Enerdrive EPL-100BT-12V-SLIM User manual
Enerdrive B-TEC Lithium (LiFePO4), Lithium Ion Phosphate
Prismatic Cell Battery with Smart Phone Monitoring
Enerdrive B-TEC G2 Manual (Rev. 3.1)
EPL-100BT-12V-SLIM EPL-125BT-12V-G2 EPL-200BT-12V-G2
EPL-300BT-12V-G2 EPL-100BT-24V EPL-150BT-24V-G2 EPL-100BT-36V
Enerdrive B-TEC G2 Manual (Rev. 3.1)
For safe and optimum performance, the Enerdrive ePOWER B-TEC LiFePO4 Lithium Ion Phosphate Battery
with Smart Phone Monitoring must be used properly. Carefully read and follow all instructions and
guidelines in this manual and give special attention to the CAUTION and WARNING statements.
EPL-100BT-12V-SLIM
EPL-125BT-12V-G2
EPL-200BT-12V-G2
EPL-300BT-12V-G2
EPL-100BT-24V
EPL-150BT-24V-G2
EPL-100BT-36V
2021
Warranty Returns: Reply Paid 8786, Wynnum Plaza, QLD 4178
Dometic Power & Control (Enerdrive) Pty Ltd
Email: [email protected]
Support Contact Information
Please be sure to read and save the entire manual before using your Enerdrive ePOWER B-TEC LiFePO4
Lithium Ion Phosphate Battery with Smart Phone Monitoring. Misuse may result in damage to the battery,
and/or cause harm or serious injury. Read manual in its entirety before using the unit and save manual for
future reference.
Enerdrive B-TEC G2 Manual (Rev. 3.1)
www.enerdrive.com.au Page 3
TABLE OF CONTENTS
SECTION 1 - INSTALLATION 4
SECTION 2 - CONNECTIONS 4
SECTION 3 - CHARGING 5
SECTION 4 - DISCHARGING (USING THE BATTERY) 6
SECTION 5 - PROTECTING YOUR BATTERY 7
SECTION 6 - RESTARTING YOUR BATTERY 8
SECTION 7 - USING THE SMART PHONE BATTERY MONITOR APP 9
SECTION 8 - WARNINGS 10
SECTION 9 - FAQ 11
SECTION 10 - BATTERY SPECIFICATIONS 13
SECTION 11 - DIMENSIONS 15
SECTION 12 - WARRANTY 22
SECTION 1 - INSTALLATION 4
SECTION 2 - CONNECTIONS 4
SECTION 3 - CHARGING 5
SECTION 4 - DISCHARGING (USING THE BATTERY) 6
SECTION 5 - PROTECTING YOUR BATTERY 7
SECTION 6 - RESTARTING YOUR BATTERY 8
SECTION 7 - USING THE SMART PHONE BATTERY MONITOR APP 9
SECTION 8 - WARNINGS 10
SECTION 9 - FAQ 11
SECTION 10 - BATTERY SPECIFICATIONS 13
SECTION 11 - DIMENSIONS 15
SECTION 12 - WARRANTY 22
Page 4
Section 1 - Installation
Section 2 - Connection
Cable Conversion Guide
The spring washers must be used on the battery terminal bolts - they apply pressure to the lugs for a secure
connection. There is no need to over-tighten the bolts, simply ensure there is no movement of the cables.
Make sure the main Battery Cable lug is mounted directly onto the Battery terminal with no washers
between them.
Your B-TEC battery must be installed in a dry and cool location.
Supplied battery trays and straps are the preferred mounting method. Ensure that suciently rated
fasteners are used to hold the tray rmly to the mounting material.
Enerdrive highly recommend the battery is installed in the upright position.
Enerdrive approve installation of B-TEC batteries in accommodation areas of RV's. Temperatures must not
exceed the rated operating temperatures therefore natural, or fan forced ventilation maybe required.
There should be 25mm clear space around the B-TEC battery.
Consideration should be taken to not mount the battery near any metallic service lines such as LPG, diesel, or
petrol lines. This is to ensure no accidental shorting of the battery terminals occur, especially when tting or
removing the battery.
B-TEC batteries must not be installed -
• In vehicle engine bays or in high heat environments, refer to Section 10 - Battery Specications
• In wet areas such as caravan chassis mounts, open ute trays or boat deck areas.
• Inside compartments dedicated to carrying gas.
It is recommended that no more than four terminals be connected to a battery terminal, if you do have more
than 4 terminals the use of a fuse block and negative busbar are recommended.
Cable terminal should be in the order with heaviest current draw (largest cable) in contact with the battery
to light est. current draw (smallest cable) terminals on the top.
Use of insulating terminal boots is recommended, especially in areas where accidental shorting may occur,
such as storage lockers or under lounges and beds. Connect the Positive (Red) and Negative (Black) cables to
the battery, ensuring you are using cable that is of adequate size for the demands of the system, and well
crimped and protected termination lugs.
Example;
1000W Inverter - at least Guage 2 (35mm²)
2000W Inverter - at least Guage 00 (70mm²
3000W Inverter - at least Guage 000 (95mm²)
Enerdrive B-TEC G2 Manual (Rev. 3.1)
www.enerdrive.com.au Page 5
Section 3 - Charging
Lithium batteries need to be charged slightly dierent to other batteries.
To ensure they live a long life and provide maximum capacity, you must use a charger with a lithium LiFeP04
setting - this includes:
• AC Chargers
• DC to DC Chargers
• Solar Controllers
If your charger allows, set the charge voltage from 14.2 - 14.6 Volts and Float 13.5 - 13.6 Volts and proceed
with charging. We recommend charging at the lower end of the voltage scale for maximum longevity of the
battery.
