Extron electronics EBDB User manual

EBDB • Setup Guide

The Extron EBDB is an eBUS®signal distribution hub for use with eBUS-enabled IP Link®Pro control processors. It includes ten

eBUS ports, connected in parallel, which allows each port to act as an input or an output for communication between IPCPPro

control processors and other eBUS devices. A front panel LED indicates when power is present on one or more of the ports.

The EBDB does not need to be set up. Other components of an eBUS-enabled system (an IPCPPro control processor and eBUS

peripheral products such as EBPs [eBUS button panels]) must be configured using Extron Global Configurator (GC) software (in

GCProfessional or GCPlus mode), which is available at www.extron.com.

Features

eBU S DI S T R I B U TI O N HU B

–

Power

LED

ZipClip

Mounting Slot

(front and rear)

Notches for

Securing

Tie Wrap

eBUS

Distr

ibution

rts

Figure 1. EBDB Rear and Front Panel Features

Cabling: eBUS Connections

Attach cables using the following diagrams as a guide. Extron STP20-2/1000 or STP20-2P/1000 cable is recommended for eBUS

connections.

ATTENTION: Installation and service must be performed by authorized personnel only.

eBUS DISTRIBUTION HUB

V+

S G

–

V+

S G

–

V+

S G

–

V+

S G

–

V+

S G

–

S+

V+

S G

–

S+

V+

S G

–

S+

V+

S G

–

V+

S G

–

S+

V+

S G

–

Rear Panel

Front Panel

eBUS port on an

EBP or other

eBUS endpoint

device

V+

S G

–

V+

S G

–

eBUS port on an

IPCP Pro Control

Processor or an eBUS

endpoint device

Tie drain wires to ground.

+Signal

Signal

+12 VDC

S+S

Ground

S+S

3/16" (5 mm) Max.

eBUS Connections

• Connect up to nine (9) eBUS endpoint devices

and one IPCP Pro control processor or ten

endpoint devices.

• Wire the connectors the same at both ends for

every eBUS device.

• Power is provided by the IPCP Pro or an

additional power supply.

Power LED Indications

LED unlit — No power is present.

LED lit — Power is present.

Figure 2. Basic eBUS Wiring and Indications

EBDB • Setup Guide (Continued)

eBUS DISTRIBUTION HUB

V+

S G

–

V+

S G

–

V+

S G

–

V+

S G

–

V+

S G

–

S+

V+

S G

–

S+

V+

S G

–

S+

V+

S G

–

V+

S G

–

S+

V+

S G

–

eBUS®port on

an EBP or other

eBUS endpoint

device

V+

S G

–

PWR OUT = 6W

VCG

VOL

POWER

12V

1.0A MAX

Tx Rx

RTSCTS

COM 1

12 4G

DIGITAL I/O

Tx Rx

COM 2

-S+V +S G

eBUS

C12

RELAYS

IR/S

LAN

IPCP PRO 250

MAC: 00-05-A6-XX-XX-XX

S/N: ####### E######

IPCP Pro

Ground

+Signal

Signal

+12 VDC

S+S

+S G

S+S

Tie drain wires to ground.

Tie drain wires

to ground.

Powered

eBUS

device(s)

3/16" (5 mm) Max.

eBUS Connections

• Connect up to ten (10) eBUS devices to the

EBDB eBUS Distribution Hub.

• Wire the connectors the same at both ends.

EBDB Rear Panel

ATTENTION: Do NOT

connect the power pin

to any device that is

already powered by the

IPCP Pro control

processor or by an

additional power supply.

Figure 3. eBUS Wiring for a System with Two Power Sources

Installation

1. Mount the EBDB and the IPCPPro to the rack or furniture (see Mounting on page3).

2. Connect the EBDB and any eBUS endpoint devices to each other in a daisy-chain or a star arrangement. Wire both ends of

each cable the same (pin 1 to pin 1, pin 2 to pin 2, and so forth).

3. Connect the IPCPPro to the EBDB, making sure that both ends of the cable are wired the same.

NOTE: See the attention information in figure 3 so you do not connect the power pins (labeled V+) on the EBDB to two

powered devices. Power should be supplied to the EBDB by only one source.

4. Connect power to the devices, connect the IPCPPro to a network, and set up the IPCPPro and its connected eBUS

endpoint devices.

Additional Instructions, Information, and Assistance

• Instructions on configuration are available in the user and setup guides for the IPCPPro control processor and for the eBUS

endpoints, and in the Global Configurator Help file. The Global Configurator Help file includes an introduction to the software

and how to start a GC project, as well as instructions on configuration.

