Electrolux FN31LP/NG User manual

Grill Assembly

Built-In Instructions 5-12

13-15

21-22

16-19

NECO MODEL

FN31LP/NG

Amendment Pages

(Use these pages in place of

standard manual)

NECOMODEL AMENDMENT SHEETS

Welcome & Congratulations

Please record Grill information for future reference and service work:

Model #:

Serial #:

Date of Purchase:

Gas Type:

Please retain this manual for future reference

Congratulations on your purchase of a new gas grill! At Electrolux Home Products, we

are very proud of our product and are completely committed to providing you with the

best service possible. Your satisfaction is our number one priority.

We know you’ll enjoy your new gas grill and Thank You for choosing our product. We

hope you consider us for future purchases.

PLEASE CAREFULLY READ AND SAVE THESE INSTRUCTIONS

This Use & Care Manual provides specific operating instruction for your model. Use your

gas grill only as instructed in this manual. These instructions are not meant to cover every

possible condition and situation that may occur. Common sense and caution must be

practiced when installing, operating and maintaining any appliance.

Questions? 1-800-320-0859

TESTED IN ACCORDANCE WITH ANSI

Z21.58b-2002/CGA 1.6b-M02 STANDARD FOR

OUTDOOR COOKING GAS APPLIANCES.

THIS GRILL IS FOR OUTDOOR USE ONLY.

Check your local building codes for the proper

method of installation. In the absence of local

codes, this unit should be installed in accordance

with the National Fuel Gas Code No. Z223.1-2002

and the National Electrical Code ANSI/NFPA No.

70-1990

WARNING

DO NOT try lighting this appliance without reading

the “LIGHTING INSTRUCTIONS” section of this

manual.

FOR YOUR SAFETY

DO NOT store or use gasoline or other flammable vapors and

liquids in the vicinity of this or any other appliance.

An LP cylinder not connected for use shall not be stored in

the vicinity of this or any other appliance.

General Safety Instructions

IMPORTANT SAFETY INFORMATION

-Read this manual carefully before using your grill to reduce the risk of fire, burn hazard or

other injury.

- Extreme care should be used because of the high temperatures produced by this appliance. CHILDREN SHOULD NOT BE LEFT

UNATTENDED IN AN AREA WHERE THE GRILL IS BEING OPERATED.

- This appliance must be kept clear from combustible materials, gasoline or other flammable vapors and liquids. Do not allow

flammable materials to come in contact with grate, burner or hot surfaces.

- Do not repair or replace any part of this appliance unless it is specifically recommended in this manual. A qualified service techni-

cian should conduct all other service.

- Follow the installation and servicing instructions provided with this product. Have your grill installed by a qualified service techni-

cian. Locate the main gas supply valve so that you know how to shut the gas off to your grill. If you smell gas, make sure all gas

connections are tight before operation. If you continue to smell gas call a qualified technician.

- When lighting a burner, always pay close attention to what you are doing. Be certain you are pushing the ignitor that lights the

burner you intend on using.

FOR YOUR SAFETY

If you smell gas:

1. Shut off gas to the appliance.

2. Extinguish any open flames.

3. Open lid.

4. If odor continues, immediately

call your gas supplier.

FOR OUTDOOR USE ONLY

This appliance is not intended to be

installed in or on recreational vehicles or boats.

CALIFORNIA PROPOSITION 65 - WARN-

ING: The Burning of gas cooking fuels generates

some by products which are on the list of substances

which are known by the State of California to cause

cancer or reproductive harm. California law requires

businesses to warn customers of potential exposure to

such substances. To minimize exposure to these sub-

stances, always operate this unit according to the use

and care manual, ensuring you provide good ventila-

tion when cooking with gas.

Grill Features: FN31

1. Roll top grill hood 8. Warming shelf

2. Grilling/Cooking surface 9. Infrared back burner

3. Side Shelf 10. Electronic ignitor: main, rear infrared

& side burner

4. Control knob: back infrared burner 11. Cart w/door

5. Control knobs: main burners 12. Ignitor access opening

6. Convection vents 13. Side Burner

7. Handle 14. Control knob: Side Burner

Cart Assembly, Door Stops & Door Pivot Bolts

1. Attach the two L-shaped sides to the back portion

of the cart, making sure the two holes face up &

the key holes are on the top, using the (4) self

tapping hex head screws. (See Fig. 1)

Note: A power screwdriver is required to install the

screws-be cautious not to over-tighten and strip

the screws.

