Electrolux EWN 10470 W User manual

User Manual

EWN 10470 W

Washing Machine

132963290_EN.qxd 22/02/2008 9.59 Pagina 1

Downloaded From WashingMachine-Manual.com Manuals

132963290_EN.qxd 22/02/2008 9.59 Pagina 2

Downloaded From WashingMachine-Manual.com Manuals

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class product from Electrolux, which hopefully will

provide you with lots of pleasure in the future. The Electrolux ambition is to offer a

wide variety of quality products that make your life more comfortable. You find

some examples on the cover in this manual. Please take a few minutes to study

this manual so that you can take advantage of the benefits of your new machine.

We promise that it will provide a superior User Experience delivering Ease-of-

Mind. Good luck!

132963290_EN.qxd 22/02/2008 9.59 Pagina 3

Downloaded From WashingMachine-Manual.com Manuals

4 contents electrolux

Contents

Safety information..............................5

Product description ...........................7

Control panel .....................................8

Use..................................................11

Washing hints ..................................16

Washing programmes......................19

Programme information ...................21

Care and cleaning ...........................22

What to do if....................................25

Technical data .................................29

Consumption values ........................30

Installation .......................................31

Environment concerns .....................35

The following symbols are used in this manual:

Important information concerning your personal safety and information on how

to avoid damaging the appliance.

General information and tips

Environmental information

132963290_EN.qxd 22/02/2008 9.59 Pagina 4

Downloaded From WashingMachine-Manual.com Manuals

safety information electrolux 5

Safety Information

In the interest of your safety and to

ensure the correct use, before

installing and first using the

appliance, read this user manual

carefully, including its hints and

warnings. To avoid unnecessary

mistakes and accidents, it is

important to ensure that all people

using the appliance are thoroughly

familiar with its operation and safety

features. Save these instructions

and make sure that they remain

with the appliance if it is moved or

sold, so that everyone using it

through its life will be properly

informed on appliance use and

safety.

General safety

●It is dangerous to alter the

specifications or attempt to modify

this product in any way.

●During high temperature wash

programmes the door glass may get

hot. Do not touch it!

●Make sure that small pets do not

climb into the drum. To avoid this,

please check into the drum before

using.

●Any objects such as coins, safety

pins, nails, screws, stones or any

other hard, sharp material can cause

extensive damage and must not be

placed into the machine.

●Only use the advised quantities of

fabric softener and detergent.

Damage to the fabric can ensue if

you over-fill. Refer to the

manufacturer’s recommendations of

quantities.

●Wash small items such as socks,

laces, washable belts etc in a

washing bag or pillow case as it is

possible for such items to slip down

between the tub and the inner drum.

●Do not use your washing machine to

wash articles with whalebones,

material without hems or torn

material.

●Always unplug the appliance and

turn off the water supply after use,

clean and maintenance.

●Under no circumstances should you

attempt to repair the machine

yourself. Repairs carried out by

inexperienced persons may cause

injury or serious malfunctioning.

Contact your local Service Centre.

Always insist on genuine spare parts.

Installation

●This appliance is heavy. Care should

be taken when moving it.

●When unpacking the appliance,

check that it is not damaged. If in

doubt, do not use it and contact the

Service Centre.

●All packing and transit bolts must be

removed before use. Serious

damage can occur to the product

and to property if this is not adhered

to. See relevant section in the user

manual.

●After having installed the appliance,

check that it is not standing on the

inlet and drain hose and the worktop

is not pressing the electrical supply

cable.

●If the machine is situated on a

carpeted floor, please adjust the feet

in order to allow air to circulate freely

●Always be sure, that there is no

water leakage from hoses and their

connections after the installation.

132963290_EN.qxd 22/02/2008 9.59 Pagina 5

Downloaded From WashingMachine-Manual.com Manuals

6electrolux safety information

●If the appliance is installed in a

location subject to frost, please read

the “dangers of freezing”chapter.

●Any plumbing work required to install

this appliance should be carried out

by a qualified plumber or competent

person.

●Any electrical work required to install

this appliance should be carried out

by a qualified electrician or

competent person.

