Ericsson T28s User manual

Visit us on our website

http://mobile.ericsson.com

Ericsson Mobile Communications AB, SE-221 83 Lund, Sweden

EN/SVV 000 000 R1A

Mobile Phone

T28s

User’s Guide

NotforCommercialUse

EricssonMobileCommunicationsAB

Contents

at a Glance

Getting Started 3

Preparing Your Phone for Use 4

Turning Your Phone On and Off 9

Display Information and Key Functions 11

Making and Receiving Calls 13

During a Call 16

Functions and Settings 19

T28 Features 20

Using the Menus 21

Your Personal Phone Book 27

Using the Call List 35

Your Voice Mail Service 37

Personalizing Your Phone 39

Sending and Receiving Text Messages (SMS) 46

Diverting Incoming Calls 56

Security for Your Phone and Subscription 58

Handling More than One Call Simultaneously 65

Setting Network Preferences 70

Knowing the Call Time/Call Cost 73

Using Two Voice Lines 75

Voice Control 76

Calling Card Calls 79

Sending and Receiving Fax and Data Calls 82

Extras 84

The Profile Concept 88

Accessories 91

Online Services 99

Additional Information 103

Quick Keys 104

Troubleshooting 106

Ericsson Mobile Internet 108

Technical Data 109

Glossary 110

Guidelines for Safe and Efficient Use 115

Warranty 121

Declaration of Conformity 123

Index 125

Ericsson T28s

Second edition (September 1999)

This manual is published by Ericsson

Mobile Communications AB, without any

warranty. Improvements and changes to

this manual necessitated by typographical

errors, inaccuracies of current information,

or improvements to programs and/or equip-

ment, may be made by Ericsson Mobile

Communications AB at any time and with-

out notice. Such changes will, however, be

incorporated into new editions of this

manual.

©Ericsson Mobile Communications AB,

1999

Publication number: EN/LZT 126 1456 R1B

Printed in Sweden

INNOVATRON PATENTS

NotforCommercialUse

EricssonMobileCommunicationsAB

Please note!

Some of the services in this manual are not supported by all

networks. This also applies to the GSM International Emergency

Number 112.

Please contact your network operator or service provider if you are

in doubt whether you can use a particular service or not.

Note! You should read the Guidelines for Safe and Efficient Use

and the Warranty chapters before using your mobile phone.

The symbol on our products signifies that they have been

certified according to the EMC directive 89/336/EEC, the

Telecommunications directive 91/263/EEC, and the Low Voltage

directive

73/23/EEC when applicable. The products fulfil the requirements

according to the following standards:

Cellular Phones and Accessories in Combination:

ETS 300 342-1 EMC for European digital cellular

telecommunications.

Accessories Without Direct Connection to a Cellular Phone:

EN 50081 Electromagnetic compatibility, Generic Emission

Standard, and EN 50082 Electromagnetic compatibility, Generic

Immunity Standard.

NotforCommercialUse

EricssonMobileCommunicationsAB

Preparing Your Phone for Use 4

Turning Your Phone On and Off 9

Display Information and Key Functions 11

Making and Receiving Calls 13

During a Call 16

Getting Started

NotforCommercialUse

EricssonMobileCommunicationsAB

4 Preparing Your Phone for Use

Preparing Your Phone

for Use

Front

Back

Overview

Antenna

Indicator light

Earpiece

Power On/Off

Flip release button

Microphone

Volume key

Display

Keypad

Flip

Connector for external antenna

ole for belt clip

Battery release catch

Flip release button

Handsfree

connector

Charging

connector

Battery

NotforCommercialUse

EricssonMobileCommunicationsAB

Preparing Your Phone for Use 5

You need to do the following to use your phone:

•insert the SIM card

•attach the battery to the phone

•charge the battery

When you register as a subscriber with a network operator, you get a SIM

(Subscriber Identity Module) card. The SIM card contains a computer chip

that keeps track of your phone number, the services included in your

subscription, and your Phone Book information, among other things.

SIM cards come in two sizes. One is the size of a credit card and the other is

smaller. Your phone uses the smaller card. Many credit card-sized SIM cards

have a perforated smaller card that you can take out easily. Before you can use

your phone, you must insert the SIM card as shown below.

Inserting and Removing the SIM Card

1. Remove the battery if attached. Slide the SIM card into the slot, under the

silvery holders, with the golden connectors facing down and the cut corner

to the right.

Assembly

The SIM Card

NotforCommercialUse

EricssonMobileCommunicationsAB

6 Preparing Your Phone for Use

2. Raise the edge of the SIM card and slide it out.

The PIN

Most SIM cards are supplied with a security code, also known as PIN

(Personal Identity Number), which you need to access the network. Every

time you turn on your phone, you are asked to enter your PIN. You will find

your PIN in the information from your operator.

Some operators may have services that require a second PIN, your PIN2.

You should be careful with your PIN, since it is your protection against

unauthorized use of your subscription.

If your PIN is entered incorrectly three times in a row, the SIM card is

blocked. If this happens, you can unlock it by using your PUK (Personal

Unblocking Key code), which you also get from your operator.

Your T28 comes with a lithium battery. The battery is not charged when you

buy your phone, but there may be enough power to switch the phone on. We

recommend that you charge the battery up to three hours before you use the

phone for the first time.

Attaching the Battery to Your Phone

When to Charge the Battery

The battery that comes with your phone can be charged whenever you wish

without affecting its performance. You can also charge the battery when the

phone is off.

To remind you that you will soon need to charge the battery or replace it with

a charged one:

•an alarm signal (a short beep) sounds and the message

Attention! Battery low

appears in the display

The Battery

•

Place the battery on the back of the phone and push until you hear a click.

