Electrolux ETG729GKT User manual

Please read the instruction manual carefully before using and keep it for future reference and

maintenance. This manual contains important message, includes safe operation and special

notes, structure diagram, main technical data, installation instruction, operation steps and

adjustment ways, clean and maintenance, and trouble shooting.

Thanks for choosing and using Electrolux home appliances.

Electrolux Group of Sweden is one of the world largest home appliances companies, with more than

65 million Electrolux products being used by millions of households worldwide each year, it is also

the world largest manufacturer of kitchen electrical appliances. The group has sold more than 56 million

kitchen products, which is equivalent to the combined height of 5 Mount Everest, besides that, more than

2/3 of the world star hotel use Electrolux professional kitchen equipment.

Clearly, the excellent achievement of Electrolux over the last 80 years has been recognized by 450 million

families all over the world. Now we are please to make some of the best products from this renowned brand

available to consumer in Southeast Asia. To us not only is Electrolux one of the most reliable brands in

dealing with home appliances, it is also brand that promises to bring innovative lifestyles to all families

through its cutting edge technologies and excellent designs. For not only to add & tough of elegance to

your kitchen,but Electrolux products also makes cooking easier, more enjoyable and something to share with.

Enjoy happy cooking now with Electrolux kitchen appliances.

Once again, we would like to extend our heartiest thanks to you for your trust in choosing Electrolux products.

Before installing or using this appliance, please read this instruction book carefully and pay particular

attention to the warning in the following page.

Should you have further enquires regarding this appliance, kindly contact our Customer Care for advise.

Please keep this instruction book for future reference and pass it on to any future owner of this appliance

Safe Operation and Special Notes Page 2

Installation Instruction Page 2,3, 4

Main Technical Data Page 5

Operation Steps and Adjustment Page 5,6

Clean and Maintenance Page 7

Trouble Shooting Page 8

Structure Diagram Page 9, 10, 11

Customer Care Center Page 12

CONTENT

Do not use gas other than that which is specified on the

label attached.

do not place anything, e.g. flame tamer, asbestos mat,

between appliance and pan support as serious damage

to the appliance may result. (Fig 1)

Do not remove the pan support and enclose the burner

with a wok stand not supplied by Electrolux as this will

concentrate the flame and deflect the heat onto the top

plate. (Fig 2)

Do not use large pots or heavy weights which can bend

the pan support or deflect the flame onto the top

plate. (Fig 3)

Locate pan centrally over burner so that it is stable and

does not overheat the appliance. (Fig 4)

Use only wok support supplied or recommended by the

manufacturer of the appliance ( Fig 5)

The unit to be used for cooking only, do not

dry towels, clothes, etc., over it, if this is done, there is

danger for fire if a gas leak is found, close stop cock,

open up all windows and call your dealer, do refrain from

turning an electric switch on or off, lighting a match

smoking or using a lighter.

Use the appliance in a well ventilated room.

Do not use vinyl gas hose. It is liable to be softened

by heat, use only a rubber hose.

Be sure to turn off the ignition knob and regulator of

the cylinder after use.

Avoid touching the burner, pan stand etc., immediately

after use. Otherwise you will get hurt.

Ensure that the rubber hose does not touch any part of

the unit or lies underneath it.

Connect the rubber hose to the gas inlet and fasten it

with a hose clamp.

The pan stand leg nearest to the flame will have

discolorations after use. Such phenomenon is normal.

SAFE INSTRUCTIONS

In the event of burner flame

being accidently extinguished,

turn off the burner control knob

and do not attempt to re ignite

the burner for at least 1 minutes.

For burner fitted with a flame

supervision device, if after 15

seconds of ignition operation the

burner has not lit, stop operating

the device and open the

compartment door and wait at least

1minute before attempting a further

ignition of the burner.

If nozzle holes are blocked,

use a thin wire or pin to pierce and

clean the nozzle holes.

WARNING:

1. Open the box, take out the polyfoam, and put it on the even ground, remove and abandon

the poly bag.

2. Take out the gas stove, and put it upside down on the polyfoam, take out the legs,

knob sets and burner caps bag, release the trivets by unfasten the ties.

3. Install four legs on the four square yard by nuts as followings show

INSTALLATION IN STRUCTION

BE CAREFUL WHEN YOU ABANDON THE POLY BAG IF IT IS ACCESSIBLE FOR CHILDREN.

IT IS NOT A TOY FOR CHILDREN

WARNING :

ETG729GKT ETG728GK ETG726GK/ETG726XS

MAKE SURE THE SUPPLIED GAS AND PRESSURE IS THE SAME AS LABEL

MARKED, DIFFERENT GAS TYPE AND PRESSURE WILL CAUSE SERIOUS

RESULT OF BODY INJURY AND FORTUNE DAMAGE, EVEN DEATH.

WARNING:

LEAKAGE MUST BE CHECKED AT THE FIRST USE, NEVER USE

THE STOVE WITHOUT LEAKAGE CHECK

WARNING:

10. It is recommended to install range hood above the stove, and the distance between

top of the stove to bottom of the range hood is about 700mm

9. The distance between the stove and cylinder

should be around 1m, the proper length of the inlet gas

hose is 1m-2m. One side of the hose connect the

cylinder, the other side connect the gas inlet. The hose

cannot contact any other parts of stove and thrill through

the bottom of the stove, cannot bend it forcedly.

The length of gas pipe

cannot exceed 2m

MAIN TECHNICAL DATA

Power off

Max flame

Min flame

Product dimension

L(mm) D(mm) H(mm)

710 410 170

710 410 148

705 405 170

705 405 148

4.3 4.3

3.4 4.3

3.0 3.0

1. Make sure all knobs are on the “off” position, then open the main gas valve

2. Press the knob down by 3mm as the follow drawing shows, then turn it counter-clockwise

until you hear ignition click, ignite the burner, then release the knob. ( it may fail to ignite

at the first time because of there is air in the hose, you have to repeat this procedure)

6. Model ETG729GTK with flame failure safety device (FFD), and the gas

supply will be cut off automatically when the flameout occurred accidently.

7. The stove has two type of trivet that be designed to heat convex bottom utensils (wok)

and pans (cookers), proper diameter of convex bottom utensil is 32cm, proper

diameter of pan is between 26-30cm. The weight of food should less then 10kg.

The trivet designed for convex

bottom utensils (wok), the fingers

are slant

The trivet designed for pan,

the fingers are even

Detatch the stainless steel or teflon panel as following indication, and assemble

it back after clean.

Note: Deformation of the panel shall be happened after several disassemble and

assemble for several times.

TROUBLE SHOOTING

Jet blocked Dredge the jet

Air humidity and smoke is too big

Yellow flame

Backfire

Abnormal flame

Flame short

Check whether there is gas in the cylinder and the

valve has been opened or damaged

Check whether there is gas in the cylinder and the

valve has been opened or damaged

Adjusting damper or waiting till humidity in

the air gets less

Pause and use again after cooling

STRUCTURE DIAGRAM
