Part number: 120139-00 Rev. 01 Published: September 2001 1

Summit24e3 Switch Quick

Reference Guide

Accessing the Switch Commands

Command Description

clear session <number> Terminates a Telnet session from the switch.

config account <username> {encrypted}

{<password>}

Configures a user account password. Passwords must have a

minimum of 1 character and can have a maximum of 32

characters. User names and passwords are case-sensitive.

config banner Configures the banner string. You can enter up to 24 rows of

79-column text that is displayed before the login prompt of each

session. Press [Return] at the beginning of a line to terminate the

command and apply the banner. To clear the banner, press

[Return] at the beginning of the first line.

config dns-client add <ipaddress> Adds a DNS name server(s) to the available server list for the

DNS client. Up to three name servers can be configured.

config dns-client default-domain

<domain_name>

Configures the domain that the DNS client uses if a fully qualified

domain name is not entered. For example, if the default domain

is configured to be foo.com, executing ping bar searches for

bar.foo.com.

config dns-client delete <ipaddress> Removes a DNS server.

config ssh2 key {pregenerated} Generates the SSH2 host key.

config sys-recovery-level [none | critical | all] Configures a recovery option for instances where an exception

occurs in ExtremeWare. Specify one of the following:

■none — Recovery without system reboot.

■critical — ExtremeWare logs an error to the syslog, and

reboots the system after critical exceptions.

■all — ExtremeWare logs an error to the syslog, and reboots

the system after any exception.

The default setting is none.

config time <date> <time> Configures the system date and time. The format is as follows:

mm/dd/yyyy hh:mm:ss

The time uses a 24-hour clock format. You cannot set the year

past 2036.

2 Summit24e3 Switch Quick Reference Guide

config timezone <gmt_offset> {autodst |

noautodst}

Configures the time zone information to the configured offset

from GMT time. The format of gmt_offset is +/- minutes from

GMT time. Specify:

■autodst —Enables automatic Daylight Savings Time

change.

■nosautodst —Disables automatic Daylight Savings Time

change.

The default setting is autodst.

config vlan <name> ipaddress <ip_address>

{<mask>}

Configures an IP address and subnet mask for a VLAN.

create account [admin | user] <username>

{encrypted} {<password>}

Creates a user account. This command is available to

admin-level users and to users with RADIUS command

authorization. The username is between 1 and 32 characters, the

password is between 0 and 16 characters.

create vlan <name> Creates a VLAN.

delete account <username> Deletes a user account.

delete vlan <name> Deletes a VLAN.

disable bootp vlan [<name> | all] Disables BOOTP for one or more VLANs.

disable cli-config-logging Disables logging of CLI commands to the Syslog.

disable clipaging Disables pausing of the screen display when a show command

output reaches the end of the page.

disable idletimeouts Disables the timer that disconnects all sessions. Once disabled,

console sessions remain open until the switch is rebooted or you

logoff. Telnet sessions remain open until you close the Telnet

client.

disable ports <portlist> Disables a port on the switch.

disable ssh2 Disables SSH2 Telnet access to the switch.

disable telnet Disables Telnet access to the switch.

enable bootp vlan [<name> | all] Enables BOOTP for one or more VLANs.

enable cli-config-logging Enables the logging of CLI configuration commands to the

Syslog for auditing purposes. The default setting is enabled.

enable clipaging Enables pausing of the screen display when show command

output reaches the end of the page. The default setting is

enabled.

enable idletimeouts Enables a timer that disconnects all sessions (both Telnet and

console) after 20 minutes of inactivity. The default setting is

disabled.

enable ssh2 {port <tcp_port_number>} Enables SSH2 Telnet sessions. By default, SSH2 uses TCP port

number 22.

enable telnet {port <tcp_port_number>} Enables Telnet access to the switch. By default, Telnet uses

TCP port number 23.

history Displays the previous 49 commands entered on the switch.