NotforCommercialUse

EricssonMobileCommunicationsAB

Preparing Your Phone for Use 7

•the indicator light on top of the phone starts flashing red

If you have an Ericsson-approved battery, you can check the remaining talk

and standby times in the Status menu by sliding the volume key upwards or

downwards in standby mode. You can move downwards in the menu by

pressing



. The remaining standby and talk times depend on the type of

battery you use and your position in the network. Please note that these times

are approximate and you may have 20% less time than is shown in the display.

Note! The phone turns itself off when the battery can no longer power it

satisfactorily.

Charging the Battery

Note! The mains plug may look different depending on the mains socket in

your country. Do not connect it to any other item than you Ericsson Travel

Charger CTR-10. It must not be separated from the charger when plugged

into the mains socket.

To indicate charging:

•the indicator on the top of the phone shows a steady red light (or green, if

the phone is switched on)

•the message

Charging only

is shown in the display

•the battery meter in the display pulses continuously

Note! If you charge a new battery that is empty, or a battery that has not been

used for a long time, it may take a while until you get an indication of

charging in the display. Only then can you switch on and use your phone.

3. Connect the charger to the phone

as shown. The flash symbol on the

plug must face upwards.

1. Make sure that the battery is

attached to the phone.

2. Connect the charger to the mains.

NotforCommercialUse

EricssonMobileCommunicationsAB

8 Preparing Your Phone for Use

An Ericsson-approved battery is indicated by

Ericsson Optimized charging

each

time you start charging the battery when the phone is switched on. For the best

charging, talk and standby times in the long run, we recommend that you use

only Ericsson-approved batteries with your phone.

Batteries that are not Ericsson-approved are charged slowly for safety reasons.

These are indicated by

Charging alien battery

each time you start charging the

battery when the phone is switched on.

Tip! You can use the phone while the battery is being charged. However, this

lengthens the charging time.

When the battery is fully charged, the battery meter in the display is full and

the indicator on the top of the phone shows a steady green light.

Disconnecting the Charger

Removing the Battery

Disconnect the charger from the phone by

moving the plug upwards.

2. Lift the battery away from the

phone.

.Slide the release catch upwards.

NotforCommercialUse

EricssonMobileCommunicationsAB

Turning Your Phone On and Off 9

Turning Your Phone On

and Off

1. Open the flip by pressing the flip release button on the right side of the

phone.

2. Press and hold the NO key until you hear a tone.

If “PIN:” Appears in the Display

Some SIM cards are protected with a PIN code. If

PIN:

appears in the display

after you have turned on the phone:

1. Enter your PIN. If you make a mistake while entering your PIN, erase the

wrong number by pressing the Ckey.

2. Press YES.

Note! If your PIN is entered incorrectly three times in a row, the SIM card is

blocked. You can unblock it by using your PUK. See “The SIM Card Lock” on

page 58.

If ‘Phone locked’ appears in the display, enter your phone lock code. See

“The Phone Lock” on page 59.

Network Search

After you have turned on the phone (and entered your PIN), the phone

searches for a network.

When a network is found, the phone beeps three times. The indicator light on

top of the phone flashes green once every second and your network operator’s

name (in most cases abbreviated) appears in the display.

This is called standby mode. You can now make and receive calls.

Note! See “Error Messages”on page 106, if you do not reach standby.

Turning your Phone on

Other manuals for T28s

This manual suits for next models

Table of contents

Other Ericsson Cell Phone manuals

Ericsson

Ericsson A2628S User manual

Ericsson

Ericsson T39 Installation manual

Ericsson

Ericsson DT292 User manual

Ericsson

Ericsson T18s User manual

Ericsson

Ericsson R520 User manual

Ericsson

Ericsson PF 768 Guide

Ericsson

Ericsson T18LX User manual

Ericsson

Ericsson T20E Quick reference guide

Ericsson

Ericsson R520S User manual

Ericsson

Ericsson R380 User manual

Ericsson

Ericsson T60d User manual

Ericsson

Ericsson R190 Satellite User manual

Ericsson

Ericsson A1228c User manual

Ericsson

Ericsson EF738 User manual

Ericsson

Ericsson A2618s User manual

Ericsson

Ericsson KF 788 User manual

Ericsson

Ericsson GF788E User manual

Ericsson

Ericsson 688 User manual

Ericsson

Ericsson R250s Pro User manual

Ericsson

Ericsson R320S Quick reference guide

Ericsson

Ericsson R250S User manual

Ericsson

Ericsson 19A705860P1 User manual

Ericsson

Ericsson AXATR-398-A2 User manual

Ericsson

Ericsson SH888 User manual

Popular Cell Phone manuals by other brands

Zte

Zte BLADE A520 quick start guide

Nokia

Nokia Lumia 620 user guide

Blackbe;rry

Blackbe;rry KEYone Safety and product information

Bea-fon

Bea-fon X5 Premium quick guide

Blackbe;rry

Blackbe;rry 8707 Series user guide

Blackbe;rry

Blackbe;rry Storm Troubleshooting

LG LM-X420QN user guide

LifeWatch

LifeWatch V user guide

Bea-fon

Bea-fon SILVER LINE SL860 user guide

IKI Mobile

IKI Mobile KF4.5i user manual

Hitech

Hitech HT-850 user guide

Yezz

Yezz Fashion F10 user manual

Point Mobile

Point Mobile PM60 user manual

Blackbe;rry

Blackbe;rry Q10 user guide

Blackbe;rry

Blackbe;rry Bold 9900 user guide

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 user guide

LG LM-K420EMW user guide

ISAFE MOBILE

ISAFE MOBILE IS655.2 operating manual