Use

●This appliance is designed for

domestic use. It must not be used

for purposes other than those for

which it was designed.

●Only wash fabrics which are

designed to be machine washed.

Follow the instructions on each

garment label.

●Do not overload the appliance. See

the relevant section in the user

manual.

●Before washing, ensure that all

pockets are empty and buttons and

zips are fastened. Avoid washing

frayed or torn articles and treat

stains such as paint, ink, rust, and

grass before washing. Underwired

bras must NOT be machine washed.

●Garments which have been in

contact with volatile petroleum

products should not be machine

washed. If volatile cleaning fluids are

used, care should be taken to

ensure that the fluid is removed from

the garment before placing in the

machine.

●Never pull the power supply cable to

remove the plug from the socket;

always take hold of the plug itself.

●Never use the washing machine if

the power supply cable, the control

panel, the working surface or the

base are damaged so that the inside

of the washing machine is

accessible.

Child safety

●This appliance is not intended for

use by person (including children)

with reduced physical sensory or

mental capabilities or lack of

experience and knowledge unless

they have been given supervision or

instruction concerning use of the

appliance by a person responsible

for their safety.

●The packaging components (e.g.

plastic film, polystyrene) can be

dangerous to children - danger of

suffocation! Keep them out of

children’s reach

●Keep all detergents in a safe place

out of children’s reach.

●Make sure that children or pets do

not climb into the drum. To avoid this

the machine incorporates special

feature. To activate this device, rotate

the button (without pressing it) inside

the door clockwise until the groove

is horizontal. If necessary use a coin.

To disable this device and restore

the possibility of closing the door,

rotate the button anti-clockwise until

the groove is vertical.

P1076

132963290_EN.qxd 22/02/2008 9.59 Pagina 6

Downloaded From WashingMachine-Manual.com Manuals

product description electrolux 7

Product description

Detergent dispenser drawer

Control panel

Door opening handle

Drain pump

Adjustable feet

Compartment for detergent used

for prewash. The prewash

detergent is added at the

beginning of the wash

programme.

Compartment for powder or liquid

detergent used for main wash.

Compartment for liquid additives

1 2

EN001

Detergent dispenser drawer

Your new appliance meets all modern requirements for effective treatment of laundry

with low water, energy and detergent consumption.

The NEW JET system allows total use of detergent and reduces water consumption

so saving energy.

132963290_EN.qxd 22/02/2008 9.59 Pagina 7

Downloaded From WashingMachine-Manual.com Manuals

8electrolux control panel

Control panel

Programme selector dial

Temperature button

Spin reduction button

Easy iron button

Extra Rinse button

1 2 3 4 6 7 85 10

Table of symbols

●Cottons , Cottons+Prewash + , Synthetics , Synthetics+Prewash + ,

Delicates , Baby , Sport Intensive , Delicate Spin , Spin ,

Drain , Delicate Rinses , Rinses , Lingerie ,Silk , Handwash ,

Wool , Jeans , Blanket , Cottons Eco+Prewash + , Cottons Eco

●Temperature , Cold ,Rinse hold , No Spin , Easy iron ,

Extra rinse , Delay , Time manager , Door locked , Child safety

Lock

Delay Start button

Display

Start/Pause button

Door locked pilot light

Time Manger buttons

Henceforth, the programme selector dial, the different buttons and the display will

be indicated in all the book with the relevant numbers given in the table below.

132963290_EN.qxd 22/02/2008 9.59 Pagina 8

Downloaded From WashingMachine-Manual.com Manuals

control panel electrolux 9

Duration of selected

programme/

After selecting a programme, the

duration is displayed in hours and

minutes (for example 2.05). The

duration is calculated automatically on

the basis of the maximum

recommended load for each type of

fabric. After the programme has

started, the time remaining is updated

every minute.

/Delayed start

The selected delay set by pressing the

relevant button appears on the display

for a few seconds, then the duration of

the previously selected programme is

displayed.

/Alarm codes

In the event of operating problems,

some alarm codes can be displayed,

for example E20 (see chapter «What to

do if...»).