Command Description

Summit24e3 Switch Quick Reference Guide 3

nslookup <hostname> Displays the IP address of the requested host.

ping {continuous} {size <start_size> {-

<end_size>}} [<ip_address> | <hostname>]

{from <src_address> | with record-route | from

<src_ipaddress> with record-route}

Enables you to send Internet Control Message Protocol (ICMP)

echo messages to a remote IP device. Specify:

■continuous —Specifies ICMP echo messages to be sent

continuously. This option can be interrupted by pressing any

key.

■size —Specifies the size of the ICMP request. If both the

start_size and end_size are specified, transmits ICMP

requests using 1 byte increments, per packet. If no

end_size is specified, packets of start_size are sent.

■<ipaddress> —Specifies the IP address of the host.

■<hostname> —Specifies the name of the host. To use the

hostname, you must first configure DNS.

■from —Uses the specified source address in the ICMP

packet. If not specified, the address of the transmitting

interface is used.

■with record-route —Decodes the list of recorded routes

and displays them when the ICMP echo reply is received.

show banner Displays the user-configured banner.

show dns-client Displays the DNS configuration.

traceroute [<ip_address> | <hostname>] {from

<src_ipaddress>} {ttl <TTL>} {port <port>}

Enables you to trace the routed path between the switch and a

destination endstation. Specify:

■ip_address —is the IP address of the destination

endstation.

■hostname —is the hostname of the destination endstation.

To use the hostname, you must first configure DNS.

■from —uses the specified source address in the ICMP

packet. If not specified, the address of the transmitting

interface is used.

■ttl —configures the switch to trace up to the time-to-live

number of the switch.

■port —uses the specified UDP port number.

unconfig switch {all} Resets all switch parameters (with the exception of defined user

accounts, and date and time information) to the factory defaults.

If you specify the keyword all, the switch erases the currently

selected configuration image in flash memory and reboots. As a

result, all parameters are reset to default settings.

Command Description

4 Summit24e3 Switch Quick Reference Guide

Managing the Switch Commands

Command Description

config radius [primary | secondary] server

[<ipaddress> | <hostname>] {<udp_port>}

client-ip <ipaddress>

Configures the primary and secondary RADIUS server. Specify

the following:

■[primary | secondary] —Configure either the primary

or secondary RADIUS server.

■[<ipaddress> | <hostname>] —The IP address or

hostname of the server being configured.

■<udp_port> —The UDP port to use to contact the RADUIS

server. The default UDP port setting is 1645.

■client-ip <ipaddress> —The IP address used by the

switch to identify itself when communicating with the RADIUS

server.

The RADIUS server defined by this command is used for user

name authentication and CLI command authentication.

config radius [primary | secondary]

shared-secret {encrypted} <string>

Configures the authentication string used to communicate with

the RADIUS server.

config radius-accounting [primary | secondary]

server [<ipaddress> | <hostname>]

{<udp_port>} client-ip <ipaddress>

Configures the RADIUS accounting server. Specify the following:

■[primary | secondary] —Configure either the primary

or secondary RADIUS server.

■[<ipadress> | <hostname>] —The IP address or

hostname of the server being configured.

■<udp_port> —The UDP port to use to contact the RADUIS

server. The default UDP port setting is 1646.

■client-ip <ipaddress> —The IP address used by the

switch to identify itself when communicating with the RADIUS

server.

The accounting server and the RADIUS authentication server

can be the same.

config radius-accounting [primary | secondary]

shared-secret {encrypted} <string>

Configures the authentication string used to communicate with

the RADIUS accounting server.

config snmp add trapreceiver <ipaddress>

community <string>

Adds the IP address of a specified trap receiver. The IP address

can be a unicast, multicast, or broadcast address. A maximum of

16 trap receivers is allowed.

config snmp community [read-only |

read-write] <string>

Adds an SNMP read or read/write community string. The default

read-only community string is public. The default

read-write community string is private. Each community

string can have a maximum of 127 characters, and can be

enclosed by double quotation marks.

config snmp delete trapreceiver [<ip_address>

community <string> | all]

Deletes the IP address of a specified trap receiver or all

authorized trap receivers.

config snmp syscontact <string> Configures the name of the system contact. A maximum of 255

characters is allowed.

