Speciﬁcations

Parameters

Mechanical Drawing

Frequency Response / Impedance

©Focal-JMlab - SCFR041108/2

dB SPL Ohm

Log Frequency - Hz

20 100 1000 10000

Unit: mm

6 W3 Be

6.5’’ Utopia Be®woofer

100 W

200 W

89 dB

Rubber

4 ohm

3.22 ohm

40 mm 1.57 in

17 mm 0.7 in

Kapton®

Copper

0.69 mH

5.5 mm

eodymium

0.8 T

6 mm 0.25 in

0.9 kg 2 Ibs

55.28 Hz

9.92 I

0.765

0.82

11.42

3.22 ohm

132.73 cm2

7.07E-08 m5/

117.32 kg/m4

3568.36 ohm.ac

4.01E-04 m/

20.67 g

0.629 kg/s

733.18 mF

11.31 mH

44.84 ohm

5.31 /A

84.95 dB/W/m

100

105

•W cone

•Neodymium magnet

•Zamak basket

On axis, 0° and 45° off axis frequency response

Nominal power

Maximum power

Sensitivity (2.83V/m)

Cone

Surround

Nom. impedance

DC resistance

VC diameter

VC height

Former

Layers

Wire

Inductance

Xmax

Magnet

Flux density

Gap height

Net weight

Vas

Qts

Qes

Qms

Cas

Mas

Ras

Cms

Mms

Rms

Ces

Les

Res

SPL

Focal®is a trademark of Focal-JMlab®

108, rue de l'Avenir - BP 374 - 42353 La Talaudière cedex - France - Tel. +33 4 77 43 57 00 - Fax +33 4 77 43 57 04 - www.focal-fr.com

Speciﬁcations

Parameters

Mechanical Drawing

Frequency Response / Impedance

Ohm

Log Frequency - Hz

20 100 1000 10000

Unit: mm

3 W2 Be

3" Utopia Be® midrange

•W cone

•Neodymium magnet

•Zamak basket

100

110

100

20 100 1000 10000

On axis, 0° and 45° off axis frequency response

dB SPL

50 W

100 W

88 dB

Rubber

4 ohm

3.37 ohm

25 mm 1 in

8.5 mm

Kapton®

Aluminum

0.11 mH

2 mm 0.08 in

eodymium

1.2 T

4 mm 0.16 in

0.18 kg 0.4 Ib

188.74 Hz

0.31 I

0.729

0.770

13.790

3.37 ohm

30.19 cm2

2.18E-09 m5/

325.84 kg/m4

28021.38 ohm.ac

2.39E-04 m/

2.97 g

0.255 kg/s

192.67 mF

3.69 mH

60.35 ohm

3.93 /A

86.12 dB/W/m

Nominal power

Maximum power

Sensitivity (2.83V/m)

Cone

Surround

Nom. impedance

DC resistance

VC diameter

VC height

Former

Layers

Wire

Inductance

Xmax

Magnet

Flux density

Gap height

Net weight

©Focal-JMlab - SCFR041108/3
