Electrolux EHS 60020 K User manual

user manual

Ceramic glass hob

EHS 60020 K

We were thinking of you

when we made this product

electrolux 3

Welcome to the world of Electrolux

Thank you for choosing a first class

product from Electrolux, which hopefully

will provide you with lots of pleasure in

the future. The Electrolux ambition is to

offer a wide variety of quality products

that make your life more comfortable.

You will find some examples on the cov-

er in this manual. Please take a few min-

utes to study this manual so that you

can take advantage of the benefits of

your new machine. We promise that it

will provide a superior User Experience

delivering Ease-of-Mind. Good luck!

4electrolux contents

Contents

Safety instructions 5

Description of the Appliance 7

Operating the appliance 9

Tips on cooking and frying 12

Cleaning and care 15

What to do if … 17

Disposal 19

Installation Instructions 20

Assembly 22

Guarantee/Customer Service 26

Service and Spare Parts 29

he following symbols are used in this user manual:

Important information concerning your personal safety and information on

how to avoid damaging the appliance.

3General information and tips

2Environmental information

safety instructions electrolux 5

Safety instructions

Please comply with these instruc-

tions. If you do not, any damage re-

sulting is not covered by the

warranty.

This appliance conforms with the

following EU Directives:

–73/23/EEC dated 19.02.1973 Low

Voltage Directive

–89/336/EEC dated 03.05.1989 EMC

Directive inclusive of Amending Di-

rective 92/31/EEC

–93/68/EEC dated 22.07.1993 CE

Marking Directive

Correct use

•This appliance should be used only

for normal domestic cooking and fry-

ing of food.

•The appliance must not be used as a

work surface or as a storage surface.

•Additions or modifications to the ap-

pliance are not permitted.

•Do not place or store flammable liq-

uids, highly inflammable materials or

fusible objects (e.g. plastic film, plas-

tic, aluminium) on or near the appli-

ance.

Child safety

•Small children must be kept away

from the appliance.

•Only let bigger children work on the

appliance under supervision.

General safety

•The appliance may only be installed

and connected by trained, registered

service engineers, or competent per-

sons.

•Built-in appliances may only be used

after they have been built in to suita-

ble built-in units and work surfaces

that meet standards.

•In the event of faults with the appli-

ance or damage to the glass ceramic

(cracks, scratches or splits), the ap-

pliance must be switched off and

disconnected from the electrical

supply to prevent the possibility of an

electric shock.

•Repairs to the appliance must only

be carried out by trained registered

service engineers.

Safety during use

•Remove stickers and film from the

glass ceramic.

•There is the risk of burns from the

appliance if used carelessly.

•Cables from electrical appliances

must not touch the hot surface of the

appliance or hot cookware.

•Overheated fat and oil can ignite

quickly. When cooking with fat or oil

(e.g. frying chips) do not leave the

appliance unattended.

•Switch the cooking zones off after

each use.

6electrolux safety instructions

Safety when cleaning

•For cleaning, the appliance must be

switched off and cooled down.

•For safety reasons, the cleaning of

the appliance with steam jet or high-

pressure cleaning equipment is not

permitted.

How to avoid damage to the appli-

ance

•The ceramic glass can be damaged

by objects falling onto it.

•The edge of the ceramic glass can

be damaged by being knocked by

the cookware.

•Cookware made of cast iron, cast

aluminium or with damaged bottoms

can scratch the ceramic glass if

pushed across the surface.

•Objects that melt and things that boil

over can burn onto the ceramic glass

and should be removed straighta-

way.

•To avoid damaging cookware and

glass ceramics, do not allow sauce-

pans or frying pans to boil dry.

•Do not use the cooking zones with

empty cookware or without cook-

ware.

description of the appliance electrolux 7

Description of the Appliance

Cooking surface layout

Control panel layout

Single cooking zone

2300W

Single cooking zone

1800W

Single cooking zone

1200W

Control panel Single cooking zone

1200W

Display

Cooking zones and heat setting selection

On/Off

8electrolux description of the appliance

Touch Control sensor fields

The appliance is operated using the

Touch Control sensor fields. Functions

are controlled by touching sensor fields

and confirmed by displays.

Touch the sensor fields from above,

without covering other sensor fields.

Displays

Residual heat indicator

Warning! Risk of burns from residu-

al heat. After being switched off, the

cooking zones need some time to

cool down. Look at the residual heat

indicator .

Residual heat can be used for melt-

ing and keeping food warm.

Sensor field Function

On / Off Switches appliance on and off

Increase settings Select cooking zone

Increases heat setting

Reduce settings Reduces heat setting

Display Description

Cooking zone is switched off

- Heat settings Heat setting is set

ER Fault Malfunction has occurred

Residual heat Cooking zone is still hot

Child safety device Lock/child safety device is set.

operating the appliance electrolux 9

Operating the appliance

Switching the appliance on and off

Selecting the cooking zone

The decimal point is displayed by

the selected cooking zone. Then a

heat setting must be set for this

cooking zone within 6 seconds, oth-

erwise it must be re-selected.

Selecting the heat setting

After selecting the cooking zone,

briefly release the sensor field .

After 6 seconds with no input the

selection is cancelled and the deci-

mal point goes out. To set the re-

quired cooking zone again, make

another selection.

Control panel Display

Switch on Touch for 2 seconds. / Decimal point flashes

Switch off Touch for 1 second / none

Control panel Display

Select Touch Decimal point illuminates

Control panel Display

Increase Touch to

Decrease Touch to

Switch off Touch and at the same time

10 electrolux operating the appliance

Using the child safety device

The child safety device prevents unin-

tentional use of the appliance.

The child safety device can only be

activated immediately after the ap-

pliance has been switched on.

Switching on the child safety device

To override or switch the child safe-

ty device off sucessfully, the steps

must be performed immediately one

after the other. No other sensor

fields must be touched between the

steps described.

Overriding the child safety device

The child safety device can be switched

off in this way for a single cooking ses-

sion; it remains activated afterwards.

Switching off the child safety device

Step Control panel Display

Switch on appliance.

(Do not set a heat setting.)

/ (if hot)

Touc h for 5 seconds is displayed.

Appliance switches off.

Step Control panel Display

Switch appliance on / (if hot)

Touch the two of the front cook-

ing zones at the same time

Decimal points flash

Until the appliance is next switched off, it can used as normal.

Step Control panel Display

Switch appliance on / (if hot)

Touc h for 5 seconds or

Decimal points flash

Appliance switches off.
