FlexQube eQart User manual
UNBOXING &
QUICK START
eQart®
UNBOXING.
1. Loosen the
screws
2. Open the box
and place the
ramp
3. Remove the
straps
Use a Torx T25 and a
screwdriver to remove the screws.
WATCH THE UNBOXING VIDEO SCAN CODE
4. Find the
maintenance drive
5. Connect the
maintenance drive
6. Pull the eQart
out from the box
7. Remove the
maintenance drive
When you hear a ‘click’ the drive is
connected. It also indicates that the
brakes are released.
Because the eQart is heavy, it is
recommended to use two people.
After you have removed the
maintenance drive, the eQart is ready!
Ensure the e-stops are NOT acti-
vated. Rotate clockwise to deacti-
vate.
Ensure the key is in position as in
the photo.
®
IN THE SHIPMENT.
1x eQart
10xRed and blue tape
1x Charger
20x RFID tags
You Should Have
1x User manual
1x Maintenance
drive
1x Cockpit with
LTE/4G SIM
1x Battery cable
1xLaser scanner cable
1x Arduino cable
START THE EQART.
The ON/OFF switch is placed in front of the
battery module.
Make sure no emergency stop buttons are pushed in before proceeding.
eQart Switch - ON eQart Switch - OFF Remove eQart Switch
MAIN MENU.
eQart Cockpit Main
1. Cockpit
2. Navigation
There are ve main functions in the eQart Cockpit, which
all are located under the Main Menu.
3. Map & Routes
4. Mission Planner
5. Settings
COCKPIT.
eQart Cockpit Manual Drive View
Direction
Fwd. or Rev.
Press the
arrow to
switch
direction.
eQart Rotation
This will Highlight Blue when the
eQart has Located the Line
Direction
Right or Left
Start / Stop Line Follow Speed Control
Go to
Navigation
Go to
Mission
Find Cart
Tablet BatteryeQart Status Cart Battery
Cart Location
MAP & ROUTES.
Create a Route
Simple or Circular Path
For all corners or junctions, the radius of
curvature must be 1 meter or larger.
It is also essential that the lines are connected
and that it creates a continuous path for the
eQart.
CIRCULAR PATH SIMPLE PATH
There are two types of paths, simple and circular path. A circular path
means there is one closed loop in the path.
r = 1 meter
