Focal GRANDE UTOPIA BE User manual

Focal-JMlab®

BP 374 - 108, rue de l’Avenir - 42353 La Talaudière cedex - France - Tel. 00 33 4 77 43 57 00 - Fax 00 33 4 77 37 65 87 - www.focal-fr.com

• Unpacking procedure.

Procédure de déballage.

• Accessories per speaker.

Accessoires par enceinte.

1 - Right the packaging. Beware the up and down

sides. 4 people required.

1 - Redressez l’emballage en respectant le sens.

4 personnes minimum.

2 - Unscrew the side panel of the bo and

remove it.

2 - Dévissez le couvercle puis le retirer.

1 2

x 1 x 4 x 4 x 4

A B C D

Unpacking Grande Utopia Be

Déballage Grande Utopia Be

4 - Lay down the loudspeaker sideways on

a surface protected with felt or foam for

e ample. 4 people required.

4 - Couchez l’enceinte sur le ﬂanc sur une surface

protégée (feutre, mousse...).

4 personnes minimum.

4

3 - Install the ramp as indicated. Carefully pull

out the loudspeaker thanks to the girth.

3 - Placez les encoches de la rampe sur les 2 ergots

au bas de l’emballage. Dégagez l’enceinte douce-

ment en tirant sur la sangle.

3

A

6 - Assembly the cones without including

the spike. Insert the assembly under the

loudspeaker as indicated.

6 - Assemblez les cônes sur la tige ﬁletée sans la pointe

terminale, puis ﬁxez-les àla base de l’enceinte.

7 - Right again the loudspeaker.

4 people required.

7 - Redressez l’enceinte. 4 personnes minimum.

6

7

8 - Install the loudspeaker at the chosen location.

Insert the spikes by lifting the loudspeaker

one corner after the other.

8 - Approchez l’enceinte de son emplacement déﬁnitif.

Basculez l’enceinte sur le côtépour y insérer les

pointes terminales. Le cas échéant, utilisez des

coupelles sous les pointes pour protéger le sol.

8

22 mm

5 - Unscrew the lower plate using a 22mm

bo spanner.

5 - Dévissez les 4 vis pour dégager le plateau inférieur

au moyen d’une clef àdouille de 22 mm.

5

Unpacking Grande Utopia Be

Déballage Grande Utopia Be

B C

D

©Focal-JMlab-SCOS-030708/3

Focal-JMlab®

BP 374 - 108, rue de l’Avenir - 42353 La Talaudière cedex - France

Tel. 00 33 4 77 43 57 00 - Fax 00 33 4 77 37 65 87 - www.focal-fr.com