7.1 /Incorrect option selection

If an option which is not compatible

with the set wash programme is

selected, the message Err is displayed

for a few seconds and the integrated

red light of button 8starts blinking.

/End of programme

When the programme has finished

three blinking zeros 0.00 are displayed,

the pilot light 9and the pilot light of

button 8go out and the door can be

opened.

Washing phase icons

By selecting the wash programme, the

washing programme phase icons

corresponding to the various phases

making up the programme are shown

in the bottom of the display.

After the machine has started, only the

running icon stays on. When the

programme has finished, a flashing

zero (0.00) is displayed.

7.2

2.05

7.1

7.27.3

7.4 7.5

Display (7)

132963290_EN.qxd 22/02/2008 9.59 Pagina 9

Downloaded From WashingMachine-Manual.com Manuals

10 electrolux control panel

Heating phase

During the washing cycle the display

shows a temperature icon to indicate

that the appliance has started the

heating phase of the water in the tub.

Soil level icons

When selecting a programme on the

display appears an icon indicating the

degree of soilness automatically

proposed by the machine.

Child lock

This device permits you to leave the

appliance unsupervised during it’s

functioning.

Door locked light (9)

The pilot light 9 illuminates to indicate

that the appliance starts operating and

the door is locked.

The pilot light 9indicates if the door

can be opened:

●light on: the door is locked and

cannot be opened.

●light blinking: the door is opening.

●light off: the door is unlocked and

can be opened.

7.5

7.4

7.3

132963290_EN.qxd 22/02/2008 9.59 Pagina 10

Downloaded From WashingMachine-Manual.com Manuals

Table of contents

Other Electrolux Washer manuals

Electrolux

Electrolux EW 1280F User manual

Electrolux

Electrolux EWN 13570 W User manual

Electrolux

Electrolux EWT 126451 W User manual

Electrolux

Electrolux ZWF1211W User manual

Electrolux

Electrolux EWS 10470 W User manual

Electrolux

Electrolux Lavamat 60800 Operation manual

Electrolux

Electrolux WF 1029 User manual

Electrolux

Electrolux EWC 10550 W User manual

Electrolux

Electrolux EWF 10190 W User manual

Electrolux

Electrolux EWT 0862 EOW User manual

Electrolux

Electrolux EWF 1073 User manual

Electrolux

Electrolux WAVE-TOUCH 137356900 A User manual

Electrolux

Electrolux Swissline L EWF 1090 Operation manual

Electrolux

Electrolux WWS833FS2 User manual

Electrolux

Electrolux W555H User manual

Electrolux

Electrolux EW402F User manual

Electrolux

Electrolux AQUALUX 1000 EW 1006 F Quick guide

Electrolux

Electrolux EW 550 F User manual

Electrolux

Electrolux EW6F528W User manual

Electrolux

Electrolux WH1018 Instruction Manual

Electrolux

Electrolux EIFLW55HIW - 27" Front-Load Washer Instruction Manual

Electrolux

Electrolux EWF 1674 FDW User manual

Electrolux

Electrolux EW 1042 S User manual

Electrolux

Electrolux EWF1481 User manual

Popular Washer manuals by other brands

Tricity Bendix

Tricity Bendix AW 1000 W Operating & installation instructions

Panasonic

Panasonic NA-F60L5WRB operating instructions

GE WSLP1500 Dimensions and installation information

Bosch

Bosch WAN2829BSN User manual and installation instructions

LG TV2516DV3B owner's manual

LG TH2517DSAV owner's manual

VESTEL

VESTEL CMH-XL 7510 TE user manual

AEG

AEG 74335 User information

Johnson

Johnson JWF721A user manual

Beko

Beko WTE7604XLW0 owner's manual

Danby

Danby DTT100A1WDB Owner's use and care guide

Amica

Amica WA 14 Ex operating instructions

Daewoo

Daewoo DWD-F1222 instruction manual

Bosch

Bosch WAS28461AU instruction manual

Miele

Miele PW 6080 Vario manual

Finlux

Finlux FLX108CF220 user manual

Whirlpool

Whirlpool 3LBR5132AN0 Use and care guide

Beko

Beko WKB 51231 PTMA manual