2. Set the base on the top of the cart assembly, with

large opening closer to back portion of cart, and

align the eight mounting holes. Then set the 2

wheel channels on the base and attach them using

the (8) bolts provided, from inside the cart

upwards through wheel channels. (See Fig. 2)

Note: Tighten the bolts securely

3. Door Stop: Insert Door Stop Bolt downward

from bottom side of Cart Base through the hole

found in the right/front of the base. (See Fig 3)

4. Screw Rubber Cap onto Bolt from the topside of

Cart Base and tighten securely. (See Fig 4)

4. Door Pivot Bolt: Insert Bolt downward from

bottom side of Cart Base through the hole found

in the left/front of the base and secure with

bolt. (See Fig. 2)

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Note: Prior to assembly remove protective film from stainless steel parts

Screws

Assembly requires: 4 tools and a Friend

Tools required:

Power screwdriver

Screwdriver extension

1/4” socket wrench

1/2” socket wrench

adjustable wrench

scissors

Caution: Gas regulator is not flush with

bottom. DO NOT let the Grill head sit flat

without placing support around regulator

to prevent damage to the regulator prior

to installing on cart.

Bolt up through

bottom of cart base

LP Tank

cutout

Door Pivot

Bolt Hole

Door Stop

Hole

Wheel Channel

Grill Assembly

Attaching Grill Head to Cart

1. While keeping the Grill on the foam base

lean it onto its back. (be sure to hold the

hood shut when doing this.) With the Grill

on its back, loosen all 4 bolts on the

bottom side of the Grill, but do not

remove.(See Fig. 5)

2. Using 2 self tapping hex head screws,

attach the magnetic door catch in the 2 holes

in the bottom of the grill. (See Fig. 6)

3. Have someone help you pick up the grill

and set it on the top of the cart, with the front

of the grill above the door opening. Make

sure the 4 bolt heads fall through the large

opening of the key hole slots in the top of the

cart. Slide the grill head backward, so the

bolts are resting in the small opening of the

key hole slots. Tighten the bolts securely.

Be sure not to over tighten and strip the

bolts. Next insert 4 hex head screws into grill

bottom through cart. (See Fig. 7)

Note: This is a very heavy step that requires

two individuals to complete.

Installing the Cart Door

1. While holding the door line up the bottom

hole on the door with the bolt sticking up

through base of cart. Next place a nylon

bushing onto the top pin, then depress the pin

and insert into the hole in the bottom of the

grill. (See Fig. 8)

Fig. 7

Fig. 8

Nylon Bushing

Door Pivot Bolt

Fig. 6

Screws

Catches face

towards front

of grill

Screw holes

Bolts

Fig. 5

Screw hole for

magnetic catch

Grill Assembly

Installing the Cart Door Handles

1. Using a 5/32” allen wrench insert 1 screw

through the inside of the door front into

a bar handle end and tighten securely.

(See Fig. 9)

2. Insert Bar Handle into the End Cap

attached to the door and then into the

other End Cap and tighten End Cap with

allen wrench and screw. (See Fig. 10)

3. Complete Door. (See. Fig. 11)

Installing the Drip Tray

1. The drip pan is installed inside of the cart

under the grill head.

2. Slide the drip pan onto the two ledges located

on the bottom of the grill, by inserting it from

the front of the cart. (See Fig. 12)

Screw Holes

End Cap

Backside of door:

2 screw locations

Fig. 9

Fig. 10

Fig. 11

Fig. 12

Bar Handle

Grill Assembly

Front of

Grill

Slide onto rails

under grill

Side Shelf /Rotis Bracket Attachment

1. Attach the shelf and Rotisserie Bracket to the

left side of grill by lining up the 7 bolt holes

on the side shelf bracket & rotis bracket to the

side of the grill. (See Fig. 13)

2. Insert the (7) bolts through the rotis bracket

and side shelf bracket into the grill. Be sure

the rotis bracket faces forward (See Fig. 14)

Interior parts installation

1. Check to make sure the bottom Flavor

Grids are correctly installed in the cutouts and

around the ignitors, as they may have shifted

during shipment. (See Fig. 15)

2. Insert the second row of Flavor Grids into

cutouts with triangle ridges facing up.

(See Fig. 16)

3. Install cooking grates on the ledges provided

on the grill to create your cooking surface.

