Epson Work Force 7110 User manual

Refill system for

EPSON Work Force 7110

INSTALLATION GUIDE

Thank you for choosing our products. Before the installation read ca-

refully this instructions. For any clarification or tecnical support

contact our costumer service: www.cheapoffice.it

3) Manually move the printer trolley in

the cartridges change area, gently

remove the trolley cover levering with

a flat-blade screwdriver. Photo 2

4) Place the ink tanks on the

right side of the printer using

the adhesive velcro. Photo 3

5) Unscrew the bottle and

screw the measuring spout.

Photo 4

2) To facilitate assembly operations is necessary turn on the printer, wait a few

seconds and remove the power cable while the trolley moves to the left. After

removing the power cable, the printer trolley might be easly moved with your

hands.

1) Open the printer cover and insert a small piece of paper or plastic in the

closing sensor to allow the printer to work with the cover open without repor-

ting errors. Photo 1

6) Fill the tanks K/C/M/Y

following the colors sequen-

ce (photo 5).

NB: On the tanks upside the-

re are 4 big holes to refill

and 4 small holes that du-

ring the operation will must

be open, eventually you can

insert in them an air filter.

7) Reverse the cartridge

group. With a pen tip pierce

the plastic operulum that

protects the valves (Photo 6).

Pag 1/2

IMPORTANT NOTE: before starting to print verify that the ink quantityis

sufficient in order to avoid that the ink tanks get completely empty.

11) For the right functioning the pipe

should not ridde the the trolley race.

To make shure that it moves correctly

we raccommend to move manually the

trolley to the right and to the left

(photo 10-11). In this way you can a-

djust the pipe length so that, during

the movement will always remain well

stretched out and do not tuck into i-

tself.

12) During the operation the printer

will must be have the lid oper to let the

pie turn correctly.

13) When you see the message of empty

cartridge it will be necessary bring the

machine in cartridge change position

following the display instructions, it will

not be necessary remove the cartridges,

you just have to press the reset button

for 10 seconds. Photo 12

8) Insert completely the

syringe tip in a cartridge val-

ve and aspire until the syrin-

ge is full of ink. You can

return the ink that is accu-

mulate in the syringe in the

tank of the corresponding

color. Repeat the operation

for all the colors.

(Photo 7)

9)Place the cartridges in the

print trolley and press the

block untill you hear the

hooking click. photo 8

10) Place the adhesive

clip and the pipes

(photo 9).

Pag 2/2

IMPORTANT NOTE: If the printer jams the paper or or turn off suddenly, don’t leave the

printer in this position. You should remove the paper and turn on the printer, so the

print trolley can resume the position.

It will be necessary turn off the printer correctly, if the trolley stays out of the correct

position, the print head could get dry and become unusable.
