a. Prepare the rack

• Provide the equivalent of two racks of vertical space for each ERS 59100

Series in an EIA or IEC-standard 19-inch (48.2-centimeter)

equipment rack.

• Ensure that the equipment rack is stable and securely attached to a

permanent structure.

• Ground the rack to the same grounding electrode used by the power

service in the area. The ground path must be permanent and must not

exceed 1 Ohm of resistance from the rack to the grounding electrode.

It is recommended to use a filter or surge suppressor.

b. When you install the switch into a network, ensure to use the

following cables:

•

Category 5E or higher specification cabling must be used for 1 Gbps/1000

Mbps operation.

• RJ-45 and DB-9 console port cables and adaptors are as follows:

Confirm that you have the tools and package contents as follows:

Tools Required:

• Phillips #2 screwdriver

• Console cable

• ESD cable (optional)

Package Contents:

Ethernet Routing Switch

59100 Series

Quick Install Guide

1. Ethernet Routing Switch 59100 Series.

2. Two rack-mounting kits. Each kit includes:

a. 2 rack-mount brackets

b. 8 screws to attach the brackets to the switch

c. 3 sets of 4 screws used to attach the bracket to the rack.

3. Documentation includes the Quick Install poster and

Regulatory document.

4. One field replaceable power supply unit.

Note: Four field replaceable power supplies are supported for models

ERS 59100GTS and ERS 59100GTS-PWR+.

5. Four fan tray modules.

Note: Power supply unit and fan tray modules are included with the

switch; however, these items are delivered in separate packages.

Note: The arrow on the Power supply units and fan tray modules depicts

the direction of air flow. Power supply units and fan tray modules should

follow the same air flow direction.

For detailed information about installing the Ethernet Routing Switch 59100

Series switches, see Installing ERS 5900 Series.

All documents referenced in this Quick Installation Guide can be downloaded

at http://www.extremenetworks.com/support/documentation/.

Depending on your hardware model, your switch may appear different than

the figures shown in this guide.

Note: Be sure to order Direct Attach cables and SFP or SFP+ Transceivers

if required.

For... Order Order Code

Front-to-Back

cooling

AC Power Supply Front to Back

Airflow (no Power Cord*)

AL7000A0F-E6

AL1905A3F-E6

Quantity

1 to 4**

Back-to-Front

cooling

AC Power Supply Back to Front

Airflow (no Power Cord*)

AL7000A0B-E6

AL1905A3B-E6

1 to 4**

4-post rack

mount bracket

(sold separately)

Four Post Server Rack Mount Kit

(optional) for ERS 59100GTS and

ERS59100GTS-PWR+

AL5911001-E6 1

Console cabling

(sold separately)

RJ-45/DB-9 Integrated console

cable

Note: 1.8m cable with DB-9 Female

for PC and RJ-45 for device

console port

AL2011022-E6 1

Be sure to order Direct Attach cables and SFP or SFP+ Transceivers as required. See

Installing Transceivers and Optical Components on Ethernet Switch 5900 Series for more

information.

** Four power supplies are recommended for redundancy, load

sharing and full hot-swap replacement of a power supply for uninterruptible operation.

Note: Power cords must be ordered separately. For information about order codes, see

Installing Ethernet Routing Switch 5900 Series.

Chassis without

fans or PSUs

Chassis without PSU, fans, and

power cord

AL590005X-E6 and

AL590006X-E6

• Unpack the Ethernet Routing Switch 59100.

• Observe ESD precautions when unpacking.

• The switch ships with a filler panel in the second power supply position. This filler

panel must stay in place if you do not intend to install a second power supply.

1. Attach a bracket to each

side of the switch.

Install using the optional 4-post rack mount bracket

1. Attach the two sets of front brackets to each guide bracket using sixteen

8.5 mm length flat head machine screws.

2. Attach the guide brackets to the switch chassis.

a. Use four M4 x 5.5 mm low profile undercut flat-head hex machine

screws to attach the rear of each guide bracket to the chassis.

b. Verify if rear screws sit flush in the guide brackets.

c. Test fit the rear mounting brackets in the guide brackets and verify that the

rear brackets can slide in the channels. Remove the rear brackets.

3. Install the switch into the equipment rack temporarily using only the front

rack mounts and screws.

4. Slide a rear mounting bracket into each

guide bracket channel until flush

with the rear rack posts.

a. Slide a rear mounting bracket

into each guide bracket

channel until flush with

the rear rack posts.

b. Secure the rear

mounting brackets

to the switch chassis

with the pan-head screws.

Product

Number

Name Short Description

AL2011022-E6

RJ-45/DB-9

CONSOLE CABLE

1.8m cable with DB-9 Female for terminal/PC

on one end and RJ-45 for device console port

connectivity on the other.

