Emporio E-3007 User manual

DOUBLE INDUCTION COOKER

  

Indukční vařič dvojplotýnkový

Indukčný varič dvojplaťňový

Indukcijsko kuhalo sa dvije ploče

  

E-3007

(model DIC112)

EMPORIO

EXCLUSIVE LINE

www.emporio-unique.com

-2-

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

Thank you for using our company induction cooker, in order to make our

products serve you better, please read the instruction carefully before using

and carefully preserved, to facilitate your future maintenance.

SPECIFICATION

Model: Emporio Exlusive Line DIC112

Power rate: 3300W–3700W

Voltage: 220-240V ~, 50/60 Hz

This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge

if they have been given supervision or instruction concerning use of the appliance in

a safe way and understand the hazards involved. Children shall not play with the

appliance Cleaning and user maintenance shall not be made by children unless theyare

older than 8 and supervised. Keep the appliance and its cord out of reach of children

less than 8 years. If the supply cord is damaged, it must be replaced by the

manufacturer, its service agent or similarly qualiﬁed persons in order to avoid a hazard.

The surfaces are liable to get hot during use. If the surface is cracked, switch off the

appliance to avoid the possibility of electric shock. Metallic objects such as knives,

forks, spoons and lids should not be placed on the hotplate since they can get hot.

Appliances are not intended to be operated by means of an external timer or separate

remote-control system. Household and indoor use only.

CORRECT DISPOSAL OF THIS PRODUCT

This marking indicates that this product should not be disposed with other household wastes

throughout the EU.To prevent possible harm to the environment or human health from uncontrolled

waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To

return your used device, please use the return and collection systems or contact the retailer where

the product was purchased. They can take this product for environmental safe recycling.

OBSAH

1. Induction cooker working principle

2. Each parts name

3. Using Method

4. Protect function

5. Safety tips

6. The pot for induction cooker is suitable or not

7. Maintenance and cleaning method

8. Fault diagnoses and treatment method

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-3-

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

1. WORKING PRINCIPLE

When connect the power on, the electric current will

produce magnetic ﬁeld in the induction coil which is

embedded in the induction cooker machine, as soon

as the magnetic force line in the magnetic ﬁeld

touches the stainless steel iron boiler, it will produces

countless small whirlpool of the heating effect, which

lead to heat the boiler and the food in it.

2. PARTS DESCRIPTION

3. USING METHOD

1. Plug into the proper socket;

2. Put an Iron or Steel pot with water or food on the center of the cooking plate;

3. Push ”ON/OFF” button, then the machine is on status;

4. Push ”FUNCTION” button to choose W or ℃;

5. Push ”+” or “-” to adjust the power or temp;

6. Start your cooking;

7. After cooking, push ”ON/OFF” button, then the machine is off status;

ENERG YIJA

IE IA

енергия · ενεργεια

(E-3007) DIC112

183.1 Wh/kg

EMPORIO

inducon cooker

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-4-

How to use the “LOCK” function?

When the machine is working, push ”LOCK” button for 3 seconds, then

the all buttons will be locked; Push ”LOCK” button for 3 seconds again,

then the all buttons will be unlocked;

How to use the “TIMER” function?

When the machine is working, push TIMER button, then push “+” or

“-” to set the TIMER (within 4 hours) time. Push or momently to set

time in 1 minute steps; Push or persistently, to set time in 10 minute

steps;

4. PROTECTIVE FUNCTIONS

1. Low power and high power protection

When power low than 88 V or high over 280 V, the machine never

heating.

2. Auto-inspection function for small object

When some small iron products (diameter is less than 8 cm), the ma-

chine will not output power and heating.

3. No pot or the material is not suitable protect

If the pot material is not suitable or the pot’s bottom size is small (less

than 8cm), the machine will not output power and heating with a BI voice

or please put pot warning. When the temperature of the plate surface is

too high, the machine will stop outputting power automatically with

a long Bi Bi voice or fault alarm, until the temperature get cool.

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-5-

5. SAFETY NOTICE

Please do not use the electrical

outlet of 15A alone, do not use

General sockets, do not use other

appliances at the same time

When using, please make induction

cooker in smooth place and keep the

distance from the wall over 10 cm

Do not clean induction

Cooker with water directly

Prevent any risks.

