ExtraHop EDA 4200 Instruction sheet

© 2020 ExtraHop Networks, Inc. All rights reserved.

Install an SSD for Packet Capture on the

ExtraHop Discover Appliance

Published: 2020-06-08

This guide explains how to install the SSD for packet capture in the EDA 4200, EDA 6200, EDA 8200, EDA

9200, and EDA 10200 appliances.

Note: You must have write access to the ExtraHop Web UI and access to the ExtraHop Admin UI

to complete the steps in this guide.

Install the SSD

The SSD for packet capture is hot-swappable. You do not need to power off the ExtraHop appliance to

complete this procedure.

1. Remove the front bezel. Press and hold the release button on the left end of the bezel and swing the

bezel slightly to the right. Gently pull the bezel forward until it disconnects from the USB connector on

the right side of the appliance.

2. Insert the SSD for packet capture that you received from ExtraHop Networks into the correct drive

slot.

Figure 1: EDA 6200 - Slot 6

Figure 2: EDA 8200 - Slot 8

Figure 3: EDA 9200 and EDA 10200 - Slot 14

Enable the packet capture disk

1. Log in to the Administration page on the ExtraHop system through https://<extrahop-

hostname-or-IP-address>/admin.

2. In the Appliance Settings section, click Disks.

Install an SSD for Packet Capture on the ExtraHop Discover Appliance 2

3. In the Unused Disks section, next to SSD Assisted Packet Capture, click Enable.

4. Click OK to add the packet capture disk.

Verify the disk

Follow the steps below to ensure that you can successfully write packets to the new packet capture disk.

1. In the Packet Captures section, click Global Packet Capture.

2. Type a name for the packet capture and then click Start.

3. Click Stop.

4. Return to main Admin UI page and click View and Download Packet Captures.

Note: On Reveal(x) systems, go to the Packets page in the Web UI and confirm that packets

appear in the packets table.

5. Verify that your named packet capture appears in the packet capture list.

6. Click the name of the packet capture and download the file to your computer.
