Epson L60IIP - TM B/W Direct Thermal Printer Quick setup guide

TM-L60II/L60II

Using this online information guid

The words on the left side of this screen are

bookmark

for all the

topics in this guide

Use the

scroll ba

next to the bookmarks to find any topic you

want. Click a bookmark to instantly jump to its topic. (If you wish,

you can increase the size of the bookmark area by dragging the

dividing bar to the right.

)

Use the

zoo

tools to magnify or reduce the page display

Click the

Fin

button if you want to search for a particular term.

(However, using the bookmarks is usually quicker.

)

Complete online documentation for Acrobat Reader is located in the Help directory for Acrobat Reader

EPSON

Guide to

TM-L60II/L60IIP

SEIKO EPSON CORPORATION

400617700

The programming examples in this manual are provided for the sole purpose of illustrating the

functions of the products. Seiko Epson Corporation makes no warranty, either expressed or implied,

as to their reliability and appropriateness for other uses.

transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or

otherwise, without the prior written permission of Seiko Epson Corporation. No patent liability is

assumed with respect to the use of the information contained herein. While every precaution has been

taken in the preparation of this book, Seiko Epson Corporation assumes no responsibility for errors or

omissions. Neither is any liability assumed for damages resulting from the use of the information

contained herein.

Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or

third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result

of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to

this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s

operating and maintenance instructions.

Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of

any options or any consumable products other than those designated as Original Epson Products or

Epson Approved Products by Seiko Epson Corporation.

EPSON is a registered trademark of Seiko Epson Corporation.

ESC/POS is a trademark of Seiko Epson Corporation.

NOTICE: The contents of this manual are subject to change without notice.

ESC/POS™ Information Manual

Guide to TM–L60II/L60IIP

9604-00

SEIKO EPSON CORPORATION

SYSTEM DEVICE DIVISION

2070 Kotobuki Koaka, Matsumoto-shi, Nagano-ken 399, Japan

Rev. A i

Introduction

ESC/POS™

The market for store automation equipment is changing rapidly with the widespread

introduction of POS (point of sale) terminals. These terminals are now appearing even in small

retail stores and specialty shops. They occupy a secure position in the range of applications

available for personal computers.

As more personal computers come to be used as POS terminals, the demand for matching

standardized peripheral devices is expected to rise. At present, however, many of the competing

POS terminal printer displays on the market employ mutually incompatible command sets. This

imposes limits on the expandability and range of applications possible with PC-based systems.

There is a need for a new command set designed to provide the expandability and universal

applicability demanded by the market.

To meet this need, Seiko Epson Corporation proposes the adoption of a newly developed

command set to standardize POS terminal peripheral devices: ESC/POS (Epson Standard Code

for Point of Sale).

The aim when developing ESC/POS was to create a set of control codes that could be used to

operate any output device connected to a POS terminal. These new codes are intended to replace

the mutually incompatible command sets previously in use.

TM/DM series models already support ESC/POS, and they have been evaluated highly in the

marketplace.

Seiko Epson Corporation plans to produce new models in the TM/DM series offering ESC/POS

support and to continue to work for the standardization of the entire POS environment to

promote the dissemination of ESC/POS.

About This Manual

❏Chapter 1 contains a table of supported commands, descriptions of all the commands

arranged by function with program examples and print samples, and character code tables.

❏Chapter 2 contains an example showing several commands used in a program for issuing a

coupon containing bar codes.

❏Chapter 3 contains a table of the commands listed by function type and a table showing

which commands are supported by various EPSON printers.

ii Rev. A

Features

The TM-L60II (RS-232 serial interface) and TM-L60IIP (parallel interface) are line thermal

printers that can print on roll paper and thermal labels. The printers have the following features:

❏Light weight and ultra-compact size.

❏High speed printing: 12 lines per second.

❏Low-noise thermal printing.

❏High reliability due to few moving parts.

❏Easy maintenance for tasks such as head cleaning.

❏Easy paper insertion with semi-auto loading for both roll paper and labels.

❏Label ejection commands prevent extraneous label feeding.

❏Serial numbers can be printed on labels.

❏Command protocol based on the ESC/POS standard.

❏Various layouts possible using page mode.

❏Font selection (12 × 24 or 9 ×24) possible using a command.

❏Character extension (up to 64 times the standard size) and character smoothing.

❏Four different print densities selectable via DIP switch settings.

