ESAB Origo Mig C170 3ph User manual

Valid for serial no. 6260349 301 116 070103

Mig C170 3ph

Mig C200 3ph

Mig C250 3ph

Origo







Instruction manual

ENGLISH

-- 2 --

TOCe

1 DIRECTIVE 3........................................................

2 AFETY 3...........................................................

3 INTRODUCTION 5...................................................

3.1 Equipment 5................................................................

4 TECHNICALDATA 5.................................................

5 IN TALLATION 6....................................................

5.1 Placing 6...................................................................

5.2 Assem lyofcomponents 6...................................................

5.3 Electricalinstallation 7.......................................................

5.4 Mainspowersupply 7........................................................

6 OPERATION 8.......................................................

6.1 Connectionandcontroldevices 8.............................................

6.2 Weldingwithoutgas 9.......................................................

6.3 Wirefeedpressure 9........................................................

6.4 Replacingandinsertingwire 9................................................

6.5 Overheatingprotection 10.....................................................

7 MAINTENANCE 10....................................................

7.1 Inspectionandcleaning 10....................................................

8 FAULTTRACING 11...................................................

9 ORDERINGOF PAREPART 11......................................

DIAGRAM 12............................................................

WEARCOMPONENT 17.................................................

ACCE ORIE 18.......................................................

-- 3 --

C17253e

1 DIRECTIVE

DECLARATION OF CONFORMITY

ESAB AB, Welding Equipment, SE--695 81 Laxå, Sweden, gives its unreserved guarantee that weld-

ing power source OrigoTM Mig C170 3ph/C200 3ph/C250 3ph from serial num er 626 complies with

standard IEC/EN 60974--1, in accordance with the requirements of directive (73/23/EEC) and adden-

dum (93/68/EEC) and with standard IEC/EN 60974--10 in accordance with the requirements of direc-

tive (89/336/EEC) and addendum (93/68/EEC).

--------------------------------------------------------------------------------------------------------------------------------------

Kent Eim rodt

Glo al Director Equipment and Automation

ESAB AB

695 81 LAXÅ

SWEDEN Tel: + 46 584 81000 Fax: + 46 584 411924

Laxå 2006--07--07

2 AFETY

Users of ESAB welding equipment have the ultimate responsi ility for ensuring that anyone who

works on or near the equipment o serves all the relevant safety precautions. Safety precautions

must meet the requirements that apply to this type of welding equipment. The following recommen-

dations should e o served in addition to the standard regulations that apply to the workplace.

All work must e carried out y trained personnel well--acquainted with the operation of the welding

equipment. Incorrect operation of the equipment may lead to hazardous situations which can result

in injury to the operator and damage to the equipment.

1. Anyone who uses the welding equipment must e familiar with:

Sits operation

Slocation of emergency stops

Sits function

Srelevant safety precautions

Swelding

2. The operator must ensure that:

Sno unauthorised person is stationed within the working area of the equipment when it is

started up.

Sno--one is unprotected when the arc is struck

3. The workplace must:

Se suita le for the purpose

Se free from draughts

4. Personal safety equipment

SAlways wear recommended personal safety equipment, such as safety glasses, flame--proof

clothing, safety gloves.

SDo not wear loose--fitting items, such as scarves, racelets, rings, etc., which could ecome

trapped or cause urns.

5. General precautions

SMake sure the return ca le is connected securely.

SWork on high voltage equipment may only be carried out by a qualified electrician.

SAppropriate fire extinquishing equipment must e clearly marked and close at hand.

SLu rication and maintenance must not e carried out on the equipment during operation.

-- 4 --

C17253e

WARNING!

Read and understand the instruction manual

efore installing or operating.

WARNING

READ AND UNDER TAND THE IN TRUCTION MANUAL BEFORE IN TALLING OR OPERATING.

ARC WELDING AND CUTTING CAN BE INJURIOU TO YOUR ELF AND OTHER . TAKE PRECAU-

TION WHEN WELDING. A K FOR YOUR EMPLOYER’ AFETY PRACTICE WHICH HOULD BE

BA ED ON MANUFACTURER ’ HAZARD DATA.

ELECTRIC HOCK -- Can kill

SInstall and earth the welding unit in accordance with applica le standards.

SDo not touch live electrical parts or electrodes with are skin, wet gloves or wet clothing.

SInsulate yourself from earth and the workpiece.

SEnsure your working stance is safe.

FUME AND GA E -- Can be dangerous to health

SKeep your head out of the fumes.

SUse ventilation, extraction at the arc, or oth, to take fumes and gases away from your reathing zone

and the general area.

ARC RAY -- Can injure eyes and burn skin.

SProtect your eyes and ody. Use the correct welding screen and filter lens and wear protective

clothing.

SProtect ystanders with suita le screens or curtains.

FIRE HAZARD

SSparks (spatter) can cause fire. Make sure therefore that there are no inflamma le materials near y.

NOI E -- Excessive noise can damage hearing

SProtect your ears. Use earmuffs or other hearing protection.

