, upload

speed:1.8Mbps

<23dBm

<-104dBm

Interface Type

Item

Content

Serial

1 RS232 port, 15KV ESD protection

Data bits: 5, 6 ,7, 8

Stop bits: 1, 1.5, 2

Parity: none, even, odd, space, mark

Baud rate: 110~230400 bps

Indicator

"Power", "ACT", "Online"

Antenna

Standard SMA female interface, 50 ohm, lighting protection(optional)

SIM/UIM

Standard 3V/1.8V user card interface, 15KV ESD protection

Power

Standard 3-PIN power jack, reverse-voltage and overvoltage protection

Power Input

Item

Content

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 9 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

Standard Power

DC 12V/0.5A

Power Range

DC 5~35V

Consumption

<200mA (12V)

Physical Characteristics

Item

Content

Housing

Iron, providing IP30 protection

Dimensions

91x58.5x22 mm

Weight

195g

Environmental Limits

Item

Content

Operating

Temperature

-25~+65ºC （-13~+149℉）

Extended

Operating

Temperature

-30~+75ºC （-22~+167℉）

Storage

Temperature

-40~+85ºC（-40~+185℉）

Operating

Humidity

95% ( Non-condensing)

User Manual

Xiamen Four-Faith Communication Technology Co.,Ltd. Page 10 of 33

Add：J1-J3,3rdFloor,No.44,GuanRiRoad,SoftWare Park,XiaMen .361008.China

http：//www.fourfaith.com Tel：+86 592-6300326 6300325 6300324 Fax：+86 592-5912735

Chapter 2 Installation Introduction

2.1 General

The MODEM must be installed correctly to make it work properly.

Warning: Forbid to install the MODEM when powered!

2.2 Encasement List

Name

Quantity

Remark

MODEM host

Antenna

Power adapter

RS232 data cable

Manual CD

Certification card

Maintenance card

2.3 Installation and Cable Connection

Dimension: (unit: mm)

58.5

22 8

Ф3

Ф5