❏Four-way routing of the interface, drawer control, and power cables: on either side,

underneath, or from the back of the case.

❏Controls on the front of the printer for easy operation, without requiring access to the sides

and back.

❏Water-resistant operation panel.

❏Bar code printing possible both in the vertical direction (fence bar code) and horizontal

direction (ladder bar code in page mode) using a command.

❏Repeated operation and copy printing possible using macro definitions.

❏Control capability for two drawers via the built-in interface.

❏Bidirectional parallel interface based on the IEEE 1284 Nibble/Byte Modes standard.

❏Thermal paper or thermal label can be selected via DIP switch settings.

Rev. A iii

The TM-L60II can also be used as the following:

❏A one-station printer for ECR and POS.

❏A ticket-issuing device.

❏An output device for weighing and other types of measurement.

❏A small scale label-marker for stores.

Option

❏EPSON power supply unit, PS-150.

Specifications

❏Printing specifications

Printing method: Thermal line printing

Printing speed: Approximately 12 lines/second (1/6-inch feed)

Dot density: 180 dpi ×180 dpi

Printing width: Thermal paper: 54.19 mm (2.13”), 384 dot positions

Thermal label : 51.93 mm (2.04”), 368 dot positions

❏Character specifications

Character fonts: 12 ×24/9 ×24

Characters per line: Thermal paper : 32/42

Thermal label : 30/40

Character size: 1.41(W) ×3.39(H) mm/.99(W) ×3.39(H) mm

Character sets: ASCII: 95 characters

International: 32 characters

Extended graphics: 128 characters ×6 pages

❏Paper size: Thermal paper : 59.0-60.5(W) mm × 83.0 mm diameter

Thermal label : 59.5-61.0(W) mm × 83.0 mm diameter

❏Interface: RS-232 (serial interface)

IEEE 1284 (parallel interface)

❏Receive buffer: 4K or 45 bytes (selectable by DIP switch)

iv Rev. A

Rev. A Command Descriptions 1-1

TM–L60II/L60IIP Information Manual

Chapter 1

Command Descriptions

Following this table are all the commands organized by function and described with program

examples and print samples.

