Focal Access 1 210 CA1 User manual

©Focal-JMlab - AS050926/2

ø5,20

ø202

ø210

186

210 C A 1

8" Access 1 coaxial

Nominal power 80 W

Maximum power 160 W

Sensitivity 93 dB

Cone Braided glass ﬁ ber®

Surround Butyl

Nom. impedance 4 ohms

DC resistance 3.31 ohms

VC diameter 30 mm 1-3/16 in

VC height 1 ,5 mm 1/ in

Former Kapton®

Layers

Wire Copper

nductance

Xmax .5 mm 1/16 in

Magnet d x h 100 x 0 mm 4 x13 /16 in

Magnet weight 0.56 kg 1. 3 Ib

Flux density 1.1 T

Gap height 5 mm 1/8 in

Net weight 1.55 kg 3.4 Ib

Fs 49.3 Hz

Vas 7.56 I

Qts 0.5

Qes 0.59

Qms 4.13

Re 3.31 ohms

Sd 6.98 cm 35. 0 in

Cas 4. 7E-07 m5/N

Mas 4.4 kg/m4

Ras 830.67 ohms.ac

Cms 4.3 E-04 m/N

Mms 4.08 g

Rms 1.807 kg/s

Ces 575. 0 mF

Les 18.10 mH

Res .98 ohms

B 6.45 N/A

SPL 89.3 dB/W/m

30°

0°

Load V (l) Fb (Hz) F-3 (Hz) Ql

Sealed 30 - 67 0,9

Sealed ----

•Adjustable aluminum inverted dome tweeter

•All weather woven glass ﬁ ber cone

•100mm (4") magnet

Speciﬁ cations

Parameters

Frequency Response / mpedance

Mechanical Drawing

Suggested application

Unit : mm

Log Frequency - Hz

10 000100010010

100

dB SPL

Ohms

Focal® is a trademark of Focal-JMlab® - BP 374 - 108, rue de l’ venir - 42353 La Talaudière cedex

France - Tél. (33) 04 77 43 57 00 - Fax (33) 04 77 37 65 87 - www.focal-fr.com - SC Z070503/3
