Electrolux EWT 2264IDW User manual

EWT 2264IDW

EN Washing Machine User Manual

CONTENTS

1. SAFETY INFORMATION....................................................................................3

2. SAFETY INSTRUCTIONS..................................................................................4

3. PRODUCT DESCRIPTION................................................................................ 5

4. CONTROL PANEL............................................................................................. 6

5. PROGRAMME CHART...................................................................................... 7

6. CONSUMPTION VALUES..................................................................................9

7. OPTIONS..........................................................................................................10

8. SETTINGS........................................................................................................11

9. BEFORE FIRST USE....................................................................................... 12

10. DAILY USE..................................................................................................... 12

11. HINTS AND TIPS........................................................................................... 15

12. CARE AND CLEANING..................................................................................16

13. TROUBLESHOOTING....................................................................................18

14. TECHNICAL DATA.........................................................................................20

WE’RE THINKING OF YOU

Thank you for purchasing an Electrolux appliance. You’ve chosen a product that

brings with it decades of professional experience and innovation. Ingenious and

stylish, it has been designed with you in mind. So whenever you use it, you can

be safe in the knowledge that you’ll get great results every time.

Welcome to Electrolux.

Visit our website for:

Get usage advice, brochures, trouble shooter, service information:

www.electrolux.com/webselfservice

www.registerelectrolux.com

Buy Accessories, Consumables and Original spare parts for your appliance:

www.electrolux.com/shop

CUSTOMER CARE AND SERVICE

Always use original spare parts.

When contacting our Authorised Service Centre, ensure that you have the

following data available: Model, PNC, Serial Number.

The information can be found on the rating plate.

Warning / Caution-Safety information

General information and tips

Environmental information

Subject to change without notice.

www.electrolux.com2

1. SAFETY INFORMATION

Before the installation and use of the appliance, carefully

read the supplied instructions. The manufacturer is not

responsible for any injuries or damages that are the

result of incorrect installation or usage. Always keep the

instructions in a safe and accessible location for future

reference.

1.1 Children and vulnerable people safety

•This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning the use of the appliance in a

safe way and understand the hazards involved.

•Do not let children play with the appliance.

•Children aged 3 years and under must be kept away

from this appliance when it is in operation at all times.

•Keep all packaging away from children and dispose of

it appropriately.

•Keep detergents away from children.

•Keep children and pets away from the appliance door

when it is open.

•Children shall not carry out cleaning and user

maintenance of the appliance without supervision.

1.2 General Safety

•Do not change the specification of this appliance.

•Do not exceed the maximum load of 6 kg (refer to the

"Programme chart" chapter).

•The operating water pressure at the water entry point

from the outlet connection must be between 0.5 bar

(0.05 MPa) and 8 bar (0.8 MPa).

•The ventilation opening in the base (if applicable) must

not be covered by a carpet, mat, or any floor covering.

ENGLISH 3

•The appliance must be connected to the water mains

using the new supplied hose sets, or other new hose

sets supplied by the Authorised Service Centre.

•Old hose sets must not be reused.

•If the mains power supply cable is damaged, it must

be replaced by the manufacturer, its Authorised

Service Centre or similarly qualified persons to avoid

an electrical hazard.

•Before any maintenance operation, deactivate the

appliance and disconnect the mains plug from the

socket.

•Do not use high pressure water sprays and/or steam

to clean the appliance.

•Clean the appliance with a moist cloth. Use only

neutral detergents. Do not use abrasive products,

abrasive cleaning pads, solvents or metal objects.

2. SAFETY INSTRUCTIONS

2.1 Installation

• Remove all the packaging and the

transit bolts.

• Keep the transit bolts in a safe place.

If the appliance is to be moved in

future they must be reattached to lock

the drum to prevent internal damage.

• Always take care when moving the

appliance as it is heavy. Always use

safety gloves and enclosed footwear.

• Do not install or use a damaged

appliance.

• Follow the installation instruction

supplied with the appliance.

