Epson PictureMate Manual

1. Press the On button to turn on the printer.

Note:

If the language setting appears, press the dbutton to highlight your preferred

language, then press the OK button. This setting appears in some areas.

2. Shake the new photo cartridge four or five times.

3. Remove the photo cartridge from its protective bag.

4. Open the cover on the back of the printer. Slide the lever to the

right, then down and to the left.

5. Place the cartridge properly into the cartridge holder, then push

in the cartridge until it clicks into place.

6. Slide the lever to the right, then up and a little to the left. Close the

cover.

cCaution:

Do not load paper until ink charging is complete.

7. The printer automatically starts to charge ink. Charging takes

about three minutes.

cCaution:

Do not turn off the printer during the ink charging process.

8. Press the OK button to finish.

Note:

The photo cartridge packaged with your printer is partly used during initial

setup. In order to produce high quality printouts, the print head in your printer

will be fully charged with ink. This one-off process consumes a quantity of

ink and subsequent cartridge will last for their full rated life.

Do not touch this part. cCaution:

❏Do not shake the photo cartridge

after removing it from the bag; it can

cause leakage.

❏Do not remove or tear the label on the

cartridge; this can cause leakage.

Setup cCautions must be observed to

avoid damage to your

equipment.

Notes contain important information

and useful tips on the operation of

your printer.

Cautions and Notes

Continue to the next page...

English

4048002-00

xxx

Connect the power cord and AC adapter, then plug-

in the printer.

2 Getting Started1 Unpacking

Color Ink Jet Printer

Remove the contents from the box. Remove all tape from the printer.

printer

photo cartridge

The contents may vary in certain locations.

Setup

DirectPrint

Guide

CD-ROM PictureMate

Photo Paper

Software

Installation

Guide

AC adapter and power cord

3 Installing the Photo Cartridge

The example below demonstrates how to print an

index of photos and then a Borderless photo.

Printing an Index

Print an index of photos.

1. Open the paper support and output tray, then load PictureMate

Photo Paper into the paper feeder. Then slide the left edge guide

against the left edge of the paper.

2. Open the memory card slot cover.

3. Insert the memory card containing your photos into the

appropriate memory card slot.

Note:

For the available memory card, refer the Direct Print Guide.

4. The Print Wizard appears when a memory card is inserted. If it does

not appear, reinsert the memory card. Press the Print button to

print an index.

Note:

For information about printing without using the Print Wizard, see the Direct

Print Guide.

5. Look at the index and choose the photo you want to print. The

photo number will be entered in the following procedure.

Printing a Photo

Print a photo selected from the index.

1. If the screen below appears on the panel, press the OK button.

2. Press the uor d button to select the photo number, and then press

the OK button.

3. Press the uor dbutton to select the number of copies, then press

the OK button.

4. Press the Print button.

5. The confirmation screen below appears. Press the Print button.

6. Now you have printed a photo!

For more information about PictureMate

If you print without using a PC, see the Direct Print

Guide.

CompactFlash/

Microdrive Memory Stick/

Memory Stick Duo/

SD Card/

MultiMediaCard/

miniSD card

SmartMedia/

xD-Picture Card

photo number

For PC users:

If you use the printer by connecting to a PC, see Software Installation Guide

to install the software.

4 Printing a Photo from a Memory Card

Printed in XXXXXX XX.XX-XX