SWarn ystanders of the risk.

MALFUNCTION -- Call for expert assistance in the event of malfunction.

PROTECT YOUR ELF AND OTHER !

Do not use the power source for thawing frozen pipes.

WARNING!

This product is solely intended for arc welding.

Do not dispose of electrical equipment together with normal waste!

In o servance of European Directive 2002/96/EC on Waste Electrical and Electronic

Equipment and its implementation in accordance with national law, electrical equipment

that has reached the end of its life must e collected separately and returned to an

environmentally compati le recycling facility. As the owner of the equipment, you should

get information on approved collection systems from our local representative.

By applying this European Directive you will improve the environment and human health!

-- 5 --

C17253e

3 INTRODUCTION

OrigoTM Mig C170 3ph/C200 3ph/C250 3ph are step controlled power sources in a compact design,

intended for welding with solid steel, stainless steel or aluminium wire as well as tu ular wire with or

without shielding gas.The possi ility of welding with homogeneous wire/shielding gas and welding with

gasless tu ular wire is o tained y switching the + and -- connections on the switching terminal y the

wire feed unit.

E AB’s accessories for the product can be found on page 18.

3.1 Equipment

The power source is supplied with:

SWelding gun

SReturn ca le with return clamp

SShelf for gas cylinder

SInstruction manual

4 TECHNICAL DATA

OrigoTM Mig C170

3ph OrigoTM Mig C200

3ph OrigoTM Mig C250

3ph

Voltage 400--415V

3∼50/60 Hz 400--415V

3∼50/60 Hz 230/400--415V

3∼50/60 Hz

Permissible load at

100% duty cycle 100A 120A 150A

60 % duty cycle 130A 150A 190A

35 % duty cycle 170A 200A 250A

etting range (DC) 30--170A 30--200A 40--280A

Open circuit voltage 15,5--30,6V 16,0--31,8V 15,0--37,0V

Open circuit power 310W 210W 340W

Power factor at max load 0,97 0,97 0,97

Control voltage 42V, 50/60Hz 42V, 50/60Hz 42V, 50/60Hz

Wire feed speed 1,0--17m/min 1,0--17m/min 1,0--17m/min

Burnback time 0,02--0,25s 0,02--0,25s 0,02--0,25s

pot welding 0,2--2,5s 0,2--2,5s 0,2--2,5s

Welding gun connection EURO EURO EURO

Wire dimension range 0,6--0,8(Fe, SS)

1,0(Al)

0,8(FCW)

0,8--1,0(CuSi)

0,6--1,0(Fe, SS)

1,0(Al)

0,8--1,0(FCW)

0,8--1,0(CuSi)

0,6--1,2(Fe, SS)

1,0--1,2(Al)

0,8--1,2(FCW)

0,8--1,0(CuSi)

Max diameter/weight

of wire bobin 300mm/15kg 300mm/15kg 300mm/15kg

Dimensions lxwxh 860x420x730 860x420x730 860x420x730

Weight 63,5kg 72,5kg 82kg

Operating temperature --10 ÷+40oC --10 ÷+40oC --10 ÷+40oC

Enclosure class IP 23 IP 23 IP 23

Application classification

-- 6 --

C17253e

Duty cycle

The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-

tain load without overloading.

Enclosure class

The IP code indicates the enclosure class, i. e. the degree of protection against penetration y solid

o jects or water. Equipment marked IP23 is designed for indoor and outdoor use.

Application class

The sym ol indicates that the power source is designed for use in areas with increased

electrical hazard.

5 IN TALLATION

The installation must be executed by a professional.

ote!

Connect the power source to the electricity mains with a network impedance of 0.268 (C250 3ph) ohm

or lower. If the network impedance is higher there is a risk of flicker in the illuminators.

WARNING!

This product is intended for industrial use. In a domestic environment this product may cause radio

interference. It is the user’s responsi ility to take adequate precautions.

5.1 Placing

Position the welding power source such way that its cooling air inlets and outlets are

not o structed.

5.2 Assembly of components

For packing and shipment of the machine the wheels are detached from the unit.

Before use attach the wheels according to instruction.

WARNING!

-- 7 --

C17253e

5.3 Electrical installation

C200 3ph

5.4 Mains power supply

Check that the unit is connected to the correct mains power supply voltage, and that it is protected y

the correct fuse size. A protective earth connection must e made, in accordance with regulations.

Rating plate with supply connection data

OrigoTM Mig C170 3ph OrigoTM Mig C200 3ph OrigoTM Mig C250 3ph

Voltage V 400--415V, 3∼50/60 Hz 400--415V, 3∼50/60 Hz 230/400--415V, 3∼50/60 Hz

Current A

at 100% duty cycle 4,0 5,3 12,1/7,0

at 60% duty cycle 6,1 6,8 17,6/10,2

at 35% duty cycle 8,9 10,1 25,3/14,6

Cable area mm2

24 x 1,5 4 x 1,5 4 x 2,5/4 x 1,5

Fuse slow A10 10 25/16

B: The mains cable areas and fuse sizes as shown above are in accordance with Swedish

regulations. They may not be applicable in other countries: make sure that the cable area and fuse

sizes comply with the relevant national regulations.