• Do not install or use the appliance

where the temperature can be less

than 0°C or where it is exposed to the

weather.

• The floor area where the appliance is

to be installed must be flat, stable,

heat resistant and clean.

• Make sure that there is air circulation

between the appliance and the floor.

• Adjust the feet to have the necessary

space between the appliance and the

flooring.

• Do not install the appliance where the

appliance lid cannot be fully opened.

• Do not put a container to collect

possible water leakage under the

appliance. Contact the Authorised

Service Centre to ensure which

accessories can be used.

2.2 Electrical connection

• The appliance must be earthed.

• Always use a correctly installed

shockproof socket.

• Make sure that the electrical

information on the rating plate agrees

with the power supply. If not, contact

an electrician.

• Do not use multi-plug adapters and

extension cables.

• Make sure not to cause damage to

the mains plug and to the mains

cable. Should the mains cable need to

be replaced, this must be carried out

by our Authorised Service Centre.

• Connect the mains plug to the mains

socket only at the end of the

installation. Make sure that there is

access to the mains plug after the

installation.

• Do not touch the mains cable or the

mains plug with wet hands.

www.electrolux.com4

• Do not pull the mains cable to

disconnect the appliance. Always pull

the mains plug.

• This appliance complies with the

E.E.C. Directives.

2.3 Water connection

• Do not cause damage to the water

hoses.

• Before connection to new pipes, pipes

not used for a long time, where repair

work has been carried out or new

devices fitted (water meters, etc.), let

the water flow until it is clean and

clear.

• Ensure that there are no visible water

leaks during and after the first use of

the appliance.

2.4 Use

WARNING!

Risk of injury, electrical

shock, fire, burns or damage

to the appliance.

• This appliance is for household use

only.

• Follow the safety instructions on the

detergent packaging.

• Do not put flammable products or

items that are wet with flammable

products in, near or on the appliance.

• Make sure that all metal objects are

removed from the laundry.

2.5 Service

• To repair the appliance contact an

Authorised Service Centre.

• Use original spare parts only.

2.6 Disposal

WARNING!

Risk of injury or suffocation.

• Disconnect the appliance from the

mains electrical and water supplies.

• Cut off the mains electrical cable

close to the appliance and dispose of

it.

• Remove the door catch to prevent

children or pets from becoming

trapped in the drum.

• Dispose of the appliance in

accordance with local requirements

for the disposal of Waste Electrical

and Electronic Equipment (WEEE).

3. PRODUCT DESCRIPTION

3.1 Appliance overview

1Control panel

2Lid

3Lid handle

4Feet for levelling the appliance

5Rating plate

ENGLISH 5

4. CONTROL PANEL

4.1 Control panel description

Essorage

Température

Rinçage

Plus

Départ

Différé

Départ/Pause

Pré-

lavage

Rinçage

Essorage

Vidange

Blanc/Couleurs

Coton Eco

Synthétiques

Chemises

Sport

Rideaux

Jeans

Couette

Soie

Laine/Lavage

à la main

Délicats

90° 60° 40°

30° 20°

1200 800 400

Repassage

Facile

1 2 3 4

910

1Programme knob

2Spin reduction touchpad

(Essorage)

3Temperature touchpad

(Température)

4Display

5Prewash touchpad (Prélavage)

6Delay start touchpad (Départ

Différé)

7Extra rinse touchpad (Rinçage

Plus)

8Easy iron touchpad

(Repassage Facile)

9Start/Pause touchpad (Départ/

Pause)

10 Time Manager touchpads

4.2 Display

A B

E D

A. The time area:

• Programme time.

• The alarm codes. Refer to the

chapter “Troubleshooting” for their

description.

• The level of the Time Manager

B. The Delay Start indicator.

C. The Child Lock indicator.

D. The Lid Lock indicator:

• It is on, you cannot open the lid.

• It is off, you can open the lid.

• It flashes, you cannot open the lid.

