Epson Stylus Pro 9890 Series User manual

ROLL PAPER COVER CONTROL PANEL

ROLL PAPER HOLDERS

TENSION LEVER

POWER LIGHT

AND BUTTON

PAUSE/RESET

AND BUTTON

INK OPEN

BUTTON

PAPER FEED UP

BUTTON

LCD SCREEN

LEFT ARROW OR

PAPER SOURCE BUTTON

PAPER FEED

DOWN BUTTON

PAPER CUT

BUTTON

OK BUTTON

PAPER RELEASE

LIGHT AND BUTTON

BLACK INK CHANGE

BUTTON

INK LIGHT

PAPER LIGHT

EPSON|STYLUS|PRO|9890|

ROLL PAPER GUIDE

AND LOCK

If there is paper already loaded into the printer, press to lift the platen and release the roll.

Lift roll paper cover and flip down lock on to the left of the roll paper guide.

Slide carriage left and remove roll.

Unlock roll paper holders by lifting the tension levers.

Adjust roll paper holders to match size of the new media by moving the blue tab to 2” or 3“.

Place roll paper holders into each side of the media. Media should be oriented with the flap coming over the

top to the front.

LOADING|MEDIA

Make sure there are no gaps between the roll paper holders and the media.

Lock roll paper holds by flipping down the tension lever.

Place media and roll paper holders onto the rightmost roll paper guide.

Slide left roll paper guide into the left roll paper holder.

Make sure there are no gaps between the roll paper holders and the guides.

Flip the lock to the left of the roll paper holder to secure paper.

Insert paper into slot and feed down. Paper should be hanging out of the bottom of the machine.

Press the button

Once it is done adjusting, check to make sure media settings on Epson match your media.

If you receive any error messages, check to make sure that there are no gaps between the media and

the roll paper holders and that there are no gaps between the roll paper holders and the guides.

LOADING|MEDIA|CONT.

PRINTING

When your file is ready to print, go to File and then Print.

The print dialog will appear. Under the Printer tab, select Epson 9890.

PRINTING|CONT.

Select Page Setup.

Select Paper Size and then select Manage Custom Sizes.

Input the size of your media and press OK. Width is the size of the media and Height is the height of your

file.

PRINTING|CONT.

Select Setup.

Select the Layout tab and then select Printer Settings.

Printer Settings allows you to change media type, black ink output, and other variables.

It’s important to get these settings correct as they will override the settings on the Epson 9890.

Page Setup

- adjusts the format

of the paper: roll, sheet, etc.

Media Type

- adjusts the kind of

media you are using: paper,

fabric, etc. Changing media

type will change the kind of

black ink that the printer uses.

Make sure you have the correct

kind selected under Ink.

Print mode

- adjusts color, b/w, and black

for non-photographic images.

Color mode

- adjusts color and allows one

to choose how to manage

the colors.

Output resolution

- adjusts the quality of the print

through dpi (dots per inch).

Higher the number, the higher

the quality.

It is important to note that one can change between Matte Black and Photo Black. Doing this requires

the Epson 9890 to flush out ink of the various parts in the machine. This consumes a fair amount of ink.

PRINTING|CONT.

When all of your settings are correct, press print.

This will reopen the original print dialog.

Check that the file is being sent to the Epson 9890 and that the media size is correct, the press print.