-- 8 --

C17253e

6 OPERATION

General safety regulations for the handling of the equipment can be found on

page 3. Read through before you start using the equipment!

WARNING!

Rotating parts can cause injury, take great care.

To prevent the reel sliding off the hu : Lock the reel in place y turning

the red kno as shown on the warning la el attached next to the hu .

WARNING!

WARNING -- TIPPING RI K!

There is a risk of tipping while transportation and operation, if the welding machine leans

more than 10o. In that case appropriate securing has to e provided !

6.1 Connection and control devices

1Mains supply switch 7Connection for return ca le (--), low inductan-

2Indicating lamp, power ON/OFF 8Kno for spot welding -- ON/OFF and time set-

ting

3Orange indicating lamp, overheating 9Kno for wire speed setting

4Welding voltage switch 10 Digital instrument -- V/A (option,see page 18)

5EURO -- connector for welding gun 11 Return ca le with return clamp

6Connection for return ca le (--), high in-

ductance *Kno for urn-- ack time setting (located on

control oard)

C250 3phC170 3ph

C200 3ph

-- 9 --

C17253e

6.2 Welding without gas

6.3 Wire feed pressure

Start y making sure that the wire moves smoothly through the wire guide. Then

set the pressure of the wire feeder’s pressure rollers. It is important that the

pressure is not too great.

Fig 1 Fig 2

To check that the feed pressure is set correctly, you can feed out the wire against

an insolated o ject, e.g. a piece of wood.

When you hold the gun approx. 5 mm from the piece of wood (fig. 1) the feed

rollers should slip.

If you hold the gun approx. 50 mm from the piece of wood, the wire should e

fed out and end (fig. 2).

6.4 Replacing and inserting wire

SOpen the side panel.

SDisconnect the pressure sensor y folding it ackwards, the pressure rollers

slide up.

-- 10 --

C17253e

SStraighten out the new wire 10--20 cm. File away urrs and sharp edges from the

end of the wire efore inserting it into the wire feed unit.

SMake sure that the wire goes properly into the feed roller track and into the outlet

nozzle and the wire guide.

SSecure the pressure sensor.

SClose the side panel.

6.5 Overheating protection

When the machine is switched on with the mains switch [1], indicating lamp [2] is on and

lamp [3] off -- the machine is ready to operate. If the internal temperature ecomes too

high, the welding is interrupted and disa led. This state is indicated y lighting of the

orange indicating lamp [3] on the front of the machine. It resets automatically when the

temperature has fallen.

7 MAINTENANCE

Regular maintenance is important for safe reliable operation.

ote!

All guarantee undertakings from the supplier cease to apply if the customer himself

attempts any work in the product during the guarantee period in order to rectify any

faults.

7.1 Inspection and cleaning

Check regularly that the power source is free from dirt.

The power source should e regularly lown clean using dry compressed air at reduced

pressure. More frequently in dirty environments. Otherwise the air inlet/outlet may e-

come locked and cause overheating.

Welding gun

SCleaning and replacement of the welding gun’s wear parts should take place at

regular intervals in order to achieve trou le--free wire feed. Blow the wire guide

clean regularly and clean the contact tip.

The brake hub

The hu is adjusted when delivered, if

readjustment is required, follow the instructions

elow. Adjust the rake hu so that wire is slightly

slack when wire feed stops.

SAdjusting the braking torque:

STurn the red handle to the locked position.

SInsert a screwdriver into the springs in the hu .

Turn the springs clockwise to reduce the raking torque

Turn the springs anticlockwise to increase the raking torque. NB: Turn oth

springs through the same amount.

Other manuals for Origo Mig C170 3ph

This manual suits for next models

Table of contents

Popular Welding System manuals by other brands

Berner

Berner PLASMACUT 54 instruction manual

Pro Spot

Pro Spot PR-155 Assembly instructions

Forney

Forney 210 operating manual

Thermal Arc

Thermal Arc 400S operating manual

Lincoln Electric

Lincoln Electric HANDYMIG 170I Operator's manual

GYS

GYS PROTIG 201 AC/DC Original instructions

TAFA

TAFA 30*8B35 owner's manual

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Technical specifications

CIGWELD

CIGWELD 636804 use instructions

Red-D-Arc

Red-D-Arc DC-400 Operator's manual

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 owner's manual

Elettro

Elettro HI-MIG 3000 SYNERGIC instruction manual

WIA

WIA Weldmatic 270 CP132-2 Operator's manual

Sonics

Sonics H520T instruction manual

Miller

Miller Big Blue 400D owner's manual

NewArc

NewArc RT2000 Operational manual

Hypertherm

Hypertherm powermax1000 Operator's manual

Lincoln Electric

Lincoln Electric POWER WAVE I400 Operator's manual
