EWS 1066 SEU EN WASHING MACHINE USER MANUAL
CONTENTS
1. SAFETY INFORMATION............................................................................................ 3
2. SAFETY INSTRUCTIONS.......................................................................................... 4
3. PRODUCT DESCRIPTION.........................................................................................5
4. CONTROL PANEL.....................................................................................................6
5. PROGRAMMES ....................................................................................................... 7
6. CONSUMPTION VALUES........................................................................................10
7. OPTIONS................................................................................................................ 11
8. SETTINGS...............................................................................................................12
9. BEFORE FIRST USE................................................................................................13
10. DAILY USE............................................................................................................ 13
11. HINTS AND TIPS...................................................................................................17
12. CARE AND CLEANING......................................................................................... 18
13. TROUBLESHOOTING........................................................................................... 22
14. TECHNICAL DATA................................................................................................ 24
WE’RE THINKING OF YOU
Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings
with it decades of professional experience and innovation. Ingenious and stylish, it has
been designed with you in mind. So whenever you use it, you can be safe in the
knowledge that you’ll get great results every time.
Welcome to Electrolux.
Visit our website for:
Get usage advice, brochures, trouble shooter, service information:
www.electrolux.com
Register your product for better service:
www.registerelectrolux.com
Buy Accessories, Consumables and Original spare parts for your appliance:
www.electrolux.com/shop
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model, PNC, Serial Number.
The information can be found on the rating plate.
Warning / Caution-Safety information
General information and tips
Environmental information
Subject to change without notice.
2 www.electrolux.com
1. SAFETY INFORMATION
Before the installation and use of the appliance, carefully
read the supplied instructions. The manufacturer is not
responsible if an incorrect installation and use causes
injuries and damages. Always keep the instructions with
the appliance for future reference.
1.1 Children and vulnerable people safety
•This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
•Do not let children play with the appliance.
•Keep all packaging away from children.
•Keep all detergents away from children.
•Keep children and pets away from the appliance door
when it is open.
•Cleaning and user maintenance shall not be made by
children without supervision.
1.2 General Safety
•Do not change the specification of this appliance.
•Obey the maximum load volume of 6 kg (refer to the
“Programme chart” chapter).
•The operating water pressure (minimum and maximum)
must be between 0,5 bar (0,05 MPa) and 8 bar (0,8
MPa).
•The ventilation openings in the base (if applicable) must
not be obstructed by a carpet.
•The appliance is to be connected to the water mains
using the new supplied hose-sets. Old hose sets must
not be reused.
•If the supply cord is damaged, it must be replaced by
the manufacturer, its Authorised Service Centre or
similarly qualified persons in order to avoid a hazard.
ENGLISH 3
•Before maintenance, deactivate the appliance and
disconnect the mains plug from the mains socket.
•Do not use water spray and steam to clean the
appliance.
•Clean the appliance with a moist soft cloth. Only use
neutral detergents. Do not use abrasive products,
abrasive cleaning pads, solvents or metal objects.
2. SAFETY INSTRUCTIONS
2.1 Installation
• Remove all the packaging and the
transit bolts.
• Keep the transit bolts. When you move
the appliance again you must block the
drum.
• Always be careful when you move the
appliance because it is heavy. Always
wear safety gloves.
• Do not install or use a damaged
appliance.
• Obey the installation instruction
supplied with the appliance.
• Do not install or use the appliance
where the temperature is less than 0
°C or where it is exposed to the
weather.
• Make sure that the floor where you
install the appliance is flat, stable, heat
resistant and clean.
• Make sure that there is air circulation
between the appliance and the floor.
• Adjust the feet to have the necessary
space between the appliance and the
carpet.
• Do not install the appliance where the
appliance door can not be fully
opened.
2.2 Electrical Connection
• The appliance must be earthed.
• Always use a correctly installed
shockproof socket.
• Make sure that the electrical
information on the rating plate agrees
with the power supply. If not, contact
an electrician.
• Do not use multi-plug adapters and
extension cables.
• Make sure not to cause damage to the
mains plug and to the mains cable.
Should the mains cable need to be
replaced, this must be carried out by
our Authorised Service Centre.
• Connect the mains plug to the mains
socket only at the end of the
installation. Make sure that there is
access to the mains plug after the
installation.
• Do not touch the mains cable or the
mains plug with wet hands.
• Do not pull the mains cable to
disconnect the appliance. Always pull
the mains plug.
• Only for UK and Ireland: The appliance
has a 13 amp mains plug. If it is
necessary to change the fuse in the
mains plug, use a 13 amp ASTA (BS
1362) fuse.
• This appliance complies with the E.E.C.
Directives.