Wait for some minutes until the

indicator is off.

E. Washing phase indicators.

• : the washing phase

• : the rinses phase

www.electrolux.com6

• : the spin phase

5. PROGRAMME CHART

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Blanc/

Couleurs

90°C - Cold

6 kg

1200 rpm

White cotton and coloured cotton. Normal soil

and light soil.

Coton

Eco1)

60° - 40°C

6 kg

1200 rpm

White cotton and fast-coloured cotton. Normal

soil. The energy consumption decreases and the

time of the washing programme is extended.

Synthétiques

60° - Cold

2,5 kg

1200 rpm

Synthetic items or mixed fabric items. Normal

soil.

Délicats

40° - Cold

2,5 kg

1200 rpm

Delicate fabrics such as acrylics, viscose,

polyester items. Normal soil.

Laine/

Lavage à la

main

40° - Cold

1 kg

1200 rpm

Machine washable wool, hand washable wool

and delicate fabrics with «hand washing» care

symbol.2)

Soie

30°C

1 kg

800 rpm

Special programme for silk and mixed synthet‐

ic items.

Couette

60° - 30°C

2 kg

800 rpm

Special programme for one synthetic blanket,

duvet, bedspread and so on.

Rinçage

Cold

6 kg

1200 rpm

To rinse and spin the laundry. All fabrics, except

woollens and very delicate fabrics. Reduce the

spin speed accordingly to the type of laundry.

Vidange 6 kg To drain the water in the drum. All fabrics.

Essorage 6 kg

1200 rpm

To spin the laundry and to drain the water in the

drum. All fabrics, except woollens and deli‐

cate fabrics.

Jeans

60° - Cold

3 kg

1200 rpm

Items in denim and jersey. Also for dark col‐

oured items.

Rideaux

40° - Cold

2,5 kg

800 rpm

Special programme for curtains. The prewash

phase is activated automatically.3)

Sport

30°C

2,5 kg

800 rpm

Synthetic and delicate items. Light soil items or

items to refresh.

ENGLISH 7

Programme

Temperature

range

Maximum

load

Maximum

spin speed

Programme description

(Type of load and soil level)

Chemises

30°C

1,5 kg

800 rpm

Synthetic and mixed fabric items. Light soil

items and items to freshen up. For 5 - 6 shirts.

1) Standard programmes for the Energy Label consumption values. According to regu‐

lation 1061/2010, these programmes are respectively the «Standard 60°C cotton pro‐

gramme» and the «Standard 40°C cotton programme». They are the most efficient pro‐

grammes in terms of combined energy and water consumption for washing normally soiled

cotton laundry.

The water temperature of the washing phase may differ from the temperature

declared for the selected programme.

2) During this cycle the drum rotates slowly to ensure a gentle wash. It can seem that the

drum doesn't rotate or doesn't rotate properly, but this is normal for this programme.

3) Do not use any detergent for prewash phase to rinse only with water.

Programme options compatibility

Programme

■ ■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■

■ ■ ■

■ ■

■ ■ ■ ■ ■

■

■ ■

■ ■ ■ ■ ■ ■

■ ■ ■ ■ ■

■ ■ ■

www.electrolux.com8

5.1 Woolmark Apparel Care -

Blue

The wool wash cycle of this machine has

been approved by The Woolmark

Company for the washing of wool

garments labelled as «hand wash»

provided that the garments are washed

according to the instructions issued by

the manufacturer of this washing

machine. Follow the garment care label

for drying and other laundry instructions.

M1145

In UK, Eire, Hong Kong and India the

Woolmark symbol is a certification

trademark.

6. CONSUMPTION VALUES

The data in this table are approximate. Different variables can affect the

data: the quantity and type of laundry, the water and ambient tempera‐

ture.

At the start of the programme, the display shows the programme dura‐

tion for the maximum load capacity.

