Electrolux EOC65140X User manual

user manual

Built-In Electric Oven

EOC65140

We were thinking of you

when we made this product

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class

product from Electrolux, which hopefully

will provide you with lots of pleasure in

the future. The Electrolux ambition is to

offer a wide variety of quality products

that make your life more comfortable.

You will find some examples on the cov-

er in this manual. Please take a few min-

utes to study this manual so that you

can take advantage of the benefits of

your new machine. We promise that it

will provide a superior User Experience

delivering Ease-of-Mind. Good luck!

4electrolux contents

Contents

Safety instructions 5

Description of the Appliance 6

Before using for the first time 10

Operating the Oven 12

Usage, Tables and Tips 28

Cleaning and care 43

What to do if … 53

Electrical Connection 55

Installation Instructions 56

Disposal 61

Guarantee/Customer Service 62

Service and Spare Parts 65

he following symbols are used in this user manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

3General information and tips

2Environmental information

Safety instructions electrolux 5

Safety instructions

Electrical safety

•This appliance must be connected by a

qualified electrician only.

•In the event of a fault or damage to the

appliance: take the fuses out or switch

off.

•Repairs to the appliance must only be

carried out by qualified service en-

gineers. Considerable danger may re-

sult from improper repairs. If repairs

become necessary, please contact

your local Service Force Centre.

Child Safety

•Never leave children unsupervised

when the appliance is in use.

Safety whilst Using

•People (including children) who, be-

cause of their physical, sensory or men-

tal capabilities or their inexperience or

ignorance are not able to use the device

safely, should not use this device with-

out supervision or instruction by a re-

sponsible person.

•This appliance is intended to be used

for cooking, roasting and baking food in

the home.

•Take care when connecting electric ap-

pliances to sockets nearby. Do not al-

low connecting leads to come into

contact with or to catch beneath the

hot oven door.

•Warning: Risk of burns! The interior

of the oven becomes hot during use.

•Using ingredients containing alcohol in

the oven may create an alcohol-air mix-

ture that is easily ignited. In this case,

open the door carefully. Do not have

embers, sparks or naked flames in the

vicinity when opening the door.

How to avoid damage to the appliance

•Do not line the oven with aluminium foil

and do not place baking trays, pots,

etc. on the oven floor, as the heat that

builds up will damage the oven enamel.

•Fruit juices dripping from the baking tray

will leave stains, which you will not be

able to remove. For very moist cakes,

use a deep tray.

•Do not put any strain on the oven door

when open.

•Never pour water directly into the oven

when it is hot. This could cause dam-

age to the enamel and discolouration.

•Rough handling, especially around the

edges of the front panel, can cause the

glass to break.

•Do not store any flammable materials

inside the oven. These could ignite

when the oven is switched on.

•Do not store any moist foods inside the

oven. This could damage the oven

enamel.

•After switching off the cooling fan, do

not keep uncovered dishes in the oven.

Moisture may condense in the oven in-

terior or on the glass doors and may get

into the units.

Note on enamel coating

Changes in the colour of the oven’s

enamel coating as a result of use do not

affect the appliance’s suitability for nor-

mal and correct use. They therefore do

not constitute a defect in the sense of

the warranty law.

6electrolux description of the appliance

Description of the Appliance

General Overview

Control panel

Door

handle

Light bar

Full glass

door

description of the appliance electrolux 7

Control Panel

Clock function buttons

Oven Functions Temperature / Time Selection

Temperature / Time Display

Oven power indicator Oven power indicator

8electrolux description of the appliance

Oven Features

Inside of door

On the inside of the oven door you will

find the numbers of the different oven

shelves.

You will also find some brief information

about the oven's functions, recom-

mended shelves and temperatures for

cooking the most popular dishes.

Top heat and heating elements

Oven lighting

Fan heating element

Fan

Bottom heat

Shelf positions

Oven shelf runners, removable

description of the appliance electrolux 9

Oven Accessories

Shelf

For dishes, cake tins, items for roasting

and grilling.

Grill set

Grill

Insert for the roasting pan for roasting

and grilling.

Roasting Pan

For baking and roasting or as a pan for

collecting fat.

10 electrolux before using for the first time

Before using for the first time

Setting and changing the cur-

rent time

The oven only operates when the

time has been set.

When the appliance has been connect-

ed to the electrical supply or when there

has been a power cut, the function indi-

cator Time flashes automatically.

1. To change a time that has already

been set, press the Select button

repeatedly until the function indicator

Time flashes.

2. Using the / control knob, set the

current time.

After approx. 5 seconds, the clock

stops flashing and the clock displays the

time of day set.

The appliance is now ready to use.

The time can only be modified, if the

child safety device is deactivated,

neither of the Countdown , Cook

time or End time clock func-

tions and no oven function is set.