2.3 Water connection
• Make sure not to cause damage to the
water hoses.
• Before you connect the appliance to
new pipes or pipes not used for a long
time, let the water flow until it is clean.
• The first time you use the appliance,
make sure that there is no leakage.
2.4 Use
WARNING!
Risk of injury, electrical
shock, fire, burns or damage
to the appliance.
• Use this appliance in a household only.
www.electrolux.com4
• Obey the safety instructions on the
detergent packaging.
• Do not put flammable products or
items that are wet with flammable
products in, near or on the appliance.
• Make sure that you remove all metal
objects from the laundry.
• Do not put a container to collect
possible water leakage under the
appliance. Contact the Authorised
Service Centre to ensure which
accessories can be used.
• Do not touch the glass of the door
while a programme operates. The
glass can be hot.
2.5 Disposal
WARNING!
Risk of injury or suffocation.
• Disconnect the appliance from the
mains supply.
• Cut off the mains cable and discard it.
• Remove the door catch to prevent
children and pets to get closed in the
appliance.
3. PRODUCT DESCRIPTION
3.1 Appliance overview
1
2
3
4
5
6
7
1Worktop
2Detergent dispenser
3Control panel
4Door handle
5Drain pump filter
6Rating plate
7Feet for the appliance level
ENGLISH 5
4. CONTROL PANEL
4.1 Control panel description
53 4
1011
8
7
9
6
1 2
1On Off button (On/Off)
2Programme knob
3Spin reduction touchpad (Spin)
4Temperature touchpad
(Temperature)
5Display
6Prewash touchpad (Prewash)
7Delay start touchpad (Delay Start)
8Extra rinse touchpad (Extra Rinse)
9Easy iron touchpad (Easy Iron)
10 Start/Pause touchpad (Start/
Pause)
11 Time Manager touchpads
(Time Manager)
www.electrolux.com6
4.2 Display
A B C D
E
FG
A) The Temperature area:
: Temperature indicator
: Cold water indicator
B) : Time Manager indicator.
C) The time area:
• : the programme duration
• : the delay start
• : the alarm codes
• : the message of error
• : the programme is completed.
D) : the child safety lock indicator.
E) Washing indicators:
• : the washing phase
• : the rinses phase
• : the spin phase
• : the Extra rinse permanent
option.
F) The spin area:
• : the Spin speed indicator
• : the No Spin indicator
• : the Rinse Hold indicator
• : the Extra Silent indicator.
G) : the Door locked indicator
5. PROGRAMMES
5.1 Programme Chart
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Washing programmes
Cottons
90°C - Cold
6 kg
1000 rpm
White cotton and coloured cotton. Normal soil
and light soil.
Cottons Eco1)
60°C - 40°C
6 kg
1000 rpm
White cotton and colour-fast cotton. Normal
soil. The energy consumption decreases and the
time of the washing programme is extended.
ENGLISH 7
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Synthetics
60°C - Cold
3 kg
1000 rpm
Synthetic items or mixed fabric items. Normal
soil.
Delicates
40°C - Cold
3 kg
1000 rpm
Delicate fabrics as acrylics, viscose, polyest-
er items. Normal soil.
Wool/Handwash
40°C - Cold
1 kg
1000 rpm
Machine washable wool, hand washable wool
and delicate fabrics with «hand washing» care
symbol.2)
Jeans
60°C - Cold
6 kg
1000 rpm
Items in denim and jersey. Also for dark col-
oured items.
Rinse
6 kg
1000 rpm
To rinse and spin the laundry. All fabrics.
Spin/Drain3)
6 kg
1000 rpm
To spin the laundry and to drain the water in the
drum. All fabrics.
Lingerie
40°C - Cold
1 kg
800 rpm
Special programme for very delicate items, as lin-
gerie, bras and underwear etc.
Silk
30°C
1 kg
800 rpm
Special programme for silk and mixed synthetic
items.
Curtains
40°C - Cold
1 kg
800 rpm
Special programme for curtains. The prewash
phase is activated automatically.4)
Duvet
60°C - 30°C
2 kg
800 rpm
Special programme for one synthetic blanket,
duvet, bedspread and so on.
Refresh
30°C
2 kg
800 rpm
Synthetic and delicate items. Light soil items or
items to refresh.
www.electrolux.com8
Programme
Temperature
range
Maximum
load
Maximum
spin speed
Programme description
(Type of load and soil level)
Quick
30°C
1 kg
800 rpm
Synthetic and mixed fabric items. Light soil and
items to freshen up.
1) Standard programmes for the Energy Label consumption values. According to regu-
lation 1061/2010, these programmes are respectively the «Standard 60°C cotton programme»
and the «Standard 40°C cotton programme». They are the most efficient programmes in terms
of combined energy and water consumption for washing normally soiled cotton laundry.