Product Number Description

AA1404037-E6

QSFP+ to QSFP+ 40G 0.5 m (Passive)

AA1404029-E6

QSFP+ to QSFP+ 40G 1 m (Passive)

AA1404031-E6

QSFP+ to QSFP+ 40G 3 m (Passive)

AA1404032-E6

QSFP+ to QSFP+ 40G 5 m (Passive)

c. Stacking cables:

2. Slide the switch into the

rack. Insert and tighten

the rack-mount screws.

For correct switch operation, install both Fan Trays so that the airflow direction

matches the primary Power Supply.

Fan trays can only be inserted in one direction.

• Use the location pin on the Fan Tray to ensure correct orientation in the chassis.

The Fan Tray is upright if the location pin is at the top.

• Once the Fan Tray is installed, tighten the thumbscrews.

Stacking

The Ethernet Routing Switch 59100 Series provides fail-safe stackability. You can

connect up to four ERS 59100 Series devices in a stack to provide uninterrupted

connectivity for up to 416 ports. You can manage the stack as a single unit.

The Ethernet Routing Switch 59100 series back panel provides a Base Unit switch,

Cascade Down connector, and Cascade Up connector for stacking purposes as

shown below:

SDN/Aux Port

Cascade

Down Port

Cascade Up Port

Base Select

Switch

Base Unit Switch – used to designate the base unit in a stack. When set to the

DOWN position, this unit acts as the Base Unit for the stack.

Cascade Down and Cascade Up connectors – used to connect a switch to the

next unit in the stack through a cascade cable. Connect one end of the Cascade

Down cable to the Cascade Up connector of the next switch in the stack (shown in

the simple three-switch stack connection block diagram below):

Simplified Stacking diagram

1 = Base unit

2 = Last unit

3 = 0.5m Cascade/Stack cable

4 = 1.0m Cascade/Stack cable

To create a stack connection, order the appropriate Ethernet Routing Switch

59100 Series cascade cables to ensure fail-safe stacking. For stacking

three or more units (maximum stack port count cannot exceed 416 ports, or

4 units), order 0.5 m, 1 m, 3 m or 5 m cables as applicable.

Note: You can mix ERS 59100 switches with other ERS 5900 models in the same

stack, as long as the total port count does not exceed 416.

1. Ensure that all switches for the stack are rack mounted.

2. Slide the Unit Select switches on the back of the units to the appropriate

position, depending on whether they are a base unit or non-base unit:

• Base Unit (Unit 1) - Slide the Base Unit switch to the DOWN position.

• Non-Base Unit (Units 2-4) - Slide the Unit Select switch to the UP position.

Because stack parameters are associated with the base unit, the physical

stack order depends on the base unit position and whether you configure the

stack cascade up (stack up) or cascade down (stack down). This designation

depends on the stack cabling arrangement.

NOTE: It is recommended you use a Cascade Down (stack down)

configuration.

3. For a Cascade Down configuration, connect stack cables as shown below:

Cascade Down configuration

1 = Base unit

2 = Last unit

3 = 0.5m Cascade/Stack cable

4 = 1.0m Cascade/Stack cable

(Return cable)

Note: Return cable length may

vary depending on unit spacing.

Please ensure proper length

return cable is ordered to

provide adequate strain relief.

Fan Tray

Location pin

Upright

Fan Trays

Unit 1

Unit 2

Unit 3

Unit 4

Unit 1

Unit 2

Unit 3

1Before you start

2Unpack equipment

4Rack mounting

5Install four Fan Trays in the ERS 59100 switch

Commissioning the ERS 59100

Property Value

Baud Rate 9600 bps

Data Bits 8

Stop Bits 1

Parity None

Flow Control None

You can install an AC power supply into either power supply slot in

the switch.

The airflow direction of the power supply in PS1 determines the primary airflow

direction for the switch. If PS1 is not present, PS2 determines the airflow

direction. If any power supply location is unpopulated, a PSU Filler Panel must

be installed.

1. Insert the first power supply into the rear PS1 power supply slot. If a blanking

plate covers the required power supply slot, remove the plate before

inserting the power supply. A small angle on the top corner of the power

supply ensures that the power supply can only be installed in one orientation

in the switch.

2. Verify that the power supply is fully seated in the slot and securely clipped in

place.

3. Optional: Install the other power supplies into the rear power supply slots.

The airflow direction must match the primary Power Supply. The switch ships

with a filler panel in PS2, PS3 and PS4 positions. Leave the filler panel in

place if you do not install the other power supplies.

Before installing, ensure the switch is up and running, and operating normally. Verify

that the SFP or SFP+ transceivers and network cabling support your network

configuration. Note: The ERS 59100 supports Hot-Swapping of SFP and SFP+

transceivers and direct attach cables.