It is recommended that the charging current should be 30% of your battery capacity. You can charge at
higher currents but 30% is the recommended for long life.
See Section 10 - Battery Specications.
*Note:
You can charge a lithium battery with a non-lithium charger, but these chargers can deliver too much or too
little voltage and may not cut o when the battery is full.
DO NOT use a charger with a “Pulse Stage”or“Equalisation Mode”. This will damage the battery and void
warranty.
DO NOT connect this battery to a start battery with a VSR (Dual Battery System or“Voltage Sensitive Relay”).
The voltage of the Lithium battery may keep the VSR switched on resulting in it discharging into the start
battery, and/or attening the start battery.
DO NOT charge B-TEC batteries direct from an alternator.
The Enerdrive B-TEC Lithium Battery can deliver a very high discharge current due to the high power, high
quality Battery Management System (BMS) and prismatic Lithium cells inside the battery.
Refer to Section 10 - Battery Specications for the maximum rated discharge current of your battery.
For this to happen, you MUST USE cable of the correct guage.
Inverter Usage
It is recommended to not put more load on your batteries than the rating of the BMS installed. We also
recommend following the below even if you have two batteries in parallel, this protects overloading a single
battery if the other battery in the bank was to shut down (i.e. low capacity).
• 12V 100AH B-TEC - 12V 1000W Inverter Max
• 12V 125AH B-TEC - 12V 1000W Inverter Max
• 12V 200AH B-TEC - 12V 2600W Inverter Max
• 12V 300AH B-TEC - 12V 3000W Inverter Max
• 24V 150AH B-TEC - 24V 3500W Inverter Max
Section 4 - Discharging (using the battery)
Enerdrive B-TEC G2 Manual (Rev. 3.1)
www.enerdrive.com.au Page 7
Lithium batteries cannot be protected eectively by monitoring voltage due to their ability to maintain a
higher voltage for much longer than AGM or ooded/sealed batteries.
“State of Charge” (SOC%) percentage is the most accurate and eective method of disconnecting loads from
the battery - this requires a battery monitor which uses a “shunt”to measure the current going into
(Charging) and coming out of (Discharging) the battery.
Example;
200 Amp Battery Fully Charged State of Charge = 100%
50 Amps used State of Charge = 75%
100 Amps used State of Charge = 50%
It is recommended that Lithium batteries not be discharged below 20% State of Charge or the battery life
may be shortened.
As an added layer of protection, the Enerdrive B-TEC Lithium Battery also has a built-in low voltage
disconnect circuit. If this occurs, please refer to Section 6 - Restarting Your Battery.
If your battery has shut down due to low voltage you must charge your battery within 14 days to prevent
permanent damage occuring to the cells.
Section 5 - Protecting Your Battery
FLAT BATTERY
RESET BUTTON
Page 8
Section 6 - Restarting Your Battery
We strongly recommend keeping the battery charged to avoid activating the internal low battery voltage
discconnect.
If your DC system shuts down, the battery may require re-starting. Please use the following procedure:
1. Turn o all DC and AC Loads
2. Connect charging source/s and switch ON
3. Hold the“Reset”button 5 seconds, release and quick press
4. Release and wait 7 seconds
5. Power will be restored and charging will commence after a few seconds
6. When the SOC (State of Charge) is above 20%, loads can be switched on if required
By continuously tripping the low voltage discconnect of the battery you may cause damage to sensitive
electronic equipment that is attached to the battery. i.e. battery chargers, solar controllers, inverters, stereo
equipment etc - all of which are not covered under the battery warranty.
To reconnect, a charge voltage of ≥12.8v must be applied to the battery before the over-discharge release
will activate and allow charge current to ow into the battery. This can be done via a momentary reset switch
between the start battery and B-TEC or by jump starting with a portable power pack.
Follow the above steps to turn o all DC and AC loads, turn on charging sources and then activate reset
switch or apply jump start pack, disconnect as soon as chargers begin charging.
Batteries with Reset Button on Battery
Batteries without Reset Button on Battery
Enerdrive B-TEC G2 Manual (Rev. 3.1)
www.enerdrive.com.au Page 9
Section 7 - Using the Smart Phone Battery Monitor App
• Battery Capacity • Individual Cell Voltage
• Battery Voltage • Battery Temperature
• Battery Current (Amps) • Battery Cycles
• Battery State of Charge (SOC) • Battery Alarms
• Battery State of Health (SOH) • Battery Notications
• Battery Status
The Enerdrive B-TEC Lithium Battery incorporates a wireless Smart Phone Monitoring system. By
downloading the Android™ or Apple® app to your Smart Phone or tablet device, you can monitor the
following information;
* The red warning light is only an indicator, not a fault condition.
* The 3 vertical dots on the lower part of the main screen allows you to change the Bluetooth name of the
battery. Touch the dots, and use 1234 as the password to enter your battery name.
* A notication will only appear in the notications page if under alarm condition.
HV - High Voltage
LV - Low Voltage
OCC - Over Current Charge
OCD - Over Current Discharge
LTD - Low Temperature Discharge
LTC - Low Temperature Charge
HTD - High Temperature Discharge
HTC - High Temperature Charge
(Refer to Section 10 - Battery Specications for values).
Alarms Denitions
Page 10
Please read and follow the cautions listed on the battery before installation. Improper use may cause heat,
re, rupture, damage or capacity deterioration of the battery. Dometic Power & Control (Enerdrive) Pty Ltd
is not responsible for any accidents cause by the usage without following our specication.
The battery has a low voltage disconnect incorporated for self-protection. If the battery is drawn down
to the internal low voltage disconnect set point 2.8v per cell (11.2V for 12V battery) the battery will
disconnect.
Section 8 - Warnings
Enerdrive B-TEC G2 Manual (Rev. 3.1)
