EPSON AMERICA, INC.

EPSON

Product Support Bulletin

Subject: AP-2250 Commonly Asked Questions and Answers

Date: 10/9/92

Page(s): 1 of 4 PSB No: P-0089A

Originator: LHT

This bulletin answers some commonly asked questions about the AP-2250 printer.

The questions and answers are listed below.

QUESTIONS AND ANSWERS ON THE AP-2250

Q. What is the AP-2250 printer?

The AP-2250 is Epson’s first narrow carriage light duty printer specifically

designed to meet the unique needs of the entry-level home computer

user.

Listed below are some of the key features of the AP-2250 printer:

ESC/P code compatible

Small size and small footprint

Built-in 50 sheet auto sheet feeder

Simple two button control panel

Easy set-up, no DIP switches

Gap free mechanism (paper thickness lever is not needed)

Two draft fonts and two letter quality fonts

5 characters code table, 13 international characters sets

Q. Why is a ON-LINE or PAUSE button not present on the AP-2250 front

panel?

The AP-2250 printer was designed to be as easy to use as possible.

Because of this, the AP-2250 was designed without any unnecessary

buttons. The AP-2250 automatically goes into a ready condition after

being powered on.

Q. What are the product codes for AP-2250 options and supplies?

A. S015047

C800262 Fabric Ribbon Cartridge

Push Tractor

PSB No: P-0089A

Page: 2 of 4

Q. What is the advantage of purchasing an optional Push Tractor?

The optional Push Tractor allows the AP-2250 to use continuous narrow

paper while still maintaining the ability to use the AP-2250’s built-in single

sheet paper cassette. When using the optional push tractor, the AP-2250

can accept a two part carbonless multi-part form with a total thickness up

to 0.18mm.

Q. With which interface does the AP-2250 come standard?

The AP-2250 comes standard with a built-in Centronics compatible parallel

interface.

6. Q.

How do I use the AP-2250 to operate with serial communications?

A. The AP-2250 only operates with parallel communications.

If a printer driver selection is not shown for the AP-2250 in my application

software programs, which printer driver selection should I choose?

The recommended printer driver selections for the AP-2250 are listed

below in order from best to worst.

AP-2250

LX-810/850

LX-800

LX-86

LX-80

FX-850

FX-86e/800

EX-800

FX-85

FX-80+

FX-80

To take full advantage of the AP-2250’s features, choose one of the first

three printers listed above. If none of these printer selections are

available from within your application software, contact your software

manufacturer to determine whether they offer a printer driver update or if

they plan to make one available in the future.

10.

11.

12.

13. Q. Can different fonts be selected on the AP-2250’s front panel?

Yes, different fonts may be selected from the AP-2250’s front panel by

using the FONT button. However, all font selections made from the front

panel can be overridden by a software application program. The

recommended method to select fonts is through the program that you are

using to print. If the program does not provide font selection abilities, then

the printer’s font panel is very useful.

PSB No: P-0089A

Page: 3 of 4

Does the AP-2250 use DIP switches?

No, the AP-2250 does not use DIP switches. The various features

settings are selected through use of the two buttons on the printer’s front

panel.

Can the AP-2250 print on labels?

Yes, the AP-2250 can print on labels The optional pull tractor is used to

load continuous labels.

Can the AP-2250 print on envelopes?

Yes, the AP-2250 can print on envelopes. The envelopes are loaded at

the rear of the printer by using the printer’s manual insertion slot. (Note:

The printer must be placed in the upright position first.)

Can the AP-2250 print on legal size paper?

Yes, the AP-2550 can print on legal paper. Legal size paper is loaded at

the rear of the printer by using the printer’s manual insertion slot. (Note:

The printer must be placed in the upright position first.)

Can the AP-2250 print in landscape orientation?

Yes, but the AP-2250 requires the use of a software application program

because landscape characters are not included in its built-in characters

set. Two very popular software application programs for printing in the

landscape mode are Sideways and Always.

PSB No: P-0089A

Page: 4 of 4

14.

Q. Why is the AP-2250’s parallel cable connector located on the side of the

printer instead of the rear like most other printer?

Since the AP-2250 may be operated in two different positions, it was

necessary to relocate the parallel cable connector to the side of the

printer.

15.

Q. Why does the AP-2250 produce two (2) long and two (2) short beeps

when first power-on?

The AP-2250 produces these beeps at power-on to indicate that it has

completed its power-on initialization process and is ready to print.

EPSON AMERIC& INC.

EPSON

Product Support Bulletin

Subject: Quick Reference for Current Dot-Matrix Printer Print Speeds

Date: 10/9/92

Page(s): 1 of 1 PSB No: P-0030C

Originator: SLS

9-PIN PRINTERS

24-PIN PRINTERS

GLOSSARY OF TERMS

CPI:

Characters Per Inch

CPS: Characters Per Second

Draft:

Draft uses a minimum number of dots per character for high-speed printing.

Elite:

12 Characters Per Inch (12 CPI)

Pica:

10 Characters Per Inch (10 CPI)

LQ:

Letter Quality reduces the print speed and increases the number of dots per

character to increase the print quality. (24-pin printers only)

NLQ:

Near Letter Quality reduces the print speed and increase the number of dots

per character to increase the print quality. NLQ printing requires two passes

per character. (Q-pin printers only)

EPSON AMERICA, INC.

EPSON

Product Support Bulletin

Subject: Quick Reference for 9/24 Pin Printer Paper Specifications

Date: 10/9/92

Page(s): 1 of 1 PSB No: P-0022D

Originator: SLS

This PSB provides a quick reference for the paper specifications on Epson’s current

line of Q-pin and 24-pin dot-matrix printers when using continuous paper. The

‘Maximum No. of Copies” is the maximum allowable number of copies when using

continuous multi-part carbonless paper. The “Total” number is the maximum

allowable number of copies including the original. The ‘Maximum Total Thickness”

is the maximum allowable total thickness including the original plus any copies.

9-PIN PRINTERS

Model

Orig. + Maximum No.

of Copies Total Maximum Total

Thickness

AP-2250 l

0.0098” (0.25mm)

LX-810

0.0098” (0.25mm)

FX-870/1170

0.0126” (0.32mm)

DFX-5000

(Front Tractor)

(Rear Tractor)

360.018" (0.46mm)

0.012” (0.30mm)

DFX-8000

(Front Tractor)

(Rear Tractor)

0.018" (0.46mm)

0.012” (0.30mm)

24-PIN PRINTERS

Model

Orig. + Maximum No.

Total Maximum Total

of Copies Thickness

AP-3250 *

0.0071” (0.18mm)

LQ-570/1070

0.0126” (0.32mm)

LQ-860

0.0126” (0.32mm)

LQ-870/1170

0.0126” (0.32mm)

LQ-2550

0.018" (0.46mm)

* Note:

The AP-2250 and AP-3250 require an optional push tractor to use

continuous paper.