Supported Commands

Command Name Function type Page

number

HT Horizontal tab Print position 1-31

LF Print and line feed Print 1-5

➀Print and return to standard mode

(in page mode) Print 1-8

➁Print and feed label to print starting position

(on label) Print 1-9

CR Print and carriage return Print 1-6

CAN Cancel print data in page mode Character 1-24

DLE EOT Real-time status transmission Status 1-44

ESC FF Print data in page mode Print 1-8

ESC SP Set right-side character spacing Character 1-12

ESC ! Select print mode(s) Character 1-17

ESC $ Set absolute print position Print position 1-29

ESC % Select/cancel user-defined character set Character 1-13

ESC & Define user-defined characters Character 1-13

ESC ✻Select bit-image mode Bit image 1-37

ESC – Turn underline mode on/off Character 1-18

ESC 2 Select default line spacing Line spacing 1-10

ESC 3 Set line spacing Line spacing 1-10

ESC = Select peripheral device Miscellaneous function 1-60

ESC ? Cancel user-defined characters Character 1-13

ESC @ Initialize printer Miscellaneous function 1-57

ESC D Set horizontal tab positions Print position 1-31

ESC E Turn emphasized mode on/off Character 1-18

ESC G Turn double-strike mode on/off Character 1-19

ESC J Print and feed paper Print 1-6

ESC L Select page mode Miscellaneous function 1-61

ESC R Select an international character set Character 1-15

ESC S Select standard mode Miscellaneous function 1-61

ESC T Select print direction in page mode Print position 1-34

1-2 Command Descriptions Rev. A

ESC V Turn 90° clockwise rotation mode on/off Character 1-21

ESC W Set printing area in page mode Print position 1-33

ESC \ Set relative print position Print position 1-29

ESC a Select justification Print position 1-30

ESC c 3 Select paper sensor(s) to output paper-end

signals Paper sensor 1-27

ESC c 4 Select paper sensor(s) to stop printing Paper sensor 1-26

ESC c 5 Enable/disable panel buttons Panel button 1-25

ESC d Print and feed

lines Print 1-7

ESC p Generate pulse Miscellaneous function 1-60

ESC t Select character code table Character 1-16

ESC u Transmit peripheral device status Status 1-47

ESC v Transmit paper sensor status Status 1-48

ESC { Turn upside-down printing mode on/off Character 1-20

GS FF Print and eject label Print 1-9

GS ! Set character size Character 1-22

GS $ Set absolute vertical print position in page mode Print position 1-36

GS ✻Define downloaded bit image Bit image 1-39

GS / Print downloaded bit image Bit image 1-39

GS : Start/end macro definition Macro function 1-55

GS < Initialize printer mechanism Miscellaneous function 1-62

GS A Adjust label print starting position Miscellaneous function 1-62

GS B Turn white/black reverse printing mode on/off Character 1-23

GS C 0 Select counter print mode Miscellaneous function 1-63

GS C 1 Select count mode (A) Miscellaneous function 1-64

GS C 2 Set counter Miscellaneous function 1-64

GS C ; Select count mode (B) Miscellaneous function 1-66

GS H Select printing position of HRI characters Bar code 1-53

GS I Transmit printer ID Miscellaneous function 1-59

GS L Set left margin Print position 1-32

GS P Set horizontal and vertical motion units Miscellaneous function 1-58

GS W Set printing area width Print position 1-32

GS \ Set relative vertical print position in page mode Print position 1-36

GS ^ Execute macro Macro function 1-55

GS a Enable/disable Automatic Status Back (ASB) Status 1-41

GS b Turn smoothing mode on/off Character 1-23

Command Name Function type Page

number

Rev. A Command Descriptions 1-3

TM–L60II/L60IIP Information Manual

GS c Print counter Miscellaneous function 1-63

GS f Set font for HRI characters Bar code 1-53

GS h Select bar code height Bar code 1-49

GS k Print bar code Bar code 1-51

GS r Transmit status Status 1-43

GS w Set bar code width Bar code 1-50

Command Name Function type Page

number

This manual suits for next models

Table of contents

Other Epson Printer manuals

Epson

Epson 2200 - Stylus Photo Color Inkjet Printer User manual

Epson

Epson EcoTank ET-1110 Series User manual

Epson

Epson C284999 - TM H6000P B/W Direct Thermal User manual

Epson

Epson CBB User manual

Epson

Epson R220 - Stylus Photo Color Inkjet Printer User manual

Epson

Epson L382 SERIES User manual

Epson

Epson Stylus 1000 User manual

Epson

Epson U220B - TM Two-color Dot-matrix Printer Use and care manual

Epson

Epson AcuLaser M4000N User manual

Epson

Epson ET-2650 Instruction Manual

Epson

Epson 3800 - Stylus Pro Color Inkjet Printer User manual

Epson

Epson Stylus Pro 5500 Use and maintenance manual

Epson

Epson EPL-N2000 User manual

Epson

Epson TM-P60II Use and care manual

Epson

Epson AL-M320DN User manual

Epson

Epson TM H6000 - B/W Direct Thermal Use and care manual

Epson

Epson 4000 - Stylus Pro Color Inkjet Printer User manual

Epson

Epson U230 - TM Two-color Dot-matrix Printer User manual

Epson

Epson XP-820 Instruction Manual

Epson

Epson LX-300+ User manual

Epson

Epson TM U295 - B/W Dot-matrix Printer User manual

Epson

Epson TM-DT Series User manual

Epson

Epson XP-243 Series' XP-245 Series User manual

Epson

Epson 1400 - Stylus Photo Color Inkjet Printer User manual

Popular Printer manuals by other brands

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series quick start guide

Evolis

Evolis Elypso user guide

Kyocera

Kyocera FS-9530DN specification

Canon

Canon LASER SHOT LBP-1210 Specifications

Samsung

Samsung BIXOLON SRP-350plusF user manual

Canon

Canon PIXMA PRO-1 Series Getting started

Canon

Canon PIXMA G3560 Online manual

Dell

Dell Color Laser Printer 2130cn user guide

Tektronix

Tektronix Phaser 840 user guide

Canon

Canon CLBR 460ps Service manual

Eltron

Eltron P210 Guide manual

Ricoh

Ricoh MD-P1 Service manual

Canon

Canon imagePASS-A2 Service guide

Canon

Canon S820D user guide

IRA3D

IRA3D POETRY4 Original instructions

Ricoh

Ricoh Aficio AP400 operating instructions

BIXOLON

BIXOLON SRP-352plusV user manual