1. If you are installing SFP direct attach cables, remove packaging, insert the

transceiver connector into a switch port and insert the opposite end into the SFP

port of the corresponding network device.

If you are installing SFP or SFP+ optical transceivers, remove packaging and insert

the pluggable transceiver connector into a switch port.

2. Remove the network interface cover from the transceiver connector

(if applicable) and insert an appropriate network interface cable into

the transceiver.

3. Connect the opposite end of the network interface cable to your network.

4. In both cases, ensure that the device clicks and locks into place.

The console port is the RJ-45 port shown with a blue border outline on the front

of your ERS 59100 Series switch (note orientation). Use the console cable

(AL2011022-E6) to connect the switch console port to your management

terminal. The maximum length of a console cable is 25 feet (8.3 meters). The

following table describes the RJ-45 console port pin-out information. You can

use the pin-out information to verify or create a console cable for use with your

maintenance terminal.

The CLI Quickstart welcome screen helps you enter the information

requested at each prompt.

Note: The ERS 59100 uses the default IP address of 192.168.1.1/24 if the switch does

not get its IP address from another source.

Note: the default IP address is not applicable to the out-of-band

management port.

Terminal emulation settings

Warning: You must use a power cord set approved for the ERS 5900 Series

switch and the power receptacle type in your country. Ensure you have properly

grounded the switch before powering up the unit.

The switch will power on immediately when it is connected to a suitable AC

power source. The switch does not have a power switch.

Check the front-panel LEDs as the device powers on to be sure the PWR LED

is lit. If not, check if the power cord is correctly connected.

Check LED status of the fans and power supplies. Status LEDs are on the left

front side of the switch. For more information on all status LEDs, see Installing

ERS 5900 Series.

PS3

PS1

Your Setup

All Setups

Status LED (Blinks) Green

until agent software is loaded,

then goes (Solid) Green

Front to Back Fans

Fan1 – Blue (Solid)

Fan2 – Blue (Solid)

Fan3 – Blue (Solid)

Fan4 – Blue (Solid)

Back to Front Fans

Fan1 – Violet (Solid)

Fan2 – Violet (Solid)

Fan3 – Violet (Solid)

Fan4 – Violet (Solid)

• One Power Supply (PS): One PS LED is solid Green

and three PS LEDs are OFF

• Two PS: Two PS LEDs are solid Green and two PS

LEDs are OFF

• Three PS: Three PS LEDs are solid Green and one

PS LED is OFF

• Four PS: Four PS LEDs are solid Green.

Note: ERS 59100 can work with one power supply

and it can be in any of the four power supply slots

Base Status

Up Down

PS1 PS2

PS3 PS4

Fan1 Fan2

Fan3 Fan4

To obtain additional documentation references, go to

http://www.extremenetworks.com/support/documentation/

and download the following:

• Locating Documentation for ERS 5900

• Documentation Reference for ERS 4900 and ERS 5900

• Installing ERS 5900

• Installation Job Aid for ERS 5900

• Release Notes for ERS 4900 and ERS 5900

Connect the console cable from the terminal to the console port of the

switch to allow initial configuration. Any terminal or PC with the appropriate

terminal emulator can be used as the management station.

Set the terminal protocol on the terminal or terminal emulation program to

VT100 or VT100/ANSI.

Connect to the switch using the terminal or terminal emulation application.

The switch banner appears when you connect to the switch through the

Console port. There is no default password for the switch for CLI console

access. Enter Ctrl+Y and type the following CLI commands:

enable

install

###########################################################################

Welcome to the 59100GTS setup utility.

You will be requested to provide the switch basic connectivity settings.

After entering the requested info, the configuration will be applied and

stored into the switch NVRAM.

Once the basic connectivity settings are applied, additional configuration

can be done using the available management interfaces.

Use Ctrl+C to abort the configuration at any time.

###########################################################################

Please provide the Quick Start VLAN <1-4094> [1]:

Please provide the in-band IP Address[192.0.2.1]:

Please provide the in-band sub-net mask[255.255.255.0]:

Please provide the Default Gateway[192.0.2.1]:

Please provide the management sub-net mask[0.0.0.0]:

Please provide the management IP Address[0.0.0.0]:

Please provide the management Default Gateway[0.0.0.0]:

Please provide the Read-Only Community String[**********]:

Please provide the Read-Write Community String[**********]:

Please provide the in-band IPV6 Address/Prefix_length[::/0]:

Please provide the in-band IPV6 Default Gateway[::]:

Please provide the management IPV6 Address/Prefix_length[::/0]:

Please provide the management IPV6 Default Gateway[::]:

###########################################################################

Basic stack parameters have now been configured and saved.

