Electrolux THERMALINE 900 User manual

Electrolux 900 thermaline h = 800 mm

Gas top on gas oven

The Electrolux 900-Thermaline of cooking equipment is designed very heavy duty requirements of hotels,

institutions, hospitals, central kitchens, in-flight kitchens and cruise ships. The series consist of a wide choice

of modular elements that can be installed as individual, free-standing units or assembled into a complete

cooking suite made virtually seamless by means of cleverly-designed connecting rails.

The models detailed on this sheet combine a gas burner top mounted on a gas oven, with models available for

operation from one side only or from both sides to suit a central cooking island. Installation options are floor

mounted on 100 or 200 mm high feet or a plinth which can be either steel or masonry construction.

581074 with accessories

EASY TO USE

• Five sizes of burners to suit

different cooking requirements

from rapid boiling to a gentle

simmer.

• Manual gas valves with fixed

high and low positions allow a

precise control of the flame

intensity.

• Large sized pan rests (380x380

mm) in enammeled cast iron with

long centre fins to allow the use of

the largest down to smallest pans.

• The level of the pan rests and

the appliance are the same which

means it possible to move pans

from one appliance to another

without lifting.

• Simple, convenient operation

with highly visible control panels

and knobs.

• Electric roasting and baking

oven for two GN2/1 shelves or

containers. Individual thermostatic

control to upper and lower heating

elements.

• Oven temperature up to 350°C.

• Thick steel base plate for the

even temperature distribution and

storage.

• Optional base plate with a fire

clay element provides a very

uniform distribution and long term

storage of the oven heat; it is

beneficial for sensitive patisserie.

• All appliances conform to ruling

European safety and hygiene

standards and are H marked.

• All models are type-approved by

an international standards

authority and are certified.

EASY TO MAINTAIN

• Flat spillage trays in AISI 304

stainless steel with cleaning

openings on front and rear side

with removable pan supports,

burner, rings and flame ignition

parts.

• Body, cupboard and rests are

made of AISI 304 stainless steel.

• No gaps or dirt traps between

adjoining appliances when

connecting rails are fitted.

• All major components may be

easily accessed from the front.

• The appliances are IP X5

certified against water jets.

Electrolux 900 thermaline h = 800 mm

Gas top on gas oven

Internet: http://www.electrolux.com/foodservice

CEAD0102010-05-28Subject to change without notice

SOLID TOP PLATE F.OPEN BURNER-360X360MM 910718 910718 910718 910718

SIMMERING PLATE-430X380 MM 910716 910716 910716 910716

S/S PLINTH 1000X900X100MM - FREESTANDING 911154 911154 911154 911154

S/S PLINTH 1000X900X100MM - AGAINST WALL 911175 911175

ROLLING RACKS COMPL. F.COOKERS,1000-MAR. 910825 910825 910825 910825

PAN REST STAINLESS STEEL-430X380 MM 910729 910729 910729 910729

FOLDING SHELF 400X900 MM 910804 910804 910804 910804

FOLDING SHELF 300X900 MM 910803 910803 910803 910803

FLEXIBLE CONNECTION HOSE 3/4'' 910720 910720 910720 910720

FIRE CLAY PLATE 2/1GN FOR OVENS 910656 910656 910656 910656

C-BOARD WELDED 1000 MM 911743 911743

BOTTOM STEEL PLATE 2/1 F.FIRE CLAY PLATE 910655 910655 910655 910655

BOTTOM PL+4 FEET 100MM-800&900MM-SPECIAL 911927 911927 911927 911927

ACCESSORIES

PAN REST CAST-IRON-430X380 MM 4 4 4 4

GRID, CHROMIUM PLATED, FOR OVENS 2/1 GN 1 1 1 1

BAKING SHEET 2/1GN FOR OVENS 1 1 1 1

INCLUDED ACCESSORIES

Net weight - kg. 160 160 160 170

Front plates power - kW 3.6, 6.5 3.6, 6.5 3.6, 7 3.6, 7

Front plates dimension - mm 420x440,

420x440

420x440,

420x440

420x440,

420x440

420x440,

420x440

Back plates power - kW 6.5, 5 6.5, 5 7, 5 7, 5

Back plate dimensions - mm 420x440,

420x440

420x440,

420x440

420x440,

420x440

420x440,

420x440

temperature min-max - °C 100, 340 100, 340 100, 340 100, 340

heat input - kW 7 7 7 7

Oven

height 270 270 270 270

depth 700 700 700 700

width 550 550 550 550

Oven cavity - mm

height 800 800 800 800

depth 900 900 900 900

width 1000 1000 1000 1000

External dimensions - mm

Both-Sides Operated ● ●

One-Side Operated ● ●

Ecoflam ● ●

Power supply Gas Gas Gas Gas

TECHNICAL DATA

LG259740E

599358

LG259739E

599357

LG259739

581074

LG259740

581075

EASY ON THE ENVIRONMENT

• Models with ECOFLAM pan

detection system assure energy

saving by limiting unecessary heat

radiation in the kitchen.

• 98% recyclable by weight.

• Packing free of toxic substances.

Electrolux 900 thermaline h = 800 mm

Gas top on gas oven

Internet: http://www.electrolux.com/foodservice

CEAD0102010-05-28Subject to change without notice

G - Gas connection 3/4" 3/4"

LEGEND

LG259740E

599358

LG259740

581075

599358, 581075

Electrolux 900 thermaline h = 800 mm

Gas top on gas oven

Internet: http://www.electrolux.com/foodservice

CEAD0102010-05-28Subject to change without notice

G - Gas connection 3/4" 3/4"

LEGEND

LG259739E

599357

LG259739

581074

599357, 581074