The water temperature of the washing phase may differ from the temperature de-
clared for the selected programme.
2) During this cycle the drum rotates slowly to ensure a gentle washing. It can seem that the
drum doesn't rotate or doesn't rotate properly. Consider this as a normal functioning of the ap-
pliance.
3) Set the spin speed. Make sure it agrees with the laundry. If you set No Spin option the only
drain phase is available.
4) Do not use any detergent for prewash phase to rinse only with water.
Programme options compatibility
Programme
Cottons ■ ■ ■ ■ ■ ■ ■ ■
Cottons Eco ■ ■ ■ ■ ■ ■
Synthetics ■ ■ ■ ■ ■ ■ ■ ■
Delicates ■ ■ ■ ■ ■ ■ ■
Wool/Handwash ■ ■ ■ ■ ■
Jeans ■ ■ ■ ■ ■ ■
Rinse ■ ■ ■ ■ ■
Spin/Drain1) ■ ■ ■
Lingerie ■ ■ ■ ■ ■
Silk ■ ■ ■
Curtains ■ ■ ■ ■ ■
Duvet ■ ■
Refresh ■ ■ ■
Quick ■ ■ ■
1) Set the spin speed. Make sure it agrees with the laundry. If you set No Spin option the only
drain phase is available.
ENGLISH 9
5.2 Woolmark Apparel Care -
Blue
The wool wash cycle of this machine has
been approved by The Woolmark
Company for the washing of wool
garments labelled as «hand wash»
provided that the garments are washed
according to the instructions issued by the
manufacturer of this washing machine.
Follow the garment care label for drying
and other laundry instructions. M1459
In UK, Eire, Hong Kong and India the
Woolmark symbol is a certification
trademark.
6. CONSUMPTION VALUES
The data of this table are approximate. Different causes can change the
data: the quantity and type of laundry, the water and ambient temperature.
At programme start the display shows the duration programme for the
maximum load capacity.
During the washing phase the programme duration is automatically calcu-
lated and can be greatly reduced if the laundry load is lower than the maxi-
mum load capacity (e.g. Cotton 60°C, maximum load capacity 6 kg, the
programme duration exceeds 2 hours; real load 1 kg, the programme du-
ration don’t reach 1 hour).
When the appliance is calculating the real programme duration a dot blinks
in the display.
Programmes Load
(kg)
Energy
consump-
tion (kWh)
Water con-
sumption
(litre)
Approxi-
mate pro-
gramme
duration
(minutes)
Remaining
moisture
(%)1)
Cottons 60 °C 6 1.26 60 183 60
Cottons 40 °C 6 0.83 60 165 60
Synthetics 40 °C 3 0.63 55 119 37
Delicates 40 °C 3 0.50 45 49 37
Wool/Handwash
30 °C 1 0.45 59 69 32
Standard cotton programmes
Standard 60 °C
cotton 6 0.76 46 202 60
www.electrolux.com10
Table of contents
Other Electrolux Washer manuals
Electrolux
Electrolux EWF8025EGWA User manual
Electrolux
Electrolux EIFLS60JIW0 User manual
Electrolux
Electrolux EWF 1486 GBW User manual
Electrolux
Electrolux MLTU16*GAWB series User manual
Electrolux
Electrolux EWF14013 User manual
Electrolux
Electrolux WASL3T100 User manual
Electrolux
Electrolux EWF 630 User manual
Electrolux
Electrolux EW6F428W User manual
Electrolux
Electrolux WASL2E 200 User manual
Electrolux
Electrolux EW6T4261 User manual
Electrolux
Electrolux EW 1100 F Quick guide
Electrolux
Electrolux EWH 127310 W User manual
Electrolux
Electrolux EWG 12450 W User manual
Electrolux
Electrolux EWF 148420 W User manual
Electrolux
Electrolux EWF1070W User manual
Electrolux
Electrolux EW 1230 I User manual
Electrolux
Electrolux EWF 1697 HBW User manual
Electrolux
Electrolux EWT9074N5SA User manual
Electrolux
Electrolux EWF 10240 W User manual
Electrolux
Electrolux IQ-Touch Wave-Touch EIFLW55H Operating manual
Popular Washer manuals by other brands
Tricity Bendix
Tricity Bendix AW 1000 W Operating & installation instructions
Panasonic
Panasonic NA-F60L5WRB operating instructions
GE
GE WSLP1500 Dimensions and installation information
Bosch
Bosch WAN2829BSN User manual and installation instructions
LG
LG TV2516DV3B owner's manual
LG
LG TH2517DSAV owner's manual
