Fortinet FortiGate 80F Series User manual

QuickStart Guide

FortiGate 80F Series

QuickStart Guide

Scan the QR Code or visit:

https://links.fortinet.com/fortiexplorer/downloads

FortiExplorer App

Rapidly provision, deploy, and monitor Security Fabric components including

FortiGate and FortiWiFi devices from your mobile. Download now for free.

Before you begin

firmware upgrades, technical support and warranty coverage.

http://support.fortinet.com

December 7, 2021

trademarks of Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or common law

trademarks of Fortinet. All other product or company names may be trademarks of their respective owners. Performance and other metrics

contained herein were attained in internal lab tests under ideal conditions, and actual performance and other results may vary. Network

variables, different network environments and other conditions may affect performance results. Nothing herein represents any binding

commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding

written contract, signed by Fortinet’s General Counsel, with a purchaser that expressly warrants that the identified product will perform

according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics expressly identified

in such binding written contract shall be binding on Fortinet. For absolute clarity, any such warranty will be limited to performance in the same

ideal conditions as in Fortinet’s internal lab tests. In no event does Fortinet make any commitment related to future deliverables, features or

development, and circumstances may change such that any forward-looking statements herein are not accurate. Fortinet disclaims in full

any covenants, representations, and guarantees pursuant hereto, whether express or implied. Fortinet reserves the right to change, modify,

transfer, or otherwise revise this publication without notice, and the most current version of the publication shall be applicable.

For Product License Agreement / EULA and Warranty Terms, visit https://www.fortinet.com/content/dam/fortinet/assets/legal/EULA.pdf

This guide covers: FG-80F, FG-81F, FG-80F-Bypass, FG-80F-POE, FG-81F-POE

This document is prepared in English and French. In case of conflict between them, the English version shall prevail over the French version.

English

FortiGate 80F Series

FG-80F, FG-81F, FG-80F-BYPASS, FG-80F-POE, and FG-81F-POE

Package Contents

FortiGate Device

1x Ethernet Cable

QuickStart Guide

1x Power Cable1x DC Power Adapter

The Essentials

For a detailed Getting Started guide, setup and configuration information,

refer to the Admin Guide on https://docs.fortinet.com/

For contracts, licensing, product registration and account management,

contact FortiCare Support at https://www.fortinet.com/support/contact

Access our knowledge base, forums, videos and technical experts at

https://www.fortinet.com/support/support-services/forticare-support

Default Logins

https://192.168.1.99

Username: admin

Password:leave blank

Admin Guide

Customer Service

Self-service Resources

Thank you for choosing Fortinet

English

Additional Setup Options

Set up your Fortinet device locally or connect using forticloud.com

GUI

Ethernet Cable

Management Computer

Port 1

https://192.168.1.99

Username: admin

No Password

Note: For static IP configuration, use 192.168.1.1 with subnet mask

255.255.255.0

Console Port

Management Computer

Note: For a detailed CLI guide, visit docs.fortinet.com

USB Console Cable

(available for purchase)

CLI

FortiGate Cloud Key

Go to forticloud.com and login with your FortiCloud Credentials or Register

Follow the on-screen instructions, then click Add FortiGate

Enter the FortiGate Cloud Key located on the sticker of your device

(Connect a WAN port to the Internet)

Speed (default): 9600

Data bits: 8

Stop bits: 1

Parity: None

Flow Control: None

Quick Setup

Unpack the box, power the device, plug the Ethernet cable from a WAN port

to the Internet and launch FortiExplorer using one of the following:

Follow the on-screen instructions to complete your setup

FortiExplorer will automatically detect your device

If the device is not detected, navigate to My Fabric, tap Add and follow

the FortiExplorer’s on-screen instructions

Scan the FortiGate Cloud Key located on your Fortinet device

Enable Bluetooth on your Fortinet device and your mobile, then place

them near each other

Connect your mobile to your Fortinet device with a USB cable

Navigate to My Fabric, then tap Add

BLE Auto Detection

Note: FortiExplorer can manage FortiGates without WiFi capabilities once

they have been provisioned to allow HTTP/S admin access

USB Connectivity

FortiGate Cloud Key Registration

-or-

English

8 9

FortiGate

Green: The device is on

Off: The device is off

Green: Both power supplies are functioning

Amber: One power supply is functioning

Off:Power is off

Amber: Bypass Port Pair is active

Off: Bypass Port Pair is off

Green: Operating normally; BLE is off

Flashing Green: Booting up

Flashing Amber: BLE is on

LOGO

POWER

STATUS

BYPASS

PORT

LINK/ACT

WAN

BLE/RESET Activates BLE management or restores to factory default

SFP

Green: Operating in an HA cluster

Amber: HA failover

Off: Not in an HA cluster

Flashing Green: 1000M/100M/10M data activity

Off: No link established

Flashing Green:1000M/100M/10M data activity

Off: No link established

Flashing Green: 1000M/100M/10M data activity

Off: No link established

Front - FG 80F Series

41 2 63 5











Back - FG 80F Series

Power Input 12V DC 3A, 100-240V AC 50/60Hz



 CLI management computer interface

Grounding Screw additional protective earth connection, reserved for

applications where a permanent local connection of protective earth is required

 1 Gbps Ethernet interface

 1 Gbps Ethernet interface

 1 Gbps Ethernet interface

 1 Gbps SFP interface

1 Gbps Ethernet interface

7 8

 USB 3.0 server port

SFP 1 WAN 1

WAN 2

2 4 6 B

3 5 A

SFP 2 – shared –

– shared –CONSOLE

USB

421 3 5 6

—BYPASS—



English

10 11



Power Input 54V DC 2.78A, 100-240V AC 50/60Hz

 CLI management computer interface

 1 Gbps Ethernet interface

 1 Gbps Ethernet interface

 1 Gbps SFP interface

1 Gbps Ethernet interface

6 7

 USB 3.0 server port

421 3 5

SFP 1 WAN 1

WAN 2

2 4 6 B

3 5 A

SFP 2 – shared –

– shared –CONSOLE

USB 54V 54V

1Grounding Screw additional protective earth connection, reserved for

applications where a permanent local connection of protective earth is required



FortiGate

Green:The device is on

Off:The device is off

Green: Both power supplies are functioning

Amber: One power supply is functioning

Off: Power is off

LOGO

PWR

STATUS

SFP/WAN



 Activates BLE management or restores to factory default

Ports

Green: Operating in an HA cluster

Amber: HA failover

Off: Not in an HA cluster

Flashing Green:1000M/100M/10M data activity

Off:No link established

Flashing Green: 1000M/100M/10M data activity

Off: No link established

Green:Operating normally; BLE is off

Flashing Green:Booting up

Flashing Amber:BLE is on

41 2 6

3 5









Red: Providing Max PoE Power, 96W

Off: PoE power available

Green: PoE power on

Off: PoE power off

HAPWR

WAN1

WAN2

5 6

SFP1

PoE

SFP2 MAX

PoE

LINK/ACT

4321 A B

STATUS

BLE / RESET

English

Guide de démarrage rapide

Série FortiGate 80F

1312

Français

This page is intentionally left blank

Cette page a été laissée blanche intentionnellement

Balayez le code QR ou rendez-vous au:

https://links.fortinet.com/fortiexplorer/downloads

FortiExplorer App

Configurez, installez et surveillez rapidement les éléments de votre Security

Fabric, dont les appareils FortiGate et FortiWiFi, à partir de votre appareil

mobile. Téléchargez l’application gratuite maintenant.

Avant de commencer

Enregistrez votre appareil pour avoir accès aux mises à jour, à la gestion

infonuagique, aux mises à niveau de micrologiciel, au soutien technique et à

la garantie de FortiGuard.

http://support.fortinet.com

1514