Do not insert wire etc. do

not jam inlet and outlet,

Prevent any risks.

Do not putt iron on the

plate. Protect high

temperature

Cause any risks.

Seal food, please heating

after open lid. Do not use induction

cooker

on iron place, include any

places where with over

10 cm metal mat.

Do not put the empty pot

on induction cooker,

prevent

affect the product’s

performance,

even any risks.

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-6-

Often clean induction

Cooker, avoid the ingress

Fan, affect the normal

work.

When using, please do

not touch the plate with

your hand, avoid scald

If the power line is

damage, must use

professional line

to replace.

Do not let children use

Induction cooker alone,

avoid scald.

Users of cardiac

pacemakers please

conﬁrm with professional

doctors, if without

inﬂuence then can use

induction cooker.

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-7-

6. FRIENDLY AND NON-FRIENDLY COOKWARE

Friendly cookware

Material: Iron or stainless steel. Shape: Bottom diameter about 12-20 cm

saucepan or bottom size is 12-20 cm square pot.

Non-friendly cookware

Material: Non-iron metal, ceramic, glass and the bottom is made of cooper

or aluminum pot. Shape: Bottom uneven, diameter less than 12 cm.

7. CLEANING TIPS

1. Before cleaning the cooker, make sure that the plug is unplugged and the

power is off.

2. To remove dirt, select litmusless detergent.

3. If the dirt is little, just clean it with a clean wet cloth.

4. Do not clean with water directly or put it in water. If water gets inside this

may cause a malfunction.

Stainless

steel kettle

Iron pot Magnetic stainless steel, steel, iron pots, kettles, pans.

Aluminium, cooking glass, ceramic cookware. Bottom not smooth, bottom with feet, small diameter of bottom.

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-8-

8. MALFUNCTION CHECK WARNINGS AND SOLUTION

If ﬁnd the induction cooker have problem as above, before send to repair please

check the machine depend on the following matters.

1. Get through power supply but no Bi

sound and press the on/off key, but

no light.

Check whether plug is good working cir-

cumstance. Check whether fuse is in good

circumstance ot not. Check whether the

electricity was cut off.

2. Induction cooker send out Bi sound Check the pit using is proper or not.

Check whether the pot is sitting in the cen-

ter of the plate or not.

Check whether the diameter of the pot is

bigger than 12 cm or not.

3. Warning with E1 Check if the voltage too low.

Check whether the socket is loose.

Check is the line diameter is too small.

4. Warning with E2 Check if the voltage too high.

5. Suddenly stop heating during

cooking, Warning with E5

Check whether the environment temperature is

very high or not. Check whether there is some

block on the air inlet or outlet. Whether the fan is

working or not. Check whether the keep warm

temperature is already reached the temperature

set or not. Check if the fan still working, it maybe

the adjustment of the unit itself, try it again after

10 minutes.

6. Warning with E4 Check thermostat was broken.

7. Warning with E6 Check radiator was broken.

8. Warning with E0 Check-No pot

Check-Unusable cooking cookware.

9. Warning with E3 Check-The pot has no water in.

ENG DOUBLE INDUCTION COOKER E-3007 (model DIC112)

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

-9-

RU    E-3007 (model DIC112)

    o o . 

,      ,   -

  .



M: Emporio Exclusive Line DIC112

: 3300W–3700W

: 220-240V ~, 50/60 Hz

         15   a  

,      

  .    ,    

  ,   ,    .

       .   

  ,  ,   

 .  ,   , ,  

,       .    

        

.       .

  

  ,          

   .        

 .



1.    

2.  e

3.      e

4.  

5.   

6.   

7.     

8.     

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com

- 10 -

RU    E-3007 (model DIC112)

1.    :

   ,   

 e e   ,

    , 

,      

    

 ,  

   , 

       .

2.  E

3.      e

1.    

2.           ;

3.   ON / OFF   ;

4.   FUNCTION  Watty  °C;

5.        

6.  

7.    ,   ON / OFF ,  ;

ENERG YIJA

IE IA

енергия · ενεργεια

(E-3007) DIC112

183.1 Wh/kg

EMPORIO

inducon cooker

Distributor for EU/Europe: Products DeLuxe s.r.o.

MADE IN P.R.C. www.emporio-unique.com