Summit24e3 Switch Quick Reference Guide 5

config snmp syslocation <string> Configures the location of the switch. A maximum of 255

characters is allowed.

config snmp sysname <string> Configures the name of the switch. A maximum of 32 characters

is allowed. The default sysname is the model name of the device

(for example, Summit24e3). The sysname appears in the

switch prompt.

config sntp-client [primary | secondary] server

[<ipaddress> | <host_name>]

Configures an NTP server for the switch to obtain time

information. Queries are first sent to the primary server. If the

primary server does not respond within 1 second, or if it is not

synchronized, the switch queries the second server.

config sntp-client update-interval <seconds> Configures the interval between polling for time information from

SNTP servers. The default setting is 64 seconds.

config tacacs [primary | secondary] server

[<ipaddress> | <hostname>] {<udp_port>}

client-ip <ipaddress>

Configure the server information for a TACACS+ server. Specify

the following:

■primary | secondary —Specifies primary or secondary

server configuration. To remove a server, use the address

0.0.0.0.

■<ipaddress> | <hostname> —Specifies the TACACS+

server.

■<udp_port> —Optionally specifies the UDP port to be used.

■client-ip —Specifies the IP address used by the switch to

identify itself when communicating with the TACACS+ server.

config tacacs [primary | secondary]

shared-secret {encrypted} <string>

Configures the shared secret string used to communicate with

the TACACS+ server.

config tacacs-accounting [primary | secondary]

server [<ipaddress> | <hostname>]

{<udp_port>} client-ip <ipaddress>

Configures the TACACS+ accounting server. You can use the

same server for accounting and authentication.

config tacacs-accounting [primary | secondary]

shared-secret {encrypted} <string>

Configures the shared secret string used to communicate with

the TACACS+ accounting server.

disable radius Disables the RADIUS client.

disable radius-accounting Disables RADIUS accounting.

disable snmp access Disables SNMP on the switch. Disabling SNMP access does not

affect the SNMP configuration (for example, community strings).

disable snmp traps Prevents SNMP traps from being sent from the switch. Does not

clear the SNMP trap receivers that have been configured.

disable sntp-client Disables SNTP client functions.

disable tacacs Disables TACACS+.

disable tacacs-accounting Disables TACACS+ accounting.

disable tacacs-authorization Disables CLI command authorization.

Command Description

6 Summit24e3 Switch Quick Reference Guide

enable radius Enables the RADIUS client. When enabled, all CLI logins are

sent to the RADIUS servers for authentication. When used with a

RADIUS server that supports ExtremeWare CLI authorization,

each CLI command is sent to the RADIUS server for

authentication before it is executed.

enable radius-accounting Enables RADIUS accounting. The RADIUS client must also be

enabled.

enable snmp access Turns on SNMP support for the switch.

enable snmp traps Turns on SNMP trap support.

enable sntp-client Enables Simple Network Time Protocol (SNTP) client functions.

enable tacacs Enables TACACS+. Once enabled, all CLI logins are sent to one

of the two TACACS+ server for login name authentication and

accounting.

enable tacacs-accounting Enables TACACS+ accounting. If accounting is use, the

TACACS+ client must also be enabled.

enable tacacs-authorization Enables CLI command authorization. When enabled, each

command is transmitted to the remote TACACS+ server for

authorization before the command is executed.

show radius Displays the current RADIUS client configuration and statistics.

show sntp-client Displays configuration and statistics for the SNTP client.

show tacacs Displays the current TACACS+ configuration and statistics.

show tacacs-accounting Displays the current TACACS+ accounting client configuration

and statistics.

telnet [<ipaddress> | <hostname>]

{<port_number>}

Enables a Telnet session on the switch. Up to eight active Telnet

sessions can access the switch concurrently. You can Telnet to

a switch by entering the IP address of the switch or the

hostname of the switch. The Telnet session defaults to port 23.

unconfig management Restores default values to all SNMP-related entries.

unconfig tacacs {server [primary | secondary]} Unconfigures the TACACS+ client configuration.

unconfig tacacs-accounting {server [primary |

secondary]}

Unconfigures the TACACS+ accounting client configuration.