• See the user guides for each eBUS product for details about eBUS addresses and about firmware updates.

• Software, help files, and guides are all available at www.extron.com.

• If you have questions during installation and setup, call the ExtronS3 Sales & Technical Support Hotline or the Extron S3

Control Systems Support Hotline (1.800.633.9877).

See the eBUS Technology Reference Guide for information

about daisy chain and star topographies.

Mounting

You can mount an EBDB to the following items:

• tabletop

• optional equipment rack shelf

• equipment rack (using mounting brackets)

• furniture (using a mounting kit)

Optional mounting kits (see the following table) are available.

Read the instructions and UL guidelines that come with any

mounting kit for installation procedures.

Using the ZipClip 200

Attaching and Removing the Clip and EBDB

To attach the EBDB to the ZipClip 200 mounting clip:

1. Insert the bottom of the EBDB down into the clip,

starting with one end.

2. Pivot the other end down and press until the clip snaps

into place.

To remove the EBDB from

the ZipClip:

1. Press the tab on

the ZipClip.

2. Pivot the EBDB

and lift it out

of the

ZipClip.

Optional Mounting Kits

RSB 123 1U Basic Rack Shelf for 3.5" Deep Products

RSF 123 1U Rack Shelf Kit for 3.5" Deep Products

RSB 126 1U Basic Rack Shelf for 6" Deep Products

RSU 126 1U Universal Rack Shelf Kit for 6" Deep Products

RSB 129 1U Basic Rack Shelf for 9.5" Deep Products

RSU 129 1U Universal Rack Shelf Kit for 9.5" Deep

Products

Using Tie Wraps for Cable Strain Relief

1. Attach the EBDB to the ZipClip 200 mounting clip as

described previously.

2. Fasten the cables to the ZipClip base.

a. Insert tie wraps (which are also called “zip ties”)

along the notches on the side of the EBDB and

through the tie wrap anchor points on the ZipClip,

then around the cord.

b. Connect and pull the tie wraps until they are

secure. Do not over tighten.

Rack Mounting

Mounting to a Rack Shelf

The EBDB is one quarter rack wide. Up to four EBDBs can

be mounted side by side directly onto a rack shelf.

1. Align the threaded holes in the bottom of the EBDB

with the holes in an Extron rack shelf and fasten the

unit to the shelf with two screws as shown below.

(2) 4-40 x 3/16"

Screws

RSB 123

Rack Shelf

On a Rack Shelf

2. Bolt the rack shelf to the rack.

Tie Wrap

eBU S DI S T R I B U T I O N HU B

–

EBDB • Setup Guide (Continued)

Extron Headquarters

+1.800.633.9876 (Inside USA/Canada Only)

Extron USA - West Extron USA - East

+1.714.491.1500 +1.919.850.1000

+1.714.491.1517 FAX +1.919.850.1001 FAX

Extron Europe

+800.3987.6673

(Inside Europe Only)

+31.33.453.4040

+31.33.453.4050 FAX

Extron Asia

+65.6383.4400

+65.6383.4664 FAX

Extron Japan

+81.3.3511.7655

+81.3.3511.7656 FAX

Extron China

+86.21.3760.1568

+86.21.3760.1566 FAX

Extron Middle East

+971.4.299.1800

+971.4.299.1880 FAX

Extron Australia

+61.8.8351.2188

+61.8.8351.2511 FAX

Extron India

1800.3070.3777

(Inside India Only)

+91.80.3055.3777

+91.80.3055.3737 FAX

Furniture Mounting

NOTE: The ZipClip is shipped with a set of four wood

screws.

1. Attach the ZipClip to the mounting surface using two

or more wood screws as shown below. Make sure the

clip is oriented with the appropriate surface facing the

mounting surface of the furniture and with the tab

accessible from the front of the furniture.

EBDB

eBUSDISTRIBUTION HUB

–

Under a Desk

68-2217-50

Rev. B

02 16

Contact Information

If you have questions during installation and setup, you can call the ExtronS3 Sales & Technical Support Hotline or the

ExtronS3 Control Systems Support Hotline (1.800.633.9877).

2. Insert the EBDB into the ZipClip as described

previously and press to snap it into place.

Mounting to Rack Rails Using a ZipClip

1. Fasten the ZipClip 200 mounting clip to a rack rail

using two rack screws as shown in the diagram below.

2. Insert the bottom of the EBDB down into the clip,

starting with one end.

3. Pivot the other end toward the clip and press until the

clip snaps into place.

eBUS DISTRI B U TIONHU B

–

Inside

Rack

ZipClip 200

Back of

Rack

Side of Rack