During the washing phase the programme duration is automatically cal‐

culated and can be greatly reduced if the laundry load is lower than the

maximum load capacity (e.g. Cotton 60°C, maximum load capacity 6 kg,

the programme duration exceeds 2 hours; actual load 1 kg, the pro‐

gramme duration will be less than 1 hour).

When the appliance is calculating the real programme duration a dot

flashes in the display.

Programmes Load

(kg)

Energy

consump‐

tion (kWh)

Water con‐

sumption

(litre)

Approxi‐

mate pro‐

gramme

duration

(minutes)

Remaining

moisture

(%)1)

Blanc/Couleurs

60°C 6 1,10 56 180 53

Blanc/Couleurs

40°C 6 0,65 54 150 53

Synthétiques 40°C 2,5 0,45 46 105 35

Délicats 40°C 2,5 0,55 46 90 35

Laine/Lavage à la

main 30°C 2) 1 0,35 50 65 30

ENGLISH 9

Programmes Load

(kg)

Energy

consump‐

tion (kWh)

Water con‐

sumption

(litre)

Approxi‐

mate pro‐

gramme

duration

(minutes)

Remaining

moisture

(%)1)

Standard cotton programmes

Standard 60°C

cotton 6 0,96 45 240 53

Standard 60°C

cotton 3 0,62 37 149 53

Standard 40°C

cotton 3 0,50 37 136 53

1) At the end of spin phase.

2) Not available for some models.

Off Mode (W) Left On Mode (W)

0.48 0.48

The information given in the chart above is compliant with the EU Commission regu‐

lation 1015/2010 implementing directive 2009/125/EC

7. OPTIONS

7.1 Température

Set this option to change the default

temperature.

Indicator = cold water.

The indicator of the set temperature

comes on.

7.2 Essorage

With this option you can change the

default spin speed.

The indicator of the set speed comes on.

Additional spin options:

No Spin

• Set this option to deactivate all spin

phases. Only the drain phase is

available.

• The related indicator comes on.

• Set this option for very delicate

fabrics.

• The rinses phase uses more water for

some washing programmes.

Rinse Hold

• Set this option to prevent the laundry

creases.

• The related indicator comes on.

• There is a water in the drum when the

programme is completed.

• The drum turns regularly to prevent

the laundry creases.

• The lid stays locked. You must drain

the water to unlock the lid.

To drain the water refer to

‘At the end of the

programme’.

Night Cycle

• Set this option to remove all spin

phases and to perform a silent

washing.

• The rinse phase uses more water for

some washing programmes.

• The related indicator comes on.

www.electrolux.com10

Table of contents

Other Electrolux Washer manuals

Electrolux

Electrolux EWC 1350 User manual

Electrolux

Electrolux ZWF1211W User manual

Electrolux

Electrolux EWG 12440 W User manual

Electrolux

Electrolux EWFLS70J IW User manual

Electrolux

Electrolux EWT 105210 W User manual

Electrolux

Electrolux EW 865T User manual

Electrolux

Electrolux EWF 1476 GDW User manual

Electrolux

Electrolux EN2F4823BF User manual

Electrolux

Electrolux EWT 1340 User manual

Electrolux

Electrolux EWF 1408 WDL User manual

Electrolux

Electrolux EW 1055 F User manual

Electrolux

Electrolux EWS 86110W User manual

Electrolux

Electrolux EWT 106415 W User manual

Electrolux

Electrolux WASL 3 T 200 User manual

Electrolux

Electrolux EW7F1482BI User manual

Electrolux

Electrolux IQ-Touch EIFLW50LIW0 User manual

Electrolux

Electrolux EWF 1249 User manual

Electrolux

Electrolux EWFH 12280 W User manual

Electrolux

Electrolux EW F147410 A User manual

Electrolux

Electrolux EWM2100 User manual

Electrolux

Electrolux EWF 1408 WDL2 User manual

Electrolux

Electrolux EW 1100 F Quick guide

Electrolux

Electrolux EWF 1284 EDW User manual

Electrolux

Electrolux EWL 105410 W User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