Command Description

Summit24e3 Switch Quick Reference Guide 7

Configuring Ports on a Switch Commands

Command Description

config ports <portlist> auto off {speed [10 |

100 | 1000]} duplex [half | full]

Changes the configuration of a group of ports. Specify the

following:

■auto off —The port will not autonegotiate the settings.

■speed —The speed of the port (for 10/100 Mbps or

100/1000 Mbps ports only).

■duplex —The duplex setting (half- or full-duplex).

config ports <portlist> auto on Enables autonegotiation for the particular port type; 802.3u for

10/100 Mbps ports or 802.3z for Gigabit Ethernet ports.

config ports <portlist> display-string <string> Configures a user-defined string for a port. The string is

displayed in certain show commands (for example, show port

all info). The string can be up to 16 characters.

config sharing address-based [mac_source |

mac_destination | mac_source_destination |

ip_source | ip_destination |

ip_source_destination]

Configures the part of the packet examined by the switch when

selecting the egress port for transmitting load-sharing data. This

feature is available using the address-based load-sharing

algorithm, only.

disable edp ports <portlist> Disable EDP on one or more ports.

disable ports <portlist Disables a port. Even when disabled, the link is available for

diagnostic purposes.

disable ports <portlist> Disables a port. Even when disabled, the link is available for

diagnostic purposes.

disable sharing <port> Disables a load-sharing group of ports.

enable edp ports <portlist> Enables the generation and processing of EDP messages on

one or more ports. The default setting is enabled.

enable ports <portlist> Enables a port.

enable sharing <port> grouping <portlist>

{address-based}

Defines a load-sharing group of ports. The ports specified in

<portlist> are grouped to the master port. The optional

load-sharing algorithm, address-based, uses addressing

information as criteria for egress port selection.

restart ports <portlist> Resets autonegotiation for one or more ports by resetting the

physical link.

show edp Displays EDP information.

show ports {<portlist>} collisions Displays real-time collision statistics.

show ports {<portlist>} configuration Displays the port configuration.

show ports {<portlist>} info {detail} Displays detailed system-related information.

show ports {<portlist>} packet Displays a histogram of packet statistics.

show ports {<portlist>} rxerrors Displays real-time receive error statistics.

show ports {<portlist>} stats Displays real-time port statistics.

show ports {<portlist>} txerrors Displays real-time transmit error statistics.

8 Summit24e3 Switch Quick Reference Guide

show ports {<portlist>} utilization Displays real-time port utilization information. Use the [Spacebar]

to toggle between packet, byte, and bandwidth utilization

information.

show sharing address-based Displays the address-based load sharing configuration.

unconfig ports <portlist> display-string <string> Clears the user-defined display string from a port.

unconfig ports <portlist> redundant <portlist> Clears a previously configured software-controlled redundant

port.

Command Description

Summit24e3 Switch Quick Reference Guide 9

VLAN Commands

Command Description

config vlan <name> delete port <portlist>

{tagged | untagged} {nobroadcast}

Deletes one or more ports from a VLAN.

config vlan <name> ipaddress <ipaddress>

{<mask>}

Assigns an IP address and an optional mask to the VLAN.

config vlan <name> tag <vlanid> Assigns a numerical VLANid. The valid range is from 1 to 4095.

config vlan <old_name> name <new_name> Renames a previously configured VLAN.

create vlan <name> Creates a named VLAN.

delete vlan <name> Removes a VLAN.

show vlan {<name>} Displays summary information about each VLAN, which includes:

■Name

■VLANid

■How the VLAN was created

■IP address

■STPD information

■QoS profile information

■Ports assigned

■Tagged/untagged status for each port

■How the ports were added to the VLAN

■Number of VLANs configured on the switch

unconfig vlan <name> ipaddress Resets the IP address of the VLAN.