###########################################################################

Command Line Interface (CLI)

You can manually load the CLI script from the console menu or automatically load

the script at startup.

Manual Configuration

You can manually configure the in-band management IP address at any time with

the following CLI command:

ip address <A.B.C.D> [netmask <A.B.C.D>] [default-gateway <A.B.C.D>]

Example:

Enter Privileged Exec mode:

Switch>enable

Enter the Global Config mode:

#config terminal

Manually configure in-band management IP information:

Switch(config)#ip address 192.0.2.1 netmask 255.255.255.0

default-gateway 192.0.2.0

Verify the information

Switch(config)#show ip

Bootp/DHCP Mode: BootP When Needed

Configured In Use Last BootP/DHCP

------------- ------------ ---------------

Stack IP Address: 0.0.0.0 0.0.0.0

Switch IP Address: 192.0.2.1 192.0.2.1 0.0.0.0

Switch Subnet Mask: 255.255.255.0 255.255.255.0 0.0.0.0

Mgmt Stack IP Address: 0.0.0.0

Mgmt Switch IP Address: 0.0.0.0

Mgmt Subnet Mask: 0.0.0.0

Mgmt Def Gateway: 0.0.0.0

Default Gateway: 192.0.2.0 192.0.2.0 0.0.0.0

CLI boot and factory-default commands:

boot - reboot the switch

boot default - reboot and use the factory default configuration

boot partial-default - reboot and use the partial factory default configuration

restore factory-default - reset the switch to factory default configuration

Command

Mode

Description Entrance

Commands

User Executive

(Exec mode)

5900>

• Default and Initial access mode

• Requires only Read access

• Used for basic commands such

as show, ping, and logoff

No entrance

command, default

mode

Exit

Commands

exit

logout

Privileged EXEC

(PrivExec mode)

5900#

• Used for basic switch level

management tasks; e.g.,

downloading software images,

setting passwords, starting the

switch

• Default and Initial access mode

• Requires only Read access

enable exit

logout

Global

Configuration

(Config mode)

5900(config)#

• Used to set and display general

switch parameters such as IP

address, ANMP parameters, Telnet

access and VLANs

• Requires Read-Write access

From Privileged EXEC

mode, enter:

configure

exit

logout

Interface

Configuration

(ifconfig mode)

5900(config-if)#

• Used to configure parameters for

each port or VLAN such as speed,

duplex mode, and rate limiting

• Requires Read-Write access

From Global

Configuration mode, to

configure a port, enter:

interface ethernet

<port_number>

To configure a VLAN,

enter:

interface vlan

<vlan_number>

To configure a loopback,

enter:

interface loopback

<loopback number>.

To configure a

management, enter:

interface mgmt <mgmt

number>

To return to Global

Configuration mode, enter:

exit

To return to Privileged

EXEC mode, enter:

end

To exit CLI completely,

enter:

logout

Note: Two console cable options are provided to connect the ERS 5900 DB9

(m) to a standard Pc/Laptop DB9 (m).

A 1.5 m integrated RJ45/DB9 (f) Console Cable (AL2011022-E6) in

conjunction with a DB9(f)/RJ45 Adapter (AL2011020-E6)

Two DB9(f)/RJ45 Adapter (AL2011020-E6) connected together using a

standard Cat5e Ethernet Cable (purchased separately)

For more information on additional modes, see Using CLI and EDM on ERS 4900

and ERS 5900 Series.

• The micro-USB port on the front panel of the ERS 59100 is not enabled.

• The SDN/AUX port on the rear panel of the ERS 59100 is not enabled.

PS4

PS2

6Powering Up 7Install SFP and SFP+ transceivers

1Connect the console cable to the ERS 59100

General notes

Popular Switch manuals by other brands

URC

URC Total Control MFS-8 installation manual

Azbil

Azbil HPQ-D11 user manual

Sony

Sony DFS-900M operating instructions

SICK

SICK i17S operating instructions

F&F

F&F SZR-277 quick start guide

Shure

Shure UAMS/BK user guide

Dräger

Dräger X-zone Switch Off Instructions for use

Asco

Asco Joucomatic 349 Series manual

BT Mini Hub user guide

D-Link

D-Link DES-1226G manual

Johnson Controls

Johnson Controls FS80-C installation instructions

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Configuration guide

MicroNet

MicroNet SP1200A user manual

Ruijie

Ruijie RG-PF2920 Series Hardware installation and reference guide

Altinex

Altinex DA1914SX user guide

MiLAN

MiLAN MIL-SM2401M user guide

RJM

RJM MASTERMIND PBC/6X user manual

Atlas

Atlas MMK-KVM8 owner's manual
