Extron electronics System 8 Plus User manual

Extron • System 8/10 PLUS • User’s Manual • P/N 68-427-01 Rev. C

Toshiba TLP Installation Configuration and Connections

Page 1

SYSTEM 8/10 Plus

PROJECTOR COMMUNICATIONS KIT

ATTENTION!

PLEASE READ THIS DOCUMENT FOR IMPORTANT

INSTALLATION INSTRUCTIONS

THIS KIT HAS BEEN SHIPPED WITHTHE FOLLOWING COMPONENTS:

Kit Type: TOSHIBA

Included Communications Adapter(s):

Quantity Part Number Description

1 26-474-01 ADP, UNV, “F”

THE TABLE BELOW LISTS THE POSSIBLE CONFIGURATION(S) AND CORRESPONDING

COMMUNICATIONS ADAPTER(S) FOR YOUR PROJECTOR MANUFACTURER’S VARIOUS

MODELS. PLEASE NOTE THAT YOUR SWITCHER HAS BEEN CONFIGURED AS

INDICATED BY THE “✔”IN THE “Config as” COLUMN. IF YOUR PROJECTOR MODEL

DIFFERS FROM THIS CONFIGURATION, YOU MUST RECONFIGURE YOUR SWITCHER

WITH THE CORRECT SETTINGS.

PLEASE REFER TO THE FOLLOWING PAGES FOR COMPLETE CONFIGURATION AND

SIGNAL CONNECTION INSTRUCTIONS.

THIS SWITCHER HAS BEEN CONFIGURED FOR: TOSHIBATLP 710U/711U

Config Model Rotary Switches Cable SW15 Settings Comm

as RS1 RS2 RS3 RS4 J2/J3 1 2 3 45678910Adapter

✔TLP-710U/711U 0 0 E 3 J2 ↓↓↑↓↑↓↓ ↓↑↓26-474-01

TLP-510/570 0 0 E 3 J2 ↓↓↑↓↑↓↓ ↓↑↓26-474-01

TLP-X10U 1 0 E 3 J2 ↓↓↑↓↑↓↓ ↓↑↓26-474-01

Extron • System 8/10 PLUS • User’s Manual • P/N 68-427-01 Rev. C

Toshiba TLP Installation Configuration and Connections

Page 2

Toshiba TLP 710U/711U Projector Configuration

Verify that the System 8/10 PLUS is already configured for the Toshiba TLP

710U/711U projector. The general setup is explained on page 3-4 and the switch

settings for the projector are repeated below.

1. Use a small screwdriver to remove the access cover from the System 8/10 PLUS

front panel. See bottom of page 3-3. The label on the back of the access cover

also has the configuration information.

__________ Before changing anything, remove the AC power cord to the System 8/10 PLUS

to verify that the main power is OFF; also turn the projector power OFF.

2. Set the switches as follows:

Config Model Rotary Switches Cable SW15 Settings Comm

as RS1 RS2 RS3 RS4 J2/J3 1 2 3 4 5 6 7 8 9 10 Adapter

✔Toshiba 710U/711U 0 0 E 3 J2 ↓↓ ↑ ↓↑

-↓ ↓↓↑↓ 26-474-01

_ RS5 is for RGB switching

delay. See page 3-4 for

more information on switch

functions.

3. Use a grease pencil (or other rub-off marker) to mark the space on the label next

to “Toshiba 710U/711U”.

4. Locate the switcher’s Address DIP switches on the rear panel, lower right. Unless

this is part of a host/peripheral system, set #3 and #5 to the up position and the

others down. See illustration to the left.

Use the illustration on the next page to do the following steps.

5. Connect the Comm Adapter’s 9-pin male connector to the 9-pin female “RS-

232C” connector on the rear panel of the projector.

6. Connect the CC-50' (or CC-100') cable from the 9-pin male connector of the

Comm Adapter to the 15-pin HD “Projector Control” port located on the rear

panel of the System 8/10 PLUS.

______ Secure the screws on all D connectors

7. Connect the BNC (RGBS) cables from the System 8/10 PLUS outputs to the

projector’s 15-pin “RGB 1 IN” connector. When using S-Video, connect the S-

Video cable to the “VIDEO 1 IN” connector of the projector. If using Composite

Video, connect the cable to the projector’s “VIDEO 2 IN” connector.

8. Apply Main Power to the System 8/10 PLUS by connecting the power cord. The

Main Power LED should light. Apply power to the projector.

9. Return System 8/10 PLUS and projector to normal operation.

Configured For:

RS-232

34567891012

SW15 DIP Switch

RS5 RS2

RS2

RS1

RS3

RS4

RS1

RS3 RS4

Extron • System 8/10 PLUS • User’s Manual • P/N 68-427-01 Rev. C

Toshiba TLP Installation Configuration and Connections

Page 3

Toshiba TLP 710U/711U Projector Connections

Use the illustration below when connecting the System 8/10 PLUS to a Toshiba

TLP 710U/711U projector. Refer to Toshiba documentation to continue the

installation.

_ If the installation includes looping (

host/peripheral

) switchers, see Chapter 5.

If Video Loop Back is part of the installation, see pages 2-10 and 2-11.

CC 50'

15-Pin HD

COM Adapter

26-474-01

15-Pin 9-Pin