10 Summit24e3 Switch Quick Reference Guide

FDB Commands

Command Description

clear fdb Clears all FDB entries.

config fdb agingtime <number> Configures the FDB aging time. The range is 15 through

1,000,000 seconds. The default value is 300 seconds. A value of

0 indicates that the entry should never be aged out.

create fdbentry <mac_address> vlan <name>

[blackhole | <portlist>] }

Creates an FDB entry. Specify the following:

■mac_address —Device MAC address, using colon

separated bytes.

■name —VLAN associated with MAC address.

■blackhole —Configures the MAC address as a blackhole

entry.

■portlist —Port numbers associated with MAC address.

If more than one port number is associated with a permanent

MAC entry, packets are multicast to the multiple destinations.

delete fdbentry <mac_address> vlan <name> Deletes a permanent FDB entry.

show fdb {<mac_address> | vlan <name> |

<portlist> | permanent}

Displays the switch FDB contents.

Other manuals for Summit Summit24

This manual suits for next models

Table of contents

Other Extreme Networks Switch manuals

Extreme Networks

Extreme Networks BlackDiamond 12800 Series Manual

Extreme Networks

Extreme Networks Summit X150-24t Manual

Extreme Networks

Extreme Networks Summit X48 User manual

Extreme Networks

Extreme Networks Summit X350-48t Reference guide

Extreme Networks

Extreme Networks BlackDiamond X8 Series Assembly instructions

Extreme Networks

Extreme Networks ExtremeSwitching 5420 Series Manual

Extreme Networks

Extreme Networks 7720 User manual

Extreme Networks

Extreme Networks Summit X440-G2-24t-10GE4 User manual

Extreme Networks

Extreme Networks BlackDiamond 10K Series User manual

Extreme Networks

Extreme Networks BlackDiamond 10808 Manual

Extreme Networks

Extreme Networks ExtremeSwitching SLX 9030 Series Manual

Extreme Networks

Extreme Networks ReachNXT 100-8t User manual

Extreme Networks

Extreme Networks SSA-G8018-0652 Manual

Extreme Networks

Extreme Networks Summit X150 Series Installation and operation manual

Extreme Networks

Extreme Networks BlackDiamond X8 Series Manual

Extreme Networks

Extreme Networks X460-G2 Series Installation and operation manual

Extreme Networks

Extreme Networks BlackDiamond 6800 User manual

Extreme Networks

Extreme Networks ExtremeSwitching X440-G2 Series Manual

Extreme Networks

Extreme Networks Summit 300-48 Safety guide

Extreme Networks

Extreme Networks Summit WM200 User manual

Extreme Networks

Extreme Networks Hubs & Switches Installation instructions

Extreme Networks

Extreme Networks Summit Summit1i Manual

Extreme Networks

Extreme Networks 59100 Series User manual

Extreme Networks

Extreme Networks Extreme Switching 3500 Series User manual

Popular Switch manuals by other brands

URC

URC Total Control MFS-8 installation manual

Azbil

Azbil HPQ-D11 user manual

Sony

Sony DFS-900M operating instructions

SICK

SICK i17S operating instructions

F&F

F&F SZR-277 quick start guide

Shure

Shure UAMS/BK user guide

Dräger

Dräger X-zone Switch Off Instructions for use

Asco

Asco Joucomatic 349 Series manual

BT Mini Hub user guide

D-Link

D-Link DES-1226G manual

Johnson Controls

Johnson Controls FS80-C installation instructions

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Configuration guide

MicroNet

MicroNet SP1200A user manual

Ruijie

Ruijie RG-PF2920 Series Hardware installation and reference guide

Altinex

Altinex DA1914SX user guide

MiLAN

MiLAN MIL-SM2401M user guide

RJM

RJM MASTERMIND PBC/6X user manual

Atlas

Atlas MMK-KVM8 owner's manual
