EnGenius EnStation 6 User manual
ENH500-AX | EnStation 6
Quick Installation Guide
Outdoor Access Point
ENH500-AX
Waterproof*2
Device*2 PoE Adapter*2 Quick Installation Guide Power Cord*2
Screw Set*2 Pole Mounting Strap*2
Adhesive Label
Quick Installation Guide
Outdoor Access Point / Client Bridge
ENH500-AX | EnStation 6
Outdoor Access Point
Minimum Requirements
Broadband Internet Service
(Cable or DSL Modem)
Internet Browser
(Internet Explorer, Safari, Firefox, Chrome, Edge)
EnStation 6
Device *2
Sealing nut*2
Dynamic Stick*2
PoE Adapter*2
Bracket*2
Screw Set*2
Quick Installation Guide
Power Cord*2
Pole Mounting Strap*2
Outdoor Access Point
1 - Connecting the Device
a. Remove the rear bottom panel.
b. Connect one end of the Ethernet Cable to the LAN(PoE) port
of the AP/Bridge and the other end to the PoE Port on the
PoE Adapter.
c. Connect the Power Cord with the PoE Adapter and plug the
other end into an electrical outlet.
d. Connect the second Ethernet Cable to the LAN port of the
PoE Adapter and the other end to the Ethernet Port on the
computer.
e. Place the panel removed from step A back into the device.
• Note: The device should ONLY be powered via Ethernet Cable
connected to the included PoE Adapter.
ENH500-AX
a)
b) c)
d)
e)
Outdoor Access Point
EnStation 6
a. Remove the rear bottom panel.
b. Connect one end of the Ethernet Cable to the LAN(PoE) port of the CPE and the other end to
the PoE Port on the PoE Adapter.
c. Connect the Power Cord to the PoE Adapter and plug the other end into an electrical outlet.
d. Connect the second Ethernet Cable to the LAN port of the PoE Adapter and the other end to
the Ethernet Port onto the computer.
e. Place the panel removed from step “a” back into the device.
• Note:
• The device should ONLY be powered via Ethernet Cable connected to the included PoE
Adapter, EnStation 6 supports Proprietary 24V/54V PoE input.
• The 2nd Ethernet Port of the device can supply the 802.3af power source when used with
the included PoE Adapter.
d)
b)
c)
e)
Outdoor Access Point
2 - IP Address Configuration
a. Once your computer is on, ensure that your TCP/IP is set to “ON” or “Enabled”. Open Network
Connections and then click Local Area Connection. Select Internet Protocol Version 4 (TCP/IPv4).
b. If your computer is already on a network, ensure that you have set it to a Static IP Address
on the interface. (Example: 192.168.1.10 and the Subnet Mask address as 255.255.255.0).
Outdoor Access Point
3 - Device Setup
a. To configure the device, open a web browser. In the web browser’s address bar enter 192 .168.1.1
and hit enter.
b. A long screen will appear. By default, the device username is “admin,” and the password is
“admin”. Enter the current username and password of the device and then click Login.
• Note: The model name on the login screen depends on the product you are using.
c. You can also use the EnWiFi App and connect to the management SSID ,which is on the device
label and GUI, to configure the device. The defailt Wi-Fi password is 12345678.
Outdoor Access Point
4 - Switching Modes
Configure on GUI
a. The device can operate in the following modes:
• Access Point, Client Bridge, WDS AP or WDS Station.
• Note: The model name on the login screen depends on the product you are using.
Outdoor Access Point
a. Click on the Wireless link under the Network and set up the Operation Mode.
b. Use EnWiFi App, open “Configure Wireless” to set up the Operation Mode.
Configure on EnWiFi App
• It may take up to 90 seconds for the device to initially power up.
Outdoor Access Point
5 - Mounting the Device
Wall Mounting
a. Determine where the Access Point is to be placed and stick the Adhesive label on the surface.
b. Use the appropriate drill bit to drill the 8.1 mm diagram and 26 mm depth holes on the
markings of the label.
c. Remove the label and Screw the anchors unto the holes until they are flush with the wall.
d. Screw the included screws into the anchors and place the Access Point against the wall with
the mounting screw heads.
a)
b)
c)
Wall
Outdoor Access Point
a. Plug the dynamic stick into the bracket.
b. Screw the sealing nut and assembled parts, tighten it with 80kgf.cm.
c. Put the nock washer on the dynamic stick.
d. Assemble the mounting parts to the device.
a)
b)
c)
d)
e. Determine the mounting location. Mark and drill two pilot holes aligning to the screw holes of the bracket.
f. Put wall anchors into the holes and insert the screw into the wall anchor.
g. Screw and secure the bracket in place.
g)
f)
e)
Wall