(placing the one with a thumb hole in the

middle) (See. Fig. 17)

4. Place warming shelf on support brackets by

setting it flat across brackets allowing the two

holes to line up with the stops on each

bracket. (See Fig. 18)

Fig. 13

Fig. 14

Fig. 15

Fig. 17

Fig. 18

Fig. 16

Bottom Flavor Grids

in between burners

Grill Assembly

Bolt Holes

Rotis Bracket

1. Attach the Side Burner to the grill by

inserting the shelf hooks into the slots on the

side of the grill and pushing down on the shelf

assembly until level with the grill

(See Fig. 19)

2. Lock the Side Burner in place by re-inserting

(2) hex head screws in the front & rear edge

of side burner. (See Fig. 20)

Note: A power screwdriver extension is needed to

insert screw.

3. Attach the Flex Line coming from the side of

the grill to the fitting on the bottom of the

Side Burner. (See Fig. 21)

4. Attach the ignitor wire coming out from the

side of the grill to the side burner ignitor

point. (See Fig. 22)

Fig. 19

Fig. 20

Fig. 21

Fig. 22

Side Burner Assembly

SCREW HOLE

Attach to fitting

Ignitor

wire

hookup

SIDE BURNER PARTS ASSEMBLY

1. Install burner into side burner tray lining up

the three cutouts on the underside of the

burner. (See Fig. 22a)

2. Install burner cap onto burner (See Fig. 22b)

3. Install grate over burner (See Fig. 23)

LEAK TESTING

Make sure all burners are turned to “OFF”.

Turn on the gas at the cylinder (LP models) or main

valve (Natural models). DO NOT turn on the side

burner. Perform a leak test at all connections and

fittings by spraying a 50/50 solution of water and

soap. If any bubbles appear, correct the leak before

attempting to light the grill or side burner.

IGNITOR ASSEMBLY

1. The Battery, Spring and Ignitor cap must be

installed before using.

2. Install the battery, positive side first.

3. Slide spring assembly over battery.

4. Screw ignitor cap onto ignitor.

Fig. 23

Fig. 22a

Fig. 22b

Side Burner Assembly

This manual suits for next models

Table of contents

Other Electrolux Grill manuals

Electrolux

Electrolux Beef Eater 1600 Series User manual

Electrolux

Electrolux EGL4401X User manual

Electrolux

Electrolux SPEEDELIGHT User manual

Electrolux

Electrolux Zanussi Professional NGG400 User manual

Electrolux

Electrolux EQBL100AS Manual

Electrolux

Electrolux FM 4500 FR-A User manual

Electrolux

Electrolux 603542 User manual

Electrolux

Electrolux EQBL100AS User manual

Electrolux

Electrolux 584089 User manual

Electrolux

Electrolux TY58TSCN User manual

Electrolux

Electrolux thermaline S90 User manual

Electrolux

Electrolux en:tice EQBM60AS User manual

Electrolux

Electrolux U24292 5330R User manual

Electrolux

Electrolux E51LK60ESS User manual

Electrolux

Electrolux E44LK60ESS User manual

Electrolux

Electrolux E44LB60ESS User manual

Electrolux

Electrolux 775302 User manual

Electrolux

Electrolux EQT4520BOZ User manual

Electrolux

Electrolux 51" Stainless Steel Gas Grill User manual

Electrolux

Electrolux EQT6540BOG User manual

Electrolux

Electrolux E57NB60ESS User manual

Electrolux

Electrolux E51LB60ESS User manual

Electrolux

Electrolux TM 63600 User manual

Electrolux

Electrolux 602104 User manual

Popular Grill manuals by other brands

Orbegozo

Orbegozo GR 2300 instruction manual

bora

bora PT11 Operating and installation instructions

Klarstein

Klarstein 10031664 manual

Garland

Garland MWE3W Installation and operation manual

Char-Broil

Char-Broil 463722714 Product guide

Nexgrill

Nexgrill 720-0830HK Operating instruction

Kenmore

Kenmore 415.16123800 Use and care guide

Camp Chef

Camp Chef PG24CLAU Warning & instruction booklet

Tucker Barbecues

Tucker Barbecues GTR Series Assembly, installation and operating instructions

Monogram

Monogram ZGG540NCP1SS owner's manual

Equipex

Equipex Sodir Savoy Operation manual

Gaggenau

Gaggenau VR 414 610 use and care manual

Miele

Miele KM 408-1 operating instructions

George Foreman

George Foreman GGR50B owner's manual

AOG

AOG T series quick start guide

Gorenje

Gorenje TG2000CB Instruction manua

Weber

Weber Genesis Silver-B Permamount NG 051701 owner's guide

Glen

Glen SA 3037 user guide
